Tuff stuff SPT-6B User manual

OWNER’S MANUAL
Maintenance & Assembly Instructions
IMPORTANT: KEEPTHIS MANUAL FOR FUTURE REFERENCE
NOTICE
It is the Purchaser’s/Owner’s obligation:
1. To disclose and post all Rules & Regulations, Alert Sign, Wall Chart, Danger,
Warning and Caution labels axed on the machine to their users.
2. Equipment to be installed byTuStu Authorized Dealer or a service
company approved by TuStu.
3. Provide scheduled inspection, maintenance & repairs and must be performed
by TuStu Authorized Dealer or a service company approved byTuStu.
4. Must use only genuine TuStu replacement parts.
www.tuffstuffitness.com
SPT-6B
Base Six-Pak Trainer
SPT-6B_Rev0
Revision Date 10-14-2013

Important Safety Instructions�����������������������������������������������������������������������Page 3
Registration, Service & Assembly ����������������������������������������������������������������Page 4
Assembly Steps �������������������������������������������������������������������������������������� Pages 5 - 16
Lat Cable Routing������������������������������������������������������������������������������������������ Page 11
Lat Cable Mapping Diagram ��������������������������������������������������������������������� Page 12
Low Row Cable Routing��������������������������������������������������������������������Pages 13 - 14
SPT-6B Exploded View ���������������������������������������������������������������������Pages 17 - 18
SPT-6B Parts List�������������������������������������������������������������������������������������������� Page 19
Inspection / Maintenance ��������������������������������������������������������������������������� Page 20
Cable Inspection��������������������������������������������������������������������������������������������� Page 21
DANGER, WARNING, & CAUTION Labels Information�������������Pages 22 - 23
SPT-6B Label Placement������������������������������������������������������������������Pages 24 - 25
L 41 1/2” x W 32 3/4” x H 80”
TOTAL UNIT WEIGHT: 433 LBS
41 1/2"
32 3/4"
2SPT-6B Base Six-Pak Trainer
www.tuffstuffitness.com
Table of Contents
Overhead Specifications
TuffStuff Fitness Equipment Inc. continually engages in research related to product improvements. Please take the time to carefully read through this manual
thoroughly. Instructions contained in this manual are not intended to cover all details or variations possible with this equipment, or to cover every contingency
that may be met in conjunction with assembly, installation, operation, maintenance or troubleshooting of the equipment. Eventhough we have prepared
this manual with extreme care, neither the manufacturer nor the author can accept responsibility for any errors in, or omission from, the information given.
Should additional information be required, or should situations arise that are not covered by this manual, the matter should be directed to Customer Service at
TuffStuff Fitness Equipment Inc. in Chino, California.

