TP-Link RE300 User manual

Quick Installation Guide
©2018 TP-Link
7106508139 REV1.0.0
Power On
1
Set Up
2
Method 3: Via the WPS Button
1. Press the WPS button on your router.
The WPS button might
look like one of these:
Method 2: Via a Web Browser
1. Connect your computer or smartphone to the
extender’s network TP-Link_Extender. If you are
using a computer, unplug the Ethernet cable if any.
Method 1: Via the Tether App
1. Get the up-to-date Tether app.
2. Connect your smartphone to the extender’s
network TP-Link_Extender.
3. Launch the Tether app, and select your extender.
Create a password to log in.
Scan for Tether Tether
or
Range Extender
RE300
Blinking Solid On
Note: If the LED does not turn solid on, try again or use Method 1
or 2.
2. Within 2 minutes, press the WPS button on the
extender for 1 second. The LED should change
from blinking to solid on, indicating successful
connection.
3. If the extender connects to a dual band router,
repeat steps 1 and 2 above to connect to the
other band.
Need setup videos?
Scan the QR code, or visit
https://www.tp-link.com/download/RE300.html
2. Launch a web browser, and enter
http://tplinkrepeater.net or http://192.168.0.254
in the address bar. Create a password to log in.
Note: If the login window does not appear, refer to FAQ > Q1.
http://tplinkrepeater.net
Start
Conrm Password
Create Password
Low Middle High
Extended Network Names:
Router’s network name with
_EXT at the end
Passwords:
Same as your router
Note: If you want to change the extended network
names, refer to Manage the Extender on the back
page.
Next to
Connections are available
Wireless Network Connection
Connect automatically Connect
√
TP-Link_Extender
Wi-Fi
Wi-Fi
TP-Link_Extender
CHOOSE A NETWORK...
Other...
< Settings
My Devices
Local Device
REXXX
XX-XX-XX-XX-XX-XX
4. Follow app instructions to complete the setup.
Note: If the LED does not turn solid on, refer to FAQ > Q2.
The LED should turn solid on, indicating
successful connection to your router.
Solid On
3. Follow web instructions to complete the setup.
Note: If the LED does not turn solid on, refer to FAQ > Q2.
The LED should turn solid on, indicating
successful connection to your router.
Solid On
Relocate
3
1. Plug in the extender about halfway between your router and the Wi-Fi dead
zone. The location you choose must be within the range of your router.
2. Wait for about 2 minutes until the LED turns solid white. If it doesn't, relocate
the extender closer to the router to achieve better signal quality.
Router Devices
Halfway
White: Suitable location
Red: Too far from router
Enjoy the internet!
Tip: For more intuitive location assistant, access extender settings via the Tether app and go to Tools >Location Assistant.
Solid On
If you cannot find the network names with _EXT in
your Wi-Fi network list, this means that the extender
has been connected to a OneMesh router and
automatically copied its Wi-Fi settings. See back for
more information.
Solid On
Plug the extender into a power outlet next to your router. Wait until its
Power LED turns solid on.

Q1. What should I do if I cannot access the extender’s web
management page?
Make sure your computer or smartphone has connected to the extender’s
network, and not that of your router. If your router and extender share the same
network name, use the Tether app.
If you are using a computer, make sure it is set to obtain an IP address and DNS
server address automatically.
Verify that http://tplinkrepeater.net or http://192.168.0.254 is correctly entered
in the web browser and press Enter. Note that http://192.168.0.254 applies only
for extenders with factory default settings.
Use another web browser and try again.
Reboot or reset the extender and try again.
If you are still having problems, contact our technical support.
Q2. What should I do if the LED doesn’t turn solid on after
completing setup via the Tether app or web browser?
You may have entered incorrect Wi-Fi passwords for your host networks during
the conguration. Check the passwords and try again.
Make sure the extender is close to your router, preferably within 16 feet, and
away from large electrical appliances.
If you have enabled wireless MAC ltering, wireless access control, or access
control list (ACL) on your router, disable them rst, then follow any method on the
front page to complete the conguration.
Try setting up via the WPS button.
Reset the extender and go through the conguration again.
If you are still having problems, contact our technical support.
Q3. How do I reset the extender?
With the extender powered on, use a pin to press the Reset button for 1 second.
The extender will reboot.
For technical support, the user guide and other information, please
visit https://www.tp-link.com/support, or simply scan the QR code.
Safety Information
Keep the device away from water, re, humidity or hot environments.
Do not attempt to disassemble, repair, or modify the device.
Do not use the device where wireless devices are not allowed.
The socket-outlet shall be installed near the equipment and shall be easily accessible.
Please read and follow the above safety information when operating the device. We cannot
guarantee that no accidents or damage will occur due to improper use of the device.
Please use this product with care and operate at your own risk.
TP-Link hereby declares that the device is in compliance with the essential requirements and other relevant
provisions of directives 2014/53/EU, 2009/125/EC and 2011/65/EU. The original EU declaration of conformity may
be found at http://www.tp-link.com/en/ce.
TP-Link OneMesh router and extenders work together to form one unied Wi-Fi
network. Walk through your home and stay connected with the fastest possible
speeds thanks to OneMesh’s seamless coverage.
OneMeshTM with Seamless Roaming
Seamless Roaming
Devices automatically switch between your router and extenders as you move through your
home for the fastest possible speeds.
Unied Wi-Fi Network
Router and extenders share the same wireless settings, including network name, password,
access control settings and more.
Easy Setup and Management
Set up a OneMesh network with a push of WPS buttons. Manage all network devices on the
Tether app or at your router’s web management page.
Reset
To check full list of TP-Link OneMesh devices, scan the QR code,
or visit https://www.tp-link.com/One-Mesh/compatibility.
Method 2: Via a Web Browser
Method 1: Via the Tether App
1. Connect your computer or smartphone to the extender’s network . If you are
using a computer, unplug the Ethernet cable if any.
2. Launch a web browser, enter http://tplinkrepeater.net in the address bar, and
log in.
Note: If the login window does not appear, refer to FAQ > Q1.
3. Manage the extender as needed.
1. Connect your smartphone to the extender‘s or router’s network.
2. Launch the Tether app, select your extender, and log in.
3. Manage the extender as needed.
Manage the Extender
After setup, you can manage the extender via any of the methods below.
Note: If your extender and router use the same network name, Method 1 is recommended.
LED Explanation
LED Status Indication (For Range Extender Mode)
The extender is connected or not connected to the
5GHz wireless network of your host router.
5GHz On/O
The extender is connected or not connected to the
2.4GHz wireless network of your host router.
2.4GHz On/O
The extender is on or o.
The system is starting up or rmware is being upgraded.
(Power)
On/O
Blinking
The extender is connected to your router’s wireless
network and is in a suitable location.
The extender is experiencing poor signal strength. Try
relocating it closer to your router.
WPS connection is in progress.
No wireless connection is established.
(Signal)
Solid white
Solid red
Blinking
O
INTERNET
Unied OneMesh Network
SAME
Network Name & Password
for seamless roaming
