Toshiba 4200 series User manual

TOSHIBA
UNINTERRUPTIBLE POWER SYSTEM
THREE PHASE- 75/100kVA UPS
4200 SERIES
MANUFACTURED IN THE U.S.A.
OPERATION MANUAL
Part Number: 51751-001
Date: March, 2003

TOSHIBA
1
4200 SERIES
THREE PHASE- 75/100 kVA
UNINTERUPTIBLE POWER SYSTEM
OPERATION MANUAL
FOR MODELS
U42B3F750C6CB
U42B3F10KC6CB
TOSHIBA INTERNATIONAL CORPORATION
INDUSTRIAL DIVISION
13131 West Little York Rd., Houston, Texas 77041

TOSHIBA
2
UNINTERUPTIBLE POWER SUPPLY
If additional information or technical assistance is required call Toshiba’s marketing department
toll free at 1-800-231-1412, or write to: Toshiba International Corporation, 13131 W. Little York
Rd., Houston, TX 77041-9990.
Please complete the following information for your records; however, please keep this manual
with the UPS equipment.
Model Number:
Serial Number:
Date of Installation:
Inspected By:
NOTE
These Instructions are not intended to cover all of the details or variations
in equipment, nor to provide for every possible contingency to be met in
connection with installation, operation, or maintenance. This manual may
change without notice. Contact your local Toshiba sales office to verify
that this is the latest revision. Should further information be desired or
should particular problems arise which are not covered sufficiently for the
purchaser’s purposes, the matter should be referred to the local Toshiba
sales office.
The contents of this instruction manual shall not become a part of or
modify any prior or existing equipment, commitment, or relationship. The
sales contract contains the entire obligation of Toshiba International
Corporation’s UPS Division. The warranty contained in the contract
between the parties is the sole warranty of Toshiba International
Corporation’s UPS Division, and any statements contained herein do not
create new warranties or modify the existing warranty.
Any Electrical or mechanical modifications to this equipment, without prior
written consent of Toshiba International Corporation, will void all
warranties and may void UL/CUL listing. Unauthorized modifications also
can result in personal injury, death, or destruction of the equipment.

TOSHIBA
3
GENERAL SAFETY INSTRUCTIONS
Warnings in this manual appear in any of four ways:
1) Danger- The danger symbol is a lightning bolt mark enclosed in a triangle which precedes the
3/16” high letters spelling the word “DANGER”. The danger symbol is used to indicate imminently
hazardous situations, locations, and conditions which, if not avoided, WILL result in death,
serious injury, and/or severe property damage.
DANGER
2) Warning- The warning symbol is an exclamation mark enclosed in a triangle which precedes the
3/16” high letters spelling the word “WARNING”. The warning symbol is used to indicate
potentially hazardous situations and conditions which, if not avoided COULD result in serious
injury or death. Severe property damage COULD also occur.
WARNING
3) Caution- The caution symbol is an exclamation mark enclosed in a triangle which precedes the
3/16” high letters spelling the word “CAUTION”. The caution symbol is used to indicate potentially
hazardous situations and conditions which, if not avoided COULD result in injury. Equipment
damage may also occur.
CAUTION
4) Attention warnings- The attention warning symbol is an exclamation mark enclosed in a triangle
which precedes the 3/16” high letters spelling the word “ATTENTION”. The Attention warning
symbol is used to indicate situations and conditions that COULD cause operator injury and/or
equipment damage.
ATTENTION
Other warning symbols may appear along with the Danger and Caution symbol. The additional symbols are
used to specify special hazards. These warnings describe particular areas where special care and/or
procedures are required in order to prevent serious injury and possible death:
1) Electrical warnings- The electrical warning symbol is a lighting bolt mark enclosed in a triangle.
The Electrical warning symbol is used to indicate high voltage locations and conditions that
COULD cause serious injury or death if the proper precautions are not observed:
2) Explosion warnings- The explosion warning symbol is an explosion mark enclosed in a triangle.
The Explosion warning symbol is used to indicate locations and conditions where molten,
exploding parts that COULD cause serious injury or death if the proper precautions are not
observed:

