TRENDnet TV-IP512WN - ProView Wireless N Internet Surveillance... User manual

TV-IP512WN
H/W: V1
Quick Installation Guide

Table of Contents
Table of Contents
English ...................................................................................................... 1
1
3
9
1. Before You Start
2. Hardware Installation and Configuration .............................................
.................................................................................
Troubleshooting ........................................................................................
Version 04.09.2009

1. Before You Start
1
English
System Requirements
Package Contents
?
?Utility CD-ROM
?Multi-Language Quick Installation
Guide
?2 x 2dBi Detachable Antenna
?
?Mounting Kit
?AC Power Adapter (12V, 1.5A)
TV-IP512WN
RJ-45 Cable
?
?CD-ROM Drive
?
?
?
?
?
?Wireless router or access point
?An available DHCP Server –routers usually have a built-in DHCP server.
10/100Mbps Ethernet Adapter
CPU: 2GHz processor or above
Memory: 256MB RAM or above / 512MB RAM or above (Windows Vista)
Windows 2000/XP/Vista
VGA Resolution: 800 x 600 or above
Web Brower: Internet Explorer (6.0 or higher)

Application
2
English
Power + Data (PoE)Power + Data (PoE)
PoE Internet Camera
Server with Audio
(TV-IP512P)
300Mbps Wireless N
ADSL2/2+ Modem Router
(TEW-635BRM)
Wireless N Internet Camera
Server with 2-Way Audio
(TV-IP512WN)
PoE Internet Camera
Server with Audio
(TV-IP512P)
Internet
24-Port 10/100Mbps Web Smart PoE switch
with 4 Gigabit Ports and 2 Mini-GBIC Slots
(TPE-224WS)

2. Hardware Installation and Configuration
3
2. Click Run autorun.exe
(Windows Vista only)
3. Click Setup Winzard.
1. Insert the Utility CD-ROM into your
CD-ROM drive.
Note:
1. It is recommended that you configure the IP Camera from a wired computer.
2. If you would like to use IPViewPro 2.0 software, please install the software
by clicking the Install IPView Pro 2.0 in the Autorun window and refer to the
User's Guide on the CD for more information.
4. Click Next. Then follow the Setup
Wizard instructions.
English

4
7. Attach the 2 antennas to the IP
camera.
8. Connect a RJ-45 network cable
from a Switch/Router to the
Ethernet port on the IP Camera.
9. Connect the AC Power Adapter to
the IP Camera and then to a power
outlet.
6. Double click on the SetupWizard
icon on your desktop.
5. Click Close.
10. Click Next.
English

5
11. Select the IP camera and click
Next.
14. Select DHCP and then click Next.
15. Click I want to use wireless for
the camera and then click Next.
12. Enter your ID and password.
Then click Next. By default:
ID: admin
Password: admin
13. If you would like to change the
administrator password, click
Change Password, enter a new
password, retype the new
password and then click Next.
English

6
Note: The TV-IP512WN will not work wirelessly until you disconnect the
Ethernet cable from the back of the camera.
16. Select your wireless network from
the dropdown list. The correct
wireless settings will be
automatically configured. If you
have Encryption enabled, please
enter your Encryption Key. Then
click Next.
17. Configure the Camera Name and
Camera Time. Then click Next.
18. Click Next.
19. Please wait while the settings on
your cameras are being saved.
20. Disconnect the RJ-45 cable and
unplug the power. Then plug the
power back in. Then verify the
Power and Link LEDs are on.
English

7
21. Click on the following URL or click
Link to open up the browser
configuration.
22. Right click on the yellow bar and
select Install ActiveX Control.
24. Right click on the yellow bar and
select Install ActiveX Control.
23. Click Install.
25. Click Run.
English

27. Use the command icons to control
the camera.
English
8
Your installation is now complete.
Note: For detailed information regarding the TV-IP512WN configuration and
advanced settings, please refer to the Troubleshooting section, User's Guide on
the Utility CD-ROM, or TRENDnet's website at http://www.trendnet.com.
Register Your Product
To ensure the highest level of customer service and support, please take a moment to
register your product Online at: www.trendnet.com/register
Thank you for choosing TRENDnet
26. Live Video will now appear.
