TRENDnet TEW-453APB - 108Mbps Wireless Super G HotSpot Access... User manual

Copyright ©2005. All Rights Reserved. TRENDware International, Inc.
TRENDnet
TRENDware, USA
What's Next in Networking
TEW-453APB
Version 03.02.2005
Hot Spot Wireless Access Point
Quick Installation Guide
Point d'accès sans fil sensible
Guide d'installation rapide
Drahtloser Access Point für Hotspots
Kurzanleitung zur Installation
Guía de instalación rápida del
punto de acceso inalámbrico Hot Spot

Table of Contents
English ......................................................................................................
Troubleshooting...........................................................................................
1
1
2
3
9
11
1. Prepare for Installation ......................................................................
2. Install Hardware ................................................................................
3. Configure TCP/IP Settings ................................................................
4. Configure the Access Point ...............................................................

Thank you for purchasing TRENDnet's TEW-453APB Hot Spot Wireless
Access Point.
This guide will help you set-up your Access Point quickly and easily. Just follow
the step-by-step instructions below, and enjoy the benefits of accessing the
Internet without ever being tied down to wires! If you run into problems, please
refer to the Troubleshooting section. If you need further technical support,
please visit www.TRENDNET.com or call technical support by phone.
Verify Equipment
Before setting up the Access Point, you should have the following:
1. A computer with Wired (RJ45) or Wireless network card.
2. TCP/IP protocol installed on the Computer.
3. A web browser such as Internet Explorer (5.0 or higher) or Netscape
Navigator (4.7 or higher).
4. A Hub or Switch connecting your existing wired network.
5. An RJ-45 Network Cable for connecting the Access Point to your network
switch.
Verify Package Contents
Please make sure you have everything in the box:
1
Power Adapter
(24V DC, 500mA)
CD-ROM
Quick Installation Guide
TEW-453APB
1. Prepare for Installation
English QIG
English
Copyright ©2005. All Rights Reserved. TRENDware International, Inc.
TRENDnet
TRENDware, USA
What's Next in Networking
TEW-453APB
Version 03.02.2005
Hot Spot Wireless Access Point
Quick Installation Guide
Point d'accès sans fil sensible
Guide d'installation rapide
Drahtloser Access Point für Hotspots
Kurzanleitung zur Installation
Guía de instalación rápida del
punto de acceso inalámbrico Hot Spot

2
1. Locate an optimum location for the Access Point. The best place for the
Access Point is usually at the center of your wireless network.
2. Connect the RJ45 network cable to the Access Point, then connect the other
end of the network cable to a Switch or Hub. The Access Point is now
connected to your 10/100mbps network.
3. Connect the power adapter to the Access Point. Make sure you use the
power adapter supplied with the Access Point; using a different power
adapter may damage the unit.
2. Install Hardware
Make sure the front panel lights are on: Power, LAN, Wireless.
Verify Hardware Installation
NOTE: If you are using a wired computer to configure the Access Point,
please connect this computer to the same Switch or Hub the
TEW-453APB is connected to.
POWER Wireless
LAN
3 22
TEW-453APB
English

3
3. Configure TCP/IP Settings
Before the Access Point can be accessed and configured, the computer's
TCP/IP settings need to be changed.
Windows 98SE/ME
1. Find the Start button located on the Desktop.
2. Click Start, click Settings, and then click on Control Panel.
3. Double-Click the Network Icon, and the Network Properties box will
appear.
4. Under the Configuration tab, locate and select TCP/IP with the
corresponding network card. Then click on the Properties button and the
TCP/IP Properties window will appear.
English

4
5. Under the IP Address tab, click on Specify an IP address and enter
192.168.0.50 for IP address and 255.255.255.0 for Subnet Mask and click
OK.
6. Click OK.
English

5English
7. At this point, the installation may require files from your Windows CD-ROM.
If you are prompted for the location of these files, insert Windows 98 CD-
ROM into your CD-ROM drive and select CD-ROM drive.
8. After the files load, the System Settings Change message appears, click Yes
to reboot your system.
9. Your computer is now ready to access and configure the Access Point.
NOTE: If this message does not appear, restart your computer
manually.

6English
Windows 2000/XP
1. Find the Start button located on the Desktop.
2. Click Start, and click on Control Panel. For Windows 2000, click Start,
highlight Settings, and click Control Panel.
3. Double-Click the Network Connection Icon.
4. Right-Click on the Local Area Connection icon and then click on
Properties. The Local Area Connection Properties box will appear.

7English
5. Under the General tab, locate and click Internet Protocol TCP/IP and then
click Properties. The Internet Protocol (TCP/IP) Properties box will appear.
6. Click on Use the following IP address. Enter 192.168.0.50 for IP address
and 255.255.255.0 for Subnet Mask, and click OK.

8English
7. Click OK.
8. Your computer is ready to access and configure the Access Point.

9
4. Configure the Access Point
From a Wired Computer
1. Open a web browser (Internet Explorer or Netscape) and enter
http://192.168.0.228 in the address bar, then press the Enter key. The TEW-
453APB's authentication window will appear. Type admin for User name,
and type password for Password.
English
2. Click System.

10
3. Select your country from the pull down menu, click Fixed IP Address, and
type in your IP address, Subnet Mask, Gateway, and DNS to match your
current network settings. Click Save.
4. Click OK.
English
5. Click Apply/Restart.
6. The TEW-453APB is now ready for your Wireless Network.

11
Troubleshooting
Q1:
A1:
Q2:
A2:
Q3.
A3:
Q4.
A4:
I specified the IP address http://192.168.0.228 in my Internet browser's
address bar, but an error message says "The page cannot be displayed". How can
I get into the TEW-453APB's web configuration page?
Please make sure that your workstation and the TEW-453APB are in the same
network segment. Make sure you change your workstation's IP Address to
192.168.0.X where “X” is a number from 1 to 227 and 229 to 254. If your
workstation and the TEW-453APB lie in the same network segment, then double-
check the connection between the TEW-453APB and your switch, and make sure
that the power adapters for your switch and the TEW-453APB are plugged in.
After I successfully configured the Access Point to meet my network settings,
I cannot connect to my network using wireless computers.
If you have a DHCP server in your network, you need to go into TCP/IP
settings again and re-select "Obtain an IP automatically" for Windows 98/ME and
"Obtain an IP Address automatically" for Windows 2000/XP to allow the PC to
regain an IP address from your DHCP server.
When I configure the network settings for the TEW-453APB, I don't have a
Domain Name Server, but the TEW-453APB requires a DNS entry. What do I do?
In this case, your DNS entry is the same as your Gateway's entry. So if
your Gateway is 192.168.1.1, then your DNS is 192.168.1.1.
All the settings are set correctly, but I still can't use the Access Point, what
should I do?
You can find additional information in the User's Guide. If you still have
problems, contact our Technical Support by email or phone.
This equipment has been tested and found to comply with FCC and CE Rules. Operation is
subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received including interference that may cause
undesired operation.
