Trotec BP5F User manual

TRT-BA-BP5F-TC-003-EN
BP5F
EN
OPERATING MANUAL
FOOD THERMOMETER

1 EN
food thermometer BP5F
Table of contents
Notes regarding the operating manual.................................1
Safety .....................................................................................1
Information about the device................................................2
Transport and storage...........................................................4
Operation ...............................................................................5
Maintenance and repair ........................................................6
Errors and faults....................................................................6
Disposal .................................................................................6
Notes regarding the operating manual
Symbols
Warning of electrical voltage
This symbol indicates dangers to the life and health of
persons due to electrical voltage.
Warning
This signal word indicates a hazard with an average
risk level which, if not avoided, can result in serious
injury or death.
Caution
This signal word indicates a hazard with a low risk
level which, if not avoided, can result in minor or
moderate injury.
Note
This signal word indicates important information (e.g.
material damage), but does not indicate hazards.
Info
Information marked with this symbol helps you to carry
out your tasks quickly and safely.
Follow the manual
Information marked with this symbol indicates that the
operating manual must be observed.
You can download the current version of the operating manual
and the EU declaration of conformity via the following link:
BP5F
https://hub.trotec.com/?id=41866
Safety
Read this manual carefully before starting or using the
device. Always store the manual in the immediate vicinity
of the device or its site of use!
Warning
Read all safety warnings and all instructions.
Failure to follow the warnings and instructions may
result in electric shock, fire and/ or serious injury.
Save all warnings and instructions for future
reference.
This appliance can be used by children aged from
8years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe
way and understand the hazards involved.
Children shall not play with the appliance. Cleaning and
user maintenance shall not be made by children
without supervision.
• Do not use the device in potentially explosive rooms.
• Do not use the device in aggressive atmosphere.
• Protect the device from permanent direct sunlight.
• Do not remove any safety signs, stickers or labels from the
device. Keep all safety signs, stickers and labels in legible
condition.
• Do not open the device with a tool.
• Observe the storage and operating conditions as given in
the Technical data chapter.

EN 2
food thermometer BP5F
Intended use
Only use the device for temperature measurements by means of
the infrared sensor or temperature probe within the measuring
range specified in the technical data.
To use the device for its intended use, only use accessories and
spare parts which have been approved by Trotec.
Improper use
This device is not suited for measuring the body temperature in
humans or animals. The device must not be pointed at people.
Do not use the device in potentially explosive atmospheres, for
measurements in liquids or at live parts. Trotec accepts no
liability for damages resulting from improper use. In such a
case, any warranty claims will be voided. Any unauthorised
modifications, alterations or structural changes to the device are
forbidden.
Personnel qualifications
People who use this device must:
• be aware of the dangers that occur when handling food at
high temperatures, e.g. frying or grilling.
• have read and understood the operating manual, especially
the Safety chapter.
Residual risks
Warning
Risk of suffocation!
Do not leave the packaging lying around. Children may
use it as a dangerous toy.
Warning
The device is not a toy and does not belong in the
hands of children.
Warning
Dangers can occur at the device when it is used by
untrained people in an unprofessional or improper way!
Observe the personnel qualifications!
Caution
Keep a sufficient distance from heat sources.
Note
To prevent damages to the device, do not expose it to
extreme temperatures, extreme humidity or moisture.
Note
Do not use abrasive cleaners or solvents to clean the
device.
Information about the device
Device description
The device BP5F is a thermometer intended for temperature
measurements in food, which are carried out by means of an
infrared sensor or temperature probe in accordance with the
HACCP standard (Hazard Analysis and Critical Control Points).
Beside the digital temperature display, three LEDs show
whether the detected temperature is within the
HACCP compliant temperature ranges.
According to the HACCP directive, complying with the
temperature ranges below 4 °C and above 60 °C is an important
way of preventing the development and reproduction of harmful
microorganisms. On the other hand, temperatures between 4 °C
and 60 °C can promote the development of germs. To quickly
show whether or not these temperature limits are complied
with, the food thermometer BP5F shows three LEDs beside the
digital temperature display which indicate the corresponding
temperature range.

