SAFETY AND INSTRUCTION MANUAL
PLEASE READ CAREFULLY
*Subject to registering your Extended Guarantee online at www.towerhousewares.co.uk.
T22014
Applicable to all
colour variants

2
GREAT BRITISH DESIGN, INNOVATION
AND EXCELLENCE SINCE 1912
Since the turn of the 20th century, Tower has been designing,
developing and manufacturing housewares and small
appliances used by millions of households throughout the
UK and beyond. During the 1960s, the rise in popularity
of pressure cooking saw Tower become the UK’s largest
producer of pressure cookers, right through into the late
1980s. In recent years the Tower brand has been reborn with
an exciting and varied range of housewares and electrical
appliances that have quickly reinstated the brand’s richly
deserved status as a household name.
Visit
www.towerhousewares.co.uk
for more fantastic products.

3
Contents:
Thank you for purchasing this appliance from the
Tower range.
Please read this manual carefully BEFORE using the
appliance for your own safety.
It has been designed to provide many years of
trouble-free use.
There are many benefits to using a Tower Garment
Steamer:
• 1000W quickly and easily deals with even the
toughest creases
• Generous 200ml water tank minimises the need
for refills
• Continuous steam lasts for over 5 minutes
• Durable ceramic soleplate distributes heat evenly
• Lengthy 2.5m power cord
1. Specifications
Components and
structure
2. Technical Data
3. Important Safety
Information
4. Before First Use
5. Using your Appliance
6. Troubleshooting
7. Recycling
8. Cleaning & Care
9. Wiring Safety
10. Warranty Information
11. Your Receipt
See back page for Customer
Service Information.

4
1. Nozzle panel
2. Brush
3. Power Indicator
4. Switch
5. Handle
6. Tank
7. Water tank release button
1 - Specifications:
Structure of your appliance:
3
1
2
4
5
6
7
This box contains:
Instruction Manual
Garment Steamer
Brush Attachment

5
Description: Garment Steamer
Model: T22014 - Applicable to all colour variants
Input: 220-240V ~50/60Hz
Power Consumption: 1000W
Documentation
We declare that this product conforms to the following product legislation in
accordance with the following directive(s):
2014/30/EU Electromagnetic Compatibility Directive.
2014/35/EU Low Voltage Directive.
2011/65/EU Restriction of Hazardous Substances Directive.
2009/125/EC Eco-Design of Energy Related Products.
RK Wholesale LTD Quality Assurance, United Kingdom.
2 - Technical Data:
Should you encounter problems or require a replacement part, contact the Tower
Customer Support Team: [phone].
Some spare parts may be ordered from the Tower website.
Your warranty becomes void should you decide to use non Tower spare parts.
Spare parts can be purchased from www.towerhousewares.co.uk
Guarantee for spare parts:
The spares and accessories are guaranteed for 1 year from date of purchase.
The main body and housing are guaranteed for the extended free warranty subject
to registration.
If any defect arises due to faulty materials of workmanship, the faulty products must
be returned to the place of purchase within 12 months from the date of purchase.
Refund or replacement is at the discretion of the retailer.

6
Please read these notes carefully BEFORE using your
Tower appliance
3 - Important Safety Information:
• Check that the voltage
of the main circuit
corresponds with the
rating of the appliance
before operating.
• Please ensure that the
appliance is used on a
stable, level, and heat
resistant surface.
• DO NOT immerse cords,
plugs or any part of the
appliance in water or any
other liquid.
• DO NOT leave the
appliance unattended
while it is operating.
• Close supervision is
necessary when any
appliance is used by or
near children or pets.
• This appliance can be
used by children aged
from 8 years and above
and persons with reduced
physical, sensory or
mental capabilities or
lack of experience and
knowledge if they have
been given supervision or
instruction concerning use
of the appliance in a safe
way and understand the
hazards involved.
• Children should not play
with the appliance.
• Cleaning and user
maintenance should not
be made by children
without supervision.
• Switch off at the wall
socket then remove the
plug from the socket
when not in use or before
cleaning.
• If the supply cord or
appliance is damaged,
stop using the appliance
immediately and
seek advice from the
manufacturer or its service
agent or a similarly
qualied person.
• DO NOT let the cord hang
over the edge of a table
or counter or let it come
into contact with any hot
surfaces.
• The use of accessory
attachments is not
recommended by the
appliance manufacturer,
apart from those supplied
with this product. DO
NOT use extension cords
with the appliance.

