Toyota CQ-SS0070F User manual

General
Power supply 12V DC (11V-16V)
Test Voltage 14.4V,
Negative ground
Maximum Power Output 30W × 4 channels
(at 400Hz, Volume Control Max.)
Power Output 15W / channel
(4, 40 to 30,000 Hz, 3% THD)
Tone Action Bass ; ±12 dB at 100Hz
Treble ; ±12 dB at 10kHz
Current Consumption Less than 2.5 A
(tape mode, 0.5W 4-speaker)
Speaker Impedance 4(4 - 8acceptable)
AM Radio
Frequency Range 531 - 1,602 kHz
FM Stereo Radio
Frequency Range 87.5 - 108.0 MHz
Useable Sensitivity 12 dBf (1.1µV/75S/N 30 dB)
50 dB Quieting Sensitivity 17 dBf (1.8µV/75)
Frequency Response 30 - 15,000Hz (±3 dB)
Alternate Channel Selectivity 75 dB
Stereo Separation 35 dB (1kHz)
CQ-SS0070F
High-power Auto Reverse Cassette/
Receiver
PART No. : 08600-00956
VEHICLE : Universal
DESTINATION : Europe
PRODUCED AFTER : Dec., 2000
Signal/Noise Ratio 70 dB (Mono)
Tape Player
Reproduction System 4 - track, 2-program stereo
Tape Speed 1-7/8" /sec (4.76cm/sec)
FF/REW Time Less than 200 sec (C-60)
Frequency Response 35 - 14,000Hz (±3 dB)
Wow and Flutter 0.12 % (WRMS)
Signal/Noise Ratio 52 dB
Dimensions** (W × H × D) 178 × 50 × 150 (mm)
Weight** 1.6 kg
*Specifications and the design are subject to possible modification
without notice due to improvements.
**Dimensions and weight shown are approximate.
Above specifications comply with EIA standards.
Specifications*
www.electronicsrepair.net

1 FEATURES 2
2 REPLACING THE FUSE 2
3 MAINTENANCE 2
4 RADIO ALIGNMENT 2
5 WIRING CONNECTION 3
6 BLOCK DIAGRAM 4
7 TERMINALS DESCRIPTION 5
1 FEATURES
• • •
• PLL (Phase Locked Loop) Synthesized Tuning
• • •
• 1DIN Size Body with Cassette Player, AM/FM Tuner, Power
AMP (30W × 4)
• • •
• 18-FM , 6-AM stations preset
• • •
• Auto preset and scan function
2 REPLACING THE FUSE
Be sure to use a fuse of the specified rating (10A) when
replacing a blown fuse. Fuses with higher capacity ratings, use
of any substitute, or connection without a fuse may result in a
fire hazard or damage to the unit.
3 MAINTENANCE
Your product is designed and manufactured to ensure a
minimum of maintenance. Use a soft cloth for routine exterior
cleaning. Never use benzine, thinner or other solvent.
4 RADIO ALIGNMENT
Do not align the AM/FM package blocks. When the package
block is necessary, it will be supplied already aligned at the
factory.
8 PACKAGE AND IC BLOCK DIAGRAM 6
9 REPLACEMENT PARTS LIST 7
10 EXPLODED VIEW (Unit) 10
11 TAPE PLAYER PARTS LIST 11
12 EXPLODED VIEW (Tape Deck) 12
13 WIRING DIAGRAM 13
14 SCHEMATIC DIAGRAM 15
CONTENTS
Page Page
2
CQ-SS0070F

