Toyota Prius V 2014 User manual

i
Introduction
This manual is made up of 2 sections.
The first describing available functions for models without navigation capabili-
ties (WITHOUT NAVIGATION) such as audio and hands-free.
The second describing available functions for models with navigation capabili-
ties (WITH NAVIGATION) such as navigation, audio, and hands-free.
For models that do not have navigation capabilities, refer to the “WITHOUT
NAVIGATION” section. For models that have navigation capabilities, refer to
the “WITH NAVIGATION” section.
■EXISTENCE OF NAVIGATION CAPABILITIES
Existence of navigation capabilities can be confirmed by performing the following:
zThe actual design and button position will differ depending on the vehicle. Some but-
tons will be in different positions or not shown. For details, refer to vehicle “Owner’s
Manual”.
CONFIRMING DISPLAY AUDIO MODEL
Navigation capabilities Reference
Not installed WITHOUT NAVIGATION (1ST SECTION
only)
Installed WITH NAVIGATION (2ND SECTION only)

ii
1 When the ignition switch is turned to the “ACC” or “ON” position, the initial
screen will be displayed and the system will begin operating.
2 Press the “APPS” button.
zIf your system does not have the “APPS” button, the Display Audio system does not
have navigation capabilities, refer to the “WITHOUT NAVIGATION” section.
If this screen is displayed, the Display Audio system has navigation capabilities.
In this manual, illustrations showing the typical Display Audio system layout,
USB port and rear view camera location, etc. has been used. The actual design
and button position may differ depending on the vehicles. For the correct loca-
tion of these items, please refer to vehicle “Owner’s Manual”.
This manual has been written using a vehicle with a gasoline engine vehicle
(without a smart entry and start system) as an example. For vehicles with a
smart entry and start system and hybrid vehicles, please refer to the following
table to confirm the engine switch name and mode.
COMMON ILLUSTRATIONS FOR ALL VEHICLE MODELS
ENGINE SWITCH NAMES AND MODES
Vehicle system Switch name and mode
Vehicles without a
smart key system Engine switch ACC ON OFF (LOCK)
Vehicles with a smart
key system
“ENGINE START
STOP” switch ACCESSORY IGNITION ON OFF
Hybrid vehicles “POWER” switch ACCESSORY ON OFF

iii
SYMBOLS USED IN ILLUSTRATIONS
Safety symbol
The symbol of a circle with a slash through it means “Do not”, “Do not
do this”, or “Do not let this happen”.
Arrows indicating operations
Indicates the action (pushing, turning, etc.)
used to operate switches and other
devices.
Indicates the outcome of an operation (e.g.
a lid opens).
HOW TO READ THIS MANUAL
No. Name Description
Operational Outlines An outline of the operation is explained.
Main Operations The steps of an operation are explained.
Related Operations A main operation’s supplementary operations are described.
Information Useful information for the user is described.

iv

1
Display_audio_U_1st
1QUICK GUIDE 7
2AUDIO SYSTEM 13
3Bluetooth®HANDS-FREE SYSTEM 67
4VEHICLE INFORMATION 85
5SETUP 91
6REAR VIEW MONITOR SYSTEM 119
INDEX 127
TABLE OF CONTENTS
WITHOUT NAVIGATION (1ST SECTION)

2
Display_audio_U_1st
Introduction
This manual explains the operation of the Display Audio system. Please read
this manual carefully to ensure proper use. Keep this manual in your vehicle at
all times.
The screen shots in this document and the actual screens of the Display Audio
system differ depending on whether the functions and/or a contract existed at
the time of producing this document.

