Transition Networks CSDTF3011-115 User manual

Installation . . . . . . . . . . . . . . . . . . . . .2
Operation . . . . . . . . . . . . . . . . . . . . . .6
Cable Specifications . . . . . . . . . . . . . .7
Technical Specifications . . . . . . . . . . .8
Troubleshooting . . . . . . . . . . . . . . . . .9
Compliance Information . . . . . . . . .12
* Typical maximum cable distance. Actual
distance is dependent upon the physical
characteristics of the network.
CSDTF3027-115 75 ohm BNC coax
100 m (328 ft.)*
ST, 1300 nm multimode
5 km (3.1 miles)*
Part Number Port One - Copper Port Two - Duplex Fiber-Optic
CSDTF3011-115 75 ohm BNC coax
100 m (328 ft.)*
ST, 850 nm multimode
2 km (1.2 miles)*
CSDTF3012-115 75 ohm BNC coax
100 m (328 ft.)*
ST, 1310 nm single mode
8 km (4.8 miles)*
CSDTF3013-115 75 ohm BNC coax
100 m (328 ft.)*
SC, 850 nm multimode
2 km (1.2 miles)*
CSDTF3014-115 75 ohm BNC coax
100 m (328 ft.)*
SC, 1310 nm single mode
20 km (12.4 miles)*
CSDTF3015-115 75 ohm BNC coax
100 m (328 ft.)*
SC, 1310 nm single mode
40 km (24.8 miles)*
CSDTF3016-115 75 ohm BNC coax
100 m (328 ft.)*
SC, 1310 nm single mode
60 km (37.3 miles)*
CSDTF3017-115 75 ohm BNC coax
100 m (328 ft.)*
SC, 1550 nm single mode
80 km (49.7 miles)*
CSDTF3018-115 75 ohm BNC coax
100 m (328 ft.)*
MT-RJ, 1300 nm multimode
2 km (1.2 miles)*
CSDTF3022-115 75 ohm BNC coax
100 m (328 ft.)*
ST, 1310 nm single mode
15 km (9.3 miles)*
CSDTF3025-115 75 ohm BNC coax
100 m (328 ft.)*
MT-RJ, 1310 nm single mode
20 km (12.4 miles)*
User’s Guide
CSDTF30xx-11x
Slide-in-Module Device
• E1 with Remote Management
• Coax (BNC) to Fiber
Transition Networks CSDTF30xx-11x series Device,
designed to be installed into the Transition Networks
PointSystem™ chassis, encodes and decodes E1 coax copper
signals over fiber optic cable to extend the distance and
transmission reliability of high-speed E1 data traffic. The
CSDTF30xx-11x is framing independent (as ESF vs. D4)
and supports all common line codes (e.g., AMI, B8ZS,
HDB3). The CSDTF30xx-11x is designed to be installed in pairs. For example, install
one CSDTF3011-115 as the local Device and another CSDTF3011-115 as the remote
Device.

224-hour Technical Support: 1-800-260-1312 -- International: 00-1-952-941-7600
CSDTF30xx-11x
* Typical maximum cable distance. Actual distance is dependent upon the physical
characteristics of the network. (TX) = transmit (RX) = receive
Part Number Port One - Copper Port 2 - Simplex Fiber Optic
CSDTF3029-115 and CSDTF3029-116 are intended to be installed
in the same link where one is the local Device and the other is the
remote Device.
CSDTF3029-117 and CSDTF3029-118 are intended to be
installed in the same link where one is the local Device and the
other is the remote Device.
