TREND T-Tech TT/KWJ650 User manual

-1-
TT/KWJ650
Dear Customer
Thank you for purchasing this Trend product, we
hope you enjoy many years of creative and
productive use.
Please remember to return your guarantee card
within 28 days of purchase.
The following symbols are used throughout this
manual:
Denotes risk of personal injury, loss of
life or damage to the tool in case of non-
observance of the instructions in this
manual.
Refer to the instruction manual of
your power tool.
This unit must not be put into service until it has
been established that the power tool to be
connected to this unit is in compliance with
98/37/EC (identified by the CE marking on the
power tool).
TECHNICAL DATA
Jig thickness 12mm
Cutter size 12.7mm
Workpiece thickness max. 45mm
Worktop width min. 400mm
max. 650mm
Guide bush size 30mm
Weight 4.3kg
CONTENTS
TECHNICAL DATA _____________________1
SAFETY ____________________________2-3
ITEMS ENCLOSED __________________4
DESCRIPTION OF PARTS_______________4
ACCESSORIES
– Recommended Cutters ________________5
– Sub-base Set ________________________5
– 30mm Guide Bush ____________________5
– Panel Butt Connector Bolts _____________6
– Biscuit Jointer for the Router ____________6
– Flat Biscuit Dowels____________________6
– Clamp______________________________6
ASSEMBLY
– Location Bush Identification _____________7
– Margin Distance ______________________7
– Setting out the Joints __________________7
OPERATION
– Setting the Length Stop _______________8
– Female Joint_________________________8
– Male Joint___________________________9
– Out-of-Square Joints __________________9
– Cutting the Bolt Recesses _____________10
– Strengthening the Joint _______________10
– Sealing the Joint ____________________11
MAINTENANCE ______________________11
RECYCLING _________________________11
GUARANTEE ________________________11
SPARE PARTS
– Spare Parts List _____________________12
– Spare Parts Diagram _________________12
TROUBLESHOOTING _________________IB
☎
If you require further technical
information or spare parts, please call
our technical support department on
01923 224681.
MANU-TT-650 v2 17/7/06 4:14 pm Page 1

