Totally Wicked Tornado-T User manual

USER GUIDE
Filling the Tornado-T Tank:
1. Remove the tank cartridge from the atomizer cone
2. Remove the end cap of the tank cartridge
3. Fill the tank cartridge, ensuring to leave a minimum
of 1mm space at the top and reattach the end cap
4. Push the tank cartridge firmly into the atomizer cone
until you hear a click
5. Screw the atomizer cone onto the battery
6. Before pressing the battery button take two sharp inhales
and one gentle exhale on the mouthpiece of the tank cartridge
7. Place the mouthpiece of the tank cartridge into your mouth,
depress the battery button and inhale gently for three-five seconds,
release the power button and exhale when ready.
8. Refill your tank cartridge when the fluid level reaches approx 5mm
in the viewing window when the device is inverted. Do not operate
with an empty cartridge.
Battery Operation:
To turn the battery on or off click the power button 5 times within 2 seconds.
The Tornado battery has 2 modes of operation, regulated and unregulated power output.
Regulated output produces a constant output of 3.7V from fully charged to discharged.
Unregulated output produces a higher output of 4.2V which diminishes to 3.3V over the
period of discharge.
To toggle between the 2 modes, turn the battery off by clicking the power button 5
times, once off hold the power button for approximately 5 seconds, the power button
will flash white for regulated mode and orange for unregulated mode, press the power
button 5 times to turn the battery back on in the mode selected.
Power
button
USB Port
Regulated mode
Unregulated mode

Charging:
To charge the battery, connect the supplied USB cable to a suitable power source such
as a computer or USB power adapter. The power button will light red until charging is
complete when the light will go out to indicate charging is complete.
Battery charge remaining:
The power button LED will show white if the charge remaining is 60% or more, the LED
will change to pale blue when below 60% charged. The LED will turn to dark blue when
there is 10% or less remaining charge. When fully discharged the LED will flash 20
times and shut down, the battery will require charging before further use.
The Tornado T can be used normally whilst being charged.
100% to 60% charged 60% to 10% charged Less than 10% charged
PRECAUTIONS
• Store the Tornado T e-cigarette and its accessories away from
children whilst not in use.
• Please only use the charging cable provided.
• Please dispose of dead batteries in accordance with your country’s
appropriate legislation.
• Do not charge the battery in a damp environment, in temperatures
under 0°C or above 45°C.
• Do not carry batteries in a pocket or bag with other metallic objects.
WARRANTY
The Tornado T components contained in
each kit have a 28-day parts warranty.
The USB cable supplied has a 12-month
warranty. If any parts are found to be faulty
within this time please contact our customer
service team, and we will arrange for a
replacement. We may require the goods to
be returned for further investigation.
Manufactured in China under the authority
of Pillbox38 UK Ltd, Stancliffe Street,
Blackburn, Lancashire, BB2 2QR.