CSDTF3029-115 75 ohm BNC coax
100 m (328 ft.)*
SC, 1310 mn (TX)/1550 nm (RX)
single mode, 20 km (12.4 miles)*
CSDTF3029-116 75 ohm BNC coax
100 m (328 ft.)*
SC, 1550 mn (TX)/1310 nm (RX)
single mode, 20 km (12.4 miles)*
CSDTF3029-117 75 ohm BNC coax
100 m (328 ft.)*
SC, 1310 mn (TX)/1550 nm (RX)
single mode, 40 km (24.8 miles)*
CSDTF3029-118 75 ohm BNC coax
100 m (328 ft.)*
SC, 1550 mn (TX)/1310 nm (RX)
single mode, 40 km (24.8 miles)*
Installation
CAUTION: Wear a grounding device and observe electrostatic discharge
precautions when setting the jumper. Failure to observe this caution could result in
damage to, and subsequent failure of, the media cverter.
Set the Hardware/Software Jumper
The jumper is located on the circuit board. Use needle-nose pliers to move the
jumper to the desired position.
Hardware The Device mode is determined by the
switch settings.
Software The Device mode is determined by the
most-recently saved, on-board
microprocessor settings.
Hardware Mode
Software Mode
H
HS
S
E1 Configuration (switch 4)
IMPORTANT: Switch 4 MUST be set to
the “down” position to set the Device for E1
configuration.
1234
E1 Configuration (down)
Important
[email protected] -- Click the “Transition Now” link for a live Web chat. 3
Switch 2. Fiber -- Transmit All Ones
Up - Disables the Transmit All Ones
function on the fiber interface.
Down - Transmits an “all ones” pattern on
the fiber interface when the signal detect on
the coax interface is lost.
Switch 3. Not in use
1234
Fiber- Transmit All Ones - Disabled
Fiber - Transmit All Ones - Enabled
Installation -- Continued
CAUTION: Wear a grounding device and observe electrostatic discharge precautions
when setting the switches. Failure to observe this caution could result in damage to, and
subsequent failure of, the Device.
Set the Configuration Switches
The configuration switches are located on the side of the Device.
Use a small, flat-blade screwdriver or a similar device to set the recessed switches.
Transmit All Ones (switches 1 & 2)
The Transmit All Ones function allows the insertion of an “all ones” pattern on the
interface when the signal detect is lost, creating an alarm condition at the device
connected to the interface.
Switch 1. Coax -- Transmit All Ones
Up - Disables the Transmit All Ones
function on the coax interface.
Down - Transmits an “all ones” pattern on
the coax interface when the signal detect on
the fiber interface is lost.
Key:
UP
DOWN
Not Used
1234
1234
Coax - Transmit All Ones - Disabled
Coax - Transmit All Ones - Enabled

424-hour Technical Support: 1-800-260-1312 -- International: 00-1-952-941-7600
CSDTF30xx-11x
Install the Slide-in-Module
CAUTION: Wear a grounding device and observe electrostatic discharge
precautions when installing the CSDTF30xx-11x slide-in-module Device. Failure
to observe this caution could result in damage to, and subsequent failure of, the
Device.
1. Locate an emply installation slot in the PointSystem™ chassis
2. Carefully slide the slide-in-module into the installation slot, aligning the
module with the installation guides.
3. Ensure that the module is firmly seated inside the chassis.
4. Push in and rotate the panel fastener screw clockwise to secure the module to
the chassis front.
Media Converter
Point System Chassis
Panel Fastener
Slot
Installation -- Continued
Set the Loop-Back Switch
Hardware Mode:
The loop-back switch is located on the front panel of the Device and is used for
installation and network debugging procedures.
To set the switch, use a small flat-blade screwdriver or a similar device (see the
drawing to the right).
CL (Coax loop-back) Enable loop-back on the local coax interface.
-- (Center position) Normal operation.
FL (Fiber loop-back) Enable loop-back on the
local fiber interface.
Software Mode:
If both Devices are under software control, the network administrator can initiate
the loop-back test function on the coax interface (local or remote) or on the fiber
interface (local or remote).
CL FL
[email protected] -- Click the “Transition Now” link for a live Web chat. 5
Installation -- Continued
Install the Copper Cable
1. Locate or build coax cables with female connectors installed at both ends.
2. Connect the coax cables to the Device as described:
• Connect the female TX cable connector to the male TX port.
