ABOUT THIS GUIDE
The 2/4 Port USB KVM Switch or 2/4 Port USB KVM Swith
with Audio lets you manage 2/4 computers with just one set of
keyboard, monitor, mouse, and a set of speakers and
microphone (TK-209 & TK-409 only ). The device comes
with 2/4 sets of USB KVM and/or Audio cables, no additional
equipment required. The USB console port provides support for
the latest USB keyboard and mouse. Popular hardware
platforms such as PC, Linux and Macs are supported. Users can
switch between PCs using hot-key, push button, or provided
Windows-based software application for flexible management.
Users can also hot-plug PCs on the fly to avoid downtime. Its
compact size makes it ideal for home and business environment.

- 3 -
Package Contents
Unpack the package and check all the items carefully, and be certain
that you have:
♦1 x TK-207/TK-407/TK-209/TK-409 USB KVM Switch.
♦1 x Utility CD-ROM
♦Multi-Language Quick Installation Guide
♦2/4 Sets of USB KVM Cables
♦2/4 Sets of Audio Cables (for TK-209 & TK-409 models only)
If any item is damaged or missing, please contact your local dealer
immediately. Also, keep the box and packing materials in case you
need to ship the unit in the future.
System Requirements
♦Operating System:
Microsoft Windows 95/98/ME/NT/2000/XP/2003 Server.
Linux, Mac OS.
♦Type A USB keyboard
♦Type A USB mouse
♦VGA or SVGA Compatible Monitor
♦Microphone and Speaker (optional)

- 4 -
General Features
♦Management 2/4 Computers
♦2/4 ports USB KVM Switch with 1 set of Microphone/Speaker port.
(Audio ports for TK-209 & TK-409 models only)
♦2/4 sets of USB KVM Cables
♦2/4 sets of Audio & Microphone Cables (for TK-209 & TK-409
models only)
♦Supports Microsoft IntelliMouse, Optical Mouse, Logitech Net
Mouse and more
♦Supports super High Video Quality, up to 2048 x 1536 VGA
resolution
♦Supports Windows 98/98SE/ME/2000/XP/2003 Server, Linux, and
Mac OS
♦Multi-Platform supports for PCs, Macintosh G3/G4, iMac and Mac
Mini
♦Hot-Plug pluggable. Adds PCs or removes the connected PCs
for maintenance without powering down the KVM Switch or other
PC’s.
♦Switches PC by hot-keys, push button or Windows-Base Client
Switching software
♦Auto-Scan & LED display for easy status monitoring
♦User definable hot-key (Windows Only)
♦USB Interface Power method
♦2-Year Warranty

- 5 -
Installing the KVM Client Switching
Software
Insert the Installation CD-ROM into your computer’s CD-ROM drive
to initiate the Auto-Run program, and the menu screen will appear as
below.
1. Click Client Switching Software from the Auto-Run menu
screen. The welcome screen appears as below. Click Next >.

- 6 -
2. When completed, click Finish.

- 7 -
3. After installing the utility, the Client Switching Software is
automatically installed to your computer, and creates a folder in
Start\Program\USBKVM Switcher.
4. After the installation is completed, you will see a KVM Switch
icon on the system tray of your window desktop. Just right click
to evoke the operation menu and double-click to evoke
configuration box. For operation details of the KVM Switcher
software, please refer to the Operation Reference.
: No live connection detected
: Current active PC channel is on port 1
: Current active PC channel is on port 2
: Current active PC channel is on port 3
(TK-407K & TK-409K only)
: Current active PC channel is on port 4
(TK-407K & TK-409K only)

- 8 -
5. Connects the shared USB keyboard, mouse, monitor,
microphone/speakers (optional) to your KVM Switch
6. Connects each KVM PC port to a computer via included USB
KVM Cables. After you have connected the KVM and computers
properly, the KVM Switch is ready to use.
NOTE:
•The KVM Switching software only supports Windows
operating system on PC Platforms. For the other platform
such as Linux, you can still use the keyboard hotkey
“ScrLK + ScrLK” to switch between PCs. Mac OS only
supports push buttons function.
•Some computers with USB interface might be need to
manual enable the USB option in the BIOS setting before
using any USB device. If your USB interface does not
work, please check the USB option Status in BIOS.
•If you are using the Windows 98(SE) and has not installed
a USB mouse yet, it is highly recommend that you connect
the USB mouse directly to computer first before it connects
to KVM Switch.