It is the responsibility of the owner and users of the equipment to review the Owner’s Manual, Exercise Chart and understand all Danger,
Warning and Caution labels axed on the machine.
SERIOUS INJURY OR DEATH CAN OCCUR IF
THESE SAFETY PRECAUTIONS ARE NOT OBSERVED:
1. Obtain a medical exam before beginning any exercise program.
2. Read and understand Owner’s Manual, Exercise Chart and all Danger,
Warning and Caution labels before using this equipment. If you
still need help, seek assistance from oor personnel or call TuStu
Fitness at 888-884-8275.
3. Inspect the equipment before each use for wear and tear, loose
ttings, worn or frayed cables and frame welds. DO NOT USE if it
appears to be inoperable or damaged.
4. Stop exercising if you feel faint or dizzy. Consult a physician if you are
experiencing pain.
5. Keep body, clothing and hair clear from all moving parts. Do not
attempt to free any jammed parts by yourself.
6. Always warm-up before and cool-down after weight training.
Warm-up for 10-15 minutes with stretching and cardiovascular
exercises. Cool-down should include light stretching exercises for
5-15 minutes.
7. Never hold your breath – will limit the ow of oxygen to your brain
and may cause dizziness.The most often used breathing is inhaling
during least resistance and exhaling during maximum resistance.
8. Do not use accessories or accessory attachments that are not
recommended by TuStu.
9. Make sure adjustment pull-pins are completely inserted and fully
engaged before each use.
10. Never pin the weights in an elevated position. Do not use the machine
if found in this condition.
Facility Safety Guidelines and Practices
1. Read and understand the Owner’s Manual before assembling,
servicing or using the equipment.
2. Equipment to be installed byTuStu Authorized Dealer or by a
Professional Service Company approved by TuStu.
3. Make sure each machine is set up and operated on a solid level
surface. Do not install equipment on an uneven surface.
4. Provide an adequate safety perimeter between the machine, walls
and other equipment to ensure that the facility has proper clearance
for usage and training.
DANGER: indicates an imminently hazardous situation which, if not
avoided, will result in death or serious injury.
WARNING: indicates a potentially hazardous situation which, if not
avoided, will result in death or serious injury.
CAUTION: indicates a hazardous situation which, if not avoided, could
result in minor or moderate injury.
5. Post and disclose all safety, rules and regulations on a bulletin board
easily accessible to users.
6. Perform regular maintenance (see Inspection Label). Pay special at-
tention to areas most susceptible to wear and tear, including but not
limited to cables, pulleys and rubber grips.
7. Do not lean against or pull on the framework, weight stack or any
component at all times.
8. Children must not be allowed near the equipment.Teenager must
be supervised.
9. Replace immediately all parts at rst sign of wear or damage. If unable
to replace worn or damaged components/parts, remove machine from
service until the repair is made.
10. Use only genuineTuStu replacement parts. Failure to do so will void
warranty and could result in serious injury or death to the users.
11. Do not remove any LABELs axed to the machine. Replace if
damaged.
12. Do not alter or modify the original manufacturer’s weight stack with
any add-on incremental weights, weight plates or dumbbells except
those with standard factory installed option.
13. Maintain a service contract with a TuStu Authorized Dealer or a
Professional Service Company approved by TuStu. Keep a service
log of all maintenance and repair activities. NOTICE: It is the sole
responsiblity of the owner or facility operator to ensure that regular
maintenance is performed.
3SPT-6B Base Six-Pak Trainer www.tuffstuffitness.com
Important Safety Instructions

Thank you for purchasing the SPT-6B Base Six-Pak Trainer. This machine is part of the TuStu line of quality strength training equipment.
To maximize your use of the equipment, please study the Owner’s Manual thoroughly.
• Allowamplespacearoundthemachineforsafeunrestricteduseand
easier access.
• Insertallboltsinthesamedirection.Foraestheticappearance,insert
all bolts in the same direction unless specied (in text or illustration) to
do otherwise.
• Leaveroomforadjustments.Donotfullytightenfastenersuntil
instructed in the assembly steps to do so (to prevent any diculty with
alignment of parts during the assembly process). When not instructed,
tighten fasteners such as bolts, nuts and screws so the unit is stable,
but leave room for adjustments.
Assembly Tips
Read all“Notes”on each page before beginning each step.
While you may be able to assemble the SPT-6B using the illustrations only,
IMPORTANT safety notes and other tips are included in the text.
Some pieces may have extra holes that you will not use. Use only those
holes indicated in the instructions and illustration.
NOTE: With so many assembled parts, proper alignment and adjustment
is critical.While tightening the nuts and bolts, be sure to leave room for
nal adjustments.
CAUTION: Obtain assistance fromTuStu if you have diculty
assemblying the SPT-6B. Please do not attempt to complete the assembly
as this could result in equipment failure and serious injuries to the users.
Symbols & Description
Loosely Tighten
70%
100%
Fully Tighten
Required Tools
The basic tools that you will need to assemble the SPT-6B but are not
limited to:
• 1/2”,9/16”,3/4”CombinationWrenches
• RatchetWrenchwith1/2”,9/16”,3/4”sockets
• CrescentAdjustableWrench
• Externalretainingringpliers
• SuperLube®spraylubricantandgrease
• Rubbermallet,measuringtape&utilityknife
• Windexorhouseholdglasscleaner
Assembly Requirements
• Aminimumoftwostrongpersonsarerequiredforthisassembly.
• FollowtheseinstallationrequirementswhenassemblyingtheSPT-6B.
• Layoutyouroorplanbeforeassemblying.
• SetuptheSPT-6Bonaclean,solid,atsurface.Asmooth,atsurface
under the machine helps keep it level.
Registration
To avoid unnecessary delays on warranty parts and to insure that a
permanent record of your purchase is on le with our company, be
sure to register online at:
http://www.tustutness.com/productregistration.jsp
within 10 days of purchase.
Obtaining Service
Please use this Owner’s Manual as your guide to all parts included in
your shipment. When ordering parts, you must specify the part number
and description from this manual. Use only genuine TuStu
replacement parts when servicing the equipment. Failure to do
so will void warranty and could result in serious injury or death.
For information about product operation or service:
Phone: [phone] Toll Free 888-884-8275
Fax: [phone]
E-mail: service@tustu.net or service1@tustu.net
Hours: M–F 8:00 – 4:30 PST
Or write to: TuStu Fitness Equipment Inc.
Customer Service
13971 Norton Avenue, Chino, CA 91710
Retain this Owner’s Manual for future reference when ordering
service or parts. To assist you better, please be prepared to
provide the following information:
1. Model Number 2. Place of Purchase
3. Serial Number 4. Part # and Description
Loosely Tighten
Loosely tighten all hardware in this step. DO NOT Fully
Tighten. Some component(s) may need pre-assembly
and or alignment during the assembly process.
Fully Tighten
Wrench tighten all hardware in this step.
Registration, Service & Assembly
4SPT-6B Base Six-Pak Trainer
www.tuffstuffitness.com