-2-
TT/KWJ650
SAFETY
Observe the safety regulations in the
instruction manual of the Power Tool to
be used or connected to this
attachment. Also observe any
applicable additional safety rules. Read
the following safety instructions before
attempting to operate this product.
PLEASE KEEP THESE
INSTRUCTIONS IN A SAFE
PLACE.
The attention of UK users is drawn to
The Provision and Use of Work
Equipment Regulations 1998, and any
subsequent amendments.
General
■Disconnect power tool, when not in
use. Before servicing and when
changing accessories such as
cutters disconnect power tool and
attachment from power supply.
Ensure the machine is switched off
before plugging tool in or
connecting to a power supply.
■Always mount the power tool,
accessory or attachment in
conformity with the present
instructions.
■Keep children and visitors away. Do
not let children or visitors touch the
tool, accessory or attachment.
Keep children and visitors away
from work area.
■Make the workshop child proof with
padlock and master switch.
■Dress properly. Do not wear loose
clothing or jewellery, they can be
caught in moving parts. Rubber
gloves and non-skid footwear is
recommended when working
outdoors. Wear protective hair
covering to contain long hair.
■Consider working environment. Do
not use the product in the rain or in
a damp environment. Keep work
area well lit. Do not use power tools
near gasoline or flammable liquids.
Keep workshop at a comfortable
temperature so your hands are not
cold.
■The accessory or attachment must
be kept level and stable at all
times.
■Keep work area clean. Cluttered
workshops and benches can cause
injuries
■Use the attachment with the power
tools and accessories specified in
this manual only. Do not force the
tool or attachment to do a job for
which it is not designed.
■Secure idle tools. When not in use,
tools should be stored in a dry and
high or locked up place, out of
reach of children.
■For best control and safety use
both hands on the power tool and
attachment. Keep both hands away
from cutting area. Always wait for
the spindle and cutter to stop
rotating before making any
adjustments.
■Always keep guards in place and in
good working order.
■Remove any nails, staples and
other metal parts from the
workpiece.
■Maintain tools and cutters with
care. Keep cutters sharp and clean
for better and safer performance.
Do not use damaged cutters.
Follow instructions for lubricating
and changing accessories. Keep
handles dry, clean and free from oil
and grease.
■Maintain accessories. Do not use
damaged accessories. Only use
accessories recommended by the
manufacturer.
■Check damaged parts. Before
operation inspect the attachment,
the power tool, the cable, extension
cable and the plug carefully for
signs of damage. Check for
alignment of moving parts, binding,
breakage, mounting and any other
conditions that may effect its
operation. Have any damage
repaired by an Authorised Service
Agent before using the tool or
accessory.
■Do not use tool if switch does not
turn it on or off. Have defective
switches replaced by an Authorised
Service Agent.
■Don't over reach. Keep proper
footing and balance at all times.
■Don’t abuse the cable. Never carry
power tool or accessory by cord or
pull it to disconnect from the
socket. Keep cord from heat, oil
and sharp edges. Always trail the
power cord away from the work
area.
■Connect dust extraction equipment.
If devices are provided for the
connection of dust extraction and
collection facilities, ensure these
are connected and properly used.
■Check all fixing and fastening nuts,
bolts and screws before use to
ensure they are tight and secure.
Periodically check when machining
over long periods.
■Stay alert. Watch what you are
doing. Use common sense. Do not
operate tools when you are tired,
under the influence of drugs or
alcohol.
■Personal Protective Equipment
(PPE). All PPE must meet current
UK and EU legislation.
■Do not leave tools running
unattended. Do not leave tool until
it comes to a complete stop.
■Always clamp workpiece being
machined securely.
■Only use cutting tools for
woodworking that meet EN847-1/2
safety standards, and any
subsequent amendments.
Routing Safety
■Disconnect router power tool.
When not in use, before servicing
and when changing accessories
such as cutters, disconnect router
and attachment from power supply.
■Ensure router cutter has stopped
rotating before changing it. Never
use the spindle lock as a brake.
■Remove adjusting keys and
spanners. Form the habit of
checking to see that keys and
adjusting spanners are removed
from the router tool, cutter and
attachment before turning router
on. Make sure cutter can rotate
freely.
■Check all ball bearing and blade
fixing screws before use to ensure
they are tight and secure.
Periodically check when machining
over long periods.
■When using a template guide bush
ensure it cannot come into contact
with collet and nut.
■Noise. Take appropriate measures
for the protection of hearing if the
sound pressure of 85dB(A) is
exceeded. Routing sound pressure
may exceed 85dB(A), so ear
protection must be worn.
MANU-TT-650 v2 17/7/06 4:14 pm Page 2