TOSHIBA
4
TABLE OF CONTENTS
GENERAL SAFETY INSTRUCTIONS................................................................................. 3
TABLE OF CONTENTS....................................................................................................... 4
IMPORTANT SAFETY INSTRUCTIONS ............................................................................. 6
1.0 Product Description .................................................................................................. 8
1.1 Theory of Operation.............................................................................................................................. 8
1.2 Application and use .............................................................................................................................. 8
1.3 Power Backup....................................................................................................................................... 8
1.4 Power Conditioning .............................................................................................................................. 8
2.0 Uncrating/Inspection/Storage/Disposal................................................................... 9
2.1 Uncrating the new UPS equipment: ..................................................................................................... 9
2.2 Inspection of the new UPS equipment ............................................................................................... 10
2.3 Storage of UPS equipment................................................................................................................. 10
2.4 Disposal .............................................................................................................................................. 10
3.0 Precautions...............................................................................................................11
3.1 Installation Precautions ...................................................................................................................... 11
3.2 Pre-start Precautions.......................................................................................................................... 12
3.3 Operating Precautions........................................................................................................................ 12
4.0 UPS Connections .................................................................................................... 13
4.1 Power Connections 75 and 100kVA................................................................................................... 13
4.1.1 Recommended Wire Size and Tightening Torque For UPS Input and Output Terminals ............ 14
4.1.2 Power Connection Cable Routing ................................................................................................. 15
4.2 Control Circuit and External Battery Interface Connections 75 and 100kVA ..................................... 16
4.2.1 Recommended Wire Size and Tightening Torque UPS Control and Battery Interface................. 16
4.3 Communication Interface.................................................................................................................... 17
4.3.1 Remote Contact (IBM AS/400)...................................................................................................... 17
4.3.2 RS-232C ........................................................................................................................................ 18
4.3.3 UPS Shutdown (via RS-232C) ...................................................................................................... 18
5.0 Specifications.......................................................................................................... 19
5.1 4200 Series Specifications 75 and 100kVA @ Standard 208Vac Output.......................................... 19
6.0 Operating the UPS................................................................................................... 20
6.1 Operating the UPS ............................................................................................................................. 20
6.1.1 AC Input Mode (normal operation) ................................................................................................ 20
6.1.2 Circuit-bypass Mode...................................................................................................................... 20
6.1.3 Battery Backup Mode .................................................................................................................... 21
6.2 Battery Backup Time and Discharge Process....................................................................................21
6.3 Battery Low Voltage Tolerances......................................................................................................... 22
6.4 Battery Recharging............................................................................................................................. 22
6.5 Front Panel Layout (All Units)............................................................................................................. 23
6.6 EPO (Emergency Power Off) Function .............................................................................................. 24
6.7 Audible Alarm Functions..................................................................................................................... 24
6.8 Light Emitting Diode (LED) Functions ................................................................................................ 25
6.8.1 Light Emitting Diode (LED) System Status.................................................................................... 25
6.9 Liquid Crystal Display (LCD) Functions.............................................................................................. 26
6.9.1 Line-1 System Messages .............................................................................................................. 26
6.9.2 Line-2 System Fault Messages ..................................................................................................... 26
6.9.3 Line-3 System Messages .............................................................................................................. 26
6.9.4 Line-4 System Messages .............................................................................................................. 27
6.10 Initial Battery Charge .......................................................................................................................... 28
6.11 Start-up Procedure ............................................................................................................................. 29
6.12 Shutdown Procedure .......................................................................................................................... 30
6.13 Keypad Overview................................................................................................................................ 31
6.14 Key Functions ..................................................................................................................................... 32
6.14.1 MONI ............................................................................................................................................. 32
6.14.2 IN ................................................................................................................................................... 32