49
60 49
12
67
49
67
49
11
49
85
91
49
85
91
25
49
85
91
25
49
85
91
68
49
56
67
49
68
49 67
49
49
56
68
49
56
67
49
68
49 67
49
49
56
Assembly List
Item # Description Qty.
11 MAIN FRAME 1
12 REAR STABILIZER 1
25 HANDLE 2
49 FLAT WASHER SAE B/O 3/8” 20
56 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 1 3/4 6
60 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 4 2
67 NYLON INSERT THIN LOCK NUT B/O 3/8-16 8
68 BLACK NYLON PULLEY 3/8 X 1 X 3 1/2 4
85 SPLIT LOCK WASHER B/O 3/8” 4
91 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 4 1/4 4
100%
Fully Tighten
Wrench tighten all hardware in this step.
5SPT-6B Base Six-Pak Trainer www.tuffstuffitness.com
Step 1

6749
67 49
6
49 58
58
49
49
11
68
4
49 67
49
57 49 67
1
49
56
49
56 49 49
5
67
49
68
69
56 49 23
23
21 21
69
49 67
67 49
69
49 56
49
67
68
68
6749
67 49
6
49 58
58
49
49
11
68
4
49 67
49 49 67
1
49
56
49
56 49 49
5
67
49
68
69
56 49 23
23
21 21
69
49 67
67 49
69
49 56
49
67
68
68
Assembly List
Item # Description Qty.
1 ADJUSTABLE DOUBLE PULLEY BRACKET 1
4 DOUBLE FLOATING PULLEY BRACKET LT 1
5 DOUBLE FLOATING PULLEY BRACKET RT 1
6 STABILIZER FRAME U SHAPE 1
21 TOP BEARING HOUSING 2
23 TOP SWIVEL PULLEY BRACKET 2
49 FLAT WASHER SAE B/O 3/8” 20
56 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 1 3/4 6
57 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 3 1
58 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 3 1/2 3
67 NYLON INSERT THIN LOCK NUT B/O 3/8-16 10
68 BLACK NYLON PULLEY 3/8 X 1 X 3 1/2 4
69 NYLON PULLEY 3/8 X 1 X 4 1/2 BLACK 4
100%
Fully Tighten
Wrench tighten all hardware in this step.
6SPT-6B Base Six-Pak Trainer
www.tuffstuffitness.com
Step 2

43
84
47
47
43
1
11
75
75 20
9
75
20
75
9
Assembly List
Item # Description Qty.
1 ADJUSTABLE DOUBLE PULLEY BRACKET 1
9 LONG DOUBLE SWIVEL PULLEY BRKT 2
20 SHORT DOUBLE SWIVEL PULLEY BRKT 2
43 FINISHED HEX NUT B/O 1/2-13 2
47 FLAT WASHER SAE B/O 1/2” 2
75 RETAINING SNAP RING EXT. PLAIN 1 1/4” 4
84 SPLIT LOCK WASHER B/O 1/2” 1
Loosely Tighten
70%
Loosely Tighten
70%
Loosely tighten all hardware in this step.
DO NOT FullyTighten. Some component(s)
may need pre-assembly and or alignment
during the assembly process.
7SPT-6B Base Six-Pak Trainer www.tuffstuffitness.com
Step 3

