TP-Link TL-SG1024 User manual

User Guide
TL-SG1016/ TL-SG1024
16/24-port Gigabit Ethernet Switch
Rev:2.0.0
7106500823

I
COPYRIGHT & TRADEMARKS
Specifications are subject to change without notice .
is a registered trademark of TP-LINK
TECHNOLOGIES CO., LTD. Other brands and product names
are trademarks or registered trademarks of their respective
holders.
No part of the specifications may be reproduced in any form
or by any means or used to make any derivative such as
translation, transformation, or adaptation without permission
from TP-LINK TECHNOLOGIES CO., LTD. Copyright © 2009
TP-LINK TECHNOLOGIES CO., LTD. All rights reserved.
http://www.tp-link.com

II
FCC STATEMENT
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to pro-vide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate
radio frequency energy and, if not in-stalled and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following
measures:
¾Reorient or relocate the receiving antenna.
¾Increase the separation between the equipment and
receiver.
¾Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
¾Consu
lt the dealer or an experienced radio/ TV techni cian for
help.
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions:
1) This device may not cause harmful interference.
2) This device must accept any interference received, including
interference that may cause undesired operation.

III
Any changes or modifications not expressly approved by the
party responsible for compliance could void the user’s authority
to operate the equipment.
CE Mark Warning
This is a class B product. In a domestic environment, this
product may cause radio interference, in which case the user
may be required to take adequate measures.
Package Contents
The following contents should be found in your package:
¾One TL-SG1016/TL-SG1024 Switch
¾One power cord
¾This User Guide
¾Rubber footpads for Desk-mount
¾Rack-mount kit for installing the switch in a 19-inch rack
Note:
Make sure that the package contains the above items. If any of
the listed items are damaged or missing, please contact with
your distributor.
Safety Notices
Do not use this product near water. Avoid using this product during
an electrical storm. Do not place heavy objects on the switch.

1
Chapter 1 Introduction of the Product
This chapter describes the features of the TL-SG1016/
TL-SG1024 16/24-port Gigabit Ethernet Switch.
1.1 Overview of the Product
The TL-SG1016/TL-SG1024 16/24-port Gigabit Ethernet Switch
provides you with a high-performance, low-cost, easy-to-use,
seamless and standard upgrade to boost your old network to
1000Mbps. Increase the speed of your network server and
backbone connections make Gigabit a reality. Power users in
the home, office, workgroup, or creative production environment
can now move large, bandwidth-intensive files faster. Transfer
graphics, CGI, CAD, or multimedia files and other applications
that have to move large files across the network almost instantly.
The TP-LINK TL-SG1016/TL-SG1024 features a non-blocking
switching architecture that forwards and filters packets at full
wire-speed for maximum throughput, MAC address auto-
learning and auto-aging, IEEE802.3x flow control for full-duplex
mode and backpressure for half-duplex mode. It is compatible
with all 10,100 and 1000Mbps Ethernet devices because it is
standard-based. It protects your existing network investments
while providing you with a straightforward migration path to
faster Gigabit speeds.
The TP-LINK TL-SG1016/TL-SG1024 is plug-and-play and no
configuration is required. Auto MDI/MDI-X cable detection on all
ports eliminate the need for crossover cable or Uplink port. Each
port can be used as general ports or Uplink ports, and any port
can be simply plugged into a server, a hub, a router or a switch,
using the straight cable or crossover cable. Diagnostic LEDs
which display link status and activity, allowing you to quickly

2
detect and correct problems on the network.
1.2 Features
¾Complies with IEEE802.3, IEEE802.3u, IEEE802.3ab
standards
¾16/24 10/100/1000Mbps Auto-Sense RJ45 ports supporting
Auto-MDI/MDIX
¾All ports Support Full/Half Duplex transfer mode for
10/100Mbps and Full Duplex transfer mode for 1000Mbps
¾Supports IEEE802.3x flow control for full-duplex mode and
backpressure for half-duplex transfer mode
¾Non-blocking switching architecture that forwards and filters
packets at full wire-speed for maximum throughput
¾Supports MAC address auto-learning and auto-aging
¾LED indicators for monitoring power, link, speed and activity
¾Rack-mountable steel case
¾Internal power supply
Chapter 2 Installation
2.1 Mounting the Switch on a Desk
Before place the Switch on a desk, attach four rubber footpads
to the flutes on the Switch bottom, then lay the Switch on the
desktop, where can be have as much as 5kg placed on top.
Note:
1. The electrical outlet shall be installed near the device and
shall be easily accessible.
2. Make sure there is free space for radiating heat and air.
3. Make sure not to place anything too heavy on top of the switch.

