True PLS1300 User manual

OWNER’S
MANUAL
PLS1300
STANDING LEG CURL
MODEL PLS1300
(MAN-PLS1300 REV01)

2
IMPORTANT!
All products shown are prototype. Actual product delivered may vary.
Product specifications, features, and software are subject to change without notice.
For the current owner’s manual and documents in additional languages please visit
https://truefitness.com/support/user-manuals/
IMPORTANTE!
Todos los productos mostrados son prototipos. La realidad el producto suministrado puede diferir. Especificaciones de
productos, características y software están sujetas a cambios sin previo aviso.
Para la más actualizada de este manual del propietario y para los documentos en otros idiomas, por favor visite
https://truefitness.com/support/user-manuals/
IMPORTANT! Tous les produits présentés sont prototype. Le produit réel livré peut varier. Spécifications du produit,
caractéristiques et logiciels sont sujettes à modification sans préavis. Pour la plus à jour le manuel du propriétaire et pour
documents dans des langues supplémentaires, veuillez https://truefitness.com/support/user-manuals/ de visite
ꄆ釐䬠炐
侁炐䢥僗◲⿁氳⸉㑔ն㲓ꡮ◫♀氳◲⿁⺎耆僗䢥┘⺱◲⿁鈺劲Ⱶ耆⽰鯻♭㞜僗催䷉䔭┘⺁车鵟湳鲂☪╙塛㵒◇㛻㛡丗氳✳
榫陱伺░⽰㵒◇⪭☽陪銧氳乃勮陴阼ꠋhttps://truefitness.com/support/user-manuals/
ھام!
جمیع المنتجات المعروضة ھي النموذج. قد تختلف المنتج الفعلي تسلیمھا.
مواصفات المنتج، والمیزات والبرامج قابلة للتغییر دون إشعار.
لمعظم ما یصل حتى الآن دلیل المالك یرجى زیارة www.truefitness.com /support/user-manuals/
للمستندات في لغات إضافیة، یرجى زیارة https://truefitness.com/support/user-manuals/
WICHTIG!
Alle hier gezeigten Produkte sind Prototypen. Das tatsächliche Produkt ausgeliefert wird, kann variieren. Produkt-
Spezifikationen, Funktionen und Software können sich ohne vorherige Ankündigung ändern. In den meisten Fällen bis zu
Bedienungsanleitung Bisher besuchen und für Dokumente in weiteren Sprachen finden Sie unter https://truefitness.com/
support/user-manuals/
BELANGRIJK!
Alle getoonde producten zijn prototype. Daadwerkelijke product geleverd kan verschillen. Product specificaties,
eigenschappen & software zijn onderhevig aan verandering zonder kennisgeving. Voor de meest actuele handleiding van
de eigenaar & voor documenten in andere talen kunt u terecht op https://truefitness.com/support/user-manuals/
ВАЖНО!
Все товары указаны прототипа. Фактический продукт, поставляемый могут отличаться. Технические
характеристики, особенности ипрограммного обеспечения могут быть изменены без предварительного
уведомления. Для получения самой последней на сегодняшний день руководство по эксплуатации и
Для документов на другие языки, пожалуйста, посетите https://truefitness.com/support/user-manuals/