67
49
49
56
68 67
49
49
56
68
68
49
56
56 49
49 67
56
49
49
67
68
67
49
67 49 67 49 68
56
49
49
20
56
49
68
9
68
49 67
49
56
68
68
11
49
67
49
67
9
20
11
67
49
49
56 68
49
56
68 49 67
4967
49 56
68
Assembly List
Item # Description Qty.
49 FLAT WASHER SAE B/O 3/8” 30
56 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 1 3/4 15
67 NYLON INSERT THIN LOCK NUT B/O 3/8-16 15
68 BLACK NYLON PULLEY 3/8 X 1 X 3 1/2 15
100%
Fully Tighten
Wrench tighten all hardware in this step.
8SPT-6B Base Six-Pak Trainer
www.tuffstuffitness.com
Step 4

49
67
49
56
49
68
84
43
22
49
56
27 18
76
76
50
50 93
93
50 50
7
26
58
49
49
67
49
67 49
58
7 7
11
Raise and hold Guide Rods 7up to assemble
hardware as shown.
49
67
49
56
49
68
84
43
22
49
56
27 18
76
76
50
50 93
93
50 50
7
26
58
49
49
67
49
67 49
58
7 7
11
Assembly List
Item # Description Qty.
7 GUIDE ROD 3/4 RD X 67 1/2 2
18 SELECTOR PIN W/COIL 3/8 X 4 GOLD KNOB 1
22 TOP PLATE PULLEY BRACKETS 1
26 10 LB STEEL WEIGHT PLATE BLACK 14
27 10 LB TOP PLATE W/ADJ SLTR BAR 1
43 FINISHED HEX NUT B/O 1/2-13 1
49 FLAT WASHER SAE B/O 3/8” 8
50 FLAT WASHER B/O 3/4 X 2” 4
56 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 1 3/4 2
58 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 3 1/2 2
67 NYLON INSERT THIN LOCK NUT B/O 3/8-16 4
68 BLACK NYLON PULLEY 3/8 X 1 X 3 1/2 2
76 RUBBER DONUT 1 X 2 1/2 4
84 SPLIT LOCK WASHER B/O 1/2” 1
93 WEIGHT STACK SPACER 5” (USED ONLY WITH 150 LB) 2
100%
Fully Tighten
Wrench tighten all hardware in this step.
9SPT-6B Base Six-Pak Trainer www.tuffstuffitness.com
Step 5

Weight stack label and lubrication instructions
1� Wipe front surface of weight stack with rubbing alcohol and wipe dry�
2� Peel o back sheet (adhesive side) from label #41 and make sure that the labels remain
attached to the application tape�
3� Line up hole on the second label to hole on the rst weight plate�
4� Make sure the hole on the last label lines up with last weight plate and slowly press into
place�
5� Gently remove application tape and rub each label rmly against the weight stack�
6� Once this is complete, repeat this procedure for top plate label�
6� Allow labels to stand for 2 days to allow adhesive to cure fully�
7� Open the lube package provided and apply a thin lm of lubricant around the rst 3 inches
of the guide rods above the top plate�
8� After the cables are installed, do a set of reps to spread the lubricant thoroughly�
NOTE:
1� TOP PLATE LABEL GOES ON HOLE OFF CENTER AS
SHOWN� LABEL WILL COVER HOLE ON CENTER�
10 SPT-6B Base Six-Pak Trainer
www.tuffstuffitness.com
Step 6