3 EN
food thermometer BP5F
Device depiction
3
4
6
5
2
1
8
9
10
7
No. Designation
1 Display
2SET button
3 Temperature probe lock
4 Temperature probe
5MEAS button
6TIMER button
7 Cover of the battery compartment
8 Measurement button
9 Infrared sensor
10 LED
Display
SCAN HOLD
MAX
SET
TIMER SET
BP5F
11
12
13
14
15
18
19
20
16
17
21
22
No. Designation
11 Battery indicator
12 Temperature unit indication
13 Measurement using the temperature probe indication
14 Timer function indication
15 Segment display for:
• maximum value of the last measurement
• minimum value of the last measurement
• time for the timer function
16 SET indication – Setting the time for the timer function
17 MAX indication – Display of the maximum value
18 Green LED – Temperature below 4°C (40°F)
19 Red LED – Temperature between 4°C and 60°C (40°F
and 140°F)
20 Green LED – Temperature above 60°C (140°F)
21 SCAN indication – Measurement is on
22 HOLD indication – Freezing the display

EN 4
food thermometer BP5F
Technical data
Parameter Value
Model BP5F
Article number 3,510,003,020
Weight 180 g
Dimensions
(length x width x
height)
185 mm x 50 mm x 67 mm
Temperature
Measuring range -40 °C to +200 °C
(-40 °F to 392 °F)
Accuracy below -5 °C (23 °F): +1 °C (1.8 °F)
between -5 °C and 65 °C (23 °F and
150 °F): +1 °C (1.8 °F)
above 65 °C (150 °F): +1%
Infrared
Measuring range -40 °C to +280 °C
(-40 °F to 536 °F)
Accuracy below -40 °C to 4 °C (-40 °F to
39.2°F): +2 °C (3.6 °F)
between 4 °C and 65 °C (39.2 °F and
150 °F): +1 °C (1.8 °F)
above 65 °C (150 °F): +1.5 %
Reaction time < 500 ms
Type of protection IP65
Emissivity adjustable between 0.10 and 1.0
Distance to measuring
spot diameter ratio
20:1
Automatic switch-off after approx. 20 seconds
Power supply 9 V battery
Scope of delivery
• 1x Device BP5F
• 1x 9 V battery
• 1 x Quick guide
Transport and storage
Note
If you store or transport the device improperly, the
device may be damaged.
Note the information regarding transport and storage of
the device.
Transport
The manufacturer packed the device to the best of his abilities
to protect it against transport damage.
Storage
When the device is not being used, observe the following
storage conditions:
• dry and protected from frost and heat
• protected from dust and direct sunlight
• The storage temperature is the same as the range given in
the Technical data chapter.
• Remove the batteries from the device.

