Travis Industries 616 GSR User manual


616 GSR Driftwood Log Set
Installation Instructions (SKU94500949)


Page 1 of 11 17601714.docx — 8/23/12 © Travis Industries, Inc.
Compatibility
616GSR
Packing List
7‐PieceDriftwoodLogSet(notshown)


StandoffPack:Includes(4)LogSupportBrackets,(6)10‐24Nuts

RearBurnerDeflector,NG/LPRearAirDeflector

BagofRockWool,BagofEmbers
WARNINGS
MakesurethegascontrolvalveisOFFandtheheateriscoolbeforeconductingservice.

Failuretopositionthepartsinaccordancewiththesediagramsorfailuretouseonlyparts
specificallyapprovedwiththisappliancemayresultinpropertydamageorpersonalinjury.

Ifusingpropane(LP),converttheappliancebeforeinstallingthelogs(seetheowner’smanual
fordetails).
Donotusecrushedglassmediawiththislogset.Itcausesexcesssooting.Useincludedrock
wool.



616 GSR Driftwood Log Set
Installation Instructions (SKU94500949)


Page 2 of 11 17601714.docx — 8/23/12 © Travis Industries, Inc.
Burner Installation
NOTE:Theinsertshouldbeinplace,withthegaslineandventattached,andthefirebacksinstalled
(seeowner’smanualforfurtherdetails)beforeproceeding.
1. Removetherearburnerasshownbelow.

2. Removethe3screwsfromthebackoftherearburnerusinga¼”nutdriver.


NOTE:Removethe
attachmentscrewfirst.




616 GSR Driftwood Log Set
Installation Instructions (SKU94500949)


Page 3 of 11 17601714.docx — 4/30/13 © Travis Industries, Inc.
3. Attachtherearairdeflectortotherearburnerwiththescrewsremovedinthepreviousstep.
NOTE:Verifythecorrectairdeflectoraccordingtoyourfueltype
IMPORTANT:Makesuretheairdeflectorholesarealigned,iftheydonotalignflipthedeflector
over.

NGInstallation

LPInstallation
4. Replacetherearburnerandsecurewiththeattachmentscrew.



ThisnotchintheLP
deflectordifferentiatesit
fromtheNGairdeflector.
Thetwotabsontherear
burnerrestontopofthe
frontburner.


616 GSR Driftwood Log Set
Installation Instructions (SKU94500949)


Page 4 of 11 17601714.docx — 8/23/12 © Travis Industries, Inc.
5. Installtherearburnerdeflector.
6. Attachthelogsupportswiththe6includednuts.



616 GSR Driftwood Log Set
Installation Instructions (SKU94500949)


Page 5 of 11 17601714.docx — 8/23/12 © Travis Industries, Inc.
Rock Wool Placement
7. Placetherockwoolasfollows:
a. Brushtherockwoolusingastiffbrushinaloose,gauze‐likelayer.
TIP:Holdtherockwoolinatightwadwithonehandwhilebrushingwiththeother.

Notehowtherockwoolisapproximately1/8”thickovertheburnerports.
TIP:Feelfreetoapplyagenerousamountofrockwooltogainadarkerflameandabrighter
coalbed.





616 GSR Driftwood Log Set
Installation Instructions (SKU94500949)


Page 6 of 11 17601714.docx — 8/23/12 © Travis Industries, Inc.
Log and Ember Chunks Placement
Thelogsarefragile,especiallyafterbeingexposedtoheat.
IMPORTANT:Theburnermustbecorrectlypositionedbeforeinstallingthelogs.Makesuretheburner
isfullyseated.
8. Placetherearlogasshownbelow.



Movethelogforwarduntilitrestsagainstthetabsontheburners.



616 GSR Driftwood Log Set
Installation Instructions (SKU94500949)


Page 7 of 11 17601714.docx — 8/23/12 © Travis Industries, Inc.
9. Placetheleftmiddlelog.
10. Placetherightmiddlelog.





616 GSR Driftwood Log Set
Installation Instructions (SKU94500949)


Page 8 of 11 17601714.docx — 8/23/12 © Travis Industries, Inc.
11. Placetheleftcrosslog.


12. Placethepilotlog.

 



616 GSR Driftwood Log Set
Installation Instructions (SKU94500949)


Page 9 of 11 17601714.docx — 8/23/12 © Travis Industries, Inc.
13. Placethefrontrightlog.


14. Placethecentercrosslog.

 




616 GSR Driftwood Log Set
Installation Instructions (SKU94500949)


Page 10 of 11 17601714.docx — 8/23/12 © Travis Industries, Inc.


15. Placetheemberchunks.Notethatroughlyhalfthebagofembersisleftover.
MakesurethattheemberchunksDONOTcoveranyburnerports.
TIP:Theemberchunksshouldbeplacedsoastohideanysheetmetalparts,rivets,andscrews.



16. Re‐applytherockwoolovertheemberchunksalongthefrontburnerandbetweenthetwo
frontlogsforanaturallook.
TIP:Naturalgas(NG)canusemorerockwoolthanpropane(LP).
NOTE:Initialapplicationofrockwoolmaycause“matting”overburnerports.Turningtheunit
onandthenoffagainwillloosentherockwool,resultinginabetterflame.




616 GSR Driftwood Log Set
Installation Instructions (SKU94500949)


Page 11 of 11 17601714.docx — 8/23/12 © Travis Industries, Inc.
17. Checktheexhaustrestrictorsettingbeforefinalizingtheinstallation.
Restrictor Settings
Driftwood Logs
Natural Gas Short Vent
(25’ or less)#1
Natural Gas Tall Vent
(25’ or more)#3 (stock)
Propane Short Vent
(25’ or less)#1
Propane Tall Vent
(25’ or more)#3 (stock)

Finalizedinstallation:

18. Test‐burntheinsertwiththeglassframeinplacebeforefinishingtheinstallation.Seethe
owner’smanualfordetailsonfinalizingtheinstallation(adjustingtheairshutter,etc.).