5 WIRING CONNECTION
3
CQ-SS0070F

6 BLOCK DIAGRAM
4
CQ-SS0070F

IC601 : LC72322N9A06
Pin
No. Name Description I/O Volt (V)
FM AM TAPE
1XIN 4.5MHz X´tal Oscillator I 2.3 2.3 2.3
2 TEST2 (Connect to Ground) - 0 0 0
3 A/B Tape Direction H:A
Side I 0 0 4
4 F/R Tape FF/REW Signal I 0.4 0.5 5
5 NC Ground - 0 0 0
6 ST Streo Indicator Signal
Input I 0 7.6 0
7 RADIO Radio On Signal O 0 0.9 8.2
8 FM Radio Band Select O 0 8.1 8.2
9 NC - - - - -
10 MONO FM MONO Switch O 0 0 0
11 PWR-CNT Power ON/OFF Output
L:OFF H:ON O 0 5 5.1
12 SDA Electronic Volume
Data Output O 4.9 5.1 5.1
13 SCK Electronic Volume
Clock O 4.9 5.1 5.1
14 SSC Tuner Search Output I 0 0 0
15 NC - - - - -
16 TAPE Tape Mode Detect I 0 0 5.6
17 NC - - - - -
18 NC - - - - -
19 MUTE Mute Output O 5 5.1 5.1
20 SYS-CNT System ON/OFF
Output L:OFF H:ON O 0 5.1 5.1
21 KS9 (NC) - - - - -
22 KS8 (NC) - - - - -
23 KS7 (NC) - - - - -
24 KS6 (NC) - - - - -
25 KS5 Key Scan Output O 0 0 0
26 KS4 Key Scan Output O 0 0 0
27 KS3 Key Scan Output O 0 0 0
28 KS2 Key Scan Output O 0 0 0
29 KS1 Key Scan Output O 0 0 0
30 KS0 Key Scan Output O 0 0 0
31 VDD Connect to 5V - 5.1 5.1 5.1
32 KI3 Key Scan Input I 0 0 0
33 KI2 Key Scan Input I 0 0 0
34 KI1 Key Scan Input I 0 0 0
35 KI0 Key Scan Input I 0 0 0
36 S28 (NC) - - - - -
37 S27 (NC) - - - - -
38 S26 (NC) - - - - -
39 S25 LCD Segment Output O 2.5 2.5 2.5
40 S24 LCD Segment Output O 0 2.5 2.5
41-63 S23-S1 LCD Segment Output O 2.5 2.5 2.5
64 COM2 LCD Common2 O 2.5 2.5 2.5
65 COM1 LCD Common1 O 2.5 2.5 2.5
66 TELIN (Connect to 5V) - 5 5.1 5.1
67 HOLD ACC Detect I 4.4 4.4 4.4
68 RES (Connect to 5V) - 5 5.1 5.1
69 ADI FM/AM VSM I 0 0 0
70 AM/FM IF FM/AM IF Counter
Input I 0 2.4 0
71 NC Ground - 0 0 0
72 SNS +5V Detect I 5 5 5
73 VDD Connect to 5V - 5 5 5.1
74 AM/FM OSC FM/AM Local OSC
Input I 0 2.5 0
75 NC (Connect to Ground) - 0 0 0
76 GND Ground - 0 0 0
77 EO1 PLL Phase Detector
Output O 3.7 1.3 1.3
Pin
No. Name Description I/O Volt (V)
FM AM TAPE
78 EO2 (NC) - - - - -
79 TEST1 (Connect to Ground) - 0 0 0
80 XOUT 4.5MHz X´tal Oscillator O 2.4 2.4 2.4
7 TERMINALS DESCRIPTION
5
CQ-SS0070F