STEP 3
E
F
G
STEP 4
I
G
H
8
51
79
86
81
92
4959
21
85
59 49
5
4
8
51
79
86
81
92
4959
21
85
59 49
5
4
STEP 5 M
LKJ
I
5
4
5
4
STEP 2
E
B
A
D
C
59
49
59
21
85
49
92
81
86
51
79
8
59
49
59
21
85
49
92
81
86
51
79
8
STARTING POINT
STEP 1
RUN CABLE THROUGH STARTING POINT INTO
TOP SWIVEL PULLEY BRACKETAS SHOWN AND
THEN ASSEMBLE IT TO THE UNIT.
FOLLOW LETTER SEQUENCE
TO ROUTE THE CABLE.
Assembly List
Item # Description Qty.
4 DOUBLE FLOATING PULLEY BRACKET LT 1
5 DOUBLE FLOATING PULLEY BRACKET RT 1
8 LAT CABLE 1
21 TOP BEARING HOUSING 2
45 Oval Head Phillips Screw #10-32 X 1 1/8 2
49 FLAT WASHER SAE B/O 3/8” 4
51 Cable Stopper Shell 1 1/2 x 1 3/4 2
59 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 3/4 4
81 SNAP LINK Z/P 8MM X 80MM 2
85 SPLIT LOCK WASHER B/O 3/8” 4
86 7/8 Rd X 1 5/8 Link 1/8 Cable 2
92 CONTOUR ERGO HANDLE SHORT STRAP 2
NOTE: PULLEY BRACKETS (#4, #5) HAVE BEEN
SWAPED PLACES FROM PREVIOUS OWNERS
MANUAL. ASSEMBLE AS SHOWN ABOVE.
11SPT-6B Base Six-Pak Trainer www.tuffstuffitness.com
Step 7 (Lat Cable Routing)
92
81
86
51
45
45
51
86
81
92

8
4
5
12 SPT-6B Base Six-Pak Trainer
www.tuffstuffitness.com
Step 8 (Lat Cable Mapping Diagram)
Assembly List
Item # Description Qty.
4 DOUBLE FLOATING PULLEY BRACKET LT 1
5 DOUBLE FLOATING PULLEY BRACKET RT 1
8 LAT CABLE 1
A
B
C
D
F
H
E
G
I
J
K
L
M

53
48
65
48
48
65
5
4
53
53
48
65
48
48
65
5
4
53
Assembly List
Item # Description Qty.
5 DOUBLE FLOATING PULLEY BRACKET RT 1
10 LOW ROW CABLE 1 45 Oval Head Phillips Screw #10-32 X 1 1/8 2 48 FLAT WASHER SAE B/O 1/4” 4 51 Cable Stopper Shell 1 1/2 x 1 3/4 2 53 HEX HEAD CAP SCREW GR-5 B/O 1/4-20 X 1 3/4 2 64 CONTOUR ERGO HANDLE LONG STRAP 2 65 NYLON INSERT LOCK NUT B/O 1/4-20 2 81 SNAP LINK Z/P 8MM X 80MM 2 86 7/8 Rd X 1 5/8 Link 1/8 Cable 2
NOTES: 1. SOME PARTS NOT SHOWN FOR CLARITY
86 51
81
79
64
86 51
81
79
64
A
B
C
STEP 1
5
79
51
86
81
64
4
5
79
51
86
81
64
4
D
C
E
F
STEP 2
13SPT-6B Base Six-Pak Trainer www.tuffstuffitness.com
Step 9 (Low Row Cable Routing)
51
45
45
51
86
81
64
86
81
64

4
10
53
48
65
48 53
63
65
5
4
10
53
48
65
48 53
63
65
5
Assembly List
Item # Description Qty.
4 DOUBLE FLOATING PULLEY BRACKET LT 1
10 LOW ROW CABLE 1 45 Oval Head Phillips Screw #10-32 X 1 1/8 2 48 FLAT WASHER SAE B/O 1/4” 4 51 Cable Stopper Shell 1 1/2 x 1 3/4 2 53 HEX HEAD CAP SCREW GR-5 B/O 1/4-20 X 1 3/4 2 63 NYLON ANKLE STRAP 1 64 CONTOUR ERGO HANDLE LONG STRAP 2 65 NYLON INSERT LOCK NUT B/O 1/4-20 2 81 SNAP LINK Z/P 8MM X 80MM 2 86 7/8 Rd X 1 5/8 Link 1/8 Cable 2
NOTES: 1. SOME PARTS NOT SHOWN FOR CLARITY
81
86
51
79
64
81
86
51
79
64
A
B
C
STEP 1
79
51 86 81
4
10
64
79
51 86 81
4
10
64
D
E
C
F
STEP 2
14 SPT-6B Base Six-Pak Trainer
www.tuffstuffitness.com
Step 10 (Low Row Cable Routing)
81
86
45
51
51 86 64
81
45
64

22298
100%
Fully Tighten
Proceed to align and Wrench Tighten these
hardware assemblies and all of the previous
assemblies that were left loosely fastened.
MAKE NECESARYADJUSTMENTS ON
THE FOUR ADJUSTABLE ADAPTERS
15SPT-6B Base Six-Pak Trainer www.tuffstuffitness.com
Step 11

