Trust 250SP User manual

L I F E I S M O R E ! T R U S T U S T R U S T . C O M
T R U S T . C O MT R U S T . C O M
T R U S T . C O M
AMI MOUSE 250SP WIRELESS OPTICAL
UK
DE
FR
IT
ES
NL
PL
User’s manual

AMI MOUSE 250SP WIRELESS OPTICAL
L I F E I S M O R E ! T R U S T U S T R U S T . C O M
T R U S T . C O MT R U S T . C O M
T R U S T . C O M
Fig. 1 Fig. 2 Fig. 3
Fig. 4 Fig. 5 Fig. 6
Fig. 7 Fig. 8 Fig. 9

TRUST AMI MOUSE 250SP WIRELESS OPTICAL
1
UK
Thank you for your purchase. Register your product via our Internet site at
www.trust.com, so that you will be eligible for optimal guarantee and service
support. You will also be automatically informed of the development of your and
other Trust products.
Vielen Dank, dass Sie unser Produkt gekauft haben. Registrieren Sie jetzt ihr
Produkt auf unserer Website, www.trust.com, so dass Sie unsere optimale
Garantie- und Serviceunterstützung in Anspruch nehmen können. Außerdem
werden Sie automatisch über die Entwicklung Ihres und anderer Produkte auf dem
Laufenden gehalten.
Nous vous remercions de votre achat. Enregistrez-le maintenant sur notre site
Internet, www;.trust.com. et vous aurez droit à une garantie et un soutien de
service optimaux. En outre, vous serez informé automatiquement des mises à jour
de votre produit et des autres produits de Trust.
Grazie per aver acquistato un prodotto Trust. Registri l' acquisto effettuato presso il
sito internet Trust (www.trust.com), in questo modo potrà usufruire dell’ assistenza
e della garanzia. Inoltre potrà ottenere informazioni aggiornate sulle novità
riguardanti il suo prodotto ed anche gli altri prodotti Trust.
Muchas gracias por su adquisición. Registre ahora su adquisición a través de
nuestro sitio en Internet, www.trust.com, de modo que tenga derecho al soporte de
garantía y de servicio óptimo. Se mantendrá, además, automáticamente al
corriente de los desarrollos de su producto y de los demás productos de Trust.
Serdecznie dziękujemy za zakup naszego produktu. Rejestrując jużteraz swój
zakup na stronie internetowej firmy Trust, www.trust.com, uzyskacie Państwo
optymalne wsparcie gwarancyjne i serwisowe. Ponadto będziecie Państwo
automatycznie informowani o wszelkich zmianach odnośnie tego i innych
produktów firmy Trust.
Hartelijk dank voor uw aankoop. Registreer nu uw aankoop via onze internet site,
www.trust.com, zodat u in aanmerking komt voor optimale garantie- en service
ondersteuning. Bovendien wordt u automatisch op de hoogte gehouden van de
ontwikkeling van uw en andere Trust producten.

TRUST AMI MOUSE 250SP WIRELESS OPTICAL
2
www.trust.com
Residents in the UK and Ireland should contact: .............................................................
From
8:00 - 16:00
UK Office
Phone [phone]
Fax [phone]
I residenti in Italia possono contattare:
Orario:
9:00 - 13:00 /
14:00 -18:00
Ufficio italiano
Telefono [phone]
Fax [phone]
Les habitants de la France et de l’Afrique du Nord peuvent contacter :
De
9:00 à 17:00
Bureau français
Téléphone [phone]
Fax [phone]
Kontaktadresse für Einwohner Deutschlands:
Erreichbar:
9:00 - 17:00
Deutsche Geschäftsstelle
Telefon 0800-00TRUST (0800-0087878)
Fax [phone]
Los habitantes de España pueden ponerse en contacto con:
De las
9:00 a las 17:00
horas
Oficina española
Teléfono [phone]
Fax [phone]
Inwoners van Nederland kunnen contact opnemen met:
Van
9:00 - 17:00 uur
Kantoor Nederland
Telefoon 0800-BELTRUST (0800-23587878)
Fax [phone]
All other countries / Alle anderen Länder / Tous les autres pays
Tutti gli altri paesi / Todos los demás países / Alle andere landen
From:
9:00 - 17:00
European Head Office
Phone [phone]
Fax [phone]