3
Thank You for Choosing TRUE!
Since its founding in 1981, TRUE Fitness has been built on two core guiding principles: Build the highest quality
products and support them with superior service. Today, TRUE is the global leader in premium fitness equipment for the
commercial and residential markets.
Over the years, the fitness industry has changed, new markets have sprung up, and the needs of our customers have
evolved, but those principles remain constant, and we remain ever-vigilant in working to achieve them.
In keeping with our values, TRUE has always strived to equip our machines with the latest technology and safety features
since the beginning, giving our customers the very best exercise experience possible while providing peace of mind.
As your dedicated partner, we will do whatever it takes to keep your facility going strong. Our experienced team provides
end-to-end service, from facility planning and maintenance to providing your machines with the newest technologies. You
can count on TRUE Fitness for the best service in the industry, provided by a team focused on optimizing the life of your
equipment.
Contacting Our Support Team
Before you contact TRUE, we recommend gathering the serial number, model number, and a brief description of the
reason for your request. After you have all the pertinent information, we suggest you contact your selling dealer or local
service company to set up an appointment. If you are not familiar with who is in your area, you can visit
https://shop.truefitness.com/store-locator/ and use our store locator to obtain the contact information for the closest dealer.
If you still need help, please contact our product support team.
Address TRUE Fitness
Attn: Product Support
865 HoffRoad
St. Louis, MO 63366
Phone [phone]
Email service@truefitness.com
Hours of Operation Monday - Thursday 8:30am - 6:00pm (CST)
Friday 8:30am - 5:00pm (CST)
Contacting Our Sales Team
Interested in owning more TRUE products? Please contact us with any product inquires so that we may direct you to the
appropriate sales representative to help answer your questions.
Address TRUE Fitness
Attn: Sales Department
865 HoffRoad
St. Louis, MO 63366
Phone [phone]
Email sales@truefitness.com
Hours of Operation Monday - Friday 8:30am - 5:00pm (CST)

4
Reporting Freight Claims or Parts Damage
Unfortunately, sometimes materials can be damaged during shipment. If materials are damaged during shipment, please
follow the guidelines below to determine the appropriate process for you to follow.
Severe Damage—Obvious damage to external packaging and internal product.
Please refuse the shipment and it will be returned to TRUE by the carrier. Contact TRUE product support by calling
800.883.8783 or sales support by calling 800.426.6570 Monday-Friday during normal business hours to notify us that the
shipment has been refused. Once we have received the damaged shipment, a replacement shipment will be sent to you.
If the shipment comes in multiple boxes, only refuse boxes with damage.
Slight Damage—Minimal damage to external packaging with unknown internal damage to product.
If the shipment has minimal damages and you are not sure if the actual product is damaged, you must sign the bill of
lading as damaged when accepting the shipment. Once you have opened the box and you have determined something
is indeed damaged, please gather the serial number, model number, description of damage, and photos of damage.
Please make sure the photos include the damaged product as well as the damaged box the product arrived in. Contact
TRUE product support (service@truefitness.com // 800.883.8783) or TRUE sales support (sales@truefitness.com //
800.426.6570) Monday-Friday during normal business hours.
Concealed Damage—No damage to external packaging but internal damage to product.
You may receive a shipment that looks intact and discover once the box has been opened that there are hidden damages.
Please notify the carrier immediately. TRUE will not be able to file a claim if the carrier is not notified in a timely manner.
Once you have called the carrier you will need to gather the serial number, model number, description of damage, and
photos of damage. Contact TRUE product support (service@truefitness.com // 800.883.8783) or TRUE sales support
(sales@truefitness.com // 800.426.6570) Monday-Friday during normal business hours.

5
SAFETY INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS—SAVE THESE INSTRUCTIONS...........................................................................6
GENERAL CARE AND MAINTENANCE.................................................................................................................................8
COMMERCIAL MAINTENANCE SCHEDULE.......................................................................................................................9
COMPLIANCES....................................................................................................................................................................9
DIMENSIONS AND WEIGHTS.............................................................................................................................................10
LABEL LOCATIONS..............................................................................................................................................................11
WARNING AND INTENDED USE LABELS...........................................................................................................................11
ASSEMBLY INSTRUCTIONS
PREASSEMBLY CHECKLIST..............................................................................................................................................13
ASSEMBLY STEPS..............................................................................................................................................................15
PREVENTATIVE MAINTENANCE
DAILY INSPECTION AND MAINTENANCE...........................................................................................................................23
WEEKLY INSPECTION AND MAINTENANCE......................................................................................................................23
OTHER SCHEDULED PREVENTATIVE MAINTENANCE....................................................................................................23
CLEANING THE EQUIPMENT.............................................................................................................................................24
WARRANTY INFORMATION
COMMERCIAL LIMITED WARRANTY..................................................................................................................................25
TABLE OF CONTENTS