TOSHIBA
5
6.14.3 OUT ............................................................................................................................................... 32
6.14.4 BATT Key ...................................................................................................................................... 33
6.14.5 MENU, F1, ENTER, UP, & DOWN Keys....................................................................................... 33
6.14.6 BATT TEST Key ............................................................................................................................ 33
6.14.7 BUZZ STOP Key ........................................................................................................................... 34
6.14.8 RESET Key.................................................................................................................................... 34
6.15 Menu Data Screens............................................................................................................................ 35
6.15.1 Settings for Calendar and Clock.................................................................................................... 35
6.15.2 Adjusting Buzzer Volume .............................................................................................................. 35
6.15.3 Settings for Display Duration ......................................................................................................... 35
6.15.4 Run Switch Select ......................................................................................................................... 36
6.15.5 Serial Com Station Address .......................................................................................................... 36
6.15.6 Output Voltage Adjustment............................................................................................................ 37
6.15.7 Charge Mode Select...................................................................................................................... 37
6.15.8 Reset to Default Settings............................................................................................................... 38
6.16 Overload Operation ....................................................................................................................... 38-39
7.0 UPS Protection System .......................................................................................... 40
7.1 System Protection Features ............................................................................................................... 40
7.2 System Protection Functions.............................................................................................................. 40
8.0 Preventive and Scheduled Maintenance / Part Replacement.............................. 41
8.1 Preventive Maintenance ..................................................................................................................... 41
8.2 Parts Replacement ............................................................................................................................. 41
9.0 External Layouts / Dimensions / Shipping Weights ............................................. 42
9.1 External Dimensions 75 and 100kVA................................................................................................. 42
9.2 Shipping Dimensions 75, and 100kVA .............................................................................................. 43

TOSHIBA
6
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS This manual contains important
instructions for 4200 Series 75/
And 100kVA that should be followed during the installation, operation, and maintenance of the UPS
Systems. Refer to the Battery System Manual for details on operating and maintaining the battery units
for each system.
UPS System’s output is not equipped with an over-current protection device, nor an output disconnect for the
AC output; therefore, a circuit breaker should be provided, by the user, between the UPS output and the
critical load input. This device should be rated as follows:
Model Rated Output Device Rating
75kVA 208/120Vac 240V, 270A
Model Rated Output Device Rating
100kVA 208/120Vac 240V, 350A
The maximum ambient temperatures in which the Uninterruptible Power Systems should be operated in is
40°C. (25°C max. if battery cabinet is subject to same ambient)
The nominal battery voltage for 75kVA is 240VDC; 100kVA is 324VDC
A qualified Toshiba Representative who is knowledgeable of batteries and the required precautions should
only perform servicing of the batteries. Keep unauthorized personnel away from batteries.
Refer to the Battery System Manual, when scheduling maintenance or battery replacement.
CAUTION Misuse of this equipment could result in human injury and equipment
damage. In no event will Toshiba Corporation be responsible or liable for
either indirect or consequential damage or injury that may result from the use of this equipment.
CAUTION Do not dispose of the batteries in a fire. The batteries may explode.
CAUTION Do not open or mutilate the batteries. Released electrolyte is harmful to
the eyes and skin and could also be toxic.
WARNING This unit contains sealed lead acid batteries. Lack of preventative
maintenance could result in batteries exploding and emitting gasses
and/or flame. An authorized, trained technician must perform annual preventative maintenance.
WARNING Failure to replace a battery before it becomes exhausted may cause the
case to crack,
p
ossibl
y
releasin
g
electrol
y
tes from inside the batter
y
, and
resulting in secondary faults such as odor, smoke, and fire.

TOSHIBA
7
WARNING Personnel knowledgeable of batteries and the required precautions
should perform installation and servicing of batteries. Keep
Unauthorized personnel away from the batteries.
WARNING Proper maintenance to the battery system of this unit must be done by a
qualified service technician, this is essential to the safety and reliability of
your UPS system. Refer to service manual.
A battery can present a risk of electrical shock and high short
DANGER circuit current. The following precautions should be observed
when working with batteries.
1) Verify that the UPS is off and is disconnected from the power source.
2) Remove watches, rings or other metal objects.
3) Use tools with insulated handles to prevent inadvertent shorts.
4) Wear rubber gloves and boots.
5) Do not lay tools or metal parts on top of batteries.
6) Determine if the battery is inadvertently grounded. If inadvertently grounded, remove
source of ground. Contact with any part of a grounded battery can result in
electrical shock. The likelihood of such shock will be reduced if such grounds are
removed during installation and maintenance.
7) Verify circuit polarities prior to making connections.
8) Disconnect charging source and load prior to connecting or disconnecting terminals.
9) VRLA batteries contain an explosive mixture of hydrogen gas. Do not smoke, or create a flame
or spark in the immediate area of the batteries. This includes static electricity from the body.
10) Do not attempt to open the batteries in order to add water or sample the specific gravity of the
electrolyte. The batteries are valve regulated lead acid type and such servicing is not possible
without damaging the battery.
11) Use proper lifting means when moving batteries and wear all appropriate safety clothing and
equipment.
12) Do not dispose of lead acid batteries except through channels in accordance with local, state
and federal regulations.
INSTRUCTIONS IMPORTANTES CONCERNANT
LA SÉCURITÉ
CONSERVER CES INSTRUCTIONS Cette notice contient des
instructions importantes
concernant la sécurté
ATTENTION Un battery puet présenter un risque de choc électrique, de brûlure
par transfert d’ énergie.
ATTENTION Por le replacement, utiliser le même nombre de batteries du modéle
suivant.
ATTENTION L’élimination des batteries est règlementèe. Consultar les codes
locaux à cet effet.