IC200 : YEAMLA3161
IC270 : YEAMHA13158A
8 PACKAGE AND IC BLOCK DIAGRAM
8.1. Main Block
P50 : C5BA00000040
6
CQ-SS0070F

9 REPLACEMENT PARTS
LIST
Notes :
1.Be sure to make your orders of replacement parts
according to this list.
2.Important safety notice: Components, identified by mark
have special characteristics important for safety. When
replacing any of these components, use only
manufacturer´s specified parts.
3.Location keys in the remarks column indicates the general
location of the parts shown in the exploded drawing, as in a
road map.
4.The marking (RTL) indicates that Retention Time is limited
for this item. After the discontinuation of assembly in
production, the item will continue to be available for a
specific period of time. The retention period of availability is
dependent on the type of assembly, and in accordance with
the laws governing part and product retention. After the end
of this period, the assembly will no longer be available.
5.“ T” marks in remarks column are indicated supply parts of
TAMACO.
9.1. IC´s and Transistors
MAIN BLOCK [E-4C162]
Ref.
No. Part No. Part Name & Description Remark s
IC200 YEAMLA3161 IC
IC205 YEAMTDA7313D IC
IC270 YEAMHA13158A IC T
IC601 LC72322N9A06 IC T
P50 C5BA00000040 AM/FM Tuner Pack T
Q503 YEANC114YST Transistor
Q605 YEAN2SK583 Transistor
Q610 YEANC114YST Transistor
Q630 YEANA114YST Transistor
Q703 YEANC114YST Transistor
Q704 YEAND1762EF Transistor
Q706 YENA123YST Transistor T
Q707 YEANB123YST Transistor
Q708 YEAN2SD2007 Transistor
Q710 YEANB1237QRT Transistor
Q711 YEANC114YST Transistor
Q715 YEAN2SD1020T Transistor
Q800 YEANDTA144ST Transistor
Q801 YEANC114YST Transistor
9.2. Diodes
MAIN BLOCK [E-4C162]
Ref.
No. Part No. Part Name & Description Remark s
D51 YEADMTZJ56CT Diode T
D52 YEADMTZJ56CT Diode T
D53 YEADMTZJ56CT Diode T
D54 YEADMTZJ56CT Diode T
D55 YEADMTZJ56CT Diode T
D56 YEADMTZJ56CT Diode T
D57 YEAD1S2473T Diode T
D400 YEADMTZ10CT Diode T
D603 YEAD1N4148C Diode T
D605 YEAD1N4148C Diode T
D607 YEAD1N4148C Diode T
D627 YEAD1N4148C Diode T
D703 YEAD1N4005T Diode T
D704 YEADMTZ91BT Diode T
D707 YEAD1N4005T Diode T
Ref.
No. Part No. Part Name & Description Remark s
D710 YEAD1N4148C Diode T
D901 YEAD1N5404FT Diode T
D650 YEADMTZ82BT Zener Diode T
D709 YEADMTZJ56CT Zener Diode T
D719 YEADRD51JS3T Zener Diode
D800 YEADMTZ82BT Zener Diode T
SWITCH BLOCK [E-4C170]
Ref.
No. Part No. Part Name & Description Remark s
D604 SLN210VCT12 LED (Red) T
9.3. Capacitors
MAIN BLOCK [E-4C162]
Ref.
No. Part No. Part Name & Description Remark s
C50 ECFL1C104KDY 0.1µF T
C54 YEE05Y103N 0.01µF
C57 ECFLD333KDY 0.033µF T
C58 ECFLD333KDY 0.033µF T
C60 YEE05Y103N 0.01µF
C201 YEE05X122M 1200pF
C202 ECEA0JKS101 Electrolytic,100µF 6.3WV
C203 ECEA1HKS010 Electrolytic,1µF 50WV
C204 ECFLD273KDY 0.027µF T
C233 ECEA1HKS3R3 Electrolytic,3.3µF 50WV
C234 ECEA1HKS0R1 Electrolytic,0.1µF 50WV
C237 ECEA1HKS0R1 Electrolytic,0.1µF 50WV
C238 YEE05X272M 2700pF
C239 ECEA1HKS3R3 Electrolytic,3.3µF 50WV
C240 ECEA1HKS3R3 Electrolytic,3.3µF 50WV
C249 YEE05X222M 2200pF
C250 YEE05X222M 2200pF
C253 ECEA1CKS100I Electrolytic,10µF 16WV
C259 ECFLD333KDY 0.033µF T
C279 ECEA1HKS010 Electrolytic,1µF 50WV
C301 YEE05X122M 1200pF
C302 ECEA1HKS010 Electrolytic,1µF 50WV
C303 ECEA0JKS101 Electrolytic,100µF 6.3WV
C304 ECFLD273KDY 0.027pF
C307 ECEA1AKS221I Electrolytic,220µF 10WV
C333 ECEA1HKS3R3 Electrolytic,3.3µF 50WV
C334 ECEA1HKS0R1 Electrolytic,0.1µF 50WV
C337 ECEA1HKS0R1 Electrolytic,0.1µF 50WV
C338 YEE05X272M 2700pF
C339 ECEA1HKS3R3 Electrolytic,3.3µF 50WV
C340 ECEA1HKS3R3 Electrolytic,3.3µF 50WV
C349 YEE05X222M 2200pF
C350 YEE05X222M 2200pF
C353 ECEA1CKS100I Electrolytic,10µF 16WV
C361 ECEA1EKS4R7I Electrolytic,4.7µF 25WV
C401 ECEA1VSN4R7I Electrolytic,4.7µF 35WV T
C402 ECEA1AKS101I Electrolytic,100µF 10WV
C408 YEU05B102K 1000pF
C554 YEE05Y103N 0.01µF
C555 ECEA1CKS470I Electrolytic,47µF 16WV
C600 ECEA0JKS331I Electrolytic,330µF 6.3WV
C606 YEU05SL220J 22pF
C607 YEU05SL220J 22pF
C624 ECEA1HKS010 Electrolytic,1µF 50WV
C625 YEU05B101K 100pF
C626 YEU05SL680J 68pF
C631 ECEA1CKS100I Electrolytic,10µF 16WV
C707 ECEA1AKS221I Electrolytic,220µF 10WV
C708 ECEA1AKS221I Electrolytic,220µF 10WV
C709 ECEA1CKS101I Electrolytic,100µF 16WV
C714 ECEA1CKS100I Electrolytic,10µF 16WV
C715 ECEA0JKS101 Electrolytic,100µF 6.3WV
C717 ECEA1CKS100I Electrolytic,10µF 16WV
C718 ECEA1HKS010 Electrolytic,1µF 50WV
C720 ECEA1CU332C Electrolytic,3.3kµF 16WV T
C722 YEE05Y103N 0.01µF
C723 ECEA0JKS101 Electrolytic,100µF 6.3WV
7
CQ-SS0070F

