Toshiba BMS-IFBN1280U-E User manual

Central Control Device
Model name:
BMS-IFBN1280U-E
BMS-IFBN1280U-TR
Installation Manual
BN interface
For commercial use
Multilingual installation manual, license agreement and license information
https://www.toshiba-carrier.co.jp/global/manual/bms-ifbn1280u.htm
[ългарски] Изтегляне на Ръководство за монтаж, Лицензионно споразумение и
Лицензна информация / [Česky] Stažení Montážní příručky, Licenční smlouvy a
Licenčních informací / [Dansk] Download installationsvejledning, licensaftale og
licensinformation / [Deutsch] Installationshandbuch, Lizenzvereinbarung und
Lizenzinformation herunterladen / [Ελληνικά] Λήψη εγγράφων «Εγχειρίδιο
εγκατάστασης», «Άδεια χρήσης» και «Πληροφορίες για την άδεια» / [English]
Installation Manual, License Agreement and License Information Download / [Español]
Descarga del Manual de instalación, del Contrato de licencia y de la Información de
licencia / [Eesti] Paigaldusjuhendi, litsentsi kokkuleppe ja litsentsiteabe allalaadimine /
[Suomi] Asennusohjeiden, lisenssisopimuksen ja lisenssitietojen lataaminen /
[Français] Téléchargement du manuel d'installation, du contrat de licence et des
informations sur la licence / [Hrvatski] Preuzimanje Priručnika za instalaciju, Ugovora o
licenci i Informacija o licenci / [Magyar] Telepítési kézikönyv, Licencszerződés és
Licencinformáció letöltése / [Italiano] Download del Manuale di installazione, del
Contratto di licenza e delle Informazioni sulla licenza / [Latviešu] Uzstādīšanas
rokasgrāmatas, licences līguma un licences informācijas lejupielāde / [Norsk]
Nedlasting av installasjonsveiledning, lisensavtale og lisensinformasjon / [Nederlands]
Installatiehandleiding, Licentieovereenkomst en Licentie-informatie downloaden /
[Polski] Pobieranie Instrukcji instalacyjnej, Umowy licencyjnej i Informacji o licencji /
[Português] Download do Manual de instalação, Contrato de Licença e das
Informações sobre a licença / [Română] Descărcarea Manual de instalare, Contract de
licență și Informații de licență / [Русский] Скачать Руководство по установке,
Лицензионное соглашение и Информацию о лицензии / [Slovensky] Stiahnutie
Montážnej príručky, Licenčnej zmluvy a Informácií o licencii / [Slovenščina] Prenos
navodil za montažo, licenčne pogodbe in licenčnih informacij / [Svenska] Nedladdning
av Installationshandbok, Licensavtal och Licensinformation / [Türkçe] Kurulum
kılavuzu, Lisans Sözleşmesi ve Lisans Bilgileri İndirme / [中文] 安装手册，许可证协议和
许可证信息下载

1-EN
BN interface Installation Manual
Contents
Precautions for safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2 Power and signal line connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
3 Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
3-1. Switch setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
3-2. LED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
4 Factory default settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
5 Test run. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
5-1. BACnet communication settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
5-2. Setting up equipment data in the indoor unit . . . . . . . . . . . . . . . . . . . . . . . . 17
5-3. Cause of problem occurring during setup . . . . . . . . . . . . . . . . . . . . . . . . . . 17
6 Turning off the BN interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
“AEEE Yönetmeligine Uygundur.”