7
• DO NOT pull the plug out
by the cord as this may
damage the plug and/or
the cable.
• DO NOT use this product
for anything other than its
intended use.
• This appliance is for
household use only.
• DO NOT carry the
appliance by the power
cord.
• DO NOT use the
appliance outdoors.
• The temperature of
accessible surfaces may be
high when the appliance is
operating.
• DO NOT let the cord
touch any hot surfaces,
such as stovetops, etc.
• NOTE: The steam head
gets extremely hot during
operation. NEVER touch
the steam head when the
unit is turned on.
• The manufacturer does
not accept responsibility
for any damage or injury
caused by improper or
incorrect use.
• In the unlikely event the
appliance develops a fault,
stop using it immediately
and seek advice from the
Customer Support Team:
[phone]

8
1. Remove your appliance from the packaging and carefully check the contents
against the parts list.
2. Check that there is no damage to the cord or any visible damage to the body.
3. Dispose of the packaging in a responsible manner.
4. Remove any stickers or labels from the appliance
5. Stand the steamer upright and straighten the cord.
6. Before first use, turn the steamer on for a few minutes. This will help remove
any impurities and odours resulting from the manufacturing process. Once
the steamer has been purified, test it on an old piece of fabric to ensure the
plate and water tank are clean of any residue.
7. To avoid a circuit overload, do not use the steamer with an extension socket.
Filling the tank with water:
CAUTION! Before filling the tank with water make sure the appliance is unplugged.
1. To use the unit, start by filling up the water tank located at the bottom.
2. To fill up the water tank, first press the tank release button on the side of the
unit to detach it from the main body of the steamer.
3. Once the water tank has been detached from the steamer, remove the
pressure cap from the filling hole at the back of the water tank. To do this,
insert a finger or fingernail into the small space at the top of the water
tank cover and pull it firmly away from the main body of the unit. Once the
water tank cover has been removed, fill the tank with fresh water. To ensure
optimum performance, be careful not to fill the tank above the Max fill line.
Note: It is not necessary to undo the screws at the back of the water tank to fill it.
DO NOT loosen any screws or attempt to disassemble the water tank.
4. When the tank has been filled with water, replace the pressure cap and slot
the tank back into the main body of the unit until it clicks into place.
5. The steamer is now ready for normal use.
Note: When the water tank is empty or there is a build-up of limescale inside, the
unit’s operation will become noisier than usual and steam will stop emitting from
the steam nozzle. When this occurs, re-fill the water tank or de-scale the unit as
detailed in the ‘Cleaning and Care’ section of this instruction manual.
To start using the garment steamer:
1. Fill the tank with water, as detailed above.
2. Once the tank has been filled and replaced into the main body of the steamer,
plug the unit into an active mains socket. The red light-up indicator at the top
of the steamer will begin to flash to indicate the unit is powered up and the
heat-up process has begun.
3. When the water inside the unit reaches the correct temperature, the red light-
up indicator will go out. The steamer is now ready for use.
4. When the steamer is ready, press the trigger at the front of the unit to begin
releasing steam. The motor unit will vibrate slightly and steam will start
emitting from the front nozzle.
4 - Before First Use
5 - Using Your Appliance

