TRENDnet TE100-S16D User manual

1.01
16-Port 10/100Mbps Switch (TE100-S16D)
24-Port 10/100Mbps Switch (TE100-S24D)
ŸQuick Installation Guide (1)
ŸTechnical Specifications (3)
ŸTroubleshooting (4)

1
System Requirements
Package Contents
If any of the above contents are missing, please contact your reseller.
1. Before You Start
ŸComputer with network adapter installed
ŸCat. 5, Cat. 5e or Cat. 6 Network Cable
ŸThe surface must support at least 1.72 kg (3.8 lbs.) for the Switch
ŸThe power outlet should be within 1.8 m (6 ft) of the switch
ŸMake sure that there is proper heat dissipation and adequate ventilation
around the Switch
ŸDo not place heavy objects on the switch
ŸTE100-S16D/TE100-S24D
ŸMulti-Language Quick Installation Guide
ŸPower Adapter (5V DC, 2A)
2. Hardware Installation
1. Connect the Power Adapter to the TE100-S16D/TE100-S24D and then to a
power outlet.

2
3. LEDs
3. Move the power switch to the on position.
2. Connect a Cat.5, Cat. 5e or Cat.6 RJ-45 network cable from the computer to
an available Ethernet port on the TE100-S16D/TE100-S24D.
POWER
ŸGreen: Power is on
ŸNot Illuminated: Power is off
LINK/ACT
ŸGreen (Solid): Connection to the port is 100/200Mbps (Half/Full Duplex) or
10/20Mbps (Half/Full Duplex)
ŸGreen (Blinking): Data transmitting/receiving at 10/20Mbps (Half/Full
Duplex) or 100/200Mbps (Half/Full Duplex)
ŸNot Illuminated: Nothing is detected on the port

Technical Specifications
Network Media
Standards
Switch Fabric
Diagnostic LED
Filtering Table
Power
CSMA/CD, Star
TE100-S16D TE100-S24D
ŸEthernet: 10Mbps/20Mbps (half/full-duplex)
ŸFast Ethernet: 100Mbps/200Mbps (half/full-duplex)
ŸEthernet: UTP/STP Cat. 5 up to 100 m
ŸFast Ethernet: UTP/STP Cat. 5, 5e, 6, up to 100 m
ŸIEEE 802.3 10Base-T
ŸIEEE 802.3u 100Base-TX
ŸIEEE 802.3x Flow Control
4.8 watts (max.)
265 x 122.7 x 41 mm (10.4 x 4.8 x 1.6 in.)
Power, Link/ACT
3.2Gbps forwarding
capacity
4.8Gbps forwarding
capacity
1.25Mbits 1.75Mbits
4K entries 8K entries
1.72 kg (3.8 lbs.)
5V DC, 2A external power adapter
Data Rates
Protocol / Topology
Power Consumption
Interface 16 x 10/100Mbps
Auto-MDIX RJ-45 ports
24 x 10/100Mbps
Auto-MDIX RJ-45 ports
Data RAM Buffer
Dimension
Weight
Temperature
Humidity
Certification
Hardware
ŸOperating: 0° ~ 40° C (32° ~ 104° F)
ŸStorage: -10° ~ 70° C (14° ~ 158° F)
Max. 90% (non-condensing)
CE, FCC
4.65 watts (max.)
3

Troubleshooting
4
1. After connecting the Switch to a power outlet, the LEDs do not turn on.
1. Check the connection of the power adapter to the TE100-S16D/
TE100-S24D and the power outlet.
2. Check that the power outlet is receiving power.
2. After I connect my PCs to the Switch, I am unable to share files.
1. Check the LEDs on the Switch. Make sure the LINK/ACT LED is on.
2. Check the network cable. The minimum length of the cable is 1.5 m and
the maximum length of the cable is 100 m.
3. Disable any software firewall program.
4. Verify that you have file sharing enabled. Please contact your Operating
System support for more information.
3. After I connect my PCs to the Switch, I can only get onto the Internet
from one computer.
The Switch was not designed to share Internet between multiple computers.
You need to get an Internet router such as the TEW-652BRP.
4. Where is the uplink port located on the Switch?
Since all the ports on the Switch are Auto-MDIX, any of the ports can be
used as an uplink port.
If you still encounter problems or have any questions regarding the
TE100-S16D/TE100-S24D please contact TRENDnet's Technical Support
Department.