11
48 54
48
24
48 54
48
Assembly List
Item # Description Qty.
24 WEIGHT SHIELD 1
48 FLAT WASHER SAE B/O 1/4” 4
54 HEX HEAD CAP SCREW GR-5 B/O 1/4-20 X 3/4 4
100%
Fully Tighten
Wrench tighten all hardware in this step.
16 SPT-6B Base Six-Pak Trainer
www.tuffstuffitness.com
Step 12

5
49
68
67
49
68
56 49
68
56
49
49
49
68
67
47
43
49 57
49
67
69
68
56
68
49
67
67
49
56
60
56
49
60
71
44
28
12
77 77
20 68
30
75
77
9
48
65
49
67 49
68
48 53 56
49
48
65
49 67 49
30
20
48
53
25
56
49
68
49
85
59
49
85
59 68
49 56
23
49
67
30
21
30
75
70
47
84
43
78
59
91
49
85
56
49
67 49
30
75
11
9
67
1
49
30
4
85
23
SEE VIEW2
SEE VIEW1
17SPT-6B Base Six-Pak Trainer www.tuffstuffitness.com
SPT-6B Exploded View

49
56
56
49
68
67
49
43
84
18
27
41
24
48 54
88
48 54
49
67
70
44
28
70
6
44
28
67
49
49
58
42
54
48
48
50
93
50
50
76
76
26
7
49
49
58
49
VIEW 2
VIEW 1
USED ONLY ON 150 LB
WEIGHT STACK
60 49
49
12 49 67
67 49 58
11
49 67
49 58
71
67
68
56 49
68
49
56
49 67
68
4967
11
49 56
49
67
22
18 SPT-6B Base Six-Pak Trainer
www.tuffstuffitness.com
SPT-6B Exploded View

