Trailer Valet STJB0010 User manual

OPERATING MANUAL
7K Jack
Rev 8.25.23

Carefully read and understand all the instructions before connecting your new
7K lb Jack.
Failure to follow these guidelines may result in serious injury to persons and property
for which Trailer Valet will not be held liable. Do not allow persons to operate or
assemble this unit until they have read this manual and have developed a thorough
understanding of how the unit works.
WARNING AND TABLE OF CONTENTS.........................................................................................................................2
IMPORTANT SAFETY INFORMATION..............................................................................................................................3
SPECIFICATIONS..................................................................................................................................................4
ASSEMBLY...................................................................................................................................................................5
OPERATING INSTRUCTIONS.................................................................................................................................................6
LIMITED MANUFACTURER’S WARRANTY....................................................................................................................7
2
OPERATING MANUAL
TABLE OF CONTENTS
WARNING
thank you for your purchase!
Congratulations on your purchase of the 7K lb Jack. For your future reference, please complete
the owner’s record below:
Purchase Date: ______________________ Order No.:______________________
Retailer:_____________________________
Be sure to keep your receipt, owner’s manual, and warranty information in a safe place.

3
IMPORTANT SAFETY INFORMATION
Failure to heed these markings may result in personal injury and/or property damage:
1. DO NOT leave your trailer free standing without the use of wheel chocks.
2. DO NOT submerge the jack in water (salt or fresh) or leave it in water for prolonged
periods, since this can damage the gears and erode lubricants.
3. Carefully read all instructions. The operator of the jack must exercise common sense,
caution, and full judgment when assessing situations not covered or cautioned in this
manual.
4. This product is designed for specic applications only. Trailer Valet will not be
responsible for issues arising from modications made on the device. Do not modify
the device or use the device for any application other than its intended purpose. Do not
exceed the designated weight limits.
5. As with all devices with moving parts, do not wear excessively loose clothing as it may
become caught, possibly resulting in injury. Tie back and secure long hair.
6. This product must be installed and used in strict accordance with these instructions.
7. Before each use of the Jack, check for damaged parts. Carefully inspect the device for
any part that appears to be damaged to determine if the device will operate properly.
Check for alignment and secure mounting of all moving parts. If the device is neither
aligned, secured, or both: DO NOT use the device.
8. When servicing, use only factory replacement parts.
9. Have wheel chocks in place before/after use and ready in case of emergency.
10. Never exceed the maximum rated capacity. Refer to the specications section of
this operating manual or decals on the product to obtain rated capacity. If uncertain,
contact Customer Support at [phone].
11. This product is designed for vertical loading. Excessive side forces may cause failure
and must be avoided.
12. The use of gloves is recommended while attaching the device to the trailer.
13. This product is only to be installed on trailer tongues that are rectangular in prole.
Cylindrical tongues are not compatible with the jack as it will rotate, allowing the trailer to
drop.
SAVE THESE INSTRUCTIONS
Phone: [phone]
Email: [e-mail]
Website: www.trailervalet.com

Specifications
4
PART # CAPACITY GEAR RATIO MOUNT TYPE
STJB0010 7,000lbs lift 3:4 Direct Weld/Bolt
STJB0011 7,000lbs lift 3:4 Bracket Mount
PART # DESCRIPTION
STA00030 Mounting Bracket with Washers, Locking Nuts, and Bracket Bolts
Upon removing items from packaging, it is very important to thoroughly inspect all parts of
the system. Any part that is missing or damaged must be immediately replaced before using
the device.
Contact Trailer Valet Customer Service at 1-844-846-9344 or [e-mail]
JACKS
MOUNT BRACKET
STJB0010 STJB0011 STA00030

