TRENDnet TEW-630APB - Wireless Access Point User manual

The 300Mbps Wireless N Draft Access Point incorporates the
latest wireless networking technology to supercharged speed,
range and performance of your wireless network. Advanced
antenna technology increases wireless data coverage throughout
homes and businesses. Increased speed and throughput makes
it the perfect solution to fulfill your wireless needs.
TEW-630APB (V2.0)
300Mbps Wireless N Access Point
• Wi-Fi Compliant with IEEE 802.11g and IEEE 802.11b Standards
• High-Speed up to 300Mbps Data Rate using IEEE 802.11n (draft) connection
• Built-in 3 External Antennas (MIMO technology) to support high speed performance and great coverage
• Supports Access Point and WDS Bridge (up to 6 units) Modes
• Supports 64/128-bit WEP(Hex) Encryption
• Supports WPA/WPA2 and WPA-PSK/WPA2-PSK Encryptions
• Supports MAC Address Filter (up to 16 entries) and SSID Broadcast Control
• Built-in DHCP Server and Client and Time Server support
• Flash Memory for Firmware Upgrade and Easy Management via Web Browser (HTTP)
• Compliant with Windows 95/98/NT/2000/XP/2003 Server/Vista, Linux and Mac OS
• Coverage up to 150 meters (500ft.) Indoor (depends on the environment)
• Coverage up to 400 meters (1300ft.) Outdoor (depends on the environment)
• 3 year limited warranty
FEATURES
wireless
**Maximum wireless signal rates are referenced from IEEE 802.11 theoretical specifications. Actual data throughput and coverage will vary
depending on interference, network traffic, building materials and other conditions.
TEW-630APB
rev: 11.05.2008

Interface
Data Rate
Reset Button
LED Indicator
Power Adapter
Power Consumption
Dimension (L x W x H)
Frequency
Security
Receiving Sensitivity
Output Power
Channels
Weights
Humidity
Temperature
Certifications
• Wired: IEEE 802.3 (10Base-T), IEEE 802.3u (100Base-TX) • Wireless: IEEE 802.11b, IEEE 802.11g, IEEE 802.11n (draft)
• 3 x 4dBi Fixed Dipole Antenna
• 1 x 10/100Mbps Auto-MDIX LAN Port
• Operation: 0°~ 40°C (32°F~ 104°F); Storage: -20°~ 60°C (-4°F~140°F)
• CSMA/CA with ACK
• Encryption: Hardware AES/TKIP, 64/128-bit WEP (Hex) • 802.1X/EAP: WPA/WPA2/802.1X authenticator
• 802.11b: -84dBm (typical) @ 11mpbs • 802.11g: -72dBm (typical) @ 54Mbps • 802.11n (draft) : -72dBm (typical) with HT40
• 802.11b: 18dBm (typical) • 802.11g: 15dBm (typical) • 802.11n (draft): 14dBm (typical) with HT20 & HT40
• 1~ 11 (US), 1~13 (EU)
• Reset to Factory Default Settings
• Power, LAN, WLAN
• 12V DC, 1A External Power Adapter
• 320g (0.7 lbs)
• 802.11b: 11Mbps, 5.5Mbps, 2Mbps, and 1Mbps
• FCC & CE
• 2.412 ~ 2.462 GHz (FCC) • 2.412 ~ 2.472 GHz (ETSI)
• WPA: WPA-PSK/WPA2-PSK, WPA-enterprise, WPA2-enterprise • SSID Broadcast Control
• 802.11g: 54Mbps, 48Mbps, 36Mbps, 24Mbps, 18Mbps, 12Mbps, 9Mbps and 6Mbps • 802.11n (draft): up to 300Mbps
• 6W @ 12V DC
• 180 x 122 x 30 mm (6.8 x 4.6 x 1.1 inches)
• Max. 90% (Non-Condensing)
Antenna
Media Access Protocol
Standards
Hardware
Wireless
TRENDnet is a registered trademark. Other Brands and product names are trademarks of their respective holders. Information provided in this document pertain to TRENDnet
products and is subject to change at any time, without notice. For the most recent product information please visit
http://www.trendnet.com.
©
Copyright TRENDnet. All Rights Reserved.
300Mbps Wireless N Access Point
TEW-630APB (V2.0)
RELATED PRODUCTS
PACKAGE CONTENTS
TEW-623PI
TEW-631BRP
TEW-621PC 300Mbps Wireless N-Draft PC Card
300Mbps Wireless N-Draft PCI Adapter
• TEW-630APB
300Mbps Wireless N-Draft Firewall Router
• Multi-Language Quick Installation Guide/ CD-ROM (User’s Guide)
ORDERING INFORMATION
To Order Please Call:
1-888-326-6061
NETWORKING SOLUTIONS
SPECIFICATIONS
• Power Adapter (12V DC, 1A)/ RJ-45 Cable (1.5m)
20675 Manhattan Place,Torrance, CA 90501 USA
Tel: [phone]
Fax: [phone]
Web:
Email: [email protected]
www.trendnet.com
Config Button • Reserved for WPS function use
HD
DATA
300Mbps, share multimedia throughout the house
300Mbps Wireless N
Access Point
(TEW-630APB)