3
2.2 Mounting the Switch in a Rack
The dimension of TL-SG1016/TL-SG1024 is designed according
to the standard 19 rack-mountable steel case of Electronic
Industries Association.
Turn off all the equipment connected to the Switch before
mounting it in the rack, then rivet the two "L" brackets onto each
side of the Switch, fasten it with screws in the rack.
Figure 2-1 Rivet the “L” brackets onto the Switch
Figure 2-2 Fasten the Switch in the rack

4
2.3 Power On
TL-SG1016/TL-SG1024 16/24-port Gigabit Ethernet Switch is
powered by AC power supply. Powering on the Switch, it will
automatically initialize and its LED indicators should respond as
follows:
1）All of the Link/Act and 1000Mbps LED indicators will flash
momentarily for one second, which represent a resetting of
the system.
2）The Power indicator will light up.
If the LED indicators don't respond as described above, please
check the power supply and connection.
Chapter 3 Identifying External Components
This Chapter describes the front panel, rear panel and LED
indicators of the Switch. TL-SG1016 and TL-SG1024 just differ
in the number of LED indicators and ports and all figures in this
guide are of TL-SG1024.
3.1 Front Panel
The front panel of the TL-SG1024 consists of switch LED
indicators, 24 10/100/1000Mbps RJ-45 ports.
Figure 3-1 TL-SG1024 Switch Front Panel sketch
3.2 Rear Panel
The rear panel of the TL-SG1024 only features a power
receptacle, which is an AC power receptacle. Connect the
female of the power cord head here, and the male head to the

5
AC power outlet.
Figure 3-2 TL-SG1024 Switch Rear Panel sketch
3.3 LED Indicators
The LED indicators include Power, Link/Act and 1000Mbps LED
indicators, which are used for monitoring and pre-
troubleshooting of the Switch. The following section shows the
LED indicators for the switch along with an explanation of each
indicator.
Figure 3-3 TL-SG1024 Switch LEDs sketch
¾Power LED: This indicator will light solid red when the
Switch powers up. If the LED is not lit, please check the
power supply and connection.
¾Link/Act LED: This indicator will light solid green when the
corresponding port is connected to another device and will
flash green when data is being transmitted or received on
the working connection.
¾1000Mbps LED: This indicator will light solid green when the
corresponding port is connected to a 1000Mbps device.

6
Appendix A: Specifications
General
Standards
IEEE802.3 10Base-T
IEEE802.3u 100Base-TX
IEEE802.3ab 1000Base-T
Topology Star
Protocol CSMA/CD
Ethernet: 10Mbps (Half Duplex), 20Mbps
(Full Duplex)
Fast Ethernet: 100Mbps (Half Duplex),
200Mbps (Full Duplex)
Data Transfer
Rate
Gigabit Ethernet: 2000Mbps (Full Duplex)
10Base-T: UTP category 3, 4, 5 cable
(maximum 100m)
EIA/TIA-568 100 STP (maximum 100m)
100Base-TX: UTP category 5, 5e cable
(maximum 100m)
EIA/TIA-568 100 STP (maximum 100m)
Network Media
(Cable)
1000Base-T: UTP category 5, 5e cable
(maximum 100m)
EIA/TIA-568 100 STP (maximum 100m)
Number of Ports 16/24 10/100/1000Mbps Auto-Negotiation
RJ-45 ports

7
LED indicators Power, Link/Act, 1000Mbps
Transfer Method Store-and-Forward
MAC Address
Learning
Automatically learning, automatically
aging
10Base-T: 14881pps/Port
100Base-Tx: 148810pps/Port
Frame Filter
Rate
1000Base-T: 1488095pps/Port
10Base-T: 14881pps/Port
100Base-Tx: 148810pps/Port
Frame Forward
Rate
1000Base-T: 1488095pps/Port
Environmental and Physical
Dimensions 17.3 ×7.1 ×1.7in. (440 ×180 ×
44mm) W×D×H
Power Supply Output 100-240V~ 50/60Hz 0.6A
Operating Temperature 0 ~40℃(32 ~104℉)
Storage Temperature -40 ~70℃(-40 ~158℉)
Operating Humidity 10%~90% non-condensing
Storage Humidity 5%~90% non-condensing

8
Appendix B: Troubleshooting
1. The Power LED is not lit
¾Make sure the AC power cord connected the Switch with
power source properly.
¾Make sure the power source is ON.
2. The Link/Act LED is not lit when a device is connected
to the corresponding port
¾Make sure that the cable connectors are firmly plugged into
the Switch and the device.
¾Make sure the connected device is turned on and working
well.
¾The cable must be less than 100 meters long(328 feet).
Appendix C: Contact Information
For help with the installation or operation of the TP-LINK
TL-SG1016/ TL-SG1024 16/24-port Gigabit Ethernet Switch,
please contact us.
E-mail: [e-mail]
Website: http://www.tp-link.com