3
Display_audio_U_1st
For safety reasons, this manual indicates
items requiring particular attention with the
following marks.
To use this system in the safest possible
manner, follow all the safety tips shown
below.
Do not use any feature of this system to
the extent it becomes a distraction and
prevents safe driving. The first priority
while driving should always be the safe op-
eration of the vehicle. While driving, be
sure to observe all traffic regulations.
Prior to the actual use of this system, learn
how to use it and become thoroughly famil-
iar with it. Read the entire Display Audio
system Owner’s manual to make sure you
understand the system. Do not allow other
people to use this system until they have
read and understood the instructions in
this manual.
For your safety, some functions may be-
come inoperable when driving. Unavail-
able screen buttons are dimmed.
IMPORTANT INFORMATION
ABOUT THIS MANUAL
CAUTION
●This is a warning against anything which
may cause injury to people if the warn-
ing is ignored. You are informed about
what you must or must not do in order to
reduce the risk of injury to yourself and
others.
NOTICE
●This is a warning against anything which
may cause damage to the vehicle or its
equipment if the warning is ignored. You
are informed about what you must or
must not do in order to avoid or reduce
the risk of damage to your vehicle and
its equipment.
SAFETY INSTRUCTION
CAUTION
●For safety, the driver should not operate
the Display Audio system while he/she
is driving. Insufficient attention to the
road and traffic may cause an accident.

4
Display_audio_U_1st

5
1
2
3
4
5
6
TABLE OF CONTENTS
Display_audio_U_1st
1. CONTROLS AND FEATURES.......... 8
OVERVIEW BUTTONS ........................... 8
SYSTEM FUNCTION INDEX ................ 10
TOUCH SCREEN OPERATION............ 11
1. AUDIO SYSTEM OPERATION........ 14
QUICK REFERENCE ............................ 14
SOME BASICS...................................... 16
RADIO OPERATION
(WITH Display Audio SYSTEM).......... 20
RADIO OPERATION
(WITH Premium Display
Audio SYSTEM).................................. 23
RADIO OPERATION
(XM®Satellite Radio
BROADCAST)..................................... 29
CD PLAYER OPERATION .................... 34
iPod OPERATION ................................. 39
USB MEMORY OPERATION................ 43
AUX DEVICE OPERATION................... 47
Bluetooth®AUDIO OPERATION........... 49
STEERING SWITCHES ........................ 57
AUDIO SYSTEM
OPERATING HINTS ........................... 60
1. Bluetooth®HANDS-FREE SYSTEM
OPERATION .................................. 68
QUICK REFERENCE ............................ 68
HANDS-FREE SYSTEM ....................... 69
REGISTER A Bluetooth®PHONE......... 74
CALL ON THE Bluetooth®PHONE ....... 76
RECEIVE ON THE Bluetooth®
PHONE ............................................... 82
TALK ON THE Bluetooth®PHONE ....... 83
1. VEHICLE INFORMATION............... 86
QUICK REFERENCE ............................ 86
FUEL CONSUMPTION .......................... 87
TIRE PRESSURE WARNING
SYSTEM.............................................. 89
1. SETUP OPERATION ...................... 92
QUICK REFERENCE ............................ 92
GENERAL SETTINGS ........................... 93
GUIDANCE SETTINGS ......................... 95
DISPLAY SETTINGS............................. 96
Bluetooth®SETTINGS........................... 98
PHONE SETTINGS ............................. 106
AUDIO SETTINGS............................... 116
VEHICLE SETTINGS........................... 117
1. REAR VIEW MONITOR
SYSTEM ...................................... 120
REAR VIEW MONITOR SYSTEM
OPERATION ..................................... 120
DRIVING PRECAUTIONS ................... 124
ALPHABETICAL INDEX................... 128
1QUICK GUIDE
2AUDIO SYSTEM
3Bluetooth®HANDS-FREE
SYSTEM
4VEHICLE INFORMATION
5SETUP
6REAR VIEW MONITOR
SYSTEM
INDEX

6
Display_audio_U_1st

1
7
1
2
3
4
5
6
Display_audio_U_1st
1. OVERVIEW BUTTONS ................... 8
2. SYSTEM FUNCTION INDEX......... 10
3. TOUCH SCREEN OPERATION.... 11
1CONTROLS AND FEATURES
QUICK GUIDE