• Connect the female RX cable connector to the male RX port.
3. Connect the coax cables to the other device (switch, workstation, etc.) as
described:
• Connect the female TX cable connector to the male RX port.
• Connect the female RX cable connector to the male TX port.
Install the Fiber Cable
1. Locate or build fiber cable with male, two-stranded TX to RX connectors
installed at both ends.
2. Connect the fiber cables to the local Device as described:
• Connect the male TX cable connector to the female TX port.
• Connect the male RX cable connector to the female RX port.
3. Connect the fiber cables to the remote Device as described:
• Connect the male TX cable connector to the female RX port.
• Connect the male RX cable connector to the female TX port.
Connect fiber cable
to media converter
as shown.
Connect fiber cable
to other device
(media converter,
hub, etc.) as shown
RX TX
RX
TX
Connect coax
cable to device
as shown
Connect coax
cable to other
device as shown
RX
TX
RX
TX

Operation
After installation, the Device should function without operator intervention. Use the
status LEDs to monitor the Device operation in the network.
SDC (Signal Detect / Coax) On = The coax link is up.
SDF (Signal Detect / Fiber) On = The fiber link is up.
PWR (Power) On = The Device is connected to
external power.
Remote Management
The CSDTF30xx-11x chassis Device can remotely manage the
SSDTF30xx-11x, the stand-alone version of the Device, or
another CSDTF30xx-11x.
For example, a local CSDTF3011-115 Device (that is installed
in a managed Transition Networks PointSystem™ chassis) is
connected, via fiber, to a remote SSDTF3011-115 Device. An
example of a managed single-fiber network has a local
CSDTF3029-115 Device connected, via fiber, to a remote
SDTF3029-116.
See the SNMP section (below) for a list of commands that can
be used to monitor and manage the CSDTF30xx-11x and
SSDTF30xx-11x Devices.
NOTE: In a managed network, both the local and remote
Devices must be set to “software” mode (see page 2).
SNMP
See the on-line documentation that comes with Transition Networks FocalPoint™
software for applicable commands and usage.
Use SNMP at an attached terminal or at a remote location to monitor the Device by
monitoring:
• Media Device power
• Copper link and fiber link status (local and/or remote)
• AIS detected on copper link and fiber link (local and/or remote)
• Hardware switch settings
Also, use SNMP to enter network commands that:
• Bootload the firmware (local only)
• Enable/disable loopback on the copper link (local and/or remote)
• Enable/disable loopback on the fiber link (local and/or remote)
• Enable/disable Transmit All Ones on the fiber link when the copper link
is down (local and/or remote)
• Enable/disable Transmit All Ones on the copper link when the fiber link
is down (local and/or remote)
• Power-down the Device
CSDTF30xx-11x
624-hour Technical Support: 1-800-260-1312 -- International: 00-1-952-941-7600
CSDTF
COAX
Fiber
SDFSDC PWR
TX
RX
RX
TX
CL FL
[email protected] -- Click the “Transition Now” link for a live Web chat. 7
Fiber Cable
Single mode fiber (recommended): 9 µm
Multimode fiber (recommended): 62.5/125 µm
