Toshiba RBC-AMT32E User manual

Pocket Quick Reference
Guide 2012
On the TOSHIBA
RBC-AMT32E / RBC-AMS41E
Remote Controllers

Quick Reference Guide
To assist service engineers working on Toshiba air conditioning equipment, there is a large quantity of
data available via the standard remote controller, either the RBC-AMT32E or the RBC-AMS41E, this
data is NOT available via an Infra Red remote or the RBC-AS21E2 simplified remote controller.
Accessing the data is a simple process of pressing a sequence of buttons on the remote controller.
Fault Code Guide
Current fault codes are displayed automatically on the left
of the remote controller, (Four figure display in Black) fault
code history can be accessed by pressing “Test and Set”
(The two yellow buttons) together and holding for 4
seconds.
Each controller will hold four fault codes per unit
controlled, the first displayed fault code is the youngest
and the fourth will be the oldest.
To scroll through the faults use the “TEMP” buttons.
Refer to the Technical Handbook for fault code diagnosis and descriptions
Data Retrieval Guide
System data can be obtained by pressing “Test and CL”
together and holding for 4 seconds
Codes are displayed on the right of the remote display
To scroll through the codes use the “TEMP ” buttons.
Data is displayed on the left of the remote controller.
Data is available for “0, 1, 2, 3 & 4 Series” Digital/Super Digital
Inverter and VRF equipment (SMMS, SHRM & SMMSI).

Digital/Super digital “0-1-2-3” series data
Code
Indoor Data
Code
Outdoor Data
00
Room Temp (Control Temp) (oC)
60
TE Sub-cooled Liquid Temp. (oC)
01
Room Temp. (Remote Controller) (oC)
61
TO Ambient Temp. (oC)
02
TA Return Air Temp. (oC)
62
TD Discharge Temp. (oC)
03
TC Coil –Vapour Temp. (oC)
63
TS Suction Temp. (oC)
04
TCJ Coil –Liquid Temp. (oC)
65
THS –Inverter Heat Sink Temp. (oC)
Digital/Super digital “4” series
Code
Indoor Data
Code
Outdoor Data
00
Room Temp (Control Temp) (oC)
60
TE Sub-cooled Liquid Temp. (oC)
01
Room Temp. (Remote Controller) (oC)
61
TO Ambient Temp. (oC)
02
TA Return Air Temp. (oC)
62
TD Discharge Temp. (oC)
03
TC Coil –Vapour Temp. (oC)
63
TS Suction Temp. (oC)
04
TCJ Coil –Liquid Temp. (oC)
65
THS –Inverter Heat Sink Temp. (oC)
07
Fan Speed (rpm)
6A
Operation Current (A)
F2
Fan Run Time (x 100h)
70
Compressor Frequency (Hz)
F3
Filter Duration Timer ( x 1h)
72
Fan Speed (Lower) –(rpm)
F8
Discharge Temp. (Indoor –If fitted) (oC)
73
Fan Speed (Upper) –(rpm)
F1
Compressor Run Time (x 100h)
VRF indoor data for Mini SMMS / SMMS / SMMSI & SHRM equipment
Code
Indoor Data
Code
Indoor Data
00
Room Temp (Control Temp) (oC)
06
Indoor Discharge Temp (If Used) - (oC)
01
Room Temp. (Remote Controller) (oC)
08
PMV Position (0 –10)
02
TA Return Air Temp. (oC)
0A
Number of Connected Indoor Units (No.)
03
TCJ Coil –Liquid Temp. (oC)
0b
Indoor Capacity (x 10 = HP)
04
TC2 Coil –PMV Pipe Temp. (oC)
0C
Number of Outdoor Units (No.)
05
TC1 Coil –Vapour Temp (oC)
0d
Outdoor Capacity ( x 10 = HP)
VRF Outdoor data for Mini SMMS / SMMS & SHRM equipment
Code
Outdoor Data
Code
Outdoor Data
*0
Td1 - Compressor 1 Discharge Temp. (oC)
*8
TU –Low Pressure Saturated Temp. (oC)
*1
Td2 - Compressor 2 Discharge Temp. (oC)
*9
Compressor 1 Current (A)
*2
Pd –High Pressure Sensor (MPa)
*A
Compressor 2 Current (A)
*3
Ps - Low Pressure Sensor (MPa)
*b
PMV1 + 2 Opening (0 –100)
*4
TS –Suction Temp. (oC)
*d
Compressor 1, 2 ON/OFF
*5
TE - Outdoor Heat Exchanger Temp. (oC)
*E
Outdoor Fan Mode (0 –31)
*6
TL –Liquid Temp. (oC)
*F
Outdoor Unit Size (HP)
Note. * Would be replaced with 1, 2, 3 or 4 to obtain data from respective outdoor unit.

