Toshiba International Corporation
Uninterruptible Power Systems
UE3G2L036C61TMB
Product Specifications
INPUT Voltage 240Vac
Voltage Range 168V~264V (+10% to -30%)
Frequency 50/60 Hz Auto Sensing
Synchronization window ± 3Hz
Power Factor Greater than 0.95
THD Current Less than 5% at Full Load
Topology True On-Line, Double Conversion, Input PF Correction
OUTPUT Voltage 240Vac
Capacity (VA) 3600
Capacity (W) 3100
Voltage Regulation ± 3%
Voltage Distortion Less than 6% THD at Full Non-Linear Load. Less than 3% THD at full Linear Load.
Step Load ± 8 % max from 100% to 0 % or from 0% to 100 % linear load
Rated Current 15A
Max Peak Current 45A
1600EP Series 3.6kVA 240V In - 240V Out Tower Maintenance Bypass Solution
Toshiba's 1600EP Series is an on-line Uninterruptible Power Supply (UPS) systems
provide continuous computer-grade ac power in a compact, high performance, and energy
efficient unit. The UPS unit assures safe and reliable operation of critical office equipment.
This can range from word processors and personal computers to mini-computers and local
area networks. All units feature an audible alarm, which sounds if the battery voltage drops
below standard during use. This is an additional aid to help in retaining the valuable office
data banks. All units allow for computer interfacing.
This model is a Maintenance Bypass solution. Maintenance Bypass solution is a two
breaker maintenance bypass panel. This is a 240V input and 240-output solution.
Toshiba International Corporation
Uninterruptible Power Systems
UE3G2L036C61TMB
Overload Capacity 125% for 30 secs, 150% for 10 secs
Crest Factor 3.0 at full load
Frequency 50/60 Hz Auto Sensing
Frequency Regulation ± 0.5Hz/± 1.0Hz/± 1.5Hz (authorized service center selectable only)
Wave Form Sine wave, Zero Transfer Time
Load Power Factor 0.85
Efficiency AC to AC Greater than 83%
Common Mode Noise Less than 0.5 Vrms
BATTERY DC Voltage 216V
Backup Time 10 min (full load) 30 min (half load)
Battery type Enersys NPX-35 Flame Retardant Lead Acid 9Ah/12V Part #: 51896
Number of batteries Pack 3 (Six batteries in each pack)
Recharge time <12 hours to 90%
PHYSICAL Interface RS-232, Dry Contact Connectivity, External Battery Connectivity
Input Hardwire Input
Output Hardwire Output
Dimensions WxDxH (mm) 838x254x711
Ship Dimensions WxDxH (mm) 965x432x940
Dimensions W x D x H (inch) 33x10x28
Ship Dimensions WxDxH (inch) 38x17x37
Weight kg (lb) 120.2 (265)
Ship Weight kg (lb) 127 (280)
OPTION External Matching Battery Cabinet Single - 70 Mins, Double - 140 Mins. Max Two Cabinets. Part #: UE3-BC-0650
Network Interface Card RemotEye II - Part #: RMTI-INT-R25
Environmental Monitoring Device Part #: RMTI-EMD-HT
ENVIRONMENT Operating Ambient Temperature 0 ~ 40oC (32 ~ 104oF)
Recommended Temperature +15oC ~ 25oC
Storage Temperature -20oC ~ 40oC
Humidity 30-90%, Non-Condensing
Audible Noise 50dB (A) maximum @ 1 meter from Front Panel
Altitude 3300 ft (1,000 m) above sea level
CONFORMANCE Regulatory Approvals UL, CUL, ISO 9001, NEMA/PEI-1993
WARRANTY Three years on electronics
Two years full replacement on battery (See Toshiba warranty policy for full details)