Multimode fiber (optional): 100/140, 85/140, 50/125 µm
CSDTF3011-115 850 nm multimode
Fiber Optic Transmitter Power: min: -14.0 dBm max: -12.0 dBm
Fiber Optic Receiver Sensitivity: min: -25.0 dBm max: -12.0 dBm
Link Budget: 11.0 dB
CSDTF3012-115 1310 nm single mode
Fiber-optic Transmitter Power: min: -27.0 dBm max: -10.0 dBm
Fiber-optic Receiver Sensitivity: min: -34.0 dBm max: -14.0 dBm
Link Budget: 7.0 dB
CSDTF3013-115 850 nm multimode
Fiber Optic Transmitter Power: min: -19.0 dBm max: -14.0 dBm
Fiber Optic Receiver Sensitivity: min: -32.5 dBm max: -14.0 dBm
Link Budget: 13.5 dB
CSDTF3014-115 1310 nm single mode
Fiber-optic Transmitter Power: min: -19.0 dBm max: -14.0 dBm
Fiber-optic Receiver Sensitivity: min: -34.0 dBm max: -3.0 dBm
Link Budget: 15.0 dB
CSDTF3015-115 1310 nm single mode
Fiber Optic Transmitter Power: min: -8.0 dBm max: -2.0 dBm
Fiber Optic Receiver Sensitivity: min: -38.0 dBm max: -8.0 dBm
Link Budget: 30.0 dB
CSDTF3016-115 1310 nm single mode
Fiber-optic Transmitter Power: min: -5.0 dBm max: 0.0 dBm
Fiber-optic Receiver Sensitivity: min: -38.0 dBm max: -8.0 dBm
Link Budget: 33.0 dB
CSDTF3017-115 1550 nm single mode
Fiber-optic Transmitter Power: min: -5.0 dBm max: 0.0 dBm
Fiber-optic Receiver Sensitivity: min: -34.0 dBm max: -7.0 dBm
Link Budget: 29.0 dB
CSDTF3018-115 1300 nm multimode
Fiber-optic Transmitter Power: min: -19.0 dBm max: -14.0 dBm
Fiber-optic Receiver Sensitivity: min: -33.5 dBm max: -14.0 dBm
Link Budget: 14.5 dB
Cable Specifications
Copper Cable
E1:
Cable Type: RG-59
Gauge: 24 to 22 AWG
Differential Characteristic Impedance: 75 ohm +/- 10%

824-hour Technical Support: 1-800-260-1312 -- International: 00-1-952-941-7600
CSDTF30xx-11x
Cable Specifications -- Continued
Fiber Cable -- Continued
CSDTF3022-115 1310 nm single mode
Fiber Optic Transmitter Power: min: -15.0 dBm max: -5.0 dBm
Fiber Optic Receiver Sensitivity: min: -25.0 dBm max: -14.0 dBm
Link Budget: 10.0 dB
CSDTF3025-115 1310 nm single mode
Fiber-optic Transmitter Power: min: -11.0 dBm max: -3.0 dBm
Fiber-optic Receiver Sensitivity: min: -20.0 dBm max: -3.0 dBm
Link Budget: 9.0 dB
CSDTF3027-115 1300 nm multimode
Fiber Optic Transmitter Power: min: -19.0 dBm max: -15.0 dBm
Fiber Optic Receiver Sensitivity: min: -32.5 dBm max: -14.0 dBm
Link Budget: 13.5 dB
CSDTF3029-115 1310 nm (TX)/1550 nm (RX) simplex
Fiber-optic Transmitter Power: min: -13.0 dBm max: -6.0 dBm
Fiber-optic Receiver Sensitivity: min: -32.0 dBm max: -3.0 dBm
Link Budget: 19.0 dB
CSDTF3029-116 1550 nm (TX /1310 nm (RX) simplex
Fiber-optic Transmitter Power: min: -13.0 dBm max: -6.0 dBm
Fiber-optic Receiver Sensitivity: min: -32.0 dBm max: -3.0 dBm
Link Budget: 19.0 dB
CSDTF3029-117 1310 nm (TX)/1550 nm (RX) simplex
Fiber-optic Transmitter Power: min: -8.0 dBm max: -3.0 dBm
Fiber-optic Receiver Sensitivity: min: -33.0 dBm max: -3.0 dBm
Link Budget: 25.0 dB
CSDTF3029-118 1550 nm (TX)/1310 nm (RX) simplex
Fiber-optic Transmitter Power: min: -8.0 dBm max: -3.0 dBm
Fiber-optic Receiver Sensitivity: min: -33.0 dBm max: -3.0 dBm
Link Budget: 25.0 dB
The fiber optic transmitters on this device meet Class I Laser safety
requirements per IEC-825/CDRH standards and comply with 21 CFR1040.10
and 21CFR1040.11.