TOSHIBA
8
1.0 Product Description
1.1 Theory of Operation
An Uninterruptible Power Supply (UPS) is a system that is installed between the commercial
power and the load equipment. The UPS provides steady AC output power during
commercial power fluctuations and interruptions.
During normal operation the UPS utilizes commercial AC power and removes high voltage
spikes and transients caused by switching and faults on the main utility. The result of this
process is maximum power conditioning and regulation.
If the AC power supplied to the UPS drops below a specified voltage level, the unit's batteries
automatically begin supplying power instead of receiving it. This insures that the loads
connected to the UPS continue to receive power with no interruption. This power is provided
for a long enough time so that the load can be shut down in an orderly fashion. This prevents
loss of data and possible damage to both hardware and software.
When AC input power becomes available again, operation returns to normal. The UPS
batteries begin to recharge, so they will be ready for the next power interruption.
1.2 Application and use
Toshiba's 4200 Series of on-line, Uninterruptible power systems (UPS) provide continuous
computer grade AC power in a compact, efficient, high performance unit. The UPS assures
safe, reliable operation of critical office equipment, ranging from personal computers to mini-
computers to local area networks (LAN). All units feature an audible alarm that sounds if the
battery voltage drops below standard during use. This is an additional aid to help in retaining
the valuable office data banks, and all units allow for computer interfacing.
1.3 Power Backup
During an electrical power failure the UPS unit's batteries automatically supply DC power to the
inverter that supports the load equipment, without interruption. For example, when used to
support a computer, the UPS’s back-up assures additional time to complete your activity and
store data after a power failure occurs.
1.4 Power Conditioning
While commercial power is present, the UPS supplies conditioned power to the load while
maintaining its batteries in a charged condition. The UPS protects the connected load against
the normal, everyday problems associated with heavy use of raw commercial power, including
power sags, surges, signal interference, and spikes. This protection keeps power-line problems
from reaching your load, where it can cause equipment to operate erratically, or damage
software and hardware.

TOSHIBA
9
2.0 Uncrating/Inspection/Storage/Disposal
2.1 Uncrating the new UPS equipment:
Upon receipt of the UPS, a careful inspection for shipping damage should be made.
1) Remove the screws that attach the
shipping crate to the pallet; remove the
crate and foam packing material.
2) Unbolt the rails from both the unit and the shipping
pallet. Place the rails on the front of the pallet as
shown in figure 2.2 and figure 2.3. Use the four
1/2x3" bolts used to secure the rails to the shipping
pallet to attach the rails as shown to the front of the
pallet.
3) Place the tie brackets as shown in
figure 2.3 in the slots at the lower
end of the ramps. SLOWLY roll the
unit down the ramp.

TOSHIBA
10
2.2 Inspection of the new UPS equipment
After Uncrating:
1) Check the unit for loose, broken, bent or other damaged parts. If damage has occurred
during shipment, keep all original crating and packing materials for return to the shipping
agent. The equipment warranty will not apply to units that are damaged during shipment.
2) Check to see that the rated capacity and the model number specified on the nameplate
conform to the order specifications.
2.3 Storage of UPS equipment
If the UPS equipment is to be subject to long or short-term storage, the following guidelines
should be used.
Avoid:
1) Storage in sites subject to extreme changes in temperature or high humidity.
2) Storage in sites subject to exposure of high levels of dust or metal particles.
3) Storage on inclined floor surfaces or in sites subject to excessive vibration.
Before storing:
1) Charge the system's batteries.
2) Perform a complete system shutdown as described in section 6.12 of this
manual.
Storing:
1) Store within a temperature range of -20° to 40° C (-4° to 104° F).
2) For best results, store the UPS in the original shipping container and place on a
wood or metal pallet.
3) The optimum storage temperature is 21° C (70° F). Higher ambient temperatures
cause UPS batteries to need recharging more frequently.
4) If stored in an ambient temperature under 20° C (68° F); recharge the batteries
every 9 months.
5) If stored in an ambient temperature of 20° to 30° C (68° to 86° F); recharge the
batteries every 6 months.
6) If stored in an ambient temperature of 30° to 40° C (86° to 104° F); recharge the
batteries every 3 months.
2.4 Disposal
Please contact your state environmental agency for details on proper disposal of electrical
components and packaging in your particular area.
ATTENTION It is illegal to dump lead-acid batteries in landfills or dispose of
improperly. Please help our Earth by contacting the environmental
protection agencies in your area, the battery manufacturer, or call Toshiba
toll-free at [phone] for more information about recycling batteries.