5 EN
food thermometer BP5F
Operation
Note
Make sure that the surface of the device is dry and the
device is switched off.
Inserting the battery
1. Open the battery compartment by unscrewing the two
screws with a suitable screwdriver.
2. Remove the battery compartment cover(7).
3. Insert the battery(1 x 9V battery) into the battery
compartment with correct polarity.
4. Fit the battery compartment cover back on the device and
tighten the screws.
Switching on and selecting the measuring mode
Note:
Note that moving from a cold area to a warm area can lead to
condensation forming on the device's circuit board. This
physical and unavoidable effect can falsify the measurement. In
this case, the display shows either no measured values or they
are incorrect. Wait a few minutes until the device has become
adjusted to the changed conditions before carrying out a
measurement.
Proceed as follows to switch between measurement with
infrared and measurement with temperature probe:
1. Press any button to switch on the device.
2. Press the MEAS button(6) to switch between
measurement with infrared and measurement with
temperature probe.
ðIf the symbol for measurement with temperature probe
is displayed on the indication(13), the corresponding
measuring mode is selected.
ðIf the symbol is not displayed, the infrared measuring
mode is selected.
Measuring with infrared
Info
Vapours and smoke can influence the measurement.
Info
Ensure that the surface to be measured is free of dust,
dirt, ice or similar substances.
Info
To be able to gain exact measurement results on
surfaces which reflect heavily, stick matt masking tape
to the surface or apply matt black paint with a very
high and known degree of emission.
Info
Note the 20:1 ratio of the distance to the measuring
spot diameter. The larger the distance to the object,
the larger the measuring spot diameter and hence, the
less precise the measured result.
1. Switch the device on and select the infrared measuring
mode.
2. Point the device at the object to be measured and hold
down the measurement button(8).
ðThe SCAN indication(21) appears on the display. The
device performs a measurement.
ðThe currently measured value is indicated.
3. Let go of the measurement button(8) again.
ðThe HOLD indication(20) appears on the display. The
device stops measuring.
ðThe last value measured is shown.
Measuring with temperature probe
1. Press the temperature probe lock(3) and fold out the
temperature probe(4).
2. Insert the temperature probe(4) into the object to be
measured by approx. 1 cm.
3. Switch the device on and select the temperature probe
measuring mode.
4. Press the MEAS button(5).
ðThe currently measured value is indicated.
Note
The temperature probe is not suitable as an ice pick
and should never be pricked into frozen objects
forcefully to prevent damages to the device.

EN 6
food thermometer BP5F
Setting the timer
The device allows you to set a timer. After the set time has
passed, a beep is emitted for 30 seconds.
Please proceed as follows to set the timer:
1. Press the TIMER button(6) to open the timer menu.
2. The timer period is displayed.
3. Press and hold the TIMER button(6) for 2 seconds to
switch between seconds, minutes and hours.
ðThe currently selected time format flashes.
4. Press and hold the SET button(2) to set the corresponding
value.
5. Press the measurement button(8) to start the timer.
ðThe timer starts and remains active in the background,
even if you switch to another menu or the device turns
off because of non-use.
ðAfter the set time has passed, a beep is emitted for
30 seconds. Press any button to switch off the beep.
The device switches off after approx. 20 seconds of non-use.
Changing the unit °C / °F indication
The default setting for the temperature unit is °C.
Please proceed as follows to change the temperature unit at the
device:
1. Press the SET button(2) to change the unit.
ðThe currently selected unit °C or °F will be indicated in
the temperature unit indication(12) of the display(1).
Maintenance and repair
Battery change
A battery change is required when a battery indication lights up
on the display(1) or the device can no longer be switched on.
See chapter Operation.
Cleaning
Clean the device with a soft, damp and lint-free cloth. Ensure
that no moisture enters the housing. Do not use any sprays,
solvents, alcohol-based cleaning agents or abrasive cleaners,
but only clean water to moisten the cloth.
Repair
Do not modify the device or install any spare parts. For repairs
or device testing, contact the manufacturer.
Errors and faults
The device has been checked for proper functioning several
times during production. If malfunctions occur nonetheless,
check the device according to the following list.
For repairs or device testing, contact the manufacturer.
Disposal
The icon with the crossed-out waste bin on waste
electrical or electronic equipment stipulates that this equipment
must not be disposed of with the household waste at the end of
its life. You will find collection points for free return of waste
electrical and electronic equipment in your vicinity. The
addresses can be obtained from your municipality or local
administration. For further return options provided by us please
refer to our website www.trotec24.com.
The separate collection of waste electrical and electronic
equipment aims to enable the re-use, recycling and other forms
of recovery of waste equipment as well as to prevent negative
effects for the environment and human health caused by the
disposal of hazardous substances potentially contained in the
equipment.
Li-Ion
In the European Union, batteries and accumulators must not be
treated as domestic waste, but must be disposed of
professionally in accordance with Directive 2006/66/EC of the
European Parliament and of the Council of 6September 2006
on batteries and accumulators. Please dispose of batteries and
accumulators according to the relevant legal requirements.

Trotec GmbH & Co. KG
Grebbener Str. 7
D-52525 Heinsberg
[phone]
[phone]
[email protected]
www.trotec.com