6
SAFETY INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS—SAVE THESE INSTRUCTIONS
!FACILITY AND USER SAFETY PRECAUTIONS
●Review and understand all of the warning labels affixed to this machine and on the facility safety sign.
●Be certain that the machine operation is understood before it is used. Refer to the instructional procedure label affixed
to the machine.
●Make sure all users are properly trained on how to use this equipment. If this machine is being used in a commercial
setting, end users may not have access to this owners manual. It is the responsibility of the facility to instruct users
as to the proper usage of the equipment as well as making them aware of potential hazards. Maximum user weight is
400 lbs / 182 kg.
●Use each machine only for the intended exercise. Do not allow anyone to invent exercises not included on the
instructional procedure label or the intended use label.
●Do not modify the machine.
●This equipment meets industry safety standards for stability when used for the intended exercise. Do not allow straps,
resistance bands or other means to be attached to the framework of this machine to perform stretching or body weight
exercises. This can result in machine instability and lead to serious crushing injuries.
●Keep children away from this equipment. Adults should closely supervise use by teenagers.
●It is recommended that users receive a thorough medical exam before commencing an exercise program. All medical
issues should be reviewed to ensure that weight training will not aggravate pre-existing medical conditions.
●If the machine appears damaged or inoperable, contact a facility staffmember to place an “OUT OF ORDER, DO
NOT USE” sign on the machine until it is repaired. Only use TRUE supplied replacement components to service this
machine.
●Instruct users not to wear loose or dangling clothes or have headphone wires hanging when using this equipment.
●Do not attempt to free any jammed assemblies by yourself as this may cause injury.
●On Plate Loaded and Free Weight machines:
○Use of spotter(s). Instruct users to seek the advice of the facility staffas to the appropriate use of spotters when
lifting. More than one spotter may be required depending upon the amount of weight being lifted.
○Instruct users to load weight plates evenly and carefully to avoid tipping equipment and crushing injuries.
○If the machine is equipped with safety stops or catches, inspect them and verify their proper operation before use
and make sure they are securely in place before using or exiting the machine. Be certain members are instructed
on how to operate and adjust all safety mechanisms.
○This equipment is designed for standard olympic size weight plates with a 50mm bore (1.9”).
○Do not exceed the maximum weight capacity of the machine. Maximum plate size is 45 lbs (25 kg).
●On Selectorized and cable equipped machines:
○Do not allow users to perform any exercise by holding the end of the cable and/or the cable end fitting. Use only
appropriate handles or attachments properly connected to the cable end.
○Do not high-pin or double-pin the weight stack. Do not allow the machine to be used if the top plate or weight
stack is pinned in a raised position. Use an assistant and carefully return the machine to the proper position with
the cap plate resting on the top weight. Inspect the entire length of the cable to ensure that it is properly seated in
all of the pulley grooves.
○Do not allow the use of weight plates or dumbbells to be used as a means to add additional weight to the weight
stacks. Use only the TRUE adder weight system specifically designed for the machine.