Assembly
Prior to install, raise the trailer tongue until you have adequate space to attach the jack. The
unit must be attached while the weight of the trailer is supported by an existing support or tow
vehicle. Having wheel chocks in place during connection will insure a safe install.
5
STJB0010
Step A: In the location of your
choosing, weld the jack mount
plate to the vertical center of an
unpainted section of your trailer
frame.
Step B: In the location of your
choosing, mark the holes for the
jack mount plate on a vertical center
of your trailer frame. Then, drill holes
through the frame at the marks and
bolt the jack to the frame.
* Bolts NOT included with STJB0010
STJB 0011
Step 1: Insert the mounting bracket through
the mounting plate. Secure with washers and
locking nut.
Step 2: Place the mounting bracket onto an
8 inch clearing on your frame. Secure with
the four included bolts at desired height.
WARNING The mount bracket is only
to be installed on trailer frames that are
rectangular in prole. Cylindrical frames are
not compatible with the mount bracket.
Step A or Step B

operating instructions
USING THE DEVICE
A. Remove the security pin to release the drop leg to the ground. Re-insert the pin to secure the
leg in the lowest possible position.
B. Crank the jack handle to raise the trailer to desired height.
C. If secured to a tow vehicle, crank the jack to fully retract. Then remove the pin to retract the
drop leg fully before re-fastening the leg with the pin. Ensure the security pin is properly locked
prior to moving tow vehicle.
STORING THE DEVICE
After use, lower your jack until your trailer frame sits level. If storing, ensure that the trailer frame
is jacked to level height.
6
3.41”
13.7” 13.6”
27.3”
A. Drop Leg Extension B. Jack Extension C. Full Extension

7
LIMITED MANUFACTURER’S WARRANTY
SuperTech S Corp warrants for one year from the purchase date that the product will be in
working condition and will be free from manufacturing defects, provided that installation and
use of the product are in accordance with product instructions. This warranty is only applicable
to the original consumer purchaser and is non-transferable.
ALL OTHER WARRANTIES IMPLIED OR EXPRESSED ARE HEREBY DISCLAIMED.
THIS WARRANTY DOES NOT COVER:
1. Normal wear and tear or normal aging of the product;
2. Consumable parts designed to diminish over time, unless failure occurred due to a
manufacturing defect;
3. Cosmetic damage, including but not limited to, scratches and dents;
4. Damage through accident, abuse, neglect, misuse, natural events, or other external causes;
5. Damage through misapplication, overloading, or improper installation;
6. Damage due to improper maintenance and repair; and/or
7. Product alterations.
LIMITATION OF LIABILITY:
EXCEPT AS PROVIDED IN THIS WARRANTY AND TO THE MAXIMUM EXTENT PERMITTED BY
LAW, SUPERTECH IS NOT RESPONSIBLE FOR ANY DIRECT, INCIDENTAL, CONSEQUENTIAL
DAMAGES, OR INJURIES RESULTING FROM ANY BREACH OF WARRANTY OR CONDITION;
INCLUDING, BUT NOT LIMITED TO, LOSS OF USE, LOSS OF REVENUE, LOSS OF ACTUAL OR
ANTICIPATED PROFITS, LOSS OF BUSINESS, LOSS OF OPPORTUNITY, LOSS OF GOOD WILL,
LOSS OF REPUTATION, OR ANY DIRECT, INDIRECT, OR CONSEQUENTIAL LOSS OR DAMAGE
WHATSOEVER CAUSED, INCLUDING THE REPLACEMENT OF EQUIPMENT AND PROPERTY.
CUSTOMER RESPONSIBILITIES:
Customers may be required to provide proof of purchase date, respond to questions designed
to assist with diagnosing potential issues, and follow Trailer Valet’s directions to make a claim
on your warranty.
TO MAKE A WARRANTY CLAIM:
Contact us either through:
PHONE: [phone]
EMAIL: [e-mail]
WEBSITE: www.trailervalet.com
TRAILER VALET SHALL HAVE THE EXCLUSIVE RIGHT TO DETERMINE IF A UNIT IS
COVERED UNDER ITS LIMITED MANUFACTURER’S WARRANTY.
SEVERABILITY:
The invalidity, illegality, or unenforceability of any provision of this warranty shall not render the
other provisions invalid, illegal, or unenforceable.
GOVERNING LAW AND JURISDICTION
This warranty shall be governed by the laws of the State of California. The courts of California
shall have the exclusive right to adjudicate any disputes arising under or in connection to this
warranty.

SUPERTECH S. CORP.
Customer Service: [phone]
Email: [e-mail]
WWW.TRAILERVALET.COM
Copyright 2023 by Supertech S. Corporation. All rights reserved. No portion of
this manual or any artwork contained herein may be reproduced in any shape or
form without the express written consent of Supertech S. Corporation.
For further information or if you have any questions, please contact:
Rev.8.25.23