Ref.
No. Part No. Part Name & Description Remark s
C725 YEE05Y103N 0.01µF
C733 YEE05X222M 2200pF
C804 ECEA1AU102BQ Electrolytic,1000µF 10WV T
9.4. Resistors
MAIN BLOCK [E-4C162]
Ref.
No. Part No. Part Name & Description Remark s
R50 ERDS2TJ5R6 Carbon,5.6Ω
ΩΩ
Ω1/4W
R51 ERDS2TJ473 Carbon,47kΩ
ΩΩ
Ω1/4W
R52 ERDS2TJ223 Carbon,22kΩ
ΩΩ
Ω1/4W
R53 ERDS2TJ221 Carbon,220Ω
ΩΩ
Ω1/4W
R54 ERD25TJ102 Carbon,1kΩ
ΩΩ
Ω1/4W
R55 ERDS2TJ104 Carbon,100kΩ
ΩΩ
Ω1/4W
R56 ERD25TJ102 Carbon,1kΩ
ΩΩ
Ω1/4W
R70 ERDS2TJ103 Carbon,10kΩ
ΩΩ
Ω1/4W
R201 ERDS2TJ333 Carbon,33kΩ
ΩΩ
Ω1/4W
R202 ERDS2TJ220 Carbon,22Ω
ΩΩ
Ω1/4W
R203 ERDS2TJ472 Carbon,4.7kΩ
ΩΩ
Ω1/4W
R204 ERDS2TJ124 Carbon,120kΩ
ΩΩ
Ω1/4W
R205 ERDS2TJ472 Carbon,4.7kΩ
ΩΩ
Ω1/4W
R256 ERDS2TJ102 Carbon,1kΩ
ΩΩ
Ω1/4W
R271 ERD25TJ101 Carbon,100Ω
ΩΩ
Ω1/4W
R272 ERD25TJ101 Carbon,100Ω
ΩΩ
Ω1/4W
R281 ERDS2TJ562 Carbon,5.6kΩ
ΩΩ
Ω1/4W
R282 ERDS2TJ562 Carbon,5.6kΩ
ΩΩ
Ω1/4W
R301 ERDS2TJ333 Carbon,33kΩ
ΩΩ
Ω1/4W
R302 ERDS2TJ220 Carbon,22Ω
ΩΩ
Ω1/4W
R303 ERDS2TJ472 Carbon,4.7kΩ
ΩΩ
Ω1/4W
R304 ERDS2TJ124 Carbon,120kΩ
ΩΩ
Ω1/4W
R305 ERDS2TJ472 Carbon,4.7kΩ
ΩΩ
Ω1/4W
R309 ERDS2TJ221 Carbon,220Ω
ΩΩ
Ω1/4W
R338 ERD25TJ102 Carbon,1kΩ
ΩΩ
Ω1/4W
R339 ERD25TJ102 Carbon,1kΩ
ΩΩ
Ω1/4W
R356 ERDS2TJ102 Carbon,1kΩ
ΩΩ
Ω1/4W
R371 ERD25TJ101 Carbon,100Ω
ΩΩ
Ω1/4W
R372 ERD25TJ101 Carbon,100Ω
ΩΩ
Ω1/4W
R381 ERDS2TJ562 Carbon,5.6kΩ
ΩΩ
Ω1/4W
R382 ERDS2TJ562 Carbon,5.6kΩ
ΩΩ
Ω1/4W
R401 ERDS2TJ472 Carbon,4.7kΩ
ΩΩ
Ω1/4W
R404 ERDS2TJ152 Carbon,1.5kΩ
ΩΩ
Ω1/4W
R405 ERDS2TJ152 Carbon,1.5kΩ
ΩΩ
Ω1/4W
R406 ERDS2TJ152 Carbon,1.5kΩ
ΩΩ
Ω1/4W
R407 ERDS2TJ471 Carbon,470Ω
ΩΩ
Ω1/4W
R408 ERD25TJ181 Carbon,180Ω
ΩΩ
Ω1/4W
R505 ERDS2TJ473 Carbon,47kΩ
ΩΩ
Ω1/4W
R542 ERDS2TJ102 Carbon,1kΩ
ΩΩ
Ω1/4W
R545 ERDS2TJ333 Carbon,33kΩ
ΩΩ
Ω1/4W
R547 ERDS2TJ103 Carbon,10kΩ
ΩΩ
Ω1/4W
R600 ERDS2TJ222 Carbon,2.2kΩ
ΩΩ
Ω1/4W
R621 ERDS2TJ103 Carbon,10kΩ
ΩΩ
Ω1/4W
R623 ERDS2TJ473 Carbon,47kΩ
ΩΩ
Ω1/4W
R628 ERDS2TJ103 Carbon,10kΩ
ΩΩ
Ω1/4W
R629 ERDS2TJ104 Carbon,100kΩ
ΩΩ
Ω1/4W
R636 ERD25TJ473 Carbon,47kΩ
ΩΩ
Ω1/4W
R637 ERD25TJ473 Carbon,47kΩ
ΩΩ
Ω1/4W
R642 ERDS2TJ822 Carbon,8.2kΩ
ΩΩ
Ω1/4W