TRUST AMI MOUSE 250SP WIRELESS OPTICAL
3
UK
Method when using for the first time Chapter
1. Connecting (3.1)
2. Uninstalling old drivers and devices (3.2)
3. Installation in Windows (3.3)
4. Checking after the installation (3.4)
1 Introduction
This instruction manual is for users of the TRUST AMI MOUSE 250SP WIRELESS
OPTICAL. This mouse allows you to work optically without the use of wires. The
mouse has two channels and 5 buttons. It is not necessary to replace the batteries.
You can simply recharge the NiMH batteries provided by placing the mouse,
including the batteries, into the recharger.
2 Safety
Carefully read the following instructions before use:
-The TRUST AMI MOUSE 250SP WIRELESS OPTICAL does not require any
special maintenance. Use a slightly damp, soft cloth to clean the mouse.
-Do not use aggressive substances, such as petrol or white spirit, to clean the
device. These may harm the material.
-Do not submerge the device in liquid. This will damage the device. Do not
use this device near water.
-Make sure nothing is placed on the cable. Do not use this device in an area
where the cable can become worn or damaged as a result of people walking
over it.
-Do not repair this device yourself.
-This product works at a frequency of 27 MHz. It is approved according to the
European R&TEE guidelines and, therefore, meets the harmonized
standards for use within the EU. There may be limitations for the use of this
device outside of the EU. In that case, check whether this device meets local
regulations. Frequency: 27,500~27,555 MHz / 27,045~27,100 MHz,
Bandwidth: 10 kHz, Power: -20dBm.
-Nowadays, there are an increasing number of wireless products (video,
audio, convenience, computer, etc.) which work in the same frequency range
as this device. It may, therefore, be possible that the functionality of this
product is limited by or is limiting for other wireless products. This can only be
avoided by paying attention to the distance between products and, where
possible, by changing channels.
-Be careful when using wireless devices if you have a pacemaker or are
dependent on other life-saving, sensitive electronic equipment, because this
product transmits radio signals.
!

TRUST AMI MOUSE 250SP WIRELESS OPTICAL
4
3 Installation
3.1 Connecting and making a wireless connection
Note: Make sure you have your Windows CD-ROM available. Certain
versions of Windows may request you to insert your Windows CD-
ROM into your CD-ROM drive.
1. Make sure the computer is turned off.
2. Connect the adapter to connection (A) on the RF receiver (see figure 1).
3. Insert the adapter into the plug socket.
4. Select a channel (1 or 2) using the channel selection switch (A) on the bottom
of the RF receiver (see figure 2).
5. Open the battery cover (A) on the bottom of the mouse (see figure 3).
6. Use the channel selection switch on the inside of the mouse’s battery
compartment to select the same channel as you selected on the RF receiver.
7. Insert the batteries into the battery compartment. The diagram inside the
battery compartment shows how the batteries should be inserted.
8. Connect the RF receiver to the PS/2 port.
9. Turn the computer on.
10. The green indicator (F) on the RF receiver will be lit when the computer is
turned on (see figure 4).
11. Immediately press the detection button (B) on the bottom of the RF receiver
(see figure 2). The green indicator on the RF receiver will start to flash.
12. Next, press the detection button (B) on the bottom of the mouse once (see
figure 3).
13. The green indicator on the RF receiver will start to flash more quickly.
14. A connection has been made once the green indicator remains continuously
lit.
15. The mouse will be detected and installed automatically in Windows ME,
Windows 2000 and Windows XP. In Windows 95 and Windows 98, you may
be asked by Windows to insert your Windows CD-ROM into your CD-ROM
drive. In that case, insert your Windows CD-ROM into your CD-ROM drive
and follow the on-screen instructions.
Your mouse is now ready for use. The software supplied should be installed for full
use of the extra buttons on your mouse.
Note: Inserting the batteries incorrectly will cause damage.
Note: The NiMH batteries provided are rechargeable. The batteries will be
recharged when the mouse is placed in the RF receiver. The batteries
will only be recharged if the RF receiver has been connected to the
power supply using the power adapter provided.