BN interface Installation Manual
2-EN
Precautions for safety
• Carefully read these "Precautions for Safety" before installation, and perform installation work safely.
• These precautions contain important information regarding safety.
• After installation work, carry out an operation trial to confirm that there are no problems, and explain to the customer how to
operate and maintain the system. Ask the customer to keep this Installation Manual.
Expressions
Graphic symbols
Warning
Text set off in this manner indicates that failure to adhere to the directions in the warning could result
in serious bodily harm (*1) or loss of life if the product is handled improperly.
Caution Text set off in this manner indicates that failure to adhere to the directions in the caution could result
in serious bodily injury (*2) or damage (*3) to property if the product is handled improperly.
*1: Serious bodily harm indicates loss of eyesight, injury, burns, electric shock, bone fracture, poisoning, and other injuries which
leave aftereffect and require hospitalization or long-term treatment as an outpatient.
*2: Bodily injury indicates injury, burns, electric shock, and other injuries which do not require hospitalization or long-term treatment
as an outpatient.
*3: Damage to property indicates damage extending to buildings, household effects, domestic livestock, and pets.
" " indicates prohibited items.
The actual contents of the prohibition are indicated by a picture or text placed inside or next to the
graphic symbol.
" " indicates compulsory (mandatory) items.
The actual contents of the obligation are indicated by a picture or text placed inside or next to the
graphic symbol.
Warning
• Installation and reinstallation should be performed by your dealer or a qualified
electrician
Attempting to carry out installation work on your own, and doing so incorrectly, may result in
electric shock or fire.
• Electrical work must be performed by a qualified electrician in accordance with
this Installation Manual. The work must satisfy all local, national and international
regulations
Inappropriate work may result in electric shock or fire.
• Be sure to turn off the power before starting work
Failure to do so may result in electric shock.
• Use only the power adapter supplied with this unit
A power adapter other than that supplied with this unit may provide a different voltage and have
different polarity (+) (−), which could lead to fire, explosion or generation of heat.
• Do not modify the unit
Doing so may result in excessive heat or fire.
The following instructions
must be observed.
Prohibited
Compulsory
Warning
This is a class A product. In a domestic environment this product may cause radio interference in which case the user may
be required to take adequate measures.

BN interface Installation Manual
3-EN
Introduction
Overview
The BN interface refers to equipment used for controlling Building Management Systems (Procured locally) and air conditioners
“TU2C-LINK Uh Line (hereinafter, referred to as Uh Line) compatible models” through communications via a network to enable
central control.
Included Items
Specifications
External View (BN interface equipment)
Component Q'ty Remarks
BN interface equipment 1
Power adapter 1BN interface power supply (model name: UI318-0526) (not include Power Cable)
Pin terminal 2Uh Line caulked connectors
Mounting bracket (DIN rail) 1Use screws to secure the unit in locations without DIN rails (walls, etc.)
Screws (M4 x 12) 2For securing the DIN rails
Rubber feet 4For levelling the unit
Screws (M3 x 8) 4For securing the rubber feet to the unit
Installation Manual 1This manual
License Agreement 1
License Information 1
Tie-wrap 1
Power supply Rated voltage 220-240 VAC 50/60 Hz
Power consumption 3 W
Operating temperature range 0°C to 40°C, 10% to 80% RH (no condensation)
Storage temperature range −10°C to +60°C, 10% to 90% RH (no condensation)
Dimensions Width 140 mm x Height 90 mm x Depth 45 mm
Mass BN interface 260 g
Power adapter 140 g



䣒䣑䣙䣇䣔 䣎䣋䣐䣍䢪䣗䣪䢫 䣅䣒䣗
(5525
About 12~13

BN interface Installation Manual
4-EN
(Power adapter)
REQUIREMENT
Power cable is not supplied for the BN Interface. Insert a two core power cord applicable to the standard of the country you use.
Component Names
Name Function
5V DCIN Connect the power adapter
USB (For service)
Ethernet (LAN) Connect to the Building Management System
Shutdown button Shutdown or switch to air-conditioning search mode
L1 BACnet communication status indicator
L2 BACnet communication status indicator, setting error indicator
722/,1*1268%
s
s
s
s