7
!INSTALLATION SAFETY PRECAUTIONS
●Read this installation manual entirely before assembling this equipment.
●Verify that there is adequate space surrounding this piece of equipment for safe access and operation. Installation
must meet ADA requirements for accessibility.
●Install this piece of equipment on a solid level surface that does not deviate more than 1/8” over a 10’ distance (or as
defined and required by local building and architectural codes.)
●TRUE strongly recommends that all equipment be anchored to the floor to prevent movement and increase stability.
○Due to the wide variation of flooring on which the unit can be installed, contact a qualified contractor to determine
an appropriate fastening system for your floor.
○Use 3/8” diameter hardware (10 mm) to anchor the machine. Anchors should have a minimum pull out force of
220 lb (110 kg) for each position.
○When attaching the machine to the floor, if there is a gap between the machine foot and the floor, do not use the
anchor to remove the gap as this can cause the machine frame to deform. Instead, place a shim between the
bottom of the foot and the floor, then tighten the anchor.
○Anchoring holes are provided on the feet of the frame. All anchoring locations must be used when anchoring the
equipment to the floor.
●DO NOT install any fitness equipment near a pool, hot tub or other damp locations. Corrosion caused by installation in
these locations can lead to premature failure of components.
●Be sure all hardware is tight before using this machine.
●Some assembly materials may come preassembled in the carton. Refer to the Assembly Instructions for more
information on disassembling any assembly materials before beginning assembly.
!MAINTENANCE SAFETY PRECAUTIONS
●Refer to the maintenance schedule table in this manual for when to perform maintenance.
●Check the function of your machine DAILY by verifying the following:
○If equipped with cables, inspect cables and end fittings for any signs of wear. Replace if worn, frayed, or damaged
with TRUE replacement components.
○Verify that all adjustments are possible and carried out with ease. Make sure that each adjustment pin inserts
completely into each position without binding.
○Verify that safety catches and stops are in proper working order and engaged.
○Verify that the exercise is performed smoothly, free of noise, and/or binding.
○If equipped with a weight stack, verify that the proper weight selector pin is in place.
●Check the function of your machine WEEKLY by verifying the following:
○Nuts, Bolts, and Fasteners: check tightness weekly. If any hardware has become loose, retighten it, use Loctite®
Threadlocker 242, or both.
○Frames and Lifting Arms: Inspect weekly for integrity and function. Replace any component at first signs of wear.
Use only TRUE supplied components.
●Replace any warning label at the first sign of wear. Labels and the facility safety sign may be obtained from TRUE.

8
GENERAL CARE AND MAINTENANCE
!IMPORTANT
Preventative maintenance is crucial to maintaining the function and safety of this equipment. Your facility must establish
written guidelines for preventative maintenance and keep written or online records of the maintenance performed on these
products. As a minimum, the items presented in the SAFETY section of this document and the items that follow here,
should be included in your maintenance program.
●Cables (if equipped)—inspect end fittings daily for wear. Inspect the entire length of the cable weekly. Replace cables
at the first sign of wear and on an annual basis. If the cable tension has been adjusted, be certain that the cable nut is
tight.
●Nuts, bolts, and fasteners—check tightness weekly. If any hardware has become loose, retighten and/or use Loctite®
brand Threadlocker 242. Be sure all hardware is tight before using the machine.
●Safety catches—inspect catches, stop rods and their associated fasteners. Tighten any loose hardware and replace
any components at first signs of wear.
●Frames—sweat, disinfecting sprays and spills can lead to corrosion which may lead to premature failure of
components. Wipe all machines down with a damp cloth and dry completely each day. This includes painted parts,
chrome parts and upholstered pads.
●Painted and chrome plated parts—use Simple Green with a dilution of 32:1 or similar cleaner for light dirt and grime.
Use Turtle Wax Polishing Compound or a good car polish to remove heavier dirt and grease as well as for polishing.
DO NOT use solvents, lacquer thinner, acetone or finger nail polish remover. For scuffs and marks that are not
removed by the above methods use a soft scrub cleanser. Make sure all parts are dry upon completion.
●Weight stack enclosures (shrouds) (if equipped)—wipe down with a damp cloth as needed.
●Exercise instruction labels—clean with soap and water as needed.
●Guide rods (if equipped)—wipe all dirt and dust from the guide rods before applying a light application of Tri-FlowTM or
other teflon spray lubricant. Spray the Tri-FlowTM on a rag and then wipe the guide rods with the rag. DO NOT use oil
lubricants such as WD-40.
!CAUTION: Tri-FlowTM will stain carpet and clothing.
●Bronze bushings—check monthly for signs of wear and replace as needed.
●Linear bearing shafts—wipe any accumulation of dust or other contaminants from the shafts on a weekly basis. Apply
a thin layer of a Teflon®(PTFE) grease on a weekly basis. TRUE recommends Magnalube®brand.
●When replacing any component, use only TRUE supplied parts.
●Be sure all hardware is tight before using the machine.
Retain these instructions for future reference. If you have any questions, do not hesitate to contact your TRUE dealer or
TRUE product support (service@truefitness.com // 800.883.8783).