Product is certified by the manufacturer to comply with DHHS Rule 21/CFR,
Subchapter J applicable at the date of manufacture.
CAUTION: Visible and invisible laser radiation when open. Do not stare into
the beam or view directly with optical instruments.
CAUTION: Use of controls, adjustments or the performance of procedures
other than those specified herein may result in hazardous radiation exposure.
[email protected] -- Click the “Transition Now” link for a live Web chat. 9
Technical Specifications
For use with Transition Networks Model CSDTF30xx-11x or equivalent
Standards Emissions: CISPR A; Telecordia TR-NWT-001089
(designed to meet; NOT tested); FCC Part 68; T1/E1
Physical layer: ITU-T, ANSI, AT&T, and ETSI; European
Technical Standard: TBR 12; British Technical
Publication: PD 7024 : 1994 (NTR 4)
Dimensions 3.4" x 5" x 0.87" (86 mm x 182 mm x 22 mm)
Shipping Weight 3 oz. (91 g) approximately
Power Consumption 3.7 Watts
MTBF 478,901 (MIL217F2 V5.0) (MIL-HDBD-217F)
1,333,687 (Bellcore7 V5.0)
Environment Tmra*: 0 to 50°C (32° to 122° F )
Storage Temp: -15° to 65°C (5° to 149°F)
Humidity: 5 to 95%, non condensing
Altitude: 0 to 10,000 feet
Warranty Lifetime
*Manufacturer’s rated ambient temperature. Tmra range for this slide-in-module
depends on the physical characteristics and the installation configuration of the
Transition Networks PointSystem™ chassis in which this slide-in-module will be
installed.
The information in this user’s guide is subject to change. For the most up-to-date
information on the CSDTF30xx-11x Device, view the user’s guide on-line at
www.transition.com.
Declaration of Conformity
Name of Mfg: Transition Networks
10900 Red Circle Drive, Minnetonka MN 55343 U.S.A.
Model: CSDTF30xx-11x Series Device
Part Number: CSDTF3011-115, CSDTF3012-115, CSDTF3013-115,
CSDTF3014-115, CSDTF3015-115, CSDTF3016-115,
CSDTF3017-115, CSDTF3018-115, CSDTF3022-115,
CSDTF3025-115, CSDTF3027-115, CSDTF3029-115,
CSDTF3029-116, CSDTF3029-117, CSDTF3029-118
Regulation: EMC Directive 89/336/EEC
Purpose: To declare that the CSDTF30xx-11x to which this declaration refers is in
conformity with the following standards.
CISPR 22:1993; EN 55022:1998+A1:2000 Class A; EN 55024:1998; FCC Part 15 Subpart
B; EN 61000-3-2:1995+A14:2000: 61000-3-3:1995; CFR 21 Subpart J
I, the undersigned, hereby declare that the equipment specified above conforms to the above
Directive(s) and Standard(s).
July 2008
Stephen Anderson, Vice-President of Engineering Date

10 24-hour Technical Support: 1-800-260-1312 -- International: 00-1-952-941-7600
CSDTF30xx-11x
Troubleshooting
1. Is the PWR (Power) LED illuminated?
NO
• Ensure the Device is inserted properly into the chassis.`
• Ensure the power cord is properly installed in the chassis and in the
grounded outlet.
• Ensure the grounded outlet provides power.
• Contact Tech Support: 1-800-260-1312, Int’l: 00-1-952-941-7600.
YES
• Proceed to step 2.
2. Is the SDC (Signal Detect/Copper) LED illuminated?
NO
• Check the coax copper cables for the proper connection.
• Contact Tech Support: 1-800-260-1312, Int’l: 00-1-952-941-7600.
YES
• Proceed to step 3.
3. Is the SDF (Signal Detect/Fiber) LED illuminated?
NO
• Check the fiber cables for proper connection.
