Trotec Pac 2000 x User manual

PAC 2000 X

TRT-BA-PAC2000X-TC-006-EN

OPERATING MANUAL

LOCAL AIR CONDITIONER

1Operating manual – Local air conditioner PAC 2000 X EN

Symbols

Danger!

Warns of a hazard which can lead to injuries.

Hazardous electric voltage!

Warns of a hazard resulting from electric voltage which

can lead to injuries.

Caution!

Warns of a hazard which can lead to property damage.

The current version of the operating manual can be found at:

Legal notice

This release replaces all previous versions. No part of this

publication may be reproduced without written permission from

Trotec. The same applies for electronically processing,

duplicating or spreading the publication. Subject to technical

guarantee that they may be used freely and primarily following

the spelling of the manufacturer. Product names are registered.

Changes to construction in the interests of constant

improvements to the product, as well as changes to the shape

and colour are reserved.

The scope of delivery may vary from product images. This

document was created with all due care. Trotec accepts no

liability whatsoever for possible mistakes or omissions. © Trotec

Table of contents

Notes regarding the operating manual .................................... 1

Information about the device................................................... 2

Technical data ........................................................................ 2

Safety ..................................................................................... 3

Transport and storage............................................................. 3

Operation................................................................................ 4

Errors and faults ..................................................................... 8

Maintenance........................................................................... 9

Disposal.................................................................................. 12

Notes regarding the operating manual

PAC 2000 X

http://download.trotec.com/?sku=1210002003&id=1

EN Operating manual – Local air conditioner PAC 2000 X 2

Device description

The primary purpose of the device is room cooling. It further filters

and dehumidifies the air thus creating an agreeable room climate.

Additionally, the device can be used as heater.

In ventilation mode the device also provides the opportunity of air

circulation without cooling effect. In dehumidification mode

moisture is withdrawn from the air.

The device operates fully automatically and thanks to its

microprocessor control features a multitude of further options,

the device can, for instance, be switched on or off automatically

with time delay via the timer function.

Handling the device can be conveniently accomplished via the

control panel at the device or the supplied infrared remote

control.

The device was designed for universal, flexible and

uncomplicated application. Due to its compact dimensions it can

be easily transported and used in all interior spaces.

The air conditioner cools the room air by withdrawing warmth.

The absorbed warmth is emitted to the outside via the exhaust air

hose; cooled air is fed to the installation site by means of a fan.

Accumulating condensate drips from the evaporator onto the hot

condenser, there it evaporates and then is transported to the

outside via the exhaust air hose.

Excess condensate is dripping from the condenser into a

condensate trap and is there re-fed to the condenser by use of a

paddle wheel, where it evaporates and is discharged along with

the exhaust air flow.

A cooling agent sees to the transport of the absorbed warmth

within the closed refrigerant circuit.

Device depiction

Scope of delivery

1 x air conditioner PAC 2000 X

1 x exhaust air hose

1 x remote control

1 x 3 V lithium battery CR002

Information about the device

No. Operating element

(1) Control panel

(2) Remote control receiver

(3) Warm air outlet

(4) Evaporator filter

(5) Cooling air inlet

(6) Exhaust air hose connector

(7) Cooling air outlet

(8) Condenser filter

(9) Ambient air inlet

(10) Drain hole

Technical data

Parameter Value

Model PAC 2000 X

Dehumidification performance 30 l per day

Cooling capacity 2000 W

Electric connection 220 V AC, 50 Hz

Nominal cooling capacity 900 W

Refrigerant R410A

Dimensions (WxDxH) 288 mm x 428 mm x 625 mm

Minimum distance

to walls or other objects

A: Top: 50 cm

B: Rear: 50 cm

C: Side: 50 cm

D: Front: 50 cm

3Operating manual – Local air conditioner PAC 2000 X EN

Carefully read the operating manual before using the device

and keep it within reach!

• Do not use the device in potentially explosive rooms.

• Do not use the device in atmospheres containing oil, sulphur,

chlorine or salt.

• Set the device up in an upright and stable position.

• Let the device dry out after a wet clean. Do not operate it

when wet.

• Make sure that the air inlet and outlet are not obstructed.

• Make sure that the suction side is kept free of dirt and loose

objects.

• Never insert objects into the device.

• Do not cover or transport the device during operation.

• Ensure that all electric cables outside of the device are

protected from damage (e.g. caused by animals).

• Observe the device's power input, cable length and intended

use when selecting extensions to the connecting cable. Avoid

electrical overload.

• Only transport the device in an upright position with an

emptied condensation tank or condensation drain hose.

• Dispose of the collected condensate. Do not drink it. Health

hazard!

• Do not remove any safety signs, stickers or labels from the

device. Keep all safety signs, stickers and labels in legible

condition.

• Observe the storage and operating conditions (see chapter

Technical data).

Intended use

Only use the device for cooling, ventilating and dehumidifying

room air in closed rooms whilst adhering to and following the

technical data.