9
COMMERCIAL MAINTENANCE SCHEDULE
Commercial Maintenance Schedule
Daily Weekly Monthly 6 Months Annually
Inspect cables for wear, tension, and proper
connection if equipped. Replace at the first sign of
wear.
X
Inspect cable length and cable end fittings.
Replace at the first sign of wear. X
Inspect all nuts and bolts and tighten if needed. X
Inspect safety catches, stop rods, and their
fasteners. Replace at the first sign of wear. X
Inspect all anti-slip surfaces and replace as
needed. X
Inspect all adjustment pins, weight stack pins,
set screws, gas shocks, snap links, and pulleys if
equipped.
X
Inspect all accessory bars and handles. X
Inspect all safety and instructional decals. X
Inspect all weight stack shields if equipped. X
Clean guide rods and lubricate with a teflon
lubricant if equipped. X
Clean and condition upholstery. X
Clean and polish frame. X
Clean and polish chrome. X
Lubricate pivot bearings and linear bearings. X
Replace cables if equipped. X
COMPLIANCES
This equipment complies with all applicable codes and regulations. For a complete list of compliances, please visit
www.truefitness.com.

10
DIMENSIONS AND WEIGHTS
●ASSEMBLED DIMENSIONS (W X D X H)
48.5" x 45” x 46.5” / 123.2 cm x 114.3 cm x 118.1 cm
DEPTH
45”
114.3 cm
WIDTH
48.5”
123.2 cm
HEIGHT
46.5”
118.1 cm
POST CAPACITY
Number of
Active Posts
Max 45LB. Plates
Per Active Post
Number of
Storage Posts
Max 45LB. Plates
Per Storage Post
Total Number of Weight
Plates Allowed
14 0 4 4
●PRODUCT WEIGHT
227 lbs / 103 kg
●MAXIMUM USER WEIGHT
400 lbs / 182 kg
●MAXIMUM LOAD (USER WEIGHT + WEIGHT PLATES)
580 lbs / 263 kg
45
LB.
20.4
KG.
weight plate
active post

11
WARNING AND INTENDED USE LABELS
!WARNING: Replace all labels that may be worn, damaged, or missing.
To replace any worn or missing decals contact TRUE product support (service@truefitness.com // 800.883.8783).
LABEL LOCATIONS
1
6
3
2
5
6
8
7
5
4
9
Item Description Qty
1 LBL-ADJ-SPL013 (Adjustment Knob) 1
2 LBL-WRN-PLS003 (Plate Weight) 1
3 B2065 (Pop Pin Warning) 1
4 LBL-WRN-PLS1301 (Finger Warning) 1
5 LBL-PRO-PLS1300 (Placard) 1
6 LBL-WRN-PLS001 (General Warning) 1
7 LBL-MTN-PLS001 (Maintenance) 1
8 LBL-LOG-010BK (Logo) 1
9 SPL-00-LBLSN (Serial Number) 1
Description Image
LBL-ADJ-SPL013 (Adjustment Knob)
LBL-WRN-PLS003 (Plate Weight)
LBL-WRN-PLS003ASTM 1749
DO NOT
EXCEED FOUR
45 LB. PLATES
PER POST

12
Description Image
B2065 (Pop Pin Warning)
LBL-WRN-PLS1301 (Keep Fingers
Clear Warning)
LBL-WRN-PLS1301
KEEP FINGERS AWAY.
DO NOT GRASP HERE.
LBL-PRO-PLS1300 (Placard)
STANDING
LEG CURL
LBL-PRO-PLS1300
LBL-WRN-PLS001 (General Warning)
LBL-MTN-PLS001 (Maintenance)
LBL-LOG-010BK (Logo)
SPL-00-LBLSN (Serial Number)
TRUE FITNESS TECHNOLOGY, INC
865 HOFF RD, ST LOUIS MISSOURI 63366 USA
MODEL NO: PLS1300
SERIAL NO: 23-PLS130001X