9
Note: For optimum results, keep a distance of at least 5cm between the steamer
and the garment or fabric.
5. The unit will now operate continuously until the trigger is released or the unit
is unplugged from the mains.
The Brush Attachment:
1. This appliance is complete with a brush attachment, ideal for use with suits
and other similar garments.
2. To attach the brush to the main unit, line up the hole at the bottom of the
attachment with the small tab underneath the steam nozzle and push it in
until it locks into place.
3. Once the underside of the brush is firmly secured into place, push the top part
of the attachment up and back until it slots into place on the main body of the
unit.
4. The brush attachment is now ready for normal use.
Note: Ensure the attachment is firmly secured before attempting to use it.
6 - Troubleshooting
Problem Solution
No operation.
• Ensure the appliance is plugged into the mains and that the
socket switch is in the ON position.
• Ensure the water tank has been filled.
• If using the unit for the first time or after a long period, press
the steam trigger for approximately 1 minute before using the
unit. This helps push the water through the steam pipe.
• Check that the fuse is not damaged. Replace the fuse if
necessary.
The unit is vibrating and making a
loud noise.
• The water tank is running low. Refill the water tank as
detailed in the ‘Filling the Water Tank’ section.
• There may be limescale in the water tank. De-scale the
unit as instructed in the ‘Cleaning and Care’ section of this
instruction manual.
There is a strange smell emitting from
the unit on first use.
• This is normal. The smell derives from oils used during the
manufacturing process, and will fade away after a few uses.
The unit is leaking. • The unit has not heated up sufficiently yet. Allow the unit to
heat up fully before attempting to use.
White flakes are coming out of the
steam holes during operation.
• There is limescale in the water tank. De-scale the unit
as instructed in the ‘Cleaning and Care’ section of this
instruction manual.
The unit is in operation but there is
no steam.
• If the unit has not been used for a while, an airlock may have
formed. Press the steam trigger for approximately 1 minute
before using the unit. This helps push the water through the
steam pipe.
• There may be limescale in the water tank. De-scale the
unit as instructed in the ‘Cleaning and Care’ section of this
instruction manual.
• The unit has not heated up sufficiently yet. Allow the unit to
heat up fully before attempting to use.

10
Limescale:
If you live in a particularly hard water area, we recommend using bottled or distilled
water.
WARNING: Never pour liquid cleaners for eliminating calcium into the water tank.
De-Scaling:
IMPORTANT! Failure to de-scale your steamer may invalidate your guarantee.
If you do not de-scale your steamer regularly, the build-up of limescale may result
in the following:
• The unit taking longer to heat up.
• Damage to the heating element.
To Minimise Scale Build-Up:
• Empty the unit of water after each use.
• Do not allow water to stand in the unit overnight.
• Use filtered water instead of tap water to help reduce limescale build up.
How To De-Scale:
• Any regular de-scaling agent may be used, provided the relevant instructions
are observed. To avoid spillage, DO NOT overfill the unit if the de-scaling agent
causes the water to foam.
• To clean the unit thoroughly of any de-calcification residue; let it go through
several heating-up cycles using clean water with each cycle. Rinse the unit with
clean water afterwards.
• It is advisable to remove limescale deposits from the unit at regular intervals.
8 - Cleaning & Care
DISPOSAL OF THE UNIT
Appliances bearing the symbol shown here may not be disposed of in domestic
rubbish. You are required to dispose of old electrical and electronic appliances like
this separately.
Please visit www.recycle-more.co.uk or www.recyclenow.co.uk for access to
information about the recycling of electrical items.
Please visit www.weeeireland.ie for access to information about the recycling of
electrical items purchased in Ireland.
The WEEE directive, introduced in August 2006, states that all electrical items must
be recycled, rather than taken to landfill.
Please arrange to take this appliance to your local Civic Amenity site
for recycling, once it has reached the end of its life.
7 - Recycling

11
Removing Limescale Build-up:
If using a cleaning solution make sure to follow the instructions.
Natural Cleaning Method for Limescale Removal:
• Fill the unit with equal parts water and vinegar (white wine vinegar, cider
vinegar or lemon juice work particularly well). Allow the unit to heat up (pay
attention that the contents do not boil over) and let it stand for 30-40 minutes.
• When finished empty the unit and rinse it with water.
• The unit should now be free from limescale and ready to be used again.
Clean the appliance regularly. This appliance contains no user serviceable parts and
requires little maintenance. Leave any servicing or repair to qualified personnel.
• To clean, wipe the exterior with a slightly dampened soft cloth or sponge and
dry with a cloth or paper towel.
• Do not use strong cleaners or abrasives that may scratch the surface, and never
spray cleaners directly onto the unit.
Note: Empty the water tank after each use or when the unit will not be used for
prolonged periods of time.
IMPORTANT!
Do not use the appliance if the surface is wet or damp. ALWAYS make sure the
steam outlet holes are dry before storing the appliance.
Store the appliance upright in a cool, dry place, out of the reach of children.
WARNING:
Do not immerse any electrical part of the appliance in water
such as motor units or plugs.
Please see cleaning section for further instructions.