-3-
TT/KWJ650
■Eye protection. Wear safety
goggles, spectacles or visors to
protect the eyes from ejected waste
particles.
■Respiratory protection. Wear a face
or dust mask, or powered
respirator. Dust masks/filters should
be changed regularly.
■Do not switch router on with the
cutter touching the workpiece.
■The direction of routing must
always be opposite to the cutter's
direction of rotation.
■After work, release the router
plunge and allow spindle to stop
rotating before putting machine
down.
■Check before cutting that there are
no obstructions in the path of the
router. When cutting through the full
thickness of the workpiece, ensure
there are no obstacles beneath
workpiece, and that a sacrificial
work surface is used.
Additional Safety Rules For
Router Cutters
■Cutting tools are sharp. Care
should be taken when handling
them.
■Always use cutters with a shank
diameter corresponding to the size
of the collet installed in your tool.
■Always run router cutters at the
spindle speed recommended and
marked accordingly. Ensure cutter
has reached correct speed before
entering workpiece. Recommended
speeds can be found on the
packaging, in cutter instructions or
in the Trend Routing Catalogue.
■Always use router cutters in a
router. Router cutters must not be
used in a drill. Drill and boring bits
must not be used in a router.
Router cutters must only be used
for the material cutting application
for which they are designed. Do not
use on metal or masonry.
■Never use cutters with a diameter
exceeding the maximum diameter
indicated in the technical data of
the powertool or attachment used.
■Do not drop cutters or knock them
against hard objects. Do not use
cutters that are damaged.
■Cutters should be kept clean. Resin
build up should be removed at
regular intervals with Resin
Cleaner®. The use of a dry
lubricant (Trendicote®PTFE) will
act as a preventative. Do not use
PTFE spray on plastic parts.
■Cutter shanks should be inserted
into the collet to the mark line on
the shank. This ensures that at
least 3/4 of the shank length is held
in the collet. Do not over-tighten the
collet nut as this will score the
shank and create a weakness and
fracture point.
■Observe the correct assembly
instructions in the router instruction
manual for fitting the collet and nut.
Observe the router power tool
manual instructions on fitting
cutters correctly.
■It is advisable to periodically check
the collet and collet nut. A worn,
distorted or damaged collet can
cause vibration and damage the
shank, and should be replaced.
Worn collet nuts should be
replaced.
■Do not take deep cuts in one pass;
take several shallow or light passes
to reduce the side load applied to
the cutter. Too deep a cut in one
pass can stall the router.
■Very small diameter cutters must
be handled and used with care.
■Always return cutter to its
packaging after use.
■Should you experience excessive
vibration during use stop
immediately. Have the eccentricity
of the router, router cutter and
clamping system checked.
■All fastening screws and nuts
should be tightened using the
appropriate spanner or key in
accordance with the manufacturers
instructions.
Using Routers In A Fixed
Position
■After work, release the router
plunge to protect the cutter.
■Always use a push-stick or push-
block for last 300mm of the cut.
■Whenever possible use a work
holding device or jig to secure
component being machined.
■Ensure attachment is securely fitted
to the workbench, with table
surface at approximately hip height.
■Ensure a No-Volt Release Switch is
fixed to or adjacent to the
attachment and that it is used
correctly.
■Check the direction of the
workpiece is always opposite to the
cutter's direction of rotation.
■Do not use awkward or
uncomfortable hand positions.
■Do not reach underneath table or
put your hands or fingers at any
time in the cutting path while tool is
connected to a power supply.
Useful Advice When Routing
■Judge your feed rate by the sound
of the motor. Feed the router at a
constant feed rate. Too slow a feed
rate will result in burning.
■Take many light passes rather than
one deep cut to reduce the side
load applied to both router and
router cutter.
■Trial cuts should be made on waste
material before starting any project.
■When using some attachments
including a router table or dovetail
jig, the use of a fine height adjuster
is highly recommended.
■When using a template guide bush,
ensure there is sufficient clearance
between cutter tip and inside edge
of bush. Ensure cutter and guide
bush are concentric.
Router Cutter Maintenance
■Composite cutting tools (brazed tip)
must be maintained by a competent
person i.e. a person of training and
experience, who has knowledge of
the design requirements and
understands the levels of safety to
be achieved.
■The design of composite tools must
not be changed in the process of
maintenance.
■Replacement parts must meet
Trend specification.
■Tolerances which ensure correct
clamping by the collet shall be
maintained.
■When re-grinding the tool, care
must be taken not to cause
weakening of the body or the
connection between the cutting
edge and the body.
Version 4.2 04/2004
MANU-TT-650 v2 17/7/06 4:14 pm Page 3

-4-
TT/KWJ650
616 650
640600500400
B
FF
M
M
B
router accessories
-TECH
T
TM
ITEMS ENCLOSED
x1
x1x1 x3
DESCRIPTION OF PARTS
616 650
640600500400
B
FF
M
M
B
f
c
e
j
fdb a i
hg g
router accessories
-TECH
T
TM
Jig body
Label
Postform joint slot
Female joint bush location hole
Length stop location hole
Male joint bush location hole
Bolt recess bush location hole
Connecting bolt recess slot
Alloy location bush
Location hole code
a
b
c
d
e
f
g
h
i
j
MANU-TT-650 v2 17/7/06 4:14 pm Page 4

