TRENDnet TV-IP751WC User manual

TV-IP751WC
rev: 08.28.2012
Wireless Cloud Camera
TV-IP751WC (v1.0R)
TRENDnet’s Wireless Cloud Camera, model TV-IP751WC, takes
the work out of viewing video over the internet. Previously to view
video remotely, users needed to perform many complicated and time
consuming steps: such as signing up for a third party dynamic IP
service and reconfi guring their router. The TRENDnet Cloud service
removes all of these complicated steps. Users simply open a web
browser and log into the TRENDnet Cloud with their unique password
to view and manage this camera. A free App for mobile devices brings
live video to smart phones and tablets.
ABOUT THE TV-IP751WC
Wireless n technology connects the camera to a wireless network and provides unsurpassed wireless coverage and improved streaming video quality. Add this camera to
your wireless network at the touch of a button with Wi-Fi Protected Setup (WPS). The TV-IP751WC offers 640 x 480 (VGA) video at up to 20 frames per second (fps),
one-way audio, motion detection recording, scheduled recordings, email alerts, date and time overlay, and four times digital zoom. A wall / ceiling mounting kit is included and
the camera’s off white housing blends into most environments.
PRODUCT OVERVIEW
• Easy remote camera viewing with free TRENDnet Cloud service
• High speed wireless n connection
• Program motion detection recording, email alerts and more
• One-way audio
• Wall / ceiling mounting kit
• Free mobile App
ABOUT SECURVIEW PRO MANAGEMENT SOFTWARE
Users can either control each TRENDnet camera individually or can use the free included enterprise class SecurView Pro software to manage up to 32 cameras. SecurView
Pro is compatible with Windows and Microsoft Server operating systems and supports all current TRENDnet cameras.
SecurView Pro provides users with extensive camera viewing options. Users can defi ne a combination of weekly recording schedules and motion detection recording;
program motion detection areas of any shape; set date, time, and text overlays; and defi ne mask overlays to conceal sensitive areas.
Zero loss architecture provides the ability to record a single video stream to multiple locations simultaneously. Manage recorded fi les by time or by storage space. A
navigation timeline of stored video provides a quick visual reference of recorded content.

TV-IP751WC
rev: 08.28.2012
Wireless Cloud Camera
TV-IP751WC (v1.0R)
TRENDNET CLOUD SERVICE
• Free cloud service
• Automatically connects to a TRENDnet Cloud camera over the internet
• Cloud service eliminates the previous requirement to sign up for a Dynamic DNS service and reconfi gure your router and IP
camera
• Cloud camera requires internet connection
• Each camera accessed individually with unique web address (URL)
• Password protected cloud service
• Access to live video
• Full camera management with adequate network connection
• A single camera can be viewed remotely by multiple users concurrently
• The number of concurrent users is limited by ISP network bandwidth
• Remotely view multiple cameras on the same local area network (LAN)
• The number of viewable cameras is limited by ISP network bandwidth
• Cloud App for mobile devices (iOS®and Android®support)
FEATURES
• Wi-Fi compliant with IEEE 802.11n standard
• Backwards compatible with IEEE 802.11g and 802.11b devices
• One touch Wi-Fi Protected Setup (WPS) connection button
• 1 x 10/100 Mbps Ethernet port (for optional wired installation)
• Power and activity LED indicators (can be disabled)
• 1-way audio
• Reset button
• 4x digital zoom
• Dynamic DNS support
• Supports up to 640 x 480 pixel MJPEG resolution at up to 20 frames per second
• Compression rate: Very Low, Low, Medium (default), High, and Very High
• Image controls: brightness, contrast, saturation, light frequency, fl ip image vertically, mirror image horizontally
• Defi ne a recording schedule or motion detection recording
• Create motion detection fi elds over the viewing area
• Supports TCP/IP networking, email, HTTP, and other internet protocols
• System controls:
• Defi ne up to 64 user login accounts
• Set the date and time or synchronize with an NTP server
• Supports wireless encryption up to WPA2-PSK
• Quick Universal Plug and Play (UPnP) installation
• Mounting base and mounting hardware included
• 3-year limited warranty

TV-IP751WC
rev: 08.28.2012
Wireless Cloud Camera
TV-IP751WC (v1.0R)
SECURVIEW PRO CAMERA SOFTWARE FEATURES
• Manage up to 32 cameras*
• Compatible with Windows and Microsoft Server 2008
• Multiple language support
• Camera Viewing
• Preset viewing modes
• Program custom viewing modes
• Full screen view
• Drag and drop live feeds to a new location
• Program camera cycle viewing sequence
• Motion detection brings video forward
• Side, top, and bottom tool bars can be hidden
• Web based access from smart phones and tablets
• Recording options
• Program weekly recording schedules
• Motion detection recording
• Defi ne motion detection areas of any shape
• Defi ne motion detection sensitivity
• Event trigger recording
• Date and time overlay
• Mask overlay to conceal sensitive areas
• Save a single video stream to multiple locations simultaneously
• Defi ne recording quotas by recording time or space allocation
• Disk clean feature condenses and optimizes old fi les
• Real time recording stats to help manage fi les
• Search and Playback
• Navigation timeline provides a quick visual reference to the recorded content
• Search continuous recordings by motion
• Search recordings by motion within a defi ned fi eld (a portion of the viewing area)
• Time lapse playback search
• Map cameras on an image such as a fl oor plan
• Map cameras on Google Maps™
*Monitoring multiple cameras may require a high performance CPU