䣒䣑䣙䣇䣔 䣎䣋䣐䣍䢪䣗䣪䢫 䣅䣒䣗
(5525
86%
/
/
9'&,1
(WKHUQHW/$1
6KXWGRZQEXWWRQ

BN interface Installation Manual
5-EN
1Installation
REQUIREMENT
Do not install the unit in any of the following places.
• Humid or wet place
• Dusty place
• Place exposed to direct sunlight
• Place where there is a TV set or radio within one meter
• Place exposed to rain (outdoors, under eaves, etc.)
BN Interface Installation and Orientation
Install and orient the interface using the DIN rail to mount the unit or wall mount or surface mount it as shown below.
Use the supplied mounting bracket to wall mount or surface mount the interface.
(3) Surface mount
Use screws to secure the supplied rubber legs to the interface before surface mounting it.
(1) DIN rail mount
Install the interface on DIN rails mounted on a switchboard or elsewhere.
Front view Back view
(2) Wall mount
Use screws to attach the supplied
DIN rails to a wall and install the
interface on the DIN rail.
Supplied DIN rail
Wall mount A Wall mount B Wall mount C
Supplied rubber leg
Supplied rubber leg
mounting screw

BN interface Installation Manual
6-EN
Installation Space and Maintenance Space
A side space for connecting through cable inlets and an upper space for maintenance must be reserved before installation.
The other sides can be adjacent to surrounding objects.
PP
PP

BN interface Installation Manual
7-EN
2Power and signal line connections
Cables
Use the following cable for signal line connections. (Procured locally)
Ethernet®is a registered trademark of Xerox Co., Ltd.
Cable Connections
Connect the cables to the specified connectors.
Length of stripped Uh Line communication cable
CAUTION
The Uh Line communication cable have no polarity.
* Secure the Uh Line communication cable and power cable to the switchboard etc. using the supplied cable tie to ensure
that no excess load is placed on the power cable connection and Uh Line communication cable connection.
No. Line Description
1For Uh Line
Type 2-core shielded wires
Wire size Refer to "Design of Control Wiring" (P.10 to P.13)
Length
2For Ethernet®Type
LAN cable (higher than Category 5, UTP)
The appropriate use of straight cable/cross cable should be done depending on your
system used
Length 100 m max.
50 10
Connect the supplied pin terminal to the Uh Line
communication cable as necessary.
8K/LQH 9'&,1 (WKHUQHW/$1
Connection of Uh Line
communication
cables
Connect the
supplied power
adapter
Connect the LAN
cable
The Uh Line communication cable must be
earthed on the air conditioner.
Do not connect the shield wire to the
connector. It should be open and
insulated.
Air conditioner

BN interface Installation Manual
8-EN
Example of System Wiring Connections
8K/LQH 9'&,1 (WKHUQHW/$1
䣒䣑䣙䣇䣔 䣎䣋䣐䣍䢪䣗䣪䢫 䣅 䣒䣗
(5525
+8%
8 8
8
8
8 8
8 8
88
8 8
BN interface
Building Management System
Power adapter Power Supply
Uh Line main bus
Outdoor unit
Outdoor unit
Indoor unit Indoor unitRemote
controller
Remote
controller

BN interface Installation Manual
9-EN
Termination resistance setting
• TU2C-LINK / TCC-LINK termination resistance setting ............<For TCC-LINK>
Leave just 1 line of the termination resistance in the
interface board of the outdoor unit (centre unit) ON, and
turn all the others OFF. (Refer to the wiring diagram
attached to the outdoor unit for the position of SW.)
<For TU2C-LINK>
For the central control wiring (Uh line), set the termination
resistance that is farthest away on the wiring between this
central controller and the other unit (VRF, light
commercial, air to air heat exchanger, general purpose
control interface, air to water heat pump) to ON.
Refer to the manual of each model for the termination resistance setting method.
Shield grounding process
• Central control wiring shielded wire ...........................................When using the central remote controller with one unit,
open the shielded wire of the central control wiring and
perform insulation processing.
When using the central remote controller with multiple
units, connect the shield of the central control wiring to the
closed end and open the shield at the final end of the
central remote controller to perform insulation processing.
Perform the central control wiring shield grounding on the
air conditioner side.
REQUIREMENT
• Be sure to install a circuit breaker or all-pole isolating switch (with a contact breaking distance of at least 3 mm) on the
primary side of the power supply.
• Fasten the screws to the terminal block with torque of 0.5 N•m.
U3 U4
LINK (Uh)
U3 U4
LINK (Uh)
U3 U4
LINK (Uh)
U3 U4
LINK (Uh)
Termination resistance
ON
Termination resistance
OFF
Termination resistance
ON

