INTRODUCTION
The LanTEK IV-S and TREND AnyWARE are a Cable Certification System.
This guide will give you an overview of the key features of LanTEK IV-S and
how to start using AnyWARE to manage your project and test results.
GETTING STARTED
Before you start using your LanTEK IV-S follow the steps below to ensure
you can take advantage of all the features your LanTEK IV-S has to oer.
1. Fully charge the display and remote units using the power supply
included in your case. This can be connected to the main charging port
on the LanTEK IV-S or the quick charge port on the battery. The quick
charge port reduces the charging time by 50%. To access the quick
charge port the battery must first be removed by releasing the retaining
screw.
2. Select the language by selecting the setup gear at the top right of the
screen.
Handset charging
port
Status LED
Red = Charging
Green = Fully Charged
Quick Charge
Port
EN

4www.trend-networks.com 163857 Rev 1. 5
Depend On Us
3. Visit anyware.trend-networks.com to setup your free TREND AnyWARE
account to Manage, Share, Edit and Pre-configure your projects. Select;
sign up for cloud based software or download for the desktop version.
4. Link your LanTEK IV-S to your TREND AnyWARE Account by logging
into your TREND AnyWARE account.
• Select Menu: Click Devices: Add Device:
• Enter your Device ID and select submit. The LanTEK IV-S device ID is
found in the settings menu (below).
EN

6www.trend-networks.com 163857 Rev 1.
HELP OPTIONS
LanTEK IV-S and AnyWARE cloud have a comprehensive on-board help
which will guide you through how to use the features. This can be accessed
as follows;
Help on the LanTEK IV-S
Icon on the Menu Bar
Or click Settings - Usage
Guides:
Help on the AnyWARE Cloud
AnyWARE Cloud assistance can be
accessed by the Walk Me Through tab
located on the bottom right-hand side.
Return to home
screen Create new job
Multiple job select
Sort jobs by date
Sort jobs by name
List of all jobs
saved to your
LanTEK IV-S
Total number of
tests within each
project
Long press job
for short cut
options
EN

6www.trend-networks.com 163857 Rev 1. 7
Depend On Us
KEY FUNCTIONS
LanTEK IV-S
USB Type A
USB Type C
Talkset Jack
Charging Port
LED Indicator
When power OFF
Flashing Green = Charging
Solid Green = Fully Charged
When power ON
White/Green flashing = Charging
White/Red flashing = Low
Battery
Autotest
Button (Press
to start
next test in
sequence)
High Voltage
Warning
Disconnect cable
immediately Status Connection
Blue when both units
are connected
Touch Screen
Display
Home Button (press
to show the active
job test list)
Back
button
Protective Cap
VisiLINQ™ incorporates a multi-
color LED indicator and action
button to initiate tests and report
the status independent of the tester
handsets.
Field
Replaceable Tip
Tip Retaining
Screw
LED Indicator
Blue =Display and Remote
connected
Green = Pass
Red = Fail
Amber = Marginal Pass/Fail
White = Torch mode
Action button;
Press to activate
white torch when
not linked.
Press to initiate
Autotest when
handsets are linked
Contextual LED
indicators - color
indicates status
Power Button
EN

8www.trend-networks.com 163857 Rev 1.
HOME SCREEN
The LanTEK IV-S home screen has been designed to display the details
of the current project in either Standard mode or Advanced mode. Press
the Settings button to change the Operation mode between Standard or
Advanced. Standard is the default mode.
Setting the Operating Mode
EN

8www.trend-networks.com 163857 Rev 1. 9
Depend On Us
HOME SCREEN (Standard)
The Standard mode displays all of the settings needed to perform a test on a
single screen and is used when sequential test IDs are used, or each ID needs
to be manually entered.
Status of last run test
Press to view result
Press to select/add new
job folders
Active test configuration,
tap box to edit
Tap to select/add new
operator name
ID of next test to
be run
ID of last run test
Standard of last
run test
Current test
standard
Name of current
job where tests
will be saved
Name of current
operator that is
attached to the
test result
Add range of test IDs and
view list of untested IDs
EN