TV-IP751WC
rev: 08.28.2012
Wireless Cloud Camera
TV-IP751WC (v1.0R)
SPECIFICATIONS
CAMERA
General • Sensor: 1/5” CMOS Sensor
• Board Lens
• Focal Length: 4 mm
• F/No: 1.5
• Minimum illumination: 1 lux
• Focus Depth: 20 cm ~ infi nity
• View:
• Horizontal: 38°
• Vertical: 28.7°
• Diagonal: 46.5°
• Digital Zoom: 4x
Audio • Built-in omni-directional microphone
• Sensitivity: -38 dB +/- 3 dB (5 meters max.)
• Frequency: 100~20000 Hz
• S/N: >60 dB
• Format: PCM
HARDWARE
Network • IEEE 802.3u 10/100 Mbps Fast Ethernet
LED • Power, Link / Act
WPS Button • Enable WPS connection
Reset Button • Reset to factory default
Power Consumption • Max 5 watts
Power • Input: 100~240 V, 50/60 Hz, 0.2A
• Output: 5V, 1.2A external power adapter
Dimension • 75 x 115 x 30 mm (2.95 x 4.5 x 1.2 in.)
Weight • 110 g (3.8 oz)
Temperature • Operating: 0°C ~ 40°C (32°F ~ 104°F)
• Storage: -15°C ~ 70°C (5°F ~ 158°F)
Humidity • Max 90% (non-condensing)
Certifi cations • CE, FCC
REQUIREMENT
Management Interface • Internet Explorer 7.0 or higher
• Firefox 3.5 or higher
• Safari 4.0 or higher
• Google Chrome 19.0 or higher
To Run software • Windows 7 (32/64-bit), Vista (32/64-bit), XP (32/64-bit)
• Windows Server 2003, 2008
SecurView Pro Software • Channel: supports up to 32 cameras
• Record / Playback / Motion Detection / Audio
Network Protocols • IPv4, ARP, TCP, UDP, ICMP
• DHCP Client, NTP Client, DNS Client, DDNS Client, SMTP Client, FTP Client
• HTTP
• PPPoE
• UPnP

TV-IP751WC
rev: 08.28.2012
Wireless Cloud Camera
TV-IP751WC (v1.0R)
SPECIFICATIONS
WIRELESS
Standard • IEEE 802.11b, 802.11g and 802.11n
Frequency • 2.4 ~ 2.497 GHz ISM band
Modulation • DQPSK, DBPSK, DSSS and CCK
Antenna • Built-in 2 dBi antenna
Data Rate • 802.11b: up to 11 Mbps
• 802.11g: up to 54 Mbps
• 802.11n: up to 150 Mbps
Security • 64/128-bit WEP, WPA / WPA2-PSK
Output Power • 802.11b: 17 dBm (typical)
• 802.11g: 14.5 dBm (typical)
• 802.11n: 14.5 dBm (typical)
Receiving Sensitivity • 802.11b: -89 dBm at 11 Mbps
• 802.11g: -74 dBm at 54 Mbps
• 802.11n: -71 dBm at 150 Mbps
Channels • 1~11 (FCC), 1~13 (ETSI)
MANAGEMENT
Accounts • Up to 64 user accounts
Remote Login • Remote management supported
Backup / Restore • Save / retrieve confi guration fi les
Cloud Link • Display status and URL, enable / disable, refresh
SETTINGS
Image • Brightness, contrast, saturation, light frequency, fl ip, mirror (horizontal / vertical)
Video Setting • Encoding: MJPEG
• Resolution and frame rate: VGA @ 20 fps, QVGA @ 30 fps, QQVGA @ 30 fps
• JPEG quality: Very Low, Low, Medium (default), High, Very High
Recording • Event based (motion detection) and scheduled
Snapshot • Trigger event: motion detection
• Action: send alert email and / or upload to FTP
• Real time snapshot
Port Settings • HTTP port: 80 (default)
Time • Synchronize with NTP server or PC, or set time / date manually

Wireless Cloud Camera
TV-IP751WC (v1.0R)
CONTACT INFORMATION
20675 Manhattan Place,Torrance, CA 90501 USA
Tel: [phone]
Fax: [phone]
Web: www.trendnet.com
Email: [email protected]
1-888-326-6061
PACKAGE CONTENTS
TV-IP751WC
CD-ROM (Utility, software, & User’s Guide)
Multi-Language Quick Installation Guide
Network cable (1.5 m / 5 ft.)
Power adapter (5V DC, 1.2A)
Camera mounting kit
RELATED PRODUCTS
TV-IP751WIC Wireless Day / Night Cloud Camera
TV-IP851WC Wireless PTZ Cloud Camera
TV-IP851WIC Wireless Day / Night PTZ Cloud Camera
