TRENDnet TEW-636APB User manual

The Wireless N Hot Spot Access Point creates a high speed wireless n
network with up to 12x the speed and 6x the coverage of wireless g.
Provide a seamless wireless experience in which multiple users can
access live media, download data intensive files, play games and talk
Online without wireless lag.
Advanced antenna technology (MIMO) delivers superior range and
eliminates dead spots. Wi-Fi Protected Setup (WPS) allows users to
securely synchronize wireless peripheral devices at the touch of a
button. A quick and intuitive installation process, remote management
capabilities and a 3-year warranty make this product well suited for your
most demanding networking needs.
TEW-636APB (V1.0R)
300Mbps Wireless N Hot Spot Access Point
TEW-636APB
rev:08.15.2008
• Wi-Fi Compliant with IEEE 802.11g and IEEE 802.11b Standards
• High-Speed up to 300Mbps Data Rate using IEEE 802.11n (draft) connection
• Built-in 3 Detachable External Antennas (MIMO Technology) to support high speed performance and great coverage
• Support for Wireless multimedia (WMM)
• Access Point Mode and Wireless Distribution System (WDS) feature
• Wireless Protected Setup (WPS) for effortless installation
• Supports 64/128-bit WEP(Hex) WPA/WPA2 and WPA-PSK/WPA2-PSK Encryption
• Advanced wireless protection (EAP-MD5, EAP-TLS, EAP-TTLS, PEAP)
• Support for 802.1x and RADIUS authentication
• Supports MAC Address Filter (up to 16 entries) and SSID Broadcast Control
• Access Control list for wireless client support
• Built-in DHCP Server and Client and Time Server support
• Flash Memory for Firmware Upgrade and Easy Management via Web Browser (HTTP)
• Configuration file backup and restore feature
• Compliant with Windows 2000/XP/2003 Server/Vista, Linux and Mac OS
• Coverage up to 150 meters (500ft.) Indoor (depends on the environment)
• Coverage up to 400 meters (1300ft.) Outdoor (depends on the environment)
• Easy to use Web based configuration
• 3-Year Warranty
FEATURES
wireless

Data Rate
Security
Output Power
Channels
• 802.11n: BPSK, QPSK, 16QAM, with OFDM
• 802.11b: 11Mbps, 5.5Mbps, 2Mbps, and 1Mbps
• 802.11n (Draft 2.0): Up to 300Mbps
• 802.11b: 18dBm (Typical)
• 1~ 11 (US), 1~13 (EU)
Certification
Humidity
Temperature
Hardware
SPECIFICATIONS
Standards
Reset Button
Config Button
Dimension (L x W x H)
Power Adapter
• 1 x 10/100Mbps Auto-MDIX LAN Port
• Wired: IEEE 802.3 (10Base-T), IEEE 802.3u (100Base-TX)
• Reserved For WPS Function Use
• 12V DC, 1A External Power Adapter
Interface
• 320g (0.7 lbs)
• Operation: 0°~ 40°C (32°F~ 104°F) • Storage: -20°~ 60°C (-4°F~140° F)
• 2.412 ~ 2.462 GHz (FCC)
• Max. 90% (Non-Condensing)
• CE, FCC
• 180 x 122 x 30 mm (6.8 x 4.6 x 1.1 inches)
• Reset To Factory Default Settings
• Wireless: IEEE 802.11b, IEEE 802.11g, IEEE 802.11n (draft 2.0)
Weight
TEW-636APB
rev:08.15.2008
LED Indicator • WPS, Power, WLAN, Status
• Encryption: Hardware AES/TKIP, 64/128-bit WEP (Hex)
Receiving Sensitivity • 802.11b: -84dBm (Typical) @ 11mpbs
• 802.11g: -72dBm (Typical) @ 54Mbps
TEW-636APB (V1.0R)
Wireless N Hot Spot Access Point
Wireless
Frequency
Module Technique
• 2.412 ~ 2.472 GHz (ETSI)
• 802.11g: 54Mbps, 48Mbps, 36Mbps, 24Mbps, 18Mbps, 12Mbps, 9Mbps and 6Mbps
• 802.1X/EAP: WPA/WPA2/802.1X authenticator
• WPA: WPA-PSK/WPA2-PSK, WPA-enterprise, WPA2-Enterprise
• SSID Broadcast Control
• 802.11g: 15dBm (Typical)
• 802.11n (Draft 2.0: 14dBm (Typical) with HT20 & HT40
• 802.11n (Draft 2.0) : -70dBm (Typical) with HT20 & HT40
• OFDM; 802.11b: CCK (11 Mbps, 5.5 Mbps), DQPSK (2Mbps), DBPSK (1 Mbps)
• CSMA/CA with ACK
Media Access Protocol
• 3 x 2dBi detachable dipole antennas
Antenna

TRENDnet is a registered trademark. Other Brands and product names are trademarks of their respective holders. Information provided in this document pertain to TRENDnet
products and is subject to change at any time, without notice. For the most recent product information please visit
http://www.trendnet.com.
©
Copyright TRENDnet. All Rights Reserved.
RELATED PRODUCTS
PACKAGE CONTENTS
• CD-ROM with user’s guide
• TEW-636APB
• Multi-Language Quick Installation Guide
ORDERING INFORMATION
To Order Please Call:
1-888-326-6061
NETWORKING SOLUTIONS
RELATED PRODUCTS
TEW-621PC
TEW-623PI Wireless N PCI Adapter
Wireless N PC Card
• Power Adapter (12V DC, 1A)
20675 Manhattan Place,Torrance, CA 90501 USA
Tel: [phone]
Fax: [phone]
Web:
Email: [email protected]
www.trendnet.com
TEW-624UB 300Mbps Wireless N USB 2.0 Adapter
Wireless N Hot Spot Access Point
10/100Mbps
300Mbps
300Mbps Wireless N
HotSpot Access Point
(TEW-636APB)
Workstation with 300Mbps
Wireless N PCI Adapter
(TEW-623PI)
Notebook with 300Mbps
Wireless N PC Card
(TEW-621PC)
4-Port Gigabit Firewall Router
(TWG-BRF114)
Workstation with 300Mbps
Wireless N USB Adapter
(TEW-624UB)
Cable/DSL
Modem
Internet
TEW-636APB (V1.0R)
