The 9dBi High Power Wireless Outdoor PoE Bridge/Access Point
provides secure Super G (108Mbps) wireless bridging in a durable
all-weather outdoor enclosure. This self-contained product comes
with a built-in directional antenna for professional long distance
wireless bridging applications. External antenna can also be used
for more challenging extended range projects. Power is supplied
through included Power over Ethernet injector, resulting in
equipment and installation cost savings.
Support for the latest wireless security protocols ensures the highest
level of network protection. A rugged UV-resistant aluminum
housing (with mounting brackets), features an IP66 waterproof
rating and delivers optimal performance in extreme weather
conditions. Remote network management using built-in web
interface or SNMP makes this product an ideal solution for rapid
wireless network implementation.
TEW-455APBO
9dBi High Power Wireless Outdoor PoE
Access Point
TEW-503PI (07-28-2005) TEW-455APBO
rev:08.24.2009
• Features Super G technology with data rates up to 108Mbps
• Device powered by an Ethernet cable with Power over Ethernet (PoE) technology
• Rugged waterproof aluminum housing and built-in antenna for extreme weather conditions
• Wireless Super G compatible Access Point with Bridge and Repeater modes
• Add additional high-gain antenna for extended range projects
• Advanced wireless security with 64/128/152-bit WEP (Wired Equivalent Privacy) & WPA (Wi-Fi Protected Access)
• Provides SSID Broadcast enable/disable controls & 802.1x Authentication Protocol support
• Feature rich device supports IPSec, PPTP, and L2TP VPN pass-through
• Flash memory allows firmware upgrades, save/restore settings
• Compatible with Windows 95/98/ME/2000/XP/Vista, Linux and Mac OS
• Range of 802.11b @ 19dBm up to 5 km in Bridge (2 x 9dBi) **
• Range of 802.11g @ 19dBm up to 2 km in Bridge (2 x 9dBi) **
• 3-year limited warranty
FEATURES
wireless

SPECIFICATIONS
LED Indicator
Management
Antenna
PoE
EXT (50ohm)
Dimension (L x W x H)
Wind Speed Support
Waterproof
Humidity
Certification
Frequency
Temperature
Power
• Wired: IEEE 802.3 (10Base-T), and IEEE 802.3u (100Base-TX)
• 7 Watts (Max.)
• Power, WLAN (Wireless activity)
• Web browser (Http), SNMP, Telnet
• 120km/h
• Max. 95% (Non-Condensing)
• CE, FCC
• Built-in 9dBi Patch Antenna, Polarization, V45° H45°
• RJ-45 Connector for Data & PoE Support
• N-Type Female connector (TEW-ASAL1 is required for use with TRENDnet high gain antennas)
• IP66 Compliant
• 250 x 260 x 80 mm (9.8 x 10 x 3.1 inches)
• 1.6kg (3.5 lbs)
• ° ° ° °30 ~ 65 C (-22 F~ 149 F)
• PoE Injector & Power Cord Included
• 2.400 to 2.4835GHz (Industrial Scientific Medical Band)
Weight
Power Consumption
Standards
Hardware
9dBi High Power Wireless Outdoor PoE Access Point
TEW-455APBO
Media Access Protocol
Data Rate (auto-fallback)
Security
Output Power
Receiving Sensitivity
• 802.11b: CCK (11 and 5.5Mbps), DQPSK (2Mbps), DBPSK (1Mbps) • 802.11g: OFDM, 16/64-QAM
• CSMA/CA with ACK
• 802.11b: 11Mbps, 5Mbps, 2Mbps and 1Mbps • 802.11g: 108Mbps, 54Mbps, 48Mbps, 36Mbps, 24Mbps, 12Mbps and 6Mbps
• 64/128/152-bit WEP (HEX/ASCII), WPA-PSK (AES/TKIP) for AP/Bridge, WPA (AES / TKIP) for AP only
• Enable/Disable SSID Broadcast, MAC Address Filtering, VPN Pass-Through
• 19dBm±1max. (Adjustable)
• 802.11b: -87dBm (typical) @ 11mpbs
• 1~11 channel (US), 1~13 channel (EU)
Channels
Module Technique
Wireless
• Wireless: IEEE 802.11g
• 802.11g: -73dBm (typical) @ 54Mbps
TEW-455APBO
rev:08.24.2009

TRENDnet is a registered trademark. Other Brands and product names are trademarks of their respective holders. Information provided in this document pertain to TRENDnet
products and is subject to change at any time, without notice. For the most recent product information please visit
http://www.trendnet.com.
©
Copyright TRENDnet. All Rights Reserved.
9dBi High Power Wireless Outdoor PoE Access Point
TEW-455APBO
RELATED PRODUCTS
PACKAGE CONTENTS
TEW-AO19D
TEW-OA24D
TEW-ASAL1 Outdoor Lightning Arrestor Kit (For TEW-455APBO)
14 dBi Outdoor High-Gain Directional Antenna
• PoE injector & Power cord
• Multi-language quick installation guide
• TEW-455APBO outdoor AP
19 dBi Outdoor High-Gain Directional Antenna
24dBi Outdoor Directional Antenna
• Mounting brackets
ORDERING INFORMATION
To Order Please Call:
1-888-326-6061
OUTDOOR ARRESTOR SOLUTION
TEW-AO14D
20675 Manhattan Place,Torrance, CA 90501 USA
Tel: [phone]
Fax: [phone]
Web:
Email: [email protected]
www.trendnet.com
9dBi High Power Wireless Outdoor PoE Access Point
(TEW-455APBO)
Cable/DSL
Modem Cable/DSL Advanced
VPN Firewall Router
(TW100-BRV304)
Workstations with
PCI Adapter
14 dBi Outdoor High-Gain
Directional Antenna
(TEW-OA14D)
16-Port 10/100Mbps
Fast Ethernet Switch
(TE100-S16R)
Internet
10/100Mbps
Multi-Port Print Server
(TE100-P21)
Printers
Workstation
with
PCI Adapter
Notebook
with
PC Card
Outdoor Surge
Arrestor Kit
(TEW-ASAL1)
• Water-proof RJ45 plug (Ethernet cable not included)
• Grounding wire
• CD-ROM (utility & user’s guide)
** Effective wireless coverage may very depending on the wireless device's
output power, antenna gain, antenna alignment, receiving sensitivity and
radio interference. For optimal results, we recommended that you consult
a professional installer for site survey, safety precautions and proper
installation