BN interface Installation Manual
10-EN
Design of Control Wiring
Communication method and model name
The TU2C-LINK model (U series) can be used together with previous models (other than U series).
For details of the model and communication method, see the following table.
Communication method TU2C-LINK (U series) TCC-LINK (other than U series)
Outdoor unit Other than on the left
(MMY-MAP***, MCY-MAP***, etc.)
Indoor unit Other than on the left
(MM*-AP***, etc.)
Wired remote controller Other than on the left
Wireless remote controller
receiver Other than on the left
Central control device Other than on the left
MMY-M P***
U series model
MM*- P***
U series model
RBC-AMS **
U series model
RBC-AXR **
U series model
TCB-AXR **
U series model
***-*** **
U series model

BN interface Installation Manual
11-EN
When the connected outdoor unit is Super Multi u series (U series)
Follow the wiring specifications in the table below even when there is a mix of U series and non-U series in the connected indoor
units or remote controllers.
Wiring specifications
REQUIREMENT
When wiring the control wiring between indoor and outdoor units (Uv line)/control wiring between outdoor units (Uc line) and
the central control wiring (Uh line), use the same wire type and diameter for each line.
Using a mixture of different wire types and diameters may cause a communication error.
System diagram
* The wiring specifications in the system diagram above are the same even when the indoor unit or remote controller are other
than the U series.
Item Communication line
Central control wiring (Uh line)
Wire diameter 1.0 to 1.5 mm2(up to 1000 m)
2.0 mm2(up to 2000 m)
Wire type 2-core, non-polar
Wire types that can be used Shielded wire
U3 U4
LINK (Uh)
U6
U4
U1 U2
Uv
AB
U6
U4
U1 U2
Uv
AB
U6
U4
U1 U2
Uv
AB
U6
U4
U1 U2
Uv
AB
U2
Uv
U5 U6
Uc
U3 U4
Uh
U1 U2
Uv
U5 U6
Uc
U3 U4
Uh
U1 U2
Uv
U5 U6
Uc
U3 U4
Uh
U1
Central control
device
<U series>
Outdoor unit
(Super Multi
u series)
<U series>
Indoor unit *
<U series>
Remote
controller *
[Central control wiring (Uh line)]
L1 = Up to 2000 m
[Control wiring between indoor and outdoor units (Uv
line)/Control wiring between outdoor units (Uc line)]
L2 = Up to 1000 m
(L3+L4) = Up to 1000 m

BN interface Installation Manual
12-EN
When the connected outdoor units are other than Super Multi u series (U series)
Wiring specifications
REQUIREMENT
When wiring the control wiring between indoor and outdoor units/central control wiring and the control wiring between outdoor
units, use the same wire type and diameter for each line.
Using a mixture of different wire types and diameters may cause a communication error.
System diagram
* The wiring specifications in the system diagram above are the same even when the indoor unit or remote controller are other
than the U series.
Item
Communication line
Control wiring between indoor and outdoor units and central control
wiring
Wire diameter 1.25 mm2(up to 1000 m)
2.0 mm2(up to 2000 m)
Wire type 2-core, non-polar
Wire types that can be used Shielded wire
U2
U4
U3 U4
U3 U4
U6
U4
U1
Uv Uv Uv Uv
U2
A
B
U6
U4
U1 U2
AB
U6
U4
U1 U2
AB
U6
U4
U1 U2
AB
U1
U3
U2
U5 U6
U3 U4
U1 U2
U5 U6
U3 U4
U1
U2 U5 U6
U3 U4
U1
LINK (Uh)
Central control
device
<Other than U
series>
Outdoor unit
(Super Module
Multi i series
• Super Multi mini)
<U series>
Indoor unit *
<U series>
Remote
controller *
[Central control wiring/Control wiring between indoor
and outdoor units]
(L1+L2+L3) = Up to 2000 m
[Control wiring between indoor and outdoor units]
L4 = Up to 100 m