R643 ERDS2TJ223 Carbon,22kΩ
ΩΩ
Ω1/4W
R698 ERDS2TJ103 Carbon,10kΩ
ΩΩ
Ω1/4W
R699 ERDS2TJ822 Carbon,8.2kΩ
ΩΩ
Ω1/4W
R705 ERD25FJ1R0 Carbon,1Ω
ΩΩ
Ω1/4W
R719 ERDS2TJ103 Carbon,10kΩ
ΩΩ
Ω1/4W
R720 ERD25FJ1R0 Carbon,1Ω
ΩΩ
Ω1/4W
R721 ERD25FJ1R0 Carbon,1Ω
ΩΩ
Ω1/4W
R722 ERDS2TJ471 Carbon,470Ω
ΩΩ
Ω1/4W
R727 ERDS2TJ473 Carbon,47kΩ
ΩΩ
Ω1/4W
R728 ERD25TJ681 Carbon,680Ω
ΩΩ
Ω1/4W
R729 ERD25TJ681 Carbon,680Ω
ΩΩ
Ω1/4W
R730 ERDS2TJ223 Carbon,22kΩ
ΩΩ
Ω1/4W
R731 ERDS2TJ103 Carbon,10kΩ
ΩΩ
Ω1/4W
R737 ERDS2TJ472 Carbon,4.7kΩ
ΩΩ
Ω1/4W
R738 ERD25TJ330 Carbon,33Ω
ΩΩ
Ω1/4W
Ref.
No. Part No. Part Name & Description Remark s
R739 ERD25TJ562 Carbon,5.6kΩ
ΩΩ
Ω1/4W
R740 ERDS2TJ472 Carbon,4.7kΩ
ΩΩ
Ω1/4W
9.5. Connectors
MAIN BLOCK [E-4C162]
Ref.
No. Part No. Part Name & Description Remark s
CN601 YEAETKCF12PS Connector
CN701 YEAE4CC0N005 Connector T
CN250 YEAE2011P05 Connector
CN702 YEAE2011P06 Connector
SWITCH BLOCK [E-4C170]
Ref.
No. Part No. Part Name & Description Remark s
CN901 YEAETKCF12XS Connector, 12P
9.6. Electric Parts
SWITCHES
Ref.
No. Part No. Part Name & Description Remark s
SW600 YEAS094C020 Switch T
SW601 YEAS094C020 Switch T
SW602 YEAS094C020 Switch T
SW603 EVQPJJ04T Switch
SW604 EVQPJH05K Switch
SW606 EVQPJJ04T Switch
SW607 EVQPJH05K Switch
SW608 YEAS094C020 Switch T
SW609 YEAS094C020 Switch T
SW610 YEAS094C020 Switch T
SW611 YEAS094C020 Switch T
SW612 YEAS094C020 Switch T
SW613 YEAS094C020 Switch T
SW614 YEAS094C020 Switch T
CRYSTAL
Ref.
No. Part No. Part Name & Description Remark s
XL600 YEXL4C45TT Crystal T
COILS
Ref.
No. Part No. Part Name & Description Remark s
J23 YELT02C101KT Coil
L101 YELT02C4R7KT Coil
L700 YETQ024C035 Choke Coil T
BPF1 YEXC07T009 Band Pass Filter
LCD
Ref.
No. Part No. Part Name & Description Remark s
LCD1 YEXDCM4C070 LCD T
POSISTOR
Ref.
No. Part No. Part Name & Description Remark s
PT701 YERT7AR4R7MT Posistor
MAIN BLOCK [E-4C162]
Ref.
No. Part No. Part Name & Description Remark s
PL703 YEAL01222 Lamp
SWITCH BLOCK [E-4C170]
Ref.
No. Part No. Part Name & Description Remark s
PL702 YEAL01222 Lamp
PL703 YEAL01222 Lamp
8
CQ-SS0070F