12
9 - Wiring Safety for UK Use Only
IMPORTANT
As the colours in the mains lead of this
appliance may not correspond with the
coloured markings identifying the terminals
in your plug, please proceed as follows:
The wires in the mains lead are labelled in
accordance with the following code:
Blue neutral [N] Brown live [L]
Green/Yellow [EARTH]
Plug Fitting Details (Where Applicable). The
wire labelled blue is the neutral and must be
connected to the terminal marked [N].
The wire labelled brown is the live wire and
must be connected to the terminal marked
[L].
The wire labelled green/yellow must be
connected to the terminal marked with the
letter [E].
On no account must either the brown or
the blue wire be connected to the [EARTH]
terminal.
Always ensure that the cord grip is fastened
correctly.
The plug must be tted with a fuse of the
same rating already tted and conforming to
BS 1362 and be ASTA approved.
If in doubt consult a qualied electrician who
will be pleased to do this for you.
Non-Rewireable Mains Plug
If your appliance is supplied with a non-
rewireable plug tted to the mains lead and
should the fuse need replacing, you must
use an ASTA approved one (conforming to
BS 1362 of the same rating).
If in doubt, consult a qualied electrician
who will be pleased to do this for you.
If you need to remove the plug - disconnect
it from the mains - then cut it off of the mains
lead and immediately dispose of it in a safe
manner. Never attempt to reuse the plug
or insert it into a socket outlet as there is a
danger of an electric shock.
FUSE
Earth
(Green/Yellow)
Fuse
Neutral
(Blue)
Live
(Brown)
WARNING:
This appliance MUST be earthed!

13
This product is guaranteed for 12 months
from the date of original purchase.
If any defect arises due to faulty materials
of workmanship, the faulty products must
be returned to the place of purchase.
Refund or replacement is at the discretion
of the retailer.
The Following Conditions Apply:
• The product must be returned to the
retailer with proof of purchase or a
receipt.
• The product must be installed and
used in accordance with the
instructions contained in this
instruction guide.
• It must be used only for domestic
purposes.
• It does not cover wear and tear,
cosmetic damage, misuse or
consumable parts.
• Tower has limited liability for incidental
or consequential loss or damage.
This guarantee is valid in the UK and Eire
only.
The standard one year guarantee is only
extended to the maximum available for
each particular product upon registration
of the product within 28 days of purchase.
If you do not register the product with us
within the 28 day period, your product is
guaranteed for 1 year only.
To validate your extended warranty, please
visit www.towerhousewares.co.uk and
register with us online.
Please note that length of extended
warranty offered is dependent on product
type and that each qualifying product
needs to be registered individually in order
to extend its warranty past the standard
1 year.
Extended warranty is only valid with proof
of purchase or receipt.
As a thank you for purchasing
one of our fantastic products,
we are offering you an extra
2 years peace of mind in
addition to your 1 year
guarantee.
To receive your extra 2 year
guarantee, register your
appliance online within 28
days of purchase by visiting
www.towerhousewares.co.uk
10 - Warranty

14
Affix your store receipt to this page for safe keeping.
11 - Your Receipt

15
Notes

thank you!
We hope you enjoy your appliance for many years. As a thank you for
purchasing one of our fantastic products, we are offering you an extra
2 years peace of mind.
*To receive your extra 2 years guarantee, register your appliance online
within 28 days of purchase by visiting:
www.towerhousewares.co.uk
Should you have a problem with your appliance, or need any spare parts,
please call our Customer Support Team:
[phone]
0720.V4
Your warranty becomes void should you
decide to use non Tower spare parts.
Spare parts can be purchased from
www.towerhousewares.co.uk