REV0
.YTQ.ONTRAPNOITPIRCSED.ONMETI.YTQ.ONTRAP.VERNOITPIRCSED.ONMETI
1 ADJUSTABLE DOUBLE PULLEY BRACKET 0 UP6165 1 56 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 1 3/4 BNH0274 29
4 DOUBLE FLOATING PULLEY BRACKET LT 0 UP6170 1 57 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 3 BNH0282 1
5 DOUBLE FLOATING PULLEY BRACKET RT 0 UP6171 1 58 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 3 1/2 BNH0280 5
6 STABILIZER FRAME U SHAPE 0 UP8000 1 59 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 3/4 BNH0283 4
7 GUIDE ROD 3/4 RD X 67 1/2 0 UP6187 2 60 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 4 BNH0285 2
14816PU0ELBACTAL8 12730HNB"23/3YOLLAYEKXEH16
9 LONG DOUBLE SWIVEL PULLEY BRKT 0 UP6173 2 62 HEX KEY LONG ARM ALLOY 3/16" BNH0371 1
24957PU0ELBACWORWOL01 13023HNBPARTSELKNANOLYN36
15716PU0EMARFNIAM11 64 CONTOUR ERGO HANDLE LONG STRAP BNH2738 4
15957PU0REZILIBATSRAER21 65 NYLON INSERT LOCK NUT B/O 1/4-20 BNH0213 4
18 SELECTOR PIN W/COIL 3/8 X 4 GOLD KNOB 0 UP3035 1 67 NYLON INSERT THIN LOCK NUT B/O 3/8-16 BNH0365 37
20 SHORT DOUBLE SWIVEL PULLEY BRKT 0 UP6182 2 68 Black Nylon Pulley Wide Groove 3/8 X 1 X 3 1/2 BNH2832 25
26616PU0GNISUOHGNIRAEBPOT12 69 Black Nylon Pulley Wide Groove 3/8 X 1 X 4 1/2 BNH2834 4
22 TOP PLATE PULLEY BRACKETS 0 UP6183 1 70 PLASTIC INSERT CAP 2" RD 10-14 GA BNH0004 2
23 TOP SWIVEL PULLEY BRACKET 0 UP3634 2 71 PLASTIC INSERT CAP 3" RD 10-14 GA BNH1364 4
15816PU0DLEIHSTHGIEW42 75 RETAINING SNAP RING EXT. 1 1/4" BNH1718 6
25707PU0ELDNAH52 48600HNB2/12X4/3TUNODREBBUR67
26 10 LB STEEL WEIGHT PLATE 4 9/16 X 9 7/16 BNH1650 14 77 RUBBER FOOT FOR 6 X 4 1/4 PLATE BNH1647 4
21040HNBDI"4/3TEMMORGREBBUR8712891HNBSTWKLB91RABRTLSJDA/WETALPPOTBL0172
65600HNBMM08XMM8P/ZKNILPANS1849722HNBRETPADAELBATSUJDA82
23560HNB"2/1O/BREHSAWKCOLTILPS48212171HNB)2/1X4/12X.D.I4(SR-02RGNIRAEBLLAB03
88560HNB"8/3O/BREHSAWKCOLTILPS5814292HNBereHnoisneTelbaCT
SUJDATNATROPMI-lebaL33
61324HNBelbaC8/1kniL8/51XdR8/76819392HNBhtaeDroyrujnIsuoireS_GNINRAWlebaL43
36 Label-EXERCISE CHART (SPT-6) BNH2277 1 87 SUPER LUBE TEFLON LUBRICANT 82340 BNH0704 2
13024HNB2x5euqalPssentiFffutSffuT8815292HNB...ecnamrofrephtoomsroFTNATROPMI-lebaL73
38 Label IMPORTANT Check Cables BNH3113 1 89 U-STYLE TAPPED HOLE NUT 1/4-20 BNH0708 4
39 Label-WARNING Keep body, hands… BNH2926 1 91 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 4 1/4 BNH0317 4
40 Label WARNING Keep body, hands, 1 1/2 x 2 1/4 BNH2908 2 92 CONTOUR ERGO HANDLE SHORT STRAP BNH2739 2
41 Label Numbers 10-150 lbs/kgs Yellow & Black BNH3096 1 93 WEIGHT STACK SPACER 5" (For 150 LB) UP5238 2
42 EDGE PROTECTOR CHROME 11 GA BNH1724 1 94 Label-INSPECTIONS Recommended Inspection… BNH2922 1
17592HNB...straPtnemecalpeRELUDEHCSlebaL5931020HNB31-2/1O/BTUNXEHDEHSINIF34
44 FINISHED HEX NUT B/O M10-1.5 BNH0651 4 96 Label-DANGER Use this equipment ONLY... BNH2903 1
45 Oval Head Phillips Screw Z/P #10-32 X 1 1/8 BNH2793 6 97 Label-DANGER Do Not Pull or Perform... BNH3112 2
49113H
NBreleveLtsujdANOITUAC-lebaL8929320HNB"2/1O/BEASREHSAWTALF74
14113HNB)B6-TPS(rebmuNlaireS-lebaL99217780HNB"4/1O/BEASREHSAWTALF84
25113HNBS906,626DtnetaP-lebaL001289320HNB"8/3O/BEASREHSAWTALF94
16113HNBS531,606DtnetaP-lebaL10148780HNB"2X4/3O/BREHSAWTALF05
51 Cable Stopper Shell 1 1/2 x 1 3/4 BNH4230 6 102 ALERT Sign for Customer 8 1/2 x 11 BNH3015 1
53 HEX HEAD CAP SCREW GR-5 B/O 1/4-20 X 1 3/4 BNH1338 4 103 RUBBER FLAT TUBE .94 ID X .115 WALL X 19 BNH2485 2
54 HEX HEAD CAP SCREW GR-5 B/O 1/4-20 X 3/4 BNH0890 4
SPT-6B
Parts List
COLOR CHART
BLACK BOLD= SUB-ASSEMBLY PARTS
BLACK= HARDWARE
19SPT-6B Base Six-Pak Trainer www.tustutness.com
SPT-6B Parts List

20 SPT-6B Base Six-Pak Trainer
www.tuffstuffitness.com
Inspection / Maintenance
Perform regular maintenance (see Inspection Label). Pay special attention to areas most susceptible to wear and tear.
TuStu recommends you maintain a service contract with a TuStu Authorized Dealer or a Professional Service Company approved by
TuStu. Keep a service log of all maintenance and repair activities. Extra copies can be downloaded from our website.
INSPECTION / MAINTENANCE RECORDS
DATE REPLACEMENT REPAIRS INSPECTED BY
WARRANTY REPAIRS
DATE REPLACEMENT REPAIRS INSPECTED BY