VRF Outdoor data for SMMSI equipment
Code
Outdoor Data
Code
Outdoor Data
*0
Pd –High Pressure Sensor (MPa)
#0
Compressor 1 Revolutions (rps)
*1
Ps –Low Pressure Sensor (MPa)
#1
Compressor 2 Revolutions (rps)
*2
Td1 –Compressor 1 Discharge Temp. (oC)
#2
Compressor 3 Revolutions (rps)
*3
Td2 –Compressor 2 Discharge Temp. (oC)
#3
Outdoor Fan Mode
*4
Td3 –Compressor 3 Discharge Temp. (oC)
#4
Compressor IPDU 1 Heat Sink Temp. (oC)
*5
TS –Suction Temp. (oC)
#5
Compressor IPDU 2 Heat Sink Temp. (oC)
*6
TE1 –Outdoor Coil Temp. (oC)
#6
Compressor IPDU 3 Heat Sink Temp. (oC)
*7
TE2 –Outdoor Coil Temp. (oC)
#7
Outdoor Fan IPDU Heat Sink Temp. (oC)
*8
TL –Liquid Temp. (oC)
#8
Heating / Cooling Recovery Controlled
*9
TO –Outdoor Ambient Temp. (oC)
#9
Pressure release
*A
PMV 1 + 2 Opening
#A
Discharge Temp. Release
*B
PMV 4 Opening
#B
Follower Unit Release
*C
Compressor 1 Current (A)
#F
Outdoor Unit Size (HP)
*D
Compressor 2 Current (A)
Note. * Would be replaced with 1, 2, 3 or 4 to
obtain data from respective outdoor unit.
# would be replaced with either 5, 6, 7, 8 to
obtain data from outdoor units 1,2,3 or 4
*E
Compressor 3 Current (A)
*F
Outdoor Fan Current (A)
For more detailed descriptions please refer to the relevant technical service manual.
NOTES:

Common Configurable Control Options
*Accessed via Toshiba hard wired remote controller RBC-AMT32E and RBC-AMS41E
Relocation of room temperature sensing from return air to remote controller sensor
Press and hold the TEST, SET & CL Buttons simultaneously for 4 seconds
The Engineering Menu is accessed at item code 10
Use the Temperature  Buttons to navigate to item code 32
Use the Timer  Buttons to adjust the value from 0000 to 0001
Press SET to acknowledge the change
Press Test to exit the Engineering Menu
The display will go blank and then flash SETTING whilst the system reconfigures
When SETTING stops flashing press ON/OFF Button to restart the operation
Automatic restart after power failure
Press and hold the TEST, SET & CL Buttons simultaneously for 4 seconds
The Engineering Menu is accessed at item code 10
Use the Temperature Buttons to navigate to item 28
Use the Timer  Buttons to adjust the value from 0000 to 0001
Press SET to acknowledge the change
Press Test to exit the Engineering Menu
The display will go blank and then flash SETTING whilst the system
reconfigures
When SETTING stops flashing press ON/OFF Button to restart the
operation

Simplified Instructions for the RBC-AMS41E Remote Controller
Setting Present Time and Day of Week
Press and hold SCHEDULE for 4 seconds, (setting appears on screen)
Press DAY until the correct day of the week is indicated
Press TIME up and down keys to set current time
Press SET to confirm entries. Day and time now set.
Setting ON and OFF Times (scheduled operations)
1. Press PROGRAM, display will flash PG-01
2. Press DAY until Monday is selected then Press SET
3. Press SET, PG-01 will stop flashing
4. Press TIME up and down keys until required ON TIME is displayed
5. Press SCHEDULE until blinks (symbol denotes start operation)
6. Press SET
7. Press UNIT, PG-02 will appear
8. Press SET, PG-02 will stop flashing
9. Press TIME up and down keys until required OFF TIME is displayed
10. Press SCHEDULE until blinks (denotes stop operation)
11. Press SET and then PROGRAM
The bar now underlining MONDAY indicates that times have now been entered
Copying From Monday to Remaining Days of Week
1. Press PROGRAM, display will flash PG-01
2. Press DAY key and select Monday
3. Press SET
4. Press UNIT key until PG-CP appears (program copy)
5. Press SET
6. Press DAY and select Tuesday
7. Press SET (Monday times have now been copied into Tuesday) to continue copying return to step 4
8. Press PROGRAM
The times have now been programmed into the controller
N.B. To activate the programmed times press SCHEDULE, will flash,
Press SET, remains displayed, scheduled programming now activated.
To deactivate the programmed times press SCHEDULE, will flash,
Press CL, disappears from screen.

Time, Temperature and Mode Selection when Programming the RBC-AMS41E
Setting Present Time and Day of Week
Press and hold SCHEDULE for 4 seconds, (setting appears on screen)
Press DAY until the correct day of the week is indicated
Press TIME up and down keys to set current time
Press SET to confirm entries. Day and time now set.
Setting Scheduled Operations with Mode and Temperature functionality
12. Press PROGRAM, display will flash PG-01
13. Press DAY until Monday is selected then Press SET
14. Press SET, PG-01 will stop flashing
15. Press TIME up and down keys until required ON TIME is displayed
16. Press MODE key selecting desired mode of operation
17. Press TEMPERATURE up & down arrows to set desired temperature
18. Press SCHEDULE until blinks (symbol denotes start operation)
19. Press SET
20. Press UNIT, PG-02 will appear
21. Press SET, PG-02 will stop flashing
22. Press TIME up and down keys until required OFF TIME is displayed
23. Press SCHEDULE until blinks (symbol denotes stop operation)
24. Press SET and then PROGRAM
The bar now underlining MONDAY indicates that times have now been entered
Copying From Monday to Remaining Days of Week
9. Press PROGRAM, display will flash PG-01
10. Press DAY key and select Monday
11. Press SET
12. Press UNIT key until PG-CP appears (program copy)
13. Press SET
14. Press DAY and select Tuesday
15. Press SET (Monday times have now been copied into Tuesday) to continue copying return to step 4
16. Press PROGRAM
The times have now been programmed into the controller
N.B. To activate the programmed times press SCHEDULE, will flash,
Press SET, remains displayed, scheduled programming now activated.
To deactivate the programmed times press SCHEDULE, will flash,
Press CL, disappears from screen.

Contact details:
Cool Designs Ltd Technical Support
0844 800 0250
Toshiba Air Conditioning
24/7 technical support
0870 843 0333
Text back service
07624 803 017
(Type fault code in lower case no spaces)
