TRENDnet TEG-448WS - Switch User manual

TEG-448WS 48-Port 10/100/1000Mbps and 4-Slot Mini-GBIC Web-
Based Smart Switch delivers high performance and scalability for
large enterprises. Its Mini-GBIC slots can use either single or
multimode fiber for constructing a high-speed network backbone.
The 48-port Copper Gigabit ports support Auto-MDIX and Auto-
Sensing for troublefree network integration. The TEG-448WS
supports advanced network protocols such as VLAN, QoS,
Trunking, and Mirroring.
TEG-448WS (B1.0R)
48-Port 10/100/1000Mbps Gigabit
Web-Based Smart Switch
TEG-448WS
rev:06.29.2010
• 48 x 10/100/1000Mbps Auto-Negotiation and Auto-MDIX Gigabit Ethernet UTP Ports
• 4 x 1000Mbps Auto-Sense mini-GBIC slots, Share with 4 1000Base-T Ports (Port 45-48)
• Full/Half-Duplex Transfer Mode for each Port
• Store and Forward Switching Architecture
• Integrated address Look-Up Engine with 8K absolute MAC address table
• Supports 1024K bytes RAM Data Buffering
• IEEE 802.3x Flow Control for Full/Half Duplex Mode
• Back Pressure Flow Control for Half Duplex Mode
• Supports Jumbo Frame (up to 9220 bytes), DHCP Client and Port settings
• Supports IEEE 802.1Q VLAN, IGMP Snooping, IEEE 802.1p QoS, Trunking and Port Mirroring
• Port Settings function, users can set each Port's Availability, Speed, Duplex mode and Flow Control
• Easy Window Based Management Utility and Web-Based Configuration
• Extensive Diagnostic LED's on the front panel
• Standard 19” (1U) Rack-Mount Size (Kit included)
• 3-Year Limited Warranty
FEATURES
gigabit

Data RAM Buffer
Network Media
Protocol /Topology
LAN Ports
Data Transfer Rate
Diagnostic LEDs
Power/Consumption
Weight
Humidity
Certification
Dimensions (W x D x H)
Temperature
• IEEE 802.3 10Base-T • IEEE 802.3u 100Base-TX • IEEE 802.3ab 1000Base-T
• 8K Entries
• IEEE 802.3z 1000Base-SX/LX (GBIC) • IEEE 802.3x Full Duplex Flow Control
• 1024KBytes
• Per Unit: Power, System • Per Cooper Gigabit Port: Link/ACT, Speed (1000M-Green, 100M-Amber)
• 440 x 310 x 44 mm (17.32" x 7.9" x 1.73")
• Operating: 10% ~ 90% RH, Storage: 5% ~ 90% RH
• Ethernet: UTP/STP Cat. 3, 4, 5 • Fast Ethernet: UTP/STP Cat. 5 • Gigabit: UTP/STP Cat. 5, 5E, 6
• CSMA/CD, Star
• 48 x 10/100/1000Mbps Auto Negotiation Gigabit Ethernet ports
• 4 x Mini-GBIC slots, Share with 4 1000BASE-T Slots (Share with 4 1000Base-T Ports)
• Per Mini-GBIC Gigabit Port: Link/ACT
• Ethernet: 10Mbps/20Mbps (Half-Duplex/Full-Duplex)
• Fast Ethernet: 100Mbps/200Mbps (Half-Duplex/Full-Duplex)
• Gigabit Ethernet: 2000Mbps (Full-Duplex)
• 4.43kg (9.75 lbs)
• 100-240V AC, 50/60Hz Internal Power Supply / 99.7 Watts (Max)
• Operation: 0°C~ 40°C (32°F~104°F), Storage: -10°C~ 70°C (14°F~158°F)
• CE, FCC
Address Table
Standards
Hardware
TRENDnet is a registered trademark. Other Brands and product names are trademarks of their respective holders. Information provided in this document pertain to TRENDnet
products and is subject to change at any time, without notice. For the most recent product information please visit
http://www.trendnet.com.
©
Copyright TRENDnet. All Rights Reserved.
48-Port 10/100/1000Mbps Gigabit Web-Based Smart Switch
TEG-448WS (B1.0R)
RELATED PRODUCTS
PACKAGE CONTENTS
TEG-2248WS
TEG-160WS
TEG-224WSplus 26-Port Gigabit Web Smart Switch
• Power Cord
• Rack-Mount Kit
52-Port Gigabit Web-Based Smart Switch
• TEG-448WS
16-Port Gigabit Web-Based Smart Switch
• Quick Installation Guide
• Utility CD-ROM
ORDERING INFORMATION
To Order Please Call:
1-888-326-6061
NETWORKING SOLUTIONS
SPECIFICATIONS
20675 Manhattan Place,Torrance, CA 90501 USA
Tel: [phone]
Fax: [phone]
Web:
Email: [email protected]
www.trendnet.com
1000Mbps
Multi-Mode Mini
GBIC Module
(TEG-MGBSX)
Multi-Mode Mini
GBIC Module
(TEG-MGBSX)
Workstations with 10/100Mbps
Fast Ethernet PCI Adapter
(TE100-PCIWN)
Serverss with
Copper Gigabit PCI Adapter
(TEG-PCITXR)
48-Port 10/100/1000Mbps Gigabit Web Smart Switch
(TEG-448WS)
Cable/DSL 4-Port
Broadband Router
(TW100-S4W1CA)
Internet
26-Port Gigabit Web Smart Switch
(TEG-224WSplus)
Workstations with
Copper Gigabit PCI Adapter
(TEG-PCITXR)
VLAN Group 2VLAN Group 1
Cable/DSL
Modem
LC Type Cable
