Treasure Garden UM920 Installation instructions

Assembly and Operation Guide
www.treasuregarden.com
©2021 Treasure Garden, Inc. - All Rights Reserved.
v.07.15.21
UM920 9’ octagon
UM907 7.5’ octagon
UM906CK 6’ octagon
PUSH BUTTON TILT
WARRANTY:
Treasure Garden warrants this product
(for residential use ONLY) to be free
from defects in original materials and
workmanship for a period of 1 year from
the date of purchase. If a defect in the
original material or workmanship appears
during the warranty period; Treasure
Garden will (at its discretion) repair or
replace the product without charge.
Simply contact your original authorized
Treasure Garden dealer with a description
of the defect. The dealer will verify the
defect and work closely with Treasure
Garden to obtain the necessary service.
In many cases, simple problems can
be solved with a replacement part that
can be shipped directly to the dealer for
professional installation / repair.
In the event that warranted factory service
is required, Treasure Garden will assume
the responsibility of the return freight
charges for the first year only.
Returned product that (upon receipt and
inspection) is deemed to be “not covered”
under our warranty, will be shipped / billed
at your expense.
This warranty gives you specific legal
rights, and you may have other rights
which vary from state to state.
RUST: Rust is a natural part of the aging
process of steel or iron based materials,
and is therefore NOT considered a defect.
CAUTION: Seaside and indoor pool
use, salt & chlorides can accumulate on
the powder coat finish, leading to finish
failure. Failure or neglect to make needed
cleanings may cause paint to blister, and
such failure will void limited warranty.
NOTE: Failure caused by unreasonable or
abusive use, or failure caused by neglect
of reasonable and necessary care, and any
modification to product are not covered by
this warranty.
Additionally, acts of nature (including but
not limited to wind, hurricanes, tornadoes,
and storms) are not covered by this
warranty.

Thank you for purchasing Treasure Garden’s Push Button Tilt Umbrella.
Please remove all contents from the package, inspect and review checklist.
STEP 1SET UP
CHECKLIST
A - (1) Finial
B - (1) Canopy/Mainframe
C - (1) Bottom Pole
A -
B -
C -
Carefully remove umbrella from box. Attach finial to top of canopy/mainframe. Insert bottom
pole into canopy/mainframe pole. Line up button with hole and snap into place.
STEP 2OPENING & TILTING UMBRELLA
Turn the umbrella upright and insert into
umbrella base. Crank handle clockwise
to open umbrella to its fully open position.
To tilt, simply press button on top pole and
manually tilt.
STEP 3CLOSING UMBRELLA
Simply push button to bring umbrella back to a horizontal
position. Turn crank handle in counter-clockwise direction
to close umbrella. Tie string around canopy and cover
umbrella with protective cover (sold separately).
21
Push button to tilt
SAFETY PRECAUTIONS
• To reduce risk of personal injury in which a person is injured or harmed, and/or damage
to personal property, read and follow the Assembly Guide prior to assembling and
operating umbrella and base.
• Close and store the umbrella in windy conditions or when a storm approaches. Never
allow the umbrella to flap in the wind; this could cause personal injury, damage to
personal property, damage to umbrella and/or umbrella canopy. Do not use tilting
function during windy conditions.
• Keep umbrella secured to umbrella base at all times. Base knobs may loosen over time.
Simply tighten base knobs during use of umbrella to ensure umbrella is secure.
• Do not leave open umbrella unattended. If damage occurs, this is not covered by the
warranty.
• When adjusting the umbrella, make sure that no person(s), item(s) or personal property
are close to the umbrella. This is important to prevent injury or material damage.
• Do not allow children to play on or with umbrella or umbrella base.
• When adjusting or assembling the umbrella or umbrella base, make sure fingers, toes
or any other parts of the body are clear from moving parts. Failing to do so many result
in serious injury.
CARE AND MAINTENANCE
• When not in use, close and cover umbrella with a protective cover (sold separately).
• Allow a wet canopy to dry while in open position, but do not leave unattended.
• If necessary, clean the fabric with lukewarm water, mild detergent, and a sponge.
• Wipe sliding marks on the aluminum poles with a damp cloth.
Winter Storage:
• Store in a dry place.
After the Winter:
• Check the condition and function of the umbrella. Any defects must be repaired by a
professional.
TO PROPERLY FOLD CANOPY:
The canopy will last longer if you fold it as it was packed and shipped. This technique is
similar to the way a parachute is folded and is especially important when folding the canopy
for seasonal storage or when left in the closed position for an extended period of time.
Using this technique at all times will significantly extend the life of the canopy.
• When the umbrella has been fully closed, stand in front of the canopy
structure and begin the folding process by pulling out two panels
opposite the main frame. Pull the two panels together and roll tight into
the canopy.
• Once rolled tight, pull adjacent panels out one at a time and fold to the
center, alternating sides until all the panels have been pulled out from
the arms and folded into the center.
• Tie string around canopy and cover umbrella with a protective cover
(sold separately).
IMPORTANT:
It is imperative to use appropriate base weight for umbrella. The minimum base weight
recommended for the 9’ and 7.5’ is 50lbs.; 6’ is 35lbs.