13
ASSEMBLY INSTRUCTIONS
TOOLS NEEDED FOR ASSEMBLY
Wire Cutters or Scissors
(used in unboxing the machine)
#2 Phillips Screwdriver or Electric Screwdriver
(both are optional in unboxing the machine)
3/8", 5/16", and 5/32" Allen Wrenches
(or ratcheting socket wrench with hex bits - ball
end recommended)
Rubber Mallet
Retaining Ring Pliers
VERIFY BOX CONTENTS
IMPORTANT! Please verify all box contents. If you have questions, or if there are any missing parts, contact
product support (service@truefitness.com // 800.883.8783).
PREASSEMBLY CHECKLIST
Use caution when assembling this product.
Unpacking and assembling this product requires two or more people.
Use caution when unpacking this product. Avoid damage to the product and product pads.
DO NOT use a box cutter. DO NOT slice into the packaging.
!CAUTION:

14
BOX CONTENTS
Item Image Qty
Main Frame
Assembly 1
Side Frame
Assembly 1
Arm Assembly 1
Leg Assembly 1
BOX CONTENTS
Item Image Qty
Foot Plate 1
Active Weight Post
Assembly 1
Thigh Pad
Assembly 1
Chest Pad 1
Roller Pad
Assembly 1
Pad Kit Hardware
Bag 1
Manual 1

15
ASSEMBLY STEPS
STEP 1—ASSEMBLE FOOT PLATE TO CENTER FRAME ASSEMBLY
Parts Used in this Step
PART# DESCRIPTION QTY
PLS-13-MFR300X ASSEMBLY, CENTER FRAME 1
PLS-13-FPT010 WELDMENT, FOOT PLATE 1
C 749B LOCK WASHER, 3/8", BLK ZP 3
C 622A SHCS, 3/8"-16 X 3/4", BLK 3
1. Using a 5/16" allen wrench, remove and set aside
the socket head cap screws and lock washers from
the center frame assembly.
2. Using two people, line up the foot plate with
the center frame assembly and finger tight the
previously removed socket head cap screws and
lock washers.
Tools Used in this Step
5/16" Allen Wrench
C 749B
C 622A
PLS-13-FPT010
PLS-13-MFR300X

16
STEP 2—ASSEMBLE SIDE FRAME ASSEMBLY TO CENTER FRAME ASSEMBLY
Parts Used in this Step
PART# DESCRIPTION QTY
PLS-13-MFR300X ASSEMBLY, CENTER FRAME 1
PLS-13-MFR250X ASSEMBLY, RIGHT FRAME 1
C 750B LOCK WASHER, 1/2MED.SPLIT, BLK 4
C 640A SHCS, 1/2"-13 X 1", BLK 4
1. Using a 3/8" allen wrench, remove and set aside the
socket head cap screws and lock washers from the
center frame assembly.
2. Using two people, line up the side frame with
the center frame assembly and finger tight the
previously removed socket head cap screws and
lock washers. Once all the frame hardware is finger
tight, use a 3/8" allen wrench and 5/16" allen wrench
to fully tighten.
Tools Used in this Step
3/8" Allen Wrench
5/16" Allen Wrench
C 750B
C 640A
PLS-13-MFR300X
PLS-13-MFR250X