-5-
TT/KWJ650
Recommended Cutters
Ref. NLE50RB or TT/50X1/2TC
A 12.7mm (1/2”) diameter cutter must be used,
which has a 50mm cutting reach and plunge cut
facility.
Router must be plunged in stages of maximum
8mm in one pass.
Sub-base Set Ref. TT/UNIBASE
To obtain a perfect accurate close fitting joint, a
30mm guide bush must be used. The guide
bush must always be fitted concentric with the
cutter. This can be achieved using a T-TECH
Universal Sub-base and 30mm outside diameter
guide bush ref. TT/GB30.
The T-TECH Universal Sub-base has a central
recess to allow fitting of the T-TECH guide bush
to most makes of routers and is available ready
to fit the most popular makes.
The Sub-base contains screws, a line up bush
and two line up pins. The line up pins and bush
ensure exact alignment of Sub-base with router
spindle, when fitted with the relevant collet.
ACCESSORIES
UNIBASE
Fits following Router Models
Performance Pro CLM1250R >11/2003, CLM2050R
T-TECH TT/R127 Atlas Copco OFSE2000 Bosch GOF
1300ACE, 1600A, 1700ACE Casals FT2000VCE DeWalt
DW625EK, 629 Draper R1900V Elu MOF 31, 77, 98,
131, 177(E) Felisatti TP246(E), R346EC Festo OF2000E
Freud FT2000E Hitachi MI12V, M12SA, TR12 Makita
3612BR, 3612(C) Metabo OF1612, OFE1812 Ryobi
RE600N, R600N, RE601, R500, R502 Skil 1875U1
Wadkin R500
General instructions for fitting
Sub-bases to Router
1. Fit line up guide bush onto sub-base, with
screws supplied.
2. Fit 12.7mm (1/2”) shank line up pin into collet
of router. Plunge router until pin projects
through base and lock plunge.
3. Locate guide bush and sub-base assembly
over protruding pin.
4. Line up fixing holes and fit screws.
5. Now tighten up screws.
6. Remove line up bush and line up pin.
Alignment should now be correct. Fit 30mm
guide bush and cutter.
7. Periodically check the sub-base is concentric
to the spindle of the router.
t
r
e
n
d
3
0
m
m
R
30mm Guide Bush
Ref. TT/GB30/B
Description Order Ref.
Universal sub-base TT/UNIBASE
Description Order Ref.
30mm guide bush to fit sub-base TT/GB30/B
MANU-TT-650 v2 17/7/06 4:14 pm Page 5

-6-
TT/KWJ650
100mm (4”) min.
throat depth
Panel Butt Connector Bolts
Ref. TT/PC/10M (Pack of ten)
Panel butt connectors are essential for
connecting worktops. They fit into the recess on
the underside of the worktop and are tightened
with a 10mm spanner. The jig has integral bolt
recess slots to allow the bolt recess to be cut in
the underside of the worktop, using the standard
router cutter. The recess is elongated to allow
easy access for the spanner.
Biscuit Jointer for the Router
Ref. TT/48X1/2TC
Worktops with inadequate support below them
need additional stability by biscuit jointing the
edges. The T-TECH biscuit jointing set for the
router together with the No.20 biscuits will
ensure worktops do not sag or warp in time.
Whenever fast action clamps are used,
ensure they do not foul the router path
and that they are securely tightened.
Clamp
Two heavy duty quick action or gripper clamps
with throats of at least 100mm (4”) are required
to secure the jig to the worktop.
Flat Biscuit Dowels
Ref. TT/BSC/20 (Pack of 100 biscuits)
Biscuits are used to strengthen the joint. When
used with PVA glue they expand ensuring a tight
joint.
No.20
MANU-TT-650 v2 17/7/06 4:14 pm Page 6