BN interface Installation Manual
13-EN
When connecting to a previous model light commercial, air to air heat exchanger, air to water
heat pump, or general purpose equipment control interface
Follow the wiring specifications in the table below even when there is a mix of U series and non-U series in the connected indoor
units or remote controllers.
Wiring specifications
REQUIREMENT
When wiring the control wiring between indoor and outdoor units (Uv line)/control wiring between outdoor units (Uc line) and the
central control wiring (Uh line), use the same wire type and diameter for each line.
Using a mixture of different wire types and diameters may cause a communication error.
System diagram
* The wiring specifications in the system diagram above are the same even when the indoor unit or remote controller are other
than the U series.
Item Communication line
Central control wiring (Uh line)
Wire diameter 1.25 mm2(up to 1000 m)
2.0 mm2(up to 2000 m)
Wire type 2-core, non-polar
Wire types that can be used Shielded wire
U2
U4
U3 U4
U3 U4
U6
U4
U1
Uv
U2
A
B
U2
U5 U6
U3 U4
U1
U3 U4 U3 U4
LINK (Uh)
U6
U4 U4
A
BU6
4
Uh
A
B
Central control
device
Outdoor unit
and Other
Indoor unit *
Hydro unit
<U series>
Remote
controller *
[Central control wiring (Uh line)]
L1 = Up to 2000 m
[Control wiring between indoor and outdoor units
(Uv line)/Control wiring between outdoor units (Uc line)]
L2 = Up to 1000 m
Light Commercial
Air to air heat
exchanger
General purpose
equipment
control
interface
Air to Water
Heat Pump
TCC-LINK
adapter

BN interface Installation Manual
14-EN
3Settings
3-1. Switch setting
SW300 Not used
SW301 Test switch
Set all bits to "OFF".
SW302 Test button
Not used during normal operation.
SW100 Uh Line termination resistance setting switch
Refer to "Termination resistance setting" (P.9)
SW700 Shutdown function / air-conditioning search mode function button
Use this button to stop BACnet process and network process of the BN interface or to start up in the air-conditioning
search mode. Note that button operation changes depending on how long it is depressed.
Time duration button is depressed Operation
Less than 4 seconds Stop BACnet process and network process of the BN interface.
4 seconds or more Starts air-conditioning in the air-conditioning search mode.
Use the air-conditioning search mode to set up equipment data in the indoor
unit.
6: 6: 6: 6:
6:

BN interface Installation Manual
15-EN
3-2. LED
4Factory default settings
LED LED color Use
POWER Red Power indicator
LINK(Uh) Orange Uh Line communication status indicator
ERROR Red Uh Line communication error indicator
CPU Green Communication status indicator in the BN interface
L1 Green BACnet communication status indicator
L2 Red BACnet communication status indicator, setting error indicator
/
/
&38
/,1.8K
32:(5
(5525
䣒䣑䣙䣇䣔 䣎䣋䣐䣍䢪䣗䣪䢫 䣅䣒䣗
(5525
䣒䣑䣙䣇䣔 䣎䣋䣐䣍䢪䣗䣪䢫 䣅䣒䣗
(5525
No. Item Factory default setting
1IP address IP address 192.168.1.100
Subnet mask 255.255.255.0
2UDP port 47808 (0xBAC0)
3Device object instance number 100
4Address setting switch 1
5Test switch All OFF
6Uh Line termination resistance select switch OFF

