Toshiba 1600 Series Installation instructions

Toshiba International Corporation
Uninterruptible Power Systems
UE3G2L036C61T
Product Specifications
INPUT Voltage 208/240Vac
Voltage Range 168V~264V (+10% to -30%)
Frequency 50/60 Hz Auto Sensing
Synchronization window ± 3Hz
Power Factor Greater than 0.95
THD Current Less than 5% at Full Load
Topology True On-Line, Double Conversion, Input PF Correction
OUTPUT Voltage 208/240/120Vac
Capacity (VA) 3600
Capacity (W) 3100
Voltage Regulation ± 3%
Voltage Distortion Less than 6% THD at Full Non-Linear Load. Less than 3% THD at full Linear Load.
Step Load ± 8 % max from 100% to 0 % or from 0% to 100 % linear load
Rated Current 15A
1600 Series 3.6kVA 208/240V In - 208/240/120V Out Tower
Hardwire Solution - UE3G2L036C61T
Toshiba's 1600EP Series is an on-line Uninterruptible Power Supply (UPS) systems
provide continuous computer-grade ac power in a compact, high performance, and
energy efficient unit. The UPS unit assures safe and reliable operation of critical
office equipment. This can range from word processors and personal computers to
mini-computers and local area networks. All units feature an audible alarm that
sounds if the battery voltage drops below standard during use. This is an additional
aid to help in retaining the valuable office data banks. All units allow for computer
interfacing. This model is a hardwire solution. Customers have the option to
choose from a range of different receptacles panels’ offers by Toshiba. Please refer
to the specification for different line cord and receptacles panels options.

Toshiba International Corporation
Uninterruptible Power Systems
UE3G2L036C61T
Max Peak Current 45A
Overload Capacity 125% for 30 secs, 150% for 10 secs
Crest Factor 3.0 at full load
Frequency 50/60 Hz Auto Sensing
Frequency Regulation ± 0.5Hz/± 1.0Hz/± 1.5Hz (authorized service center selectable only)
Wave Form Sine wave, Zero Transfer Time
Load Power Factor 0.85
Efficiency AC to AC Greater than 83%
Common Mode Noise Less than 0.5 Vrms
BATTERY DC Voltage 216V
Backup Time 10 min (full load) 30 min (half load)
Battery type Enersys NPX-35 Flame Retardant Lead Acid 9Ah/12V Part #: 51896
Number of batteries Pack 3 (Six batteries in each pack)
Recharge time <12 hours to 90%
Interface RS-232, Dry Contact Connectivity, External Battery Connectivity
Input Hardwire Input
Output Hardwire Output
Dimensions WxDxH (mm) 838x254x711
BATTERY Ship Dimensions WxDxH (mm) 965x432x940
Dimensions W x D x H (inch) 33x10x28
Ship Dimensions WxDxH (inch) 38x17x37
Weight kg (lb) 120.2 (265)
Ship Weight kg (lb) 127 (280)
External Matching Battery Cabinet Single - 70 Mins, Double - 140 Mins. Max Two Cabinets. Part #: UE3-BC-0650
Line Cord Options 3.6kVA L6-30 Plug with 8" Line Cord (3 wire) Part #: UE31-6LC-30A
Receptacles Options Four L6-30R, Two 5-15R (Duplex) Part #: UE3-RP-B3
Five 5-20R (Duplex) Part #: UE3-RP-B5
Two L6-30R, Four 5-15R (Duplex) Part #: UE3-RP-B7
Network Interface Card RemotEye II - Part #: RMTI-INT-R25
Environmental Monitoring Device Part #: RMTI-EMD-HT
ENVIRONMENT Operating Ambient Temperature 0 ~ 40oC (32 ~ 104oF)
Recommended Temperature +15oC ~ 25oC
Storage Temperature -20oC ~ 40oC
Humidity 30-90%, Non-Condensing
Audible Noise 50dB (A) maximum @ 1 meter from Front Panel

Toshiba International Corporation
Uninterruptible Power Systems
UE3G2L036C61T
Altitude 3300 ft (1,000 m) above sea level
CONFORMANCE Regulatory Approvals UL, CUL, ISO 9001, NEMA/PEI-1993
WARRANTY Three years on electronics
Two years full replacement on battery (See Toshiba warranty policy for full details)