Improper use

Do not place the device on damp or flooded ground. Do not use

the device outdoors. Do not place any objects, e.g. wet clothing,

on the device for drying. Any unauthorised changes,

modifications or alterations of the device are forbidden.

Personnel qualifications

People who use this device must:

• be aware of the dangers that occur when working with

electric devices in damp areas.

• have read and understood the operating manual, especially

the Safety chapter.

Residual risks

Hazardous electric voltage!

Work on the electrical components must only be

carried out by an authorised specialist company!

Danger!

Do not leave the packaging lying around. Children may

use it as a dangerous toy.

Danger!

This device can be dangerous if it is used by untrained

people in an unprofessional or improper way. Observe the

personnel qualifications.

Caution!

To avoid damages to the device, never operate the device

without an inserted air filter!

Transport

To make the device easier to transport, it is fitted with wheels.

Before transporting the device, proceed as follows:

1. Switch off the device.

2. Remove the mains plug from the mains socket. Do not use

the power cable to drag the device!

3. Empty the water tank.

Storage

Empty the condensation tank (see chapter Maintenance).

When the device is not being used, observe the following storage

conditions:

•dry

• protected from dust and direct sunlight

• with a plastic cover to protect it from invasive dust, if

necessary

Safety

Transport and storage

EN Operating manual – Local air conditioner PAC 2000 X 4

• Avoid open doors and windows.

• Do not exceed the recommended room size.

• Keep curtains and venetian blinds closed during the sunniest

time of the day.

• Keep the filter clean.

• Reduce the temperature and ventilation settings as soon as

the room has reached the desired ambient conditions.

• During cooling operation there is no need for a drain pipe

being installed. Make sure that the rubber cap is positioned

on the drain hole while the device is running.

Positioning the device

When positioning the device, observe the minimum distance from

walls or other objects as described in the chapter Technical data.

• Set the device up in a level, upright and stable position.

• Do not create tripping hazards when laying the power cable

or other electric cables.

• Make sure that no curtains or other objects interfere with the

air flow.

Connecting the exhaust air hose

1. Slightly tilt the device in order to extract the exhaust air hose

from the bottom of the device as depicted.

1. The exhaust air hose can be connected to the device by

turning it in the direction of the arrow.

2. Rotate the exhaust air hose again in the direction of the

arrow, this time to disconnect it.

Operation

5Operating manual – Local air conditioner PAC 2000 X EN

Discharging exhaust air

• The length of the exhaust air hose should not exceed 4 m.

The exhaust air hose must not be bent up or down.

• A minimum distance of 500 mm is to be observed between

the filter side of the device and the wall or other obstacles.

Start-up

• Prior to initial start-up, the battery included in the scope of

delivery must be inserted in the remote control.

– To do so, open the cover of the battery compartment at the

back of the remote control.

– Insert the battery observing the correct polarity. Go by the

marking inside the battery compartment.

– Then close the battery compartment.

• Check air inlets and outlets for foreign objects and remove

these, if necessary.

• Check the air filter for dirt and clean it, if required. Also see

chapter Maintenance.

Switching the device on

1. Insert the mains plug into a properly secured mains socket.

2. Use the power button (1) to switch the device on.

– To prolong the compressor lifetime, wait for at least

3.5 minutes after switch-off before switching the device

back on.

EN Operating manual – Local air conditioner PAC 2000 X 6

Control panel

No. Designation Function

1 Power Press this button to turn the device on or off.

2 Functions Use this button to set cooling, heating or dehumidification operating mode.

3 Temperature control (+) Pressing this button during cooling operation increases the preset temperature by

1 °C each time it is actuated; the maximum limit is 30 °C.

Pressing this button during heating operation increases the preset temperature

by 1 °C each time it is actuated; the maximum limit is 25 °C.

4 Temperature control (-) Pressing this button during cooling operation reduces the preset temperature by

1 °C each time it is actuated; the minimum limit is 17 °C.

Pressing this button during heating operation reduces the preset temperature by

1 °C each time it is actuated; the minimum limit is 15 °C.

5 LED display The display indicates the current temperature or timer settings.

If the set temperature or timer value is to be adjusted, the new setting will be

indicated, then the display returns to the currently set temperature.

The display also serves to indicate error messages in case of a fault, see

ERROR CODES.

6 SPEED Press this button to adjust the fan speed.

During heating and dehumidification operation this button is disabled.

7 PROGRAMMABLE TIMER

8SLEEP

9 Alarm Once the maximum filling level of the water tank is reached, E4 or the ALARM

warning light appears on the display.

10 LED speed high high fan speed indicator

11 LED speed medium medium fan speed indicator

12 LED speed low low fan speed indicator

13 LED auto mode AUTO mode indicator

14 LED sleep mode SLEEP mode indicator

15 LED dehumidifying dehumidification operating mode indicator

16 LED heating heating operating mode indicator

17 LED cooling cooling operating mode indicator

(10)

(11)

(12) (13)

(17)

(16)

(15)

(14)

7Operating manual – Local air conditioner PAC 2000 X EN

Setting the operating mode

• To set the operating mode, press the Functions button (2):

–cooling,

–heating,

– dehumidifying (drying).