-7-
TT/KWJ650
ASSEMBLY
Location Bush Identification
Three location bushes are used in different holes
in the jig to align the correct template aperture
for the application.
The holes are coded for easy identification as
follows:
F– Female Joint
M– Male Joint
B– Bolt Connector Recess
Setting out the Joints
When cutting a joint ensure location bushes
contact the postformed edge of the worktop. For
certain joints the worktop will need to be inverted
so that all cuts are made into the postformed
edge, never out through it. When routing worktop
the balancing paper on the underside may feather
edge – this feather edge should be removed with
abrasive paper.
Location bushes are held in position by ‘O’ rings.
Insert the smallest end of the bush into the hole
by lightly pushing and turning at the same time.
If the bushes are tight use a lubricant on the ‘O’
ring. Ensure bushes are fully home before use.
When using jig ensure location bushes do not
foul workbench.
Margin Distance
Allow 8.5mm when cutting joints. Measure or
use a batten of this
thickness to aid
setting out.
Cutter
Sub base
Guide bush
30mm Ø
Location
bush
Worktop
Template
8.5mm
O ring
Location
bush
In order to prevent breakout of the
laminate, rotation of the cutter and
feed direction must always be into the
postform edge of the worktop.
28mm
Plan view
of joints
Right hand joint
Male
Female
Male
Female
Cut male with laminate down
Cut female with laminate up
Postform edge
The joint takes up 28mm, this should
be allowed for with extra material in the
length of the male worktop.
Male
Female Postform edge
PENINSULAR
Postform edge
Postform edge
Male
Female
Left hand joint Cut male with laminate up
Cut female with laminate down
MANU-TT-650 v2 17/7/06 4:14 pm Page 7

-8-
TT/KWJ650
616 650
640600500400
B
FF
M
M
B
616 650
640600500400
B
F
router accessories
-TECH
T
TM
616 650
640600500400
B
FF
M
M
B
router accessories
-TECH
T
TM
Routing the female part of the Joint
Setting the Length Stop
Location bushes in
female hole
Length stop
bush
Postform
edge
Router feed
direction
Quick action clamp here
OPERATION
Setting the Length Stop for the
Female Cut
Carry out the setting operation first:
■With the label side uppermost fit the length
stop bush in one of the two holes
depending on the width of the worktop. If
worktop is not 400mm, 500mm, 600mm,
616mm or 650mm, a packing piece, or a
new hole to correct position will suffice.
Female Joint
■Fit two location bushes in female holes (F)
as shown. (The label must be uppermost.)
Leave the length stop bush in position.
■Place the template onto the worktop to be
cut, ensuring the location bushes are
touching the worktop. Now cramp securely
in position using two quick action clamps
(with minimum of 100mm throat) ensuring
they will not foul the router path.
■Set cutter depth.
■Plunge router and cut joint in a series of
passes, feeding left to right.
When cutting a joint, hold the router
guide bush hard against the template
and cut from left to right. It is
recommended that the depth stops of
the router are used to set the depths
of cut. Several shallow passes of the
router should be made and it is not
necessary to lean heavily on the
router or the jig. Allow the weight of
the router to rest on the part of the
template which is resting on the
worktop. Ensure router remains
parallel and upright at all times.
MANU-TT-650 v2 17/7/06 4:14 pm Page 8

-9-
TT/KWJ650
Male Joint
Depending on accessibility lay female worktop
into position on units. Lay male worktop on top
and support other end. Using a pencil draw
round the female cut onto the male from
underside. If inaccessible lay female onto male.
Depending on a right or left hand joint, the pencil
line may need to be transferred on to the other
side. Due to the difference between the cutter
and the guide bush diameters, the cutter path
will be 8.5mm over from the edge of the
template, therefore either measure 8.5mm or
use a packing piece of this size to offset the
template by this amount to ensure the cutter cuts
along the pencil line.
The postformed edge of the worktop must
always be in contact with the location bushes,
this means that to cut a male right hand joint, the
worktop must be inverted. Remembering to cut
into the postformed edge.
■Insert two location bushes into male holes (M)
as shown, label facing down.
■Place template across the width of the
worktop and clamp securely to worktop.
■Set cutter depth. Plunge router and cut the
male joint before finally cutting the work-top to
length. A series of passes should be made
feeding from left to right.
Out-of-square Joints (max 3°)
Only the male cut needs to be adjusted if an out-
of-square joint is required. On out-of-square
joints there is a possibility of the chipboard core
of the worktop becoming exposed which will
need to be hidden with sealant.
Depending on accessibility mark out an out-of-
square joint, first lay the female board on the
cupboard carcass in position. Next lay the male
section of board on to the carcass and on top of
the female section of the board. Support other
end. Mark around the female joint onto the male
section of board.
If inaccessible lay female onto male.
■Use only the one location bush in the male
hole indicated (M).
■Swing the template to suit the angle required
and clamp down.
■Remember to allow an 8.5mm gap between
template and cutting line.
Routing the male part of the Joint
616 650
640600500400
B
FF
M
M
B
Quick action
clamp here
Direction of
router travel
Postform edge
Location bushes
in male hole
*Please Note:
Out-of-square joints are possible, but the
finished joint will not be as good as a 90° joint.
Cutting out-of-square male joint
616650
640
600
500
400
B
F
F
M
M
B
Quick action
clamp here
Use only one male
location hole
Direction of
router travel
Postform edge
Shown exaggerated
MANU-TT-650 v2 17/7/06 4:14 pm Page 9

