Toshiba OIS40R User manual

April 2003
OIS40R
Remote Operator Interface Station
For Toshiba T-Series PLCs
The OIS40R is the same OIS (Operator Interface Station) as the OIS40 except that the PLC
communication port is selectable, RS232 or RS485. As a result, its location is not limited to the 2 m
maximum distance from the PLC like the OIS40. It can be located up to 1000 m (a little over ½ mile)
from the PLC.
Another new feature on the OIS40R is that the keypad overlay is included separately. The overlay
can easily be stuck on the OIS40R or replaced by a custom overlay which better describes the
application—giving the operator more guidance on operation / data entry.
Standard features include:
♦20 Character by 4 Line Display ♦8 Function / Macro Keys
♦Numeric Key Pad for Data Entry ♦8 User Programmable LEDs
♦Unlimited Screens & Tasks
(except by available memory)
♦16 Definable Alarms
(can be logged & printed)
Programmable Controllers

Rev 2003.4.1
SPECIFICATIONS PROTOCOLS
Power 24 VDC +/-10%, 2 W maximum Toshiba T-Series PLCs
Ke
y
p
ad IP65 rated ke
yp
ad Toshiba V-Series Inte
g
rated Controllers
Temperature Operating: 0 to 50 degrees C
Storage: -25 to 80 degrees C
Toshiba G7/S9/VF_nC1 ASDs
Modbus
Humidity 10% to 90% (Non condensing) Special (check with Toshiba)
Bezel Size 101.30 H X 182.50 W, Depth:36.80
mm
Panel cutout
79.00H X 162.00 W mm
Communication Connects to PLC RS232/R485 port
Immunit
y
to ESD Level 3 as
p
er IEC1000-4-2
Immunit
y
to Transients Level 3 as
p
er IEC1000-4-4
Radiated Susceptibility Level 3 as per IEC1000-4-3
Emission EN55011 CISPR A
ORDER NUMBERS DIMENSIONS
Part Numbers Description
OIS40R Operator Interface Station.
TKRS485 RS485 Communication Cable T2N) 2m w/ 15
pin D shell & pigtail.
CAB-OIS-T1-X RS232 Communication Cable 2m w/ 8 pin
mini DIN & 9 pin D-shell (T1)
CAB-OIS-T2-X RS232 Communication Cable (T2E/T2N/T3)
9830 Beldon RS485 Cable (or equivalent)
Communications Cable 24 AWG low
capacitance (T1, T2E, V-Series)
26-117B RadioShack RS232 Programming Cable
(or equivalent), 9 pin D shell (male & female)
Note: The OIS40R has a 9 pin D shell female connector for connection to the PLC. This connector can be setup as either
RS485 or RS232. For RS485 connection, one end of the Beldon 9830 cable must be terminated with a 9 pin D shell (male)
connector.