9.7. Accessories
PRINTING
Ref.
No. Part No. Part Name & Description Remark s
YFM284C313ZA Operating Instructions T
YFM284C314ZA Operating Instructions T
YFM284C315ZA Operating Instructions T
YFM284C316ZA Operating Instructions T
YFM284C317ZA Operating Instructions T
YFM284C318ZA Operating Instructions T
YFM284C319ZA Operating Instructions T
YFM284C320ZA Operating Instructions T
YFM284C321ZA Operating Instructions T
YFM284C322ZA Operating Instructions T
YFM284C323ZA Operating Instructions T
YFM284C324ZA Operating Instructions T
INSTALLATION PARTS
Ref.
No. Part No. Part Name & Description Remark s
YFJ024C059CA Power Cord Ass´y T
ZZBISR115 Screw Kit and Dismounting Pin T
YEFX0214198 Mounting Collar
YEFG044C002 Rear Support Strap T
9.8. Mechanical Parts
MESCELLANEOUS
Ref.
No. Part No. Part Name & Description Remark s
F1 XBB1F100NS5 Fuse, 10A
ANT1 YAA104C700ZA Antenna Jack T
Z51 YEADSPD201M Surge Protector T
AT1 YEAT03420 Terminal
AT2 YEAT03420 Terminal
AT3 YEAT03420 Terminal
1YFA074C035ZA Front Plate T
2YFF014C032XA Heat Sink T
3YFA094C081ZA Right Plate Ass´y T
4YFA084C021ZA Rear Plate T
5YFA045C026YF Under Cover T
6YFA034C031ZC Upper Cover T
8FX0214C172XA IC Bracket T
9FX0014C048ZA Panel Light (LCD) T
10 FX0214C214ZA LCD Bracket T
11 YFX184C014ZA LCD Holder T
12 YFV024C040ZA Sheet T
14 YEFR04134 Lamp Dorm
15 YEFK044C007 Lamp Gum T
16 YFX464C010ZA Eject Lever T
17 FX0214C188YA Deck Bracket T
18 YFE134C236ZA Button (EJECT) T
19 YFE134C238ZA Button (REW) T
20 YFE134C237ZA Button (FF) T
21 YFC054C039YA Trim Plate T
22 YFC024C517ZA Escutcheon Ass´y T
23 YFE134C239ZA Button (1-6) T
24 YFE134C249ZA Button (UP) T
25 YFE134C250ZA Button (DOWN) T
26 YFE134C252ZA Button (SEL) T
27 YFE134C242ZA Button (PWR) T
28 YFE134C248ZA Button (CLOCK/BAND) T
29 FX0014C049ZA Panel Light (PRESET) T
30 YFK044C012ZA Lamp Holder T
31 YFS014C028ZA Pad T
51 XTB3+6FFXS Screw
52 YEJT034C019 Screw(Cup Tight),3mm*12mm T
53 YEJT034C001 Screw T
54 XTN2+6C Screw
55 XSB26+4FX Screw
56 YEJT034C007 Screw T
9
CQ-SS0070F