- 9 -
Operate the KVM Switch
There are three methods to control your KVM Switch for PCs.
(1) face-panel push button
(2) hotkey sequence
(3) KVM Client Switching Software
Face-panel button
The face-panel button allows you a direct control over KVM
switching operation. Simply press the button to switch to the
corresponding PC port.
You can use the face-panel button to switch to an empty port that is
not connected with any computer. Normally, if you use keyboard
hotkeys or the KVM Switching software, you will not be able to
switch to an empty port.
Keyboard hotkeys
User-definable hotkeys for PC selection:
Hotkey sequence = Ctrl + Alt + [command key]*
Universal hotkey for PC toggle-switching:
* Please refer to next section for keys that are qualified to be used as
a command key

- 10 -
NOTE:
•Both the universal hotkey, ScrLk + ScrLk and the user-
definable hotkey, Ctrl + Alt + [command key] WILL NOT
allow you to switch to an empty port that is not connected
with any computer. To force your KVM to switch to an empty
port, just press the face-panel button to switch.
Universal Hotkey sequence = ScrLk + ScrLk
* For other operating systems on PC such as Linux, you can still
use this special hotkey to facilitate PC switching. This special
hotkey is not available for Mac. However, you can press button to
switch in any case.
•Each keystroke within a hotkey sequence should be pressed
within 2 seconds. Otherwise, the hotkey sequence will not be
validated.
•After perform port switching, you have to wait till the KVM
Switch icon shows forth the target port before you can
perform next switching again. The KVM Switch icon could be
found on the system tray of your Windows desktop after its
installation.
•All the hotkeys are only functional after your PCs are booting
into the OS. If you want to switch PC in the BIOS/preboot
stage, press the face-panel button to switch.
KVM Switching Software (only for Windows platform)
In addition to PC switching, the KVM Switching Software also allows
you more advanced functions such as described in the next section.

- 11 -
KVM Switch Operation Reference
Switch to PC x by Operation Menu
Right-click the KVM Switching icon from the system tray to evoke
the operation menu, then select whichever PC that is available for
switching. Once you select a PC channel, it will immediately switch to
that PC. Note that the unconnected port(s) or the active port will be
grayed-out and non-selectable.
You can also
Switch to PC x by Keyboard Hotkeys
Hit the hotkey according to your current hotkey definition:
KVM Client Switch
Operation Manual KVM Client Switch
Configuration Dialog Box

- 12 -
Hotkey sequence = Ctrl + Alt + [command key]*
* The factory default hotkey setting is Ctrl + Alt + 1/2/3/4 for PC
1/2/3/4. You can also use ScrLk + ScrLk to switch PC.
Start Auto-scan
Right-click the KVM Switch icon to evoke the operation menu, then
select Start Auto-Scan to activate auto-scanning.
Stop Auto-scan
(While auto-scanning) Right-click the KVM Switch icon to evoke the
operation menu, then select Stop Auto-Scan to de-activate auto-
scanning. Or you can press any button on the face-panel to stop Auto-
scan.
KVM Switcher configuration
Right-click the KVM Switcher icon and select Settings or double-click
the icon to bring up the configuration dialog box.
Define Hotkey commands
You can specify the command key as you like by typing it in. For
example, you can specify the hotkey for switching to PC 1 as CTRL +
ALT + A by typing an A (not case-sensitive) in the editable field.
Hotkey Sequence = CTRL + ALT + [command key]*
* The command key is user-definable via the configuration dialog box
•Except those control keys such as Alt, Ctrl, Shift, CAPS, Tab,
Esc and those functions keys and edit keys, all other keys on
the keyboard, including those number keys on the number pad
are all qualified to be used a hotkey command key. In addition

- 13 -
to the software KVM Switching by the operation menu and
the user-defined hotkeys, you can always use the universal
hotkey for PC switching – ScrLk + ScrLk
Fix Audio Port at PC x (For TK-209K & TK-409K models only)
Check this option and then select the PC to fix the audio/mic channel
to the selected PC. Once this option is checked, the audio/mic channel
will be fixed and become non-switchable.
Auto Scan Period
Select the Autoscan period from 10 ~ 60 seconds with an increment of
5 seconds. The Auto-scan period is the time your KVM Switch will
wait to switch to next PC.