TRUST AMI MOUSE 250SP WIRELESS OPTICAL
5
UK
Note:Insert the mouse into the RF receiver when it is not in use.
Note: The batteries will last for 8 to 10 hours with continuous use without the
mouse being placed in the sleep setting. The batteries work for 2 weeks
with normal use.
Note: For the best results, charge the batteries for 8 hours or until the red
indicator on the recharger flashes before using the mouse (see chapter
4.1).
Note: Only use rechargeable NiMH batteries.
Note: To save the batteries, the mouse will be placed in the sleep setting if it
is not used for 10 minutes. The mouse can be reactivated by pressing
the left or right mouse button.
3.2 Uninstalling old drivers and devices
The most common cause of faults during installation is the presence of a driver for a
similar, old product. The best solution is to first remove all drivers related to old
devices before installing the new driver.
1. Enter the Windows ‘Safe Mode’ (press F8 when starting Windows and then
select ‘Safe Mode’ from the menu which is displayed).
2. Go to ‘Start – Settings – Control Panel’ and double-click on the ‘Add/Remove
Programs’ icon.
3. Find all the programs for similar, old devices and remove these by clicking on
the ‘Add/Remove’ button. When in the ‘Safe Mode’, it is possible for some
programs to appear twice. In that case, remove all the programs which
appear twice.
4. Restart the computer.
3.3 Installing the software in Windows 95 / Windows 98 /
Windows ME / Windows 2000 / Windows XP
Note: The latest driver can be downloaded from www.trust.com/13020. Check
whether a new driver is available and use this for the installation.
Note: Make sure all other programs are closed during the installation.
Note: During installation in Windows XP, you may receive a message saying
that the driver has not been signed. This does not cause a problem for
the functionality.
Note: In the example, ‘D:\’ is used to indicate the CD-ROM drive. This may be
different for your computer.
1. Insert the CD-ROM into your CD-ROM drive. The Trust Software Installer
will start automatically.
If it does not start automatically, carry out the following:
a) Select 'Run' from the Start menu.
b) Type [D:\SETUP.EXE] and click on 'OK' to start the Trust Software
Installer.
2. Figure 5 will appear. Select the language you wish to use during the
installation.
3. Click on 'Trust AMI MOUSE 250SP WIRELESS OPTICAL‘ to start the
installation.
4. Follow the on-screen instructions.

TRUST AMI MOUSE 250SP WIRELESS OPTICAL
6
3.4 Checking after the installation
After installing the device and the driver, the following are installed on your computer
and can be checked
Taskbar
- The icon shown in figure 6 should be visible in the right-hand corner of your
taskbar.
‘Start – Settings – Control Panel’. Double-click on the ‘System’ icon and select the
‘Device Manager’ tab.
- Mouse – PS/2 Compatible Mouse Port
‘Start – Settings – Control Panel’ and then double-click on the ‘Add/Remove
Programs’ icon.
- Trust Ami Mouse 250S Series 1.2
Start - Programs - Trust - …
- Register (Here, you can register at the Trust site)
- Trust Ami Mouse 250S Series 1.2 (Here, you will find the mouse settings)
- Uninstall Trust Ami Mouse 250S Series 1.2 (Here, you can uninstall the mouse
software)
Note: The information given above will vary when the installation has been
altered by the user (for example, not everything has been installed or
locations other than the default locations have been selected).
Note: Deviations may also occur as a result of using new drivers available on
the Internet.
Note: The location or name may vary in the ‘Control Panel’ for different
operating systems.
4 Use
4.1 Recharging
The mouse batteries are empty when the indicator on the scroll button is lit. It is
recommended to regularly place the mouse in the RF receiver, so that the batteries
are always fully charged. The batteries are recharged as follows.
1. Make sure the receiver is connected as described in chapter 3.1.
2. Place the mouse in the RF receiver.
3. The red indicator on the RF receiver will remain lit when the mouse batteries
are being recharged.
4. The red indicator on the RF receiver will flash when the batteries are almost
fully charged.
5. The red indicator on the RF receiver will go out when the batteries are fully
charged.
Note: Most computers have a PS/2 port to which voltage is applied, even when
the computer is turned off. This allows the batteries to also be recharged
when the computer is turned off. See the instruction manual provided
with your computer to see whether your computer has such a PS/2 port.
4.2 Mouse
In the table below, a description is given of the function of the mouse buttons. Use
table 1 in combination with figure 4.
Item Name Function
ALeft mouse button Left mouse click.
BScroll button, third mouse
button and battery power
indicator
Scroll button, programmable third
mouse button and an indicator for when
the batteries are empty.
CRight side button Programmable button.