• Verify that the TX and RX cables on the local Device are connected to the
RX and TX ports, respectively, on the remote Device.
• Contact Tech Support: 1-800-260-1312, Int’l: 00-1-952-941-7600.
YES
• Proceed to step 4.
[email protected] -- Click the “Transition Now” link for a live Web chat. 11
4. Is Data Transfer Failing?
YES
• Verify the local copper connection by starting a local copper loop-back
(hardware mode: set the loop-back switch on the local Device to “CL”,
software mode: enter the local copper loop-back command) and then use a
bit error test unit to run a bit error test.
• Verify the local fiber connection by starting a remote fiber loop-back
(hardware mode: set the loop-back switch on the remote Device to “FL”,
software mode: enter the remote fiber loop-back command) and then use a
bit error test unit to run a bit error test.
• Verify the remote copper connection by starting a remote copper loop-back
(hardware mode: set the loop-back switch on the remote Device to “CL”,
software mode: enter the remote copper loop-back command) and then use
a bit error test unit to run a bit error test.
• Verify the remote fiber connection by starting a local copper loop-back
(hardware mode: set the loop-back switch on the local Device to “FL”,
software mode: enter the local fiber loop-back command) and then use a bit
error test unit to run a bit error test.
• Contact Tech Support: 1-800-260-1312, Int’l: 00-1-952-941-7600.
NO
• Contact Tech Support: 1-800-260-1312, Int’l: 00-1-952-941-7600.
reppoCrebiFreppoC Local
Device
Remote
Device
Bit Error
Test Unit
Remote
Device
reppoCrebiFreppoC
Bit Error
Test Unit
Local
Device
Remote
Device
Local
Device
reppoCrebiFreppoC
Bit Error
Test Unit
Local
Device
Local
Device
Remote
Device
reppoCrebiFreppoC
Bit Error
Test Unit
Local
Device
Remote
Device
Local
Device

Trademark Notice
All trademarks and registered trademarks are the property of their respective owners.
Copyright Restrictions
© 2002-2004 Transition Networks. All rights reserved. No part of this work may be reproduced or
used in any form or by any means - graphic, electronic, or mechanical - without written permission
from Transition Networks. Printed in the U.S.A.
33247.F
Compliance Information
CISPR22/EN55022 Class A + EN55024
CE Mark
FCC Regulations
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference, in which
case the user will be required to correct the interference at the user's own expense.
Canadian Regulations
This digital apparatus does not exceed the Class A limits for radio noise for digital apparatus set
out on the radio interference regulations of the Canadian Department of Communications.
Le présent appareil numérique n'émet pas de bruits radioélectriques dépassant les limites applicables
aux appareils numériques de la Class A prescrites dans le Règlement sur le brouillage
radioélectrique édicté par le ministère des Communications du Canada.
European Regulations
Warning
This is a Class A product. In a domestic environment this product may cause radio interference in
which case the user may be required to take adequate measures.
Achtung !
Dieses ist ein Gerät der Funkstörgrenzwertklasse A. In Wohnbereichen können bei Betrieb dieses
Gerätes Rundfunkstörungen. In diesem Fäll ist der Benutzer für Gegenmaßnahmen verantwortlich.
Attention !
Ceci est un produit de Classe A. Dans un environment domestique, ce produit risque de créer des
interférences radioélectriques, il appartiendra alors à l'utilsateur de prende les measures spécifiques
appropriées.
Contact Us:
Technical support is available 24 hours a day.
US and Canada: 1-800-260-1312 International: 00-1-952-941-7600
Chat live via the Web with Transition Networks Technical Support.
Log onto www.transition.com and click the Transition Now link.
Transition Networks provides seminars via live web-based training.
Log onto www.transition.com and click the Learning Center link.
Send an e-mail anytime to our technical support staff: [email protected]
Transition Networks, 10900 Red Circle Drive, Minnetonka MN 55343, USA
telephone: [phone] -- toll free: 800-526-9267 -- fax: [phone]