8
Display_audio_U_1st
1. CONTROLS AND FEATURES
1. OVERVIEW BUTTONS
zThe actual design and button position will differ depending on the vehicle. Some but-
tons will be in different positions or not shown. For details, refer to vehicle “Owner’s
Manual”.
No. Name Function Page
Touch screen
display
By touching the screen with your finger, you can
control the selected functions. 11
Disc slot Insert a disc into this slot. The CD player turns on
immediately. 34
“TUNE/SCROLL”
knob
Turn this knob to select radio station bands, tracks
and files. Also, the knob can be used for selection
from the list display.
16
“AUDIO” button Press this button to access the audio system. The
audio system turns on in the last mode used. 14, 16, 17
button* Press this button to pause or resume playing the
music. —
button Press this button to access the Bluetooth®hands-
free system. 68
“SETUP” button Press this button to customize the function set-
tings. 92
“SEEK/TRACK”
button
Press the “ ” or “ ” button to seek up or down for
a radio station, or to access a desired track or file.
21, 24, 31,
36, 37, 41,
44, 54

9
1. CONTROLS AND FEATURES
1
QUICK GUIDE
Display_audio_U_1st
*: If equipped
“CAR” button* Press this button to access the vehicle information
system. 86
“APPS” button* This button is used for an add-on external naviga-
tion system. (If equipped) —
“PWR/VOL” knob Press this knob to turn the audio system on and off,
and turn it to adjust the volume. 16
button Press this button to eject a disc. 34
No. Name Function Page

10
1. CONTROLS AND FEATURES
Display_audio_U_1st
2. SYSTEM FUNCTION INDEX
To access the audio system, press the
“AUDIO” button. The audio control screen
will be displayed. Audio sources: Radio,
CDs, iPod, USB, AUX and Bluetooth®au-
dio. For details, see pages 13.
To access the Bluetooth®hands-free sys-
tem, press the button. The driver
can make or receive phone calls without
taking their hands off the steering wheel.
For details, see pages 67.
To access the vehicle information system,
press the “CAR” button. Fuel consump-
tion and tire pressure can be checked. For
details, see pages 85.
To customize the function settings, press
the “SETUP” button. The interface lan-
guage can also be changed from the setup
menu. Function not available on all mod-
els. For details, see pages 91.
Shifting into the “R” position will automati-
cally show the view behind the rear of the
vehicle on the display screen. For details,
see page 119.
AUDIO SYSTEM
Bluetooth®HANDS-FREE
SYSTEM
VEHICLE INFORMATION
(IF EQUIPPED)
SETUP
REAR VIEW MONITOR SYSTEM
(IF EQUIPPED)

11
1. CONTROLS AND FEATURES
1
QUICK GUIDE
Display_audio_U_1st
3. TOUCH SCREEN OPERATION
zWhen a screen button is touched, a beep
sounds. (To set a beep sound, see page
93.)
This system is operated mainly by the
screen buttons.
NOTICE
●To prevent damaging the screen, lightly
touch the screen buttons with your fin-
ger.
●Do not use objects other than your finger
to touch the screen.
●Wipe off fingerprints using a glass clean-
ing cloth. Do not use chemical cleaners
to clean the screen, as they may dam-
age the touch screen.
●To prevent the 12-volt battery from being
discharged, do not leave the system on
longer than necessary when the engine
is not running (hybrid vehicles: the
hybrid system is off).
INFORMATION
●If the system does not respond to a
touch on a screen button, move your fin-
ger away from the screen and then
touch it again.
●Dimmed screen buttons cannot be oper-
ated.
●The displayed image may become
darker and moving images may be
slightly distorted when the display is
cold.
●Under extremely cold conditions, the
screen may not be displayed and the
data input by a user may be deleted.
Also, the screen buttons may be harder
than usual to depress.
●When you look at the screen through
polarized material such as polarized
sunglasses, the screen may be dark and
hard to see. If so, look at the screen
from different angles, adjust the screen
settings (See “DISPLAY SETTINGS” on
page 96.), or take off your sunglasses.

12
Display_audio_U_1st
1. QUICK REFERENCE .................... 14
2. SOME BASICS .............................. 16
TURNING THE AUDIO SYSTEM
ON OR OFF......................................... 16
CONTROLS USING
THE “TUNE/SCROLL” KNOB.............. 16
SWITCHING AUDIO SOURCE .............. 17
DSP CONTROL ..................................... 17
TONE AND BALANCE........................... 18
3. RADIO OPERATION
(WITH Display Audio
SYSTEM)..................................... 20
SWITCHING TO RADIO MODE............. 20
PRESETTING A STATION .................... 20
SELECTING A STATION ....................... 21
RADIO BROADCAST DATA
SYSTEM .............................................. 21
TRAFFIC ANNOUNCEMENT ................ 22
4. RADIO OPERATION
(WITH Premium Display
Audio SYSTEM).......................... 23
SWITCHING TO RADIO MODE............. 23
PRESETTING A STATION .................... 23
SELECTING A STATION ....................... 24
RADIO BROADCAST DATA
SYSTEM .............................................. 24
TRAFFIC ANNOUNCEMENT ................ 25
USING HD Radio™ TECHNOLOGY...... 26
1AUDIO SYSTEM OPERATION