TRUST AMI MOUSE 250SP WIRELESS OPTICAL
7
UK
Item Name Function
DRight mouse button Right mouse click.
ELeft side button Programmable button.
FGreen indicator Indicates a wireless connection.
GRed indicator Indicator for recharging the batteries.
Table 1: Explanation of the buttons
4.3 Software
1. Double-click on the Trust icon in the taskbar (see figure 6).
2. The mouse configuration window will appear (see figure 7).
3. The scroll wheel mode can be selected in the ‘Scroll wheel’ tab.
4. There are two options:
•Increased scroll mode; has all the advantages of the MS-Intellimouse
and scrolls in Windows 95, Windows 98, Windows ME, Windows
2000, Windows XP and Windows NT4.
•Intellimouse mode; works as an MS-Intellimouse.
5. Select the scroll wheel speed.
6. Select the ‘Buttons’ tab. The buttons 3, 4 and 5 can be programmed in the
‘Buttons’ tab (see figure 8).
7. Select a button and click on the arrow on the right-hand side. A drop-down
menu will appear (see figure 9).
8. Select the function you wish to use.
9. Click on ‘Apply’.
The mouse has now been programmed.
5 Selecting a new channel
You may wish to change the channel or to have the RF receiver and the mouse
detect each other again. If so, carry out the following:
1. Select the desired channel on the RF receiver using the channel selection
switch (A) (see figure 2).
2. Open the battery compartment on the mouse (A) and remove the batteries
(see figure 3).
3. Select the same channel on the mouse as on the RF receiver using the
channel selection switch in the battery compartment.
4. Reinsert the batteries and close the battery compartment.
5. Press the detection button (B) on the bottom of the RF receiver (see figure
2).
6. The green indicator (F) will start to flash (see figure 4).
7. Next, press the detection button (B) on the bottom of the mouse (see figure
3).
8. The green indicator on the RF receiver will start to flash more quickly and will
then stop flashing.
9. The mouse is now ready for use again.

TRUST AMI MOUSE 250SP WIRELESS OPTICAL
8
6 Troubleshooting
Method
1. Read the solutions given below.
2. Check for up-to-date FAQ’s, drivers and instruction
manuals on the Internet (www.trust.com/13020).
Problem Cause Possible solution
The batteries have been
inserted incorrectly.
Insert the batteries into the
battery compartment as
indicated.
The optical unit on
the bottom of the
mouse does not
light up after
inserting the
batteries.
The batteries are empty. Place the mouse in the
recharger. The batteries are
fully recharged when the red
light on the RF receiver is no
longer lit.
The red indicator on
the mouse scroll
button lights up.
The batteries are empty. Place the mouse in the
recharger. The batteries are
fully recharged when the red
light on the RF receiver is no
longer lit.
The RF receiver has not
been connected to the
computer correctly.
Check the PS/2 connection.
The green LED on
the RF receiver
does not light up.
The computer is turned
off.
Turn the computer on.
The mouse’s detection
button has not been
pressed for long enough.
Keep the detection button
pressed until the green LED on
the RF receiver stops flashing.
The mouse has not been
set to the same channel
as the RF receiver.
Set the mouse to the same
channel as the RF receiver
(see chapter 3.1).
The batteries have been
incorrectly inserted into
the mouse.
Insert the batteries into the
battery compartment as
indicated.
The batteries are empty. Place the mouse in the
recharger. The batteries are
fully recharged when the red
light on the RF receiver is no
longer lit.
The RF receiver
does not detect the
mouse and the
green light
continues to flash
quickly.
The selected channel is
disrupted by another RF
signal.
Select a different channel and
have the RF receiver and
mouse detect each other again
(see chapter 5).
It has not been connected
correctly
Connect the mouse correctly
(see chapter 3.1).
The mouse is not
detected by
Windows. Software for your
previous mouse is still
installed.
Remove the old software (see
chapter 3.2).
!