TOSHIBA
11
3.0 Precautions
Based on the 4200 Series UPS unit's external dimensions and the way the outer panels are
removed; minimum amounts of unobstructed space around the unit is necessary for ventilation
and maintenance access. Figure 3.1 shows the minimum clearances required for proper UPS
site installation.
3.1 Installation Precautions
1) Do not install the UPS on an inclined surface,
or areas that are subject to frequent vibrations
or jolting. This could damage UPS circuits.
2) Do not allow liquids or foreign objects to get
inside the UPS.
3) Allow at least 700 mm (28 in) on the front side
and 500 mm (20 in) on the rear and sides of
the UPS unit for air ventilation and
maintenance access.
4) Do not install the UPS in a location that is
subject to high humidity. Also, do not install
the unit in areas that are exposed to direct
sunlight, or contaminated areas subject to
high levels of airborne dust, metal particles, or
flammable gasses.
5) Verify the ventilation and air conditioning
system at the site is capable of removing the
heat generated by the UPS unit (see Section,
5.1 Specifications, "Environment").
Ambient temperature range for operating the UPS
is 0° to 40°C (32° ~ 104°F); 25°C (77°F) is the
recommended operating temperature for
maximum battery life.
6) Avoid installation near sources of electrical
noise. Always make sure that the unit's
ground is intact to prevent electrical shock
and help prevent electrical noise.
7) This UPS generates and radiates radio-
frequency energy during operation. Although
RFI noise filters are installed inside the unit
there is no guarantee that the UPS will not
influence some sensitive devices which are
operating in near proximity. If such
interference occurs, the UPS should either be
installed farther away from the affected
equipment and/or powered from a different
source than the affected equipment.
Figure 3.1

TOSHIBA
12
3.2 Pre-start Precautions
Before connecting the UPS to a power source; move the MCCB switch (ON/OFF), on the side
panel, to the OFF position and move the operation STOP/RUN key switch, on the front panel
(See Section 9 for location), to the STOP position.
3.3 Operating Precautions
1) The UPS should not be powered up until the entire operation manual has been reviewed,
and understood.
2) The input power source voltage must be within +10% to -15% of the rated input voltage.
The input frequency must be within the rated input frequency range. Voltages and
frequencies outside of the permissible range may cause internal protection devices to
activate.
3) The UPS should not be used with a load whose rated input is greater than the rated UPS
output.
4) Do not use the UPS to provide power to motors that require high starting current or a long
starting time such as vacuum cleaners and machine tools.
5) Do not insert metal objects or combustible materials in the unit's ventilation slots.
6) Do not place, hang, or paste any objects on the top or on the exterior surfaces of the UPS.

TOSHIBA
13
4.0 UPS Connections
4.1 Power Connections 75 and 100kVA
The following illustrates the wiring connections to the Input and Output Terminations points for
the 75 and 100kVA UPS Models
4.1.1
H1
H2
H3
Input (N)
L1
L2
L3
GND
(N)