10 EXPLODED VIEW (Unit)
10
CQ-SS0070F

Notes :
1.Be sure to make your orders of replacement parts
according to this list.
2.Important safety notice: Components, identified by mark
have special characteristics important for safety. When
replacing any of these components, use only
manufacturer´s specified parts.
3.Location keys in the remarks column indicates the general
location of the parts shown in the exploded drawing, as in a
road map.
4.“ T” marks in remarks column are indicated supply parts of
TAMACO.
Ref.
No. Part No. Part Name & Description Remarks
1X0036-1001 Main Chassis Ass´y T(2-B)
2X0036-6082 Head Plate Ass´y T(3-B)
3X0036-1009 Reel Base Ass´y T(1-A)
4X0036-1010 FR Changing Arm Ass´y T(3-B)
6X0036-1019 Eject Cam Lock Ass´y T(3-A)
7X0036-6077 Lever Bracket Ass´y T(3-C)
10 X0036-1025 FR Arm (B) Ass´y T(1-B)
11 X0138-2006 CM Bracket Ass´y T(3-B)
12 10036-60011 Flywheel Ass´y (F) T(1-C)
13 10138-6002 Pinch Arm (R) Ass´y T(2-B)
14 10138-6003 Pinch Arm (F) Ass´y T(2-C)
15 X0036-6080 Reel Spindle Ass´y T(1-A)(1-B)
16 10036-60010 Flywheel Ass´y (R) T(1-C)
19 10138-1010 Cassette Holder T(3-A)
20 10036-1006 Eject Cam T(2-A)
21 10036-1046 Eject Lever (S) T(2-A)
22 10138-1002 Cassette Hanger T(3-A)
23 10036-1015 SPG Support Plate T(4-B)
24 10036-1016 Conversion Lever T(1-B)
25 10138-1006 Adjuster Shim T(3-B)
26 10036-1018 Center Plate T(4-A)
27 10036-1013 Lock Arm T(3-C)
28 10036-1023 Change Lever (B) T(3-C)
29 10036-1026 FR Arm (B) T(1-B)
30 10036-1004 FF Lever (AT) T(4-C)
31 10036-1005 Rew Lever (AT) T(3-C)
35 10036-2001 Idle Gear T(2-A)
37 10036-20040 Reduction Gear (A) T(2-A)
38 10036-2003 Reduction Gear (B) T(2-A)
39 10036-20050 Pulley Gear T(2-B)
40 10038-2018 Tape Guide T(3-B)
41 10036-2007 Ratchet T(2-A)
42 10036-2008 FF Arm T(1-B)
43 10036-2009 Sensor Arm T(2-A)
44 10036-2010 Selector Gear T(2-A)
45 10138-20053 Adjuster Arm T(4-B)
46 10138-2004 Adjuster Link T(3-B)
47 10038-2014 Gear Lock Arm T(2-A)
48 10036-2014 Detector Gear T(1-A)
49 X0036-2015 TU Gear Arm Ass´y T(3-C)
50 X0136-2001 Detector Cam Ass´y T(1-A)(1-B)
51 10038-2034 Mute Arm (N) T(3-A)
52 10058-2004 Tape Hooker T(3-A)
53 10058-20215 Idle Pulley (A) T(2-B)
57 10036-3024 HP Roller (B) T(3-B)
58 10036-3032 FF Roller (A) T(4-B)
59 10036-3018 Collar (Selector Gear) T(2-A)
60 10036-3002 HP Roller (A) T(3-B)
62 10038-3012 Program Roller T(3-C)
Ref.
No. Part No. Part Name & Description Remarks
63 10038-3015 Mute Arm Collar T(3-A)