Thank you for purchasing Treasure Garden’s Push Button Tilt Umbrella.
Please remove all contents from the package, inspect and review checklist.
STEP 1SET UP
CHECKLIST
A - (1) Finial
B - (1) Canopy/Mainframe
C - (1) Bottom Pole
A -
B -
C -
Carefully remove umbrella from box. Attach finial to top of canopy/mainframe. Insert bottom
pole into canopy/mainframe pole. Line up button with hole and snap into place.
STEP 2OPENING & TILTING UMBRELLA
Turn the umbrella upright and insert into
umbrella base. Crank handle clockwise
to open umbrella to its fully open position.
To tilt, simply press button on top pole and
manually tilt.
STEP 3CLOSING UMBRELLA
Simply push button to bring umbrella back to a horizontal
position. Turn crank handle in counter-clockwise direction
to close umbrella. Tie string around canopy and cover
umbrella with protective cover (sold separately).
21
Push button to tilt
SAFETY PRECAUTIONS
• To reduce risk of personal injury in which a person is injured or harmed, and/or damage
to personal property, read and follow the Assembly Guide prior to assembling and
operating umbrella and base.
• Close and store the umbrella in windy conditions or when a storm approaches. Never
allow the umbrella to flap in the wind; this could cause personal injury, damage to
personal property, damage to umbrella and/or umbrella canopy. Do not use tilting
function during windy conditions.
• Keep umbrella secured to umbrella base at all times. Base knobs may loosen over time.
Simply tighten base knobs during use of umbrella to ensure umbrella is secure.
• Do not leave open umbrella unattended. If damage occurs, this is not covered by the
warranty.
• When adjusting the umbrella, make sure that no person(s), item(s) or personal property
are close to the umbrella. This is important to prevent injury or material damage.
• Do not allow children to play on or with umbrella or umbrella base.
• When adjusting or assembling the umbrella or umbrella base, make sure fingers, toes
or any other parts of the body are clear from moving parts. Failing to do so many result
in serious injury.
CARE AND MAINTENANCE
• When not in use, close and cover umbrella with a protective cover (sold separately).
• Allow a wet canopy to dry while in open position, but do not leave unattended.
• If necessary, clean the fabric with lukewarm water, mild detergent, and a sponge.
• Wipe sliding marks on the aluminum poles with a damp cloth.
Winter Storage:
• Store in a dry place.
After the Winter:
• Check the condition and function of the umbrella. Any defects must be repaired by a
professional.
TO PROPERLY FOLD CANOPY:
The canopy will last longer if you fold it as it was packed and shipped. This technique is
similar to the way a parachute is folded and is especially important when folding the canopy
for seasonal storage or when left in the closed position for an extended period of time.
Using this technique at all times will significantly extend the life of the canopy.
• When the umbrella has been fully closed, stand in front of the canopy
structure and begin the folding process by pulling out two panels
opposite the main frame. Pull the two panels together and roll tight into
the canopy.
• Once rolled tight, pull adjacent panels out one at a time and fold to the
center, alternating sides until all the panels have been pulled out from
the arms and folded into the center.
• Tie string around canopy and cover umbrella with a protective cover
(sold separately).
IMPORTANT:
It is imperative to use appropriate base weight for umbrella. The minimum base weight
recommended for the 9’ and 7.5’ is 50lbs.; 6’ is 35lbs.