-10-
TT/KWJ650
Cutting the Bolt Recesses
When the joint has been tested, proceed as
follows to cut the recess for panel butt
connectors on the underside of the worktop.
The same cutter and guide bush are retained
and used with the integral bolt recess slots in
the jig to produce the recesses for the panel butt
connectors. The bolt recess position can be
gauged approximately 150mm from the edge of
the postform edge, or where access is possible
with kitchen units. Mark with pencil both
positions on the underside of the worktop.
Insert the location bushes into the bolt recess
holes (B) as shown.
■The template may need to be inverted when
cutting some bolt recesses.
■Securely clamp jig to worktop.
■The bolt recesses should be approximately
20mm deep although this will depend upon
the thickness of worktop.
■Once one bolt recess is cut move jig over to
the remaining pencil lines and repeat.
■Repeat the procedure for the male joint.
Best results are achieved when the
centre line of the bolt corresponds to
the centre line of the worktop. Clamp
jig securely to worktop.
Strengthening the Joint
If the joint between the worktops is not supported
underneath, after some time the joint may ‘sag’
and become misaligned; to reduce this the joint
should be reinforced with a loose tongue or
biscuit dowels. The T-TECH biscuit jointing
cutter set Ref. TT/48 can be used with a portable
router. The size of biscuit used should be No.
20.
Ref. TT/BSC/20 (100 biscuits)
A 650mm worktop should have at least 5 biscuits.
Routing the bolt recess in the
female part of the joint
616 650
640600500400
B
FF
M
M
B
router accessories
-TECH
T
TM
Quick action
clamp here
150mm
Location bushes in
bolt recess hole
Pencil
mark
Direction of
router travel
Underside of worktop
Quick action
clamp here
Pencil
mark
Routing the bolt recess in the
male part of the joint
150mm Location bushes in
bolt recess hole
Pencil
mark
Direction of
router travel
Quick action clamp here Underside of
worktop
Postform edge
Pencil
mark
Underside View
Worktop Recess
Thickness Depth
30 22mm
40 28mm
MANU-TT-650 v2 17/7/06 4:14 pm Page 10

-11-
TT/KWJ650
Sealing the Joint
The cut edges of the joint should be coated with
a water-resistant adhesive, or worktop sealant
before assembly, to prevent moisture seeping
into the core of the worktops, which would swell,
and disfigure the worktop.
Use a fine grit abrasive paper to clean up the
torn wood chips of both mating surfaces. Lightly
run the abrasive paper along the edges to de-nib
the cut chipboard edge. This will ensure a tidy
joint is achieved.
MAINTENANCE
The jig has been designed to operate over a
long period of time with a minimum of
maintenance. Continual satisfactory operation
depends upon proper tool care and regular
cleaning.
■Cleaning
Regularly clean the jig with a soft cloth.
■Lubrication
Your jig requires no additional lubrication.
RECYCLING
Jig, accessories and packaging should be sorted
for environmentally friendly recycling.
GUARANTEE
The jig carries a manufacturers guarantee in
accordance with the conditions on the enclosed
guarantee card.
No.20
PVA
SEALANT
Waterproof
Biscuit
MANU-TT-650 v2 17/7/06 4:14 pm Page 11

