Tripp Lite BP192V18-4U User manual

Tripp Lite
1111 West 35th Street
Chicago, IL 60609 USA
Telephone: +[phone]
E-mail: [email protected]
Model #: BP192V18-4U
BP192V18-4U - External Battery Pack for UPS System
Highlights
Extends runtime of compatible Tripp Lite UPS Systems with 192VDC external
battery connection
Provides daisy-chain capability
Simple installation; 4U rackmount, tower or stack adaptable
Simple maintenance chassis contains (4) 40lb. single-user replaceable battery
modules
Description
Tripp Lite's BP192V18-4U rack/tower external battery pack offers extended battery runtime when used in conjunction with compatible Tripp Lite UPS
systems. Multi-use form factor supports configuration in rackmount or stacking applications using only 4 rack spaces (4U). Upright tower
configuration supported with optional 2-9USTAND accessory. Includes heavy-gauge cabling with high-current DC connectors for simple installation.
Additional output connector allows multiple BP192V18-4U battery packs to be daisy-chained to the UPS for even longer extended run operation.
COMPATIBLE UPS SYSTEMS - SU12000RT4U, SU12000RT4UHW, SU16000RT4U, SU16000RT4UHW, and other Tripp Lite UPS systems that
specify the use of this battery pack.
Applications
Ideal means of lengthening the battery runtime provided by compatible Tripp Lite UPS systems. Additional battery packs may be ordered at
time of original UPS purchase or sourced at a later date to extend runtime performance if site power conditions deteriorate and longer
battery runtime is desired.
Package Includes
BP192V18-4U external battery pack
Mounting Hardware
Instruction manual with warranty information
Features
Offers extended-run UPS operation when used in conjunction with compatible Tripp Lite UPS systems
Supports stacking or rackmount installation using only 4 rack spaces (4U)
Supports upright tower installation with optional 2-9USTAND accessory (holds 2 battery packs in tower configuration)
Set of input/output connectors allows multiple BP192V18-4U battery packs to be daisy-chained to the UPS for even longer extended run
operation
Includes heavy-gauge cabling with high-current DC connectors for simple installation
Simple maintenance chassis contains (4) 40lb. single-user replaceable battery modules
Specifications

OUTPUT
Overload protection 120A DC output fuse system
INPUT
UPS Input cord length (ft.) 16 in./ .41m, 4 AWG, 2 conductor
UPS Input cord length (m) 4.88
BATTERY
Expandable battery runtime Includes a second input/output connector to daisy-chain multiple BP192V18-4U battery packs
DC system voltage (VDC) 192
Battery Access Front-panel battery access
Battery replacement
description
Simple maintenance chassis contains (4) 40lb. single-user replaceable sealed, flame retardant, non-spillable
battery modules.
Connects to UPS via Detachable cable with UPS specific DC connector (40.6 cm length, 4 gauge cable)
Typical battery lifespan 4-6 years typical (North America)
PHYSICAL
Shipping weight (lbs) 288
Shipping weight (kg) 129.6
Unit Dimensions (HWD/in) 7 x 17.5 x 27.8
Unit Dimensions (HWD/cm) 18 x 44.5 x 70.6
Shipping Dimensions
(HWD/in)
13 x 23.25 x 34.25
Shipping Dimensions
(HWD/cm)
33 x 59.1 x 87
Unit weight (lbs) 239
Unit weight (kg) 107.55
Material of construction Black steel cabinet
Form factors supported 4U rack/tower
WARRANTY
Product Warranty Period
(U.S. & Canada)
2-year limited warranty
Product Warranty Period
(International)
1-year limited warranty
Product Warranty Period
(Mexico)
1-year limited warranty
Product Warranty Period
(Puerto Rico)
1-year limited warranty
Optional Coverage 3 year, 5 year, next day, on-site warranty coverage available
Related Items
Optional Products
Product Type Related Model Description Qty.

Extended Warranties WEXT3-BP192V18 3-Year Extended Warranty - For BP192V18-4U 1
Extended Warranties WEXT5-BP192V18 5-Year Extended Warranty - For BP192V18-4U 1
Rackmount/Wallmount Kits 2POSTRMKITHD Enables 2-Post Rackmount Installation of 3U and Larger UPS,
Transformer and Battery Pack Components
1
Tower Stands 2-9USTAND Enables Tower Placement of Rackmount UPS Systems 1
More information, including related products, owner's manuals, and additional technical specifications, can be found online at
www.tripplite.com/en/products/model.cfm?txtModelID=3654.
Copyright © 2012 Tripp Lite. All rights reserved. All trademarks are the sole property of their respective owners. Tripp Lite has a policy of continuous
improvement. Specifications are subject to change without notice. Photos may differ slightly from final products.