17
STEP 3—ASSEMBLE ARM ASSEMBLY TO SIDE FRAME ASSEMBLY
Tools Used in this Step
5/16" Allen Wrench
Rubber Mallet
1. Using a 5/16" allen wrench, remove the
preassembled socket head cap screws, lock
washers, caps, and axle from the side frame
assembly.
2. Using two people, place the arm assembly in
between the brackets of the side frame assembly.
3. Line up the flat edge of the axle with the flat edge of
the frame/shaft and using a rubber mallet, lightly tap
the axle into place.
4. Using a 5/16" allen wrench, attach the socket head
cap screws, lock washers, and caps to secure the
arm assembly to the side frame assembly.
Parts Used in this Step
PART# DESCRIPTION QTY
PLS-13-ARM200X ASSEMBLY, LIFTING ARM 1
PLS-13-MFR250X ASSEMBLY, RIGHT FRAME 1
PLS-01-AXL001 AXLE, PIVOT 1
PLS-00-CAP005 ALM BOLT CAP 2
C 622A SHCS, 3/8"-16 X 3/4" 2
C 749B LOCK WASHER, 3/8", BLK ZP 2
PLS-13-MFR250X
PLS-00-CAP005
PLS-01-AXL001
PLS-13-ARM200X
C 749B
C 622A
flat edge
of axle
flat edge
of shaft

18
STEP 4—ASSEMBLE ANKLE ASSEMBLY TO LIFTING ARM ASSEMBLY
Tools Used in this Step
Retaining Ring
Pliers
5/16" Allen Wrench
Parts Used in this Step
PART# DESCRIPTION QTY
PLS-13-ARM200X ASSEMBLY, LIFTING ARM 1
PLS-13-ARM150X ASSEMBLY, RIGHT ANKLE ARM 1
C 749B LOCK WASHER, 3/8", BLK ZP 1
C 622A SHCS, 3/8"-16 X 3/4", BLK 1
SPL-00-CAP002 CAP, BOLT, ALUMINUM 1
D 132 RING, WST-137 MED HVY DUTY RETAINING 1
D2208 SPRING, EXTENSION 1
1. Using a 5/16" allen wrench and retaining ring pliers, remove and set aside the socket head cap screw, lock washer,
cap, and retaining ring from the leg assembly.
2. Attach the ankle assembly to the lifting arm assembly.
3. Using retaining ring pliers and a 5/16" allen wrench, securely fasten the previously removed retaining ring, cap, lock
washer, and socket head cap screw.
4. Attach the extension spring to the lifting arm assembly and ankle assembly.
C 622A
SPL-00-CAP002
PLS-13-ARM150X
PLS-13-ARM200X
PLS-13-ARM150X
D 132
C 749B
IMPORTANT! Verify the retaining
ring is completely wrapped around
the end of the ankle assembly axle.
retaining
ring
retaining
ring
D2208

19
STEP 5—ATTACH PADS TO MAIN FRAME AND ANKLE ASSEMBLY
Parts Used in this Step
PART# DESCRIPTION QTY
PLS1300 PAD KIT PAD KIT PLS 1
PAD KIT HARDWARE
C 624A SHCS, 3/8"-16 X 1-1/4", BLK 7
C 749A LOCK WASHER, 3/4 MED SPLIT, BLKPHOS/OIL BLK 7
C 754B WASHER, FLAT, 3/8" SAE, BLK 7
C 749B LOCK WASHER, 3/8", BLK ZP 1
C 623A SHCS, 3/8"-16 X 1" BLK ZP 1
SPL-11-ADJ157 ROLLER PAD WASHER 1
PAD-RLR100X-2 ROLLER PAD END CAP 1
C 749A
C 749A
C 754B
C 754B
C 624A
C 624A
1. Using a 5/16" allen wrench, attach the three socket
head cap screws, lock washers, and flat washers to
secure the upper pad assembly to the main frame
assembly.
2. Using a 5/16" allen wrench, attach the four socket
head cap screws, lock washers, and flat washers to
secure the middle pad assembly to the main frame
assembly.
Tools Used in this Step
5/16" Allen Wrench

20
STEP 5—ATTACH PADS TO MAIN FRAME AND ANKLE ASSEMBLY CONTINUED
C 749B
SPL-11-ADJ157
PAD-RLR100X-2
C 623A
3. Using a 5/16" allen wrench, attach the socket head cap screw, lock washer, and flat washer to secure the roller pad
assembly to the ankle assembly.