Setting the temperature

• Use the temperature control buttons (+ (3) or - (4)) to set the

desired temperature.

Setting the fan speed

• Choose from the available speed levels by pressing the

button Speed (6).

–Low

–Medium

–High

–Auto

Note:

During dehumidification operation this button is disabled, since in

dehumidification mode the device can only be operated at low fan

speed.

If AUTO is selected during cooling operation, the device

automatically switches between the other three speed levels –

depending on the temperature difference between the set and the

actual ambient temperature.

Setting the timer

Timer on

TIMER ON is used to turn the device on automatically after the set

time has passed.

• Press the TIMER button (7) in stand-by to set the desired

time.

• Once the set number of hours has lapsed, the device will

switch on automatically.

• If you press the POWER button (1) before the time has

expired, the device will switch on and the set time will be

deleted.

• You can also determine the function and fan speed while

setting the timer.

Timer off

TIMER OFF is used to turn the device off automatically after the

set time has passed.

• Press the TIMER button (7) during operation to set the desired

time.

• Once the set number of hours has lapsed, the device will

switch off automatically.

• If you press the POWER button (1) before the time has

expired, the device will switch off and the set time will be

deleted.

Sleep control function

Note:

The sleep control function is only available in cooling mode.

• Press the SLEEP button (8) during cooling operation to set the

temperature. After one hour the temperature increases by

1 °C and maximally by 2 °C after 2 hours.

• Actuating the SLEEP button (8) again deactivates this setting.

Dehumidification operation (drying)

• The temperature cannot be regulated during

dehumidification operation, the fan speed is low.

• In dehumidification (drying) mode humidity is extracted from

the air and collected in an internal tank.

• Once the maximum filling level of the water tank is reached,

E4 or the ALARM warning light appears on the display.

• Drain the water tank when it is full. See Emptying the

condensation tank on page 11.

Discharging the condensate

• In dehumidification mode the rubber cap on the drain hole (1)

is to be removed and replaced by a proper drain pipe.

• Remove the exhaust air hose, connect a drain pipe to the

drain hole (1) and drain the water to enhance the

dehumidification capacity.

EN Operating manual – Local air conditioner PAC 2000 X 8

Heating

• If you want to utilize the heating function, the following

modification is required:

1. Detach the exhaust air hose.

2. Mount the connection piece for the exhaust air hose (6) to the

cooling air outlet (7).

3. Fit the exhaust air hose to the connection piece (6).

4. Align the pivotable nozzle.

Start heating function

• Press the functions button (2) until the LED for heating (16)

lights up.

– The device will start after a few seconds.

Note:

Heating is possible up to a max. ambient temperature of 25 °C.

At an ambient temperature of more than 25 °C the heating

function will not start.

Remote control

All settings of the device can also be made using the remote

control included in the scope of delivery. Please gather the button

functions from the Control panel paragraph.

Shutdown

1. Use the power button (A) to switch the device off.

2. Remove the mains plug from the mains socket.

3. Clean the device, and especially the air filter, according to

chapter Maintenance.

4. Store the device according to the Storage chapter.

The device has been checked for proper functioning several times

during production. If malfunctions occur nonetheless, check the

device according to the following list.

Your device still does not operate correctly after these

checks?

Bring the device to a specialist company for cooling and

air-conditioning or to Trotec for repair.

(6)

(7)

No. Operating element Function

1. Power Power button

2. Func Operating mode selector

3. Timer Timer switch

4. Auto Automatic fan speed

5. Hi High fan speed

6. Mid Medium fan speed

7. Low Low fan speed

8. Sleep Sleep control function

9. Temp Temperature control

Errors and faults

Display indica-

tion Cause Troubleshooting

E1 Short circuit on both

temperature sensor and

PCB.

Contact an electrician for

repair.

E2 Short circuit on

temperature sensor copper

tube and PCB wiring.

Contact an electrician for

repair.

ALARM / E4 Indicates full water tank or

poor contact of the signal

plug.

Drain water.

See Emptying the

condensation tank on

page 11.

9Operating manual – Local air conditioner PAC 2000 X EN

Maintenance intervals

Maintenance and care log

Device type: ............................ Device number: .......................................

Maintenance

Maintenance and care interval before every

start-up as needed at least every

2weeks

at least every

4weeks

at least every

6 months

at least

annually

Empty the condensation tank x

Check the air inlets and outlets for dirt and

foreign objects and clean if necessary x

Clean the exterior xx

Visually check the inside of the device for dirt xx

Check the air inlet grid and air filter for dirt

and foreign objects and clean or replace if

necessary

Replace the air filter x

Check for damage x

Check the attachment screws xx

Test run x

Maintenanceandcareinterval 12345678910111213141516

Check air inlets and outlets for dirt and foreign

objects and clean if necessary

Clean the exterior

Visually check the inside of the device for dirt

Check the air inlet grid and air filter for dirt and

foreign objects and clean or replace if necessary

Replace the air filter

Check for damage

Check the attachment screws

Test run

1. Date: ..........................................
