Tri-Tronics Mark-Eye MEWL Manual

Mark•Eye™ SETUP INSTRUCTIONS
TRI-TRONICS COMPANY, INC. • P.O. Box 25135, Tampa, FL 33622-5135 • 813.886.4000 VOICE • 800.237.0946 TOLL FREE • 813.884.8818 FAX
Web color/background is Lighter than the mark (See Figure A)
Position the detection zone of the sensor between the registration marks and press the “LIGHTER
THAN MARK” button to initiate the AUTOSET™ routine.
The green LED AUTOSET indicator will rapidly blink until the proper setting is achieved. The red LED
output indicator and output transistors will turn “OFF”. When the mark passes through the detection
zone, the red LED output indicator and output transistors will turn “ON” for the duration of time that the
mark is in view.
NOTE: Detection of a Dark colored mark on a light colored background is impossible if the light source can
not penetrate through the light colored background. If this condition occurs during a light colored
background AUTOSET routine, both the red and green LEDs will flash twice.
Web color/background is Darker than the mark (See Figure B)
Position the detection zone of the sensor between the registration marks and press the “DARKER
THAN MARK” button to initiate the AUTOSET routine.
The green LED AUTOSET indicator will rapidly blink until the proper setting is achieved. The red LED
output indicator and output transistors will turn “OFF”. When the mark passes through the detection
zone, the red LED output indicator and output transistors will turn “ON” for the duration of time that
the mark is in view.
Inverting the Output
Depress both buttons for 3 seconds.
Pulse Stretcher
The Markeye sensor can be programmed to provide a 15-millisecond pulse stretcher timing function.
To determine if the pulse stretcher is enabled, during initial power-up the AUTOSET LED will rapidly
flash twice, verifying that the pulse stretcher is enabled.
Enabling or Disabling the Pulse Stretcher
To toggle the status of the pulse stretcher to the opposite state:
1. Remove power from the sensor.
2. Depress and hold both buttons simultaneously and apply power.
3. After applying power, note that the AUTOSET LED will flash; release both buttons.
4. Depress the “LIGHTER THAN MARK” to toggle the pulse stretcher to the opposite state.
5. Remove power from the sensor.
6. Whenever power is applied, the pulse stretcher will be enabled and the AUTOSET™ LED will flash
twice. The pulse stretcher can be disabled when these steps are repeated.
NOTE: The factory’s default setting for the pulse stretcher is the disabled state.
Optimized for the Detection of Registration Marks on Translucent or Transparent Web Materials
Dark Mark on a Light Web (Figure A) Light Mark on a Dark Web (Figure B)
Web: ttco.com

Sensor Selection Guide
Model Description
P.O. Box 25135, Tampa, FL 33622-5135
TEL: [phone] / TOLL FREE: [phone]
FAX: [phone] / TOLL FREE: [phone]
www.ttco.com / inf[email protected]
070-0149 REV-2
Product subject to change without notice.
DIMENSIONS
SUPPLY VOLTAGE
•10 to 30 VDC
•Polarity Protected
CURRENT REQUIREMENTS
•45 milliamps (exclusive of load)
OUTPUT TRANSISTORS
•(1) NPN and (1) PNP output transistors
•Sensor outputs can sink or source up to 150 milliamps
(current limit)
•All outputs are continuously short-circuit protected
REMOTE AUTOSET INPUT
•Opto isolated momentary sinking input (10 milliamps)
RESPONSE TIME
•Light state response = 100 microseconds
•Dark state response = 100 microseconds
LED LIGHT SOURCE
•Pulse modulated high intensity white LED
PUSHBUTTON CONTROL
•One pushbutton set-up
•Automatic set-up routines based on web opacity
•Simultaneously pushing both buttons inverts the output
•On power-up, simultaneously pushing both buttons enables
the program mode, allowing the pulse stretcher to be
enabled or disabled
SPECIFICATIONS
HYSTERESIS
•Minimal hysteresis promotes detection of low contrast
registration marks
LIGHT IMMUNITY
•Responds to sensor’s pulse modulated light source …
immune to most ambient light
INDICATORS
•
Green AUTOSET LED flashes when AUTOSET routine is
activated and stays illuminated when AUTOSET is completed
•Red Output LED illuminates when sensor’s output
transistors are “ON”
•On power-up, the AUTOSET LED flashes twice when
the pulse stretcher is enabled
AMBIENT TEMPERATURE
•- 40°C to 70°C (- 40°F to 158°F)
RUGGED CONSTRUCTION
•Chemical resistance to harsh cleaners, such as
detergents, alcohols, and ketones
•Waterproof ratings: NEMA 4 and IP66
•
Conforms to heavy industry grade CE and UL requirements
SELECTABLE PULSE STRETCHER
•Provides a minimum of 10 milliseconds output duration
MEWL White LED, 5-conductor cable
MEWLC White LED, 5- pin micro
connector on a 6” pigtail
Cable Selection Guide (5 Wire)
Model Micro Cable (M12) Description
GSEC-2MU 6.5 ft. (2.0m) Low Cost, Unshielded
GSEC-5MU 16 ft. (5.0m) Low Cost, Unshielded
GSEC-6 6 ft. (1.8m) Shielded Cable
GSEC-15 15 ft. (4.6m) Shielded Cable
GPSEC-15 15 ft. (4.6m) Shielded Cable