BN interface Installation Manual
16-EN
5Test run
To perform test run of the BN interface, BACnet communication settings and the equipment data of the connected indoor units
are required.
Items to be set during trial run
5-1. BACnet communication settings
Set the IP address of the BN interface and the device object instance number of the BACnet communications. These setting
can set from Setting File Creation Software 2. For details, contact your dealer.
Equipment Item Setting method
Outdoor unit Uh Line address Line address Use the DIP switch on the outdoor
unit circuit board.
Indoor unit Uh Line address
Line address Use the address setting function of
wired remote controller.
(Except for simple wired remote
controller)
Unit address
Central control address
Group address
BN interface
IP address IP address
Use Setting File Creation Software 2.
(See Section 5-1.)
Network mask
BACnet communication device
identification number
BACnet device object instance
number
When using together with a
central control device not
compatible with Uh Line
Setting of old BN interface
Setting for combined use with
old controller
When replacing with a BN
interface that does not support
Uh Line
Setting of old BN interface
Indoor unit information
(DN code setting values)
Line address
When setup work (see Section 5-2)
is performed, the BN interface reads
out the set values from the indoor
unit and records them on the SD card
of the BN interface.
Perform setup work after changing
the device information of the indoor
unit.
Unit address
Central control address
Group address
Operation mode setting range
Temperature setting range
Fan speed setting range
Flap type
Ventilation amount setting
range
Ventilation mode setting range
Availability of ventilation
operation
Availability of save function

BN interface Installation Manual
17-EN
5-2. Setting up equipment data in the indoor unit
Obtain the equipment data of the indoor unit that is controlled by the BN interface from the indoor unit via the Uh Line
communication cable.
Preparing to set up equipment data in the indoor unit
• Central Control address must be set in the indoor unit you want to control.
For information on how to set the address, refer to the installation manual of each indoor unit.
• Turn on all indoor and outdoor units. Set up as follows, waiting 10 minutes after turning on all the units.
Setup work
• Turn on the BN interface.
• When 10 minutes has elapsed since turning on the BN interface, hold down the shutdown button for 4 seconds or longer.
L1 LED goes on.
• When the BN interface has started up normally, start reading the equipment data of the interface unit. During this operation
L1 LED will be on while L2 LED will be blinking on the BN interface.
• When reading of equipment data in the indoor unit ends normally, the BN interface will automatically start preparing for
BACnet communication. L1 LED on the BN interface is blinking.
• When the preparations for BACnet communications end normally, L1 LED and L2 LED of the BN interface will start
blinking.
• If an error occurs during reading of equipment data from the indoor unit or when preparing for BACnet communications,
L1 LED and L2 LED of the BN interface will go on.
Determining the cause of such an error will require the use of engineering tools. For details, contact your dealer.
5-3. Cause of problem occurring during setup
6Turning off the BN interface
Press the shutdown button, then wait 5 minutes before turning it off.
CAUTION
As the air-conditioning search mode will be engaged if the shutdown button is pressed for 4 seconds or longer, do not hold down
the button.
Cause of problem Cause Action
The indoor unit cannot be found.
The indoor and outdoor units have not been
turned on.
Make sure that indoor and outdoor units are
turned on.
The indoor and outdoor units are being
initialized and it is not possible to
communicate with them.
LINK(Uh) LED does not blink at all
Make sure that indoor and outdoor units are
turned on.
Make sure they have been on for at least
10 minutes.
The Uh Line cables have been incorrectly
connected. Connect the cables correctly.
The central control address has not been set
in the indoor units.
Make sure that the central control address has
been set in the indoor units.
The central control address set in
the indoor units are not unique.
The same central control address has been
set in a number of indoor units.
Make sure that the central control address has
been correctly set in the indoor units.

BN interface Installation Manual
18-EN

DEC0209101-1
Klimanıza ilişkin daha ayrıntılıbilgiler için ürün tanıtım broşürlerine,
gerektiğinde Alarko Carrier Yetkili Satıcıve Servislerine ulaşabilmek için 444 0 128 numaralı
Müşteri Danışma Hattımıza başvurabilirsiniz.