10 www.trend-networks.com 163857 Rev 1.
HOME SCREEN (Advanced Mode)
The Advanced mode is used primarily when a pre-defined list of test ID’s has
been created in the LanTEK or downloaded from AnyWARE Cloud.
Test Count is
the number of
tests saved/
total memory
capacity
Settings and Help
Active job name, total number
of tests and progress bar
Red = Fail
Green = Pass
Grey = Untested
Last test
completed
Test list display
options
Start test
Long press to access test
options:
List of tests in the
current job:
Green = Pass
Red = Fail
Amber = Marginal
Tap to view test
results
= Next test
Will execute when
VisiLINQ action/
Autotest button
pressed
JOBS menu
displays all jobs
stored on the
tester
SYNC to upload/
download tests
to AnyWARE
Cloud or export
to USB drive
Tap to view test
results
EN

10 www.trend-networks.com 163857 Rev 1. 11
Depend On Us
SETTINGS
The settings can be accessed from the settings menu on the home screen.
Choose language
Connect to a hotspot/Wi-Fi
Set reference for Cat 8.2, patch
cord adapters and fiber jumper
calibration
View calibration details/export
calibration certificate to USB as
PDF file
Start tone generator
Software version,
serial number
and MAC address
How to use your
LanTEK IV-S
Device ID,
required to
register your
LanTEK IV-S with
AnyWARE cloud
Set the date/time and
measurement units
Set operator name
Sound on and o
Screen brightness
Activate remote control
(Team Viewer)
Show cursor when using
USB mouse
EN

12 www.trend-networks.com 163857 Rev 1.
CREATING A JOB
To create a job, select JOBS from the menu bar and then select:
Enter job name and if required,
select the job identifiers
(optional). This will allow tests
to be grouped specifically by
building, floor, etc.
Select when complete.
1
2
Select the newly
created job from the
jobs screen.
3
Select +to add tests
to the job, then
choose Copper or
Fiber
4
In Create Tests, enter the prefix (optional) and
the test range.
Test Ranges
Enter an alpha-numeric value in Test Range
from: that is the first test ID of a sequence.
Then enter the last value of the sequence in
Test range to: generate the list of test ID’s.
A red warning will be shown if the from and to
ranges cannot create a continuous series.
EN

12 www.trend-networks.com 163857 Rev 1. 13
Depend On Us
CREATING A JOB
8
9
Select standard
5 6 Choose the
appropriate
standard
7Choose type of
link
Optional Step, During
the set-up the Cable
and Connector
manufacture can be
selected to add more
detail to the finished
report
Select when
completed
EN

14 www.trend-networks.com 163857 Rev 1.
CONNECTING TO WI-FI
To connect LanTEK IV-S to Wi-Fi, firstly select the Settings menu:
Select Wi-Fi from the Settings menu and switch toggle to turn on Wi-Fi.
Select your chosen Network and enter password (if required).
Wi-Fi successfully connected
EN

14 www.trend-networks.com 163857 Rev 1. 15
Depend On Us
SYNCHRONISING
Selecting SYNC will allow you to download pre-configured jobs or upload
completed jobs to the cloud. If you are using the TREND AnyWARE desktop
SYNC will also allow you to download results to USB. To SYNC your
LanTEK IV-S:
Select SYNC
EN
Download all new jobs from the cloud
Upload all jobs to the cloud
Display a list of jobs and select the job(s) to be
downloaded from the cloud
Display a list of jobs and select the job(s) to be
uploaded to the cloud
Display a list of jobs and select the job(s) to be
downloaded from a USB drive
Display a list of jobs and select the job(s) to be
uploaded to a USB drive
Download all new jobs from a USB drive
Upload all new jobs to a USB drive

16 www.trend-networks.com 163857 Rev 1.
LIVE WIREMAP
Live Wiremap allows an instant, constantly updating wiremap view for
connected links without the need to perform an Auto test. Live Wiremap can
be used in two ways. In an active job or free mode which does not require a
project to be set-up.
To activate Live Wiremap in
free mode. Swipe down from
the top of the screen.
Activate Live Wiremap in a
job select the test list options
menu.
EN