2
13
1
2
3
4
5
6
Display_audio_U_1st
5. RADIO OPERATION
(XM®Satellite Radio
BROADCAST) ............................. 29
HOW TO SUBSCRIBE TO
AN XM®Satellite Radio ...................... 29
DISPLAYING THE RADIO ID................ 29
SWITCHING TO SATELLITE RADIO
MODE ................................................. 30
CHANNEL CATEGORY ........................ 30
PRESETTING A CHANNEL .................. 30
SELECTING A CHANNEL..................... 31
DISPLAYING THE TITLE AND
NAME.................................................. 31
IF THE SATELLITE RADIO
TUNER MALFUNCTIONS .................. 32
6. CD PLAYER OPERATION ............ 34
INSERTING OR EJECTING A DISC ..... 34
SWITCHING TO CD MODE .................. 35
PLAYING AN AUDIO CD ...................... 35
PLAYING A MP3/WMA DISC................ 37
7. iPod OPERATION ......................... 39
CONNECTING AN iPod ........................ 39
SWITCHING TO iPod MODE ................ 39
PLAYING AN iPod................................. 40
8. USB MEMORY OPERATION ........ 43
CONNECTING A USB MEMORY ......... 43
SWITCHING TO USB MODE................ 43
PLAYING A USB MEMORY .................. 44
9. AUX DEVICE OPERATION........... 47
CONNECTING A PORTABLE
AUDIO DEVICE................................... 47
SWITCHING TO AUX MODE ................ 48
PLAYING A PORTABLE AUDIO
DEVICE ............................................... 48
10. Bluetooth®AUDIO
OPERATION ............................... 49
SWITCHING TO Bluetooth®
AUDIO MODE ..................................... 50
CONNECTING A Bluetooth®
AUDIO PLAYER.................................. 51
PLAYING A Bluetooth®
AUDIO PLAYER.................................. 53
11. STEERING SWITCHES................. 57
STEERING SWITCHES
(WITH TWO DIRECTION
STEERING SWITCH).......................... 57
STEERING SWITCHES
(WITH FOUR DIRECTION
STEERING SWITCH).......................... 58
12. AUDIO SYSTEM OPERATING
HINTS .......................................... 60
RADIO RECEPTION.............................. 60
iPod........................................................ 61
USB MEMORY ...................................... 62
CARING FOR YOUR CD PLAYER
AND DISCS......................................... 62
MP3/WMA FILES................................... 64
CD-R AND CD-RW DISCS .................... 65
TERMS .................................................. 66
AUDIO SYSTEM

14
Display_audio_U_1st
1. AUDIO SYSTEM OPERATION
1. QUICK REFERENCE
zThe actual design and button position will differ depending on the vehicle. Some but-
tons will be in different positions or not shown. For details, refer to vehicle “Owner’s
Manual”.
To access the audio system, press the “AUDIO” button. The audio system turns
on in the last mode used.
No. Name Function Page
Audio control
screen
A selected audio source is displayed, and it can be
operated with the touch screen controls. 
Disc slot Insert a disc into this slot. The CD player turns on
immediately. 34
“Source” Touch to select your desired audio sources. The
audio source selection screen will be displayed. 17
“TUNE/SCROLL”
knob
Turn to select radio station bands, tracks and files.
Also, the knob can be used for selection from the
list display.
16
“AUDIO” button Press to display the audio control screen. The au-
dio system turns on in the last mode used. 16, 17
button* Press to pause or resume playing the music. 
“SEEK/TRACK”
button
Press the “ ” or “ ” button to seek up or down for
a station, or to access a desired track or file.
21, 24, 31,
36, 37, 41,
44, 54