-12-
TT/KWJ650
TT/KWJ650 SPARE PARTS DIAGRAM
616 650
640600500400
B
FF
M
M
B
router accessories
-TECH
T
TM
1
234
TT/KWJ650 - SPARE PARTS LIST v1.0 03/2004
No. Qty. Desc. Ref.
1 1 TT/KWJ650 Jig TT/KWJ650
2 1 Alloy Bush for KWJ (pack of 3) TT/KWJ/BPK
3 1 Combi Jig ‘O’ Ring Pack for Bushes (pack of 5) CJ/ORS
4 1 Manual MANU/TT/650
v1.0 03/2004
MANU-TT-650 v2 17/7/06 4:14 pm Page 12

-IB-
TT/KWJ650
Fault Cause Remedy
■Joint does not fit correctly Cutter or guide bush is the Check concentricity of cutter
at the radius. incorrect diameter or location with guide bush. Cutter 12.7mm
bushes are not against diameter with 30mm diameter
worktop edge. guide bush. Ensure location
bushes touch worktop.
■The back edge of the joint Either the length stop or Check position of length stop
does not line up. template was in the incorrect and re-cut joints.
position, or the worktop has
not pushed up against the
length stop when the joint
was cut.
■When clamped together the The guide bush has drifted away Check with a straight edge
joint has irregular gaps. from the edge of the template which part of the joint is uneven
whilst cutting either part of the and re-cut (this can only be
joint, or wood chips in particle done on the male cut) ensuring
board have torn slightly. that the guide bush is kept
against the template by
machining from left to right. Use
abrasive paper to remove torn
wood chips.
■Chipped laminate Can be caused by a blunt cutter Always use sharp cutters and
or removing too much material when cutting through the
at one pass or exiting out of laminate cut 3–4mm of material.
postform edge. Maintain correct feed direction,
to ensure cutter enters
postform edge.
■Jig slipping on material Clamps not secure or too deep Check clamps for wear. Clamp
a cut being made or cutter is securely, take shallow passes,
blunt. use a sharp cutter.
■Cut joints not square Router has tilted or operator Ensure jig is supported and do
has leaned heavily on router not push hard on router taking
causing jig flex. shallow passes. Ensure weight
of router is on supported part
of jig and that the router is
upright.
■Assembled joint not flush Worktop different thickness or Ensure worktop is same
or bowed worktop not flat (cupped). thickness and flat.
TROUBLE SHOOTING
MANU-TT-650 v2 17/7/06 4:14 pm Page 13

© Copyright Trend 2006. No part of this publication may be reproduced, stored or transmitted in any form without prior permission. Our
policy of continuous improvement means that specifications may change without notice. Trend Machinery and Cutting Tools cannot be
held liable for any material rendered unusable or any form of consequential loss. E&OE
Trend Machinery & Cutting Tools Ltd.
Technical Hotline: ______________01923 224681
Email: [email protected]
Web: ________________www.trendmachinery.co.uk
RECYCLABLE
MANU/TT/650 v2.0
MANU-TT-650 v2 17/7/06 4:14 pm Page 14

400, 500, 600, 616, 640, 650mm
INCLUDES:
3 x Setting Bushes
1 x Instruction Manual
REQUIRES:
1/2” Collet Plunge Router
1/2” x 50mm TCT Router Cutter
Ref. TT/50X1/2TC
30mm Guide Bush
Ref. TT/GB30/B
Universal Sub-base for Guide Bush
Ref. TT/UNIBASE*
Two 100mm (4”) Throat Clamps
Panel Butt connectors
Ref. TT/PC/10M
*For certain makes and models of routers
FOR CREATING A
KITCHEN WORKTOP
JOINT WITH A
ROUTER
Made from durable
12mm thick phenolic.
JOINT
Trend Machinery & Cutting Tools Ltd.
Technical Hotline: ____________01923 224681
Email: [email protected]
Web: ____________www.trendmachinery.co.uk
TT/KWJ650
WORKTOP WIDTH
400mm 650mm
650mm TRADE
KITCHEN WORKTOP
JIG
Router and worktop not included