16 www.trend-networks.com 163857 Rev 1. 17
Depend On Us
CREATING A TEST REPORT
Jobs can be reviewed and edited using TREND AnyWARE Cloud or Desktop,
Jobs synced via Wi-Fi will automatically be added to jobs menu of the cloud.
Key:
Upload jobs from
USB using the Cloud
and Desktop Swipe
down from the top of
the screen
Generate a PDF test
report
View, download and
email PDF reports
Share the report via
an email link where
the recipient can
view and save the
report
Download
report
EN

18 www.trend-networks.com 163857 Rev 1.
INTRODUCTION
Les certificateurs LanTEK IV-S et les logiciels TREND AnyWARE de chez
TREND Networks sont des outils complémentaires. Ce guide vous donne
un aperçu des fonctionnalités principales des testeurs LanTEK IV-S et du
logiciel associé AnyWARE pour l’édition des tests et des rapports PDF.
DEMARRER
Avant de commencer à utiliser votre LanTEK IV-S, merci de suivre les étapes
ci-dessous afin de bien maitriser toutes ses fonctionnalités.
1. Chargez totalement les deux boîtiers de tests en utilisant les deux blocs
alimentation/chargeur fournis, qui vont ainsi remplir à 100% les batteries
intégrées. Ces dernières peuvent également être extraites en dévissant
la vis dédiée au dos de chaque appareil puis chargées directement avec
les mêmes blocs alimentation/chargeur, hors des testeurs donc, pour
des cycles de charge qui seront 50% plus rapides que si laissées dans les
appareils.
2. Choisir la langue française en cliquant sur la la roue des paramètres en
haut à droite de l’écran tactile.
Interface de
charge testeurs
classique
Indicateur LED
Rouge : en chargé
Vert : complètement chargé
Interface de
charge batterie
rapide
FR

18 www.trend-networks.com 163857 Rev 1. 19
Depend On Us
FR
3. Sur votre ordinateur, allez sur le site “anyware.trend-networks.com”
pour créer votre compte gratuit sur notre logiciel “TREND AnyWARE”
et pouvoir ensuite gérer, préconfigurer, partager, modifier vos projets &
tests. Sélectionnez “S’enregistrer” pour exploiter le logiciel via Cloud - ou
sur “Télécharger” pour la version PC.
4. Pour lier votre compte TREND AnyWARE que vous venez de créer, avec
votre LanTEK IV-S : valider en cliquant sur “S’enregistrer”
• Sélectionnez le Menu : Puis cliquez sur “Appareils” :
Puis sur “Ajoutez un appareil” avec le + en haut à droite :
• Entrez l’identifiant de votre LanTEK IV-S constitué du N° de série à
deux champs du boitier principal, et sélectionnez “Soumettre”; vous
le trouverez dans les “Paramètres” de l’appareil (voir la capture ci-
dessous). Pensez aussi à créer votre “Compte utilisateur”

20 www.trend-networks.com 163857 Rev 1.
AIDES
Les LanTEK IV-S et AnyWARE Cloud intègrent une Aide didactique
embarquée qui vous expliquera les fonctionnements et menus. Vous pouvez
y accéder en suivant les étapes ci-dessous :
Rubrique “Aide” dans le LanTEK
IV-S
Icône du Menu
Ou cliquez sur “Paramètres”
- puis sur “Manuel
d’utilisation” :
Rubrique “Aide” sur TREND AnyWARE
Utilisez l’onglet Assistance étape
par étape située en bas à droite de
l’écran (“Aide didactique” = “Walk Me
Through”)
Retour à l’écran
principal
Liste de tous
les dossiers
sauvegardés
dans le LanTEK
IV-S
Nombre total de
tests au sein de
chaque dossier
En gardant le doigt
appuyé longtemps
sur un répertoire,
on accède aux
raccourcis (= clique
droit d’une souris)
FR
Créer un nouveau dossier
Sélectionner plusieurs dossiers
Trier les dossiers par date
Trier les dossiers
par nom