64 10036-4001 FF/Rew Lever SPG T(3-C)(4-C)
65 10036-4022 Lock Lever SPG (A) T(3-C)
66 10036-4003 Gear Lock Arm SPG T(2-A)
67 10036-4004 Eject Lever SPG T(2-A)
68 10036-4005 Eject Cam SPG T(2-A)
69 10036-4006 Head Plate SPG T(3-B)
70 10036-4007 Eject Cam Lock SPG T(4-A)
71 10036-4008 Program Arm SPG T(3-C)
72 10036-4010 Adjuster Arm SPG (A) T(4-B)
73 10036-4011 Adjuster Arm SPG (B) T(4-B)
74 10036-4012 Pinch Arm SPG (F) T(2-C)
75 10036-4013 Pinch Arm SPG (R) T(2-B)
76 10038-4014 Ratchet SPG T(2-A)
77 10036-4015 Dash SPG T(1-A)
78 10058-4036 Tambler SPG (B) T(4-A)
79 10036-4017 Changing Arm SPG T(3-C)
80 10036-4018 Earth SPG (R) T(2-B)
82 10036-4032 Back Tension SPG (MH) T(1-A)(1-B)
85 10036-5018 Sub Belt (C) T(2-B)
86 10038-5001 Selector Link T(3-C)
87 10036-5004 Main Belt T(1-C)
89 10036-5006 Return Link T(4-A)
92 X0036-6075 Motor Ass´y T(4-B)
94 10036-7001 SW PWB T(2-C)
95 10036-7002 Wire (A) Black 60mm T(2-C)
96 10036-7003 Wire (B) Red 60mm T(2-C)
97 10036-7004 Wire (C) Yellow 55mm T(2-C)
98 10036-7005 Head T(4-B)
99 10036-7034 Power SW T(2-B)
100 10036-7007 Slide SW T(2-C)
101 10138-7002 Mute PWB T(2-C)
102 10138-7087 Mute SW T(2-B)
105 21711-504016 E-Ring 1.5mm T
106 21711-603296 E-Ring 1.6 × 3.2mm T(3-B)
107 21712-005016 E-Ring 2mm T
108 21712-506016 E-Ring 2.5mm T
109 21331-7030C2 Machine Screw S-Type Plain
#3 M 1.7 × 3 T
111 21812-0030D2 PSW-S 1.2 × 3.0 × t0.25 T
112 10036-5019 Reel PSW T(1-A)(1-B)
113 21821-0032D1 PSW T(3-B)
114 21331-7040C2 +Machine Screw S-Type Plain
#3 M1.7 × 4 T(3-C)
116 21331-7060C2 +Machine Screw S-Type Plain
#3 M1.7 × 6 T(2-B)
117 21382-0030C2 +Machine Screw B-Type Plain
#3 M2 × 3 T
118 21362-0040F2 +Machine Screw B-Type Flat
#1 M2 × 4 T(3-A)
119 21332-0040C1 +Machine Screw S-Type Plain
#3 M2 × 4 T(3-C)
120 21032-0070C2 +Machine Screw Plain #3 M2 ×
7T(3-B)
121 21032-0025C2 +Machine Screw Plain #3 M2 ×
2.5 T(3-B)
122 21012-0040C2 +Machine Screw Plain #1 M2 ×
4T(4-B)
123 21012-0030F2 +Machine Screw Flat #1 M2 ×
3T(2-C)
124 10138-5002 Azimuth Screw Plain #1 P0.25
M2 × 5 T(4-B)
125 10036-5005 Eject Hook Screw M2 × 5 T(2-B)
126 10136-5001 LMW (Rew) 2.1 × 3.5 t0.05 T(1-A)(1-B)
127 10036-5024 PSW (Reel)B 1.5 × 3.2 t0.25 T
11 TAPE PLAYER PARTS LIST
11
CQ-SS0070F

12 EXPLODED VIEW (Tape Deck)
12
CQ-SS0070F

13 WIRING DIAGRAM
13.1. Main Block
13
CQ-SS0070F

13.2. Front Switch Block
13.3. Tape Block
14
CQ-SS0070F

14 SCHEMATIC DIAGRAM CQ-SS0070F
15

CQ-SS0070F
16