TOSHIBA
14
Recommended Wire Size and Tightening Torque For UPS Input and Output
Terminals
Minimum Wire Size and Tightening Torque of UPS Input and Output Terminals
75 & 100kVA
(USE MINIMUM 90° C INSULATED COPPER WIRING)
75kVA 100kVA
Phase: (A) (B) (C)
Input: (H1) (H2) (H3)
(N)
AWG
(H1)-(H3)
AWG
(N)
Tightening
Torque
(in-lbs.)
(L1)-(L3) (N)
AWG
(H1)-(H3)
AWG
(N)
Tightening
Torque
(in-lbs.)
(L1)-(L3) (N)
208/120 300MCM 400MCM 325 375 350MCM 700MCM 325 375
All wire sizes are per the NEC
75kVA 100kVA
Output: (L1) (L2) (L3)
(N) AWG
(L1)-(L3)
AWG
(N)
Tightening
Torque
(in-lbs.)
(L1)-(L3) (N)
AWG
(L1)-(L3)
AWG
(N)
Tightening
Torque
(in-lbs.)
(L1)-(L3) (N)
208/120 300MCM 400MCM 325 375 350MCM 700MCM 325 375
Neutral Conductors are rated @ 1.73 or 200% of phase conductors, per NEC
75kVA 100kVA
Input/Output (GND) AWG Tightening Torque AWG Tightening
Torque
(G) 2150 in-lbs. 2150 in-lbs.

TOSHIBA
15
4.1.2 Power Connection Cable Routing
The following illustrates the proper cable routing that should be followed during the
power connection process of the 75 and 100kVA.
Note:
1) Input and Output conductors shall be installed in separate conduits, and installed in
accordance with the latest edition of NEC and the authority having jurisdiction.
2) Battery conductors shall be installed in a separate conduit and be of low resistance type.
Top Conduit Entry
Main Input
Main MCCB
Main Input (N)
Output
Ground
Bottom Conduit Entry

TOSHIBA
16
4.2 Control Circuit and External Battery Interface Connections 75 and 100kVA
The following illustrates the wiring connections of the Control Circuits, and Battery Interface
Circuits.
4.2.1 Recommended Wire Size and Tightening Torque UPS Control and Battery
Interface
Minimum Wire Size and Tightening Torque for UPS Control and Battery Interface Circuits
USE MINIMUM 75° C COPPER WIRING
TERMINAL
(TERMINAL #)
75kVA 100kVA
AWG
TIGHTENING
TORQUE AWG
TIGHTENING
TORQUE
UPS CONTROL CIRCUITS
(1-24)*
14-16 8 in-lbs. 14-16 8 in-lbs.
BATTERY CONTROL
CIRCUITS (3-6)*
14-16 8 in-lbs. 14-16 8 in-lbs.
*Indicates Class 1 wiring methods is to be used.

TOSHIBA
17
4.3 Communication Interface
4.3.1 Remote Contact (IBM AS/400)
The AS/400 interface is a standard feature and is available as dry switch contacts
through a DB9 male connector located on the back side of the UPS (see Section 9
for DB9 connector location). The following schematic shows the contact state and
pin assignment for each signal and the associated DB9 connector pin-out.
Notes:
1) Pin "switches" are shown in their inactive states (if battery voltage is low pin 7 will be connected to
System Common).
2) Contacts are resistive loads rated at 30 Vdc, 0.1 amp. (125VAC 3A)
3) Pin number 3 is not used.
5 System Common
6 Bypass Active
Fault Signal Detect
1
2
8 UPS On-line
7 Battery Voltage Low
Battery Discharge
9
4
DB9 Male Connector Outline
(Facing Connector)
1 2 3 4 5
6 7 8 9

TOSHIBA
18
4.3.2 RS-232C
The RS-232C serial communication interface is available through a DB9 female
connector located on the backside of the UPS (see Section 9 for DB9 connector
location). This interface allows control of the UPS from a personal computer running
special Toshiba software. The computer and the UPS are connected through a serial
RS-232C communication port. The available data from the UPS, via the RS-232C
communication link, is shown below:
Operating Conditions
Input Voltage
Output Voltage
Output Current
Battery Voltage
Input Frequency
Output Frequency
UPS Operating Status
(Described as “yes or “no”)
Utility Power OK
Low Battery Voltage Detected
UPS in BYPASS Mode
UPS in NORMAL Mode
Input and Output Frequency Synchronized
UPD FAULT Occurred
Fault Details
(Described as “occurred” or “not occurred”)
DC Bus Over-Current
DC Bus Over-Voltage
DC Bus Under-Voltage
Input Over-Current
Overheat
Overload Being Timed
Overload (allowable time exceeded)
Output Over-Voltage (during Normal Mode)
Output Under-Voltage (during Normal Mode)
The connector pin assignment and female connector outline are illustrated below.
DB9 Female Connector Outline
(facing connector)
Pin I/O Symbol Description
1This pin is not used
2Input RXD Receive Data
3Output TXD Transmit Data
4Output DTR Data Terminal Ready
5 - SG Signal Ground
6Input DSR Data Set Ready
7Output RTS Request To Send
8Input CTS Clear To Send
9This pin is not used
4.3.3 UPS Shutdown (via RS-232C)
When the UPS is operating from its internal batteries, a 'shutdown' order can be sent
to the UPS telling it to turn OFF after a user-specified amount of time. This function
can allow you to stop discharging the UPS batteries after an orderly system
shutdown has been completed. The UPS can be programmed to turn OFF up to 8
minutes after the 'shutdown' command is given. This command can be cancelled
before the specified time has elapsed by following the directions listed on the RS232
screen.
54 321
9876

TOSHIBA
19
5.0 Specifications
5.1 4200 Series Specifications 75 and 100kVA @ Standard 208Vac Output
Model Number U42B3F750C6CB U42B3F10KC6CB
Rated Output Capacity 75kVA 100kVA
External Dimensions 0 0
Rated Voltage 208V/120V
Voltage Variation +10% to –15% ; (-15% to –30%) ****
Rated Frequency 50/60 Hz
Number Phases / Wires 3 Phases ; 4 Wire + GND
* Power Factor Greater than .98 when in inverter mode
Required Input KW 75 100
Walk-in Function From 20% to 100% over 5 seconds
Inrush Current Less than 12 times rated current under synchronous operation
Current Limit 115% maximum
Input
* Harmonic Currents Less than 3% THD
DC Nominal (Voltage Range) 240VDC (210 to 276VDC) 324VDC (284 to 374VDC)
Float Charge (Regulation) 274VDC (±2%) 2.28V/cell 370VDC (±2%) 2.28V/cell
Ripple Voltage 2% R.M.S.
**Rated Back-up Time Refer to Battery System Manual
Battery
Rated Charge Current 20.0 Amps
Rated Voltage 208 / 120 VAC
Rated Current 208.3 Amps 277.8 Amps
Rated Power Factor .8 lagging
Number Phases / Wires 3-phase 4 Wire + GND
Voltage Regulation (phase-phase) ±2% (0-100% balanced load); ±3% (0-100% unbalanced load)
Voltage Adjustment Range ±5V Manually from front key pad
Phase Displacement ±2°(0-100% balanced load); ±4°(unbalanced load)
Rated Frequency 50 / 60 Hz
Frequency Regulation ±0.1% in free running mode
Frequency Synchronous ±.5/1.0/1.5 Hz (±1.0 Hz. std.) switch selectable by qualified technician
Frequency Slew Rate 1 Hz/s to 3Hz/s
Voltage Transients
(Recovery time: 50 msec.)
±5% (100% load step change); ±3% (loss or return of input voltage);
±8% (transfer of bypass to inverter)
Inverter Overload Capacity 125% 30 sec ; 150% 5sec
Bypass Overload Capacity 1000% 10msec; 125% 10 min.
Crest Factor 2.5
Neutral Line Conductor 1.73 times line rating
Harmonic Voltage Distortion 1.5% max (linear load)
Output
Inrush Current protection Automatic transfer to bypass, then retransfer to inverter
Efficiency ac/dc/ac: 90% ; dc/ac: 92%
Heat loss to be removed 22178 Btu/hr (5586kcal/hr) 27296 Btu/hr (6879 kcal/hr)
Audible Noise 75db (A) at 1 meter from the units front display
Operating Temperature 0°-40°C; optimal temperature is 25°C
Operating Humidity Less than 90% RH (no condensation)
Environment
Altitude *** Less than 1000 meters
Items marked with an (*) are specified at rated conditions under balanced linear loads.
(**) Battery backup time may vary depending on the operating conditions and ambient temperature at the installation site, and an initial
charge time of 24 hrs is necessary to obtain proper battery performance level before the unit is placed in operation.
(***) At 6600-ft (2000 m) above sea level, output capacity should be derated by 3%. (Consult Factory for higher elevations)
(****) Prolonged operation at this level requires some deration of output capacity.
