Tuttnauer LAVA 50 DRS User manual

Instruction manual
User Manual
WASHER DISINFECTOR
LAVA 50 DRS - LAVA 50/2 DRS
LAVA 50 DRSD - LAVA 50/2 DRSD
Serial N°: ___________________________________
0051

REV_2.00_COD.500159_A4 PAG. 2
Paardeveide 36 P.O.B. 7191
4800 GD Breda
NETHERLAND
Manufacturer:
STEELCO S.p.A.
Via Balegante, 27
31039 Riese Pio X (TV)
ITALIA
APPLY
HERE
LABEL
WITH
SERIAL NUMBER

REV_2.00_COD.500159_A4 PAG. 3
CONTENTS
1. GENERAL RULES......................................................................................................................................5
1.1 LIMITS OF MANUFACTURER'S LIABILITY.......................................................................................................................5
1.2 MANUAL VALIDITY,CONTENTS AND CONSERVATION ....................................................................................................5
2. SAFETY INFORMATION............................................................................................................................6
2.1 INTENDED USE,IMPROPER USE ................................................................................................................................6
2.2 IMPORTANT WARNINGS AND SUGGESTIONS................................................................................................................6
2.3 SAFETY RECOMMENDATIONS ...................................................................................................................................7
2.4 RECOMMENDATIONS TO ENSURE HIGH QUALITY PERFORMANCE....................................................................................8
2.5 RESIDUAL RISKS.....................................................................................................................................................9
2.6 SAFETY SIGNAL USED............................................................................................................................................10
2.7 TRAINING.............................................................................................................................................................11
2.7.1 STAFF QUALIFICATION...................................................................................................................................11
2.8 INDICATION OF SOUND LEVEL .................................................................................................................................12
3. INSTALLATION INSTRUCTIONS............................................................................................................12
4. INSTALLATION (FOR THE INSTALLER ONLY).....................................................................................13
4.1 ACTIVITY WARNINGS AND SUGGESTION ...................................................................................................................13
4.2 POSITIONING........................................................................................................................................................13
4.2.1 MOVEMENT,UNPACKING AND PLACING............................................................................................................13
4.2.2 MAXIMUM FLOOR LOAD..................................................................................................................................14
4.2.3 POSITIONING OF THE MACHINE .......................................................................................................................14
4.3 WATER CONNECTION (FOR THE INSTALLER ONLY) ....................................................................................................15
4.4 ELECTRICAL CONNECTION .....................................................................................................................................16
4.5 FUSES ................................................................................................................................................................17
4.6 DETERGENT DISPENSER........................................................................................................................................18
4.7 CHEMICAL ACID DETERGENT DISPENSER (OPTIONAL)...............................................................................................19
4.8 CONNECTING THE DISCHARGE PIPE ........................................................................................................................20
4.9 WATER SOFTENER BUILT-IN (LAVA 50 DRSD -LAVA 50/2 DRSD) ........................................................................21
4.10 DRYING AIR FILTRATION.........................................................................................................................................21
5. CHECKS PRIOR TO START-UP..............................................................................................................22
5.1 INTRODUCTION.....................................................................................................................................................22
5.2 CHECKS OF SAFETY SYSTEMS................................................................................................................................22
5.3 GENERAL CONTROLS ............................................................................................................................................22
6. USING THE MACHINE (FOR THE USER)...............................................................................................23
6.1 CHECKS..............................................................................................................................................................23
6.2 OPENING AND CLOSING THE DOOR..........................................................................................................................23
6.3 PREPARATION......................................................................................................................................................23
6.4 FUNCTIONING.......................................................................................................................................................24
6.5 TREATMENT OF TURBINES AND STRAIGHT AND ANGULAR HAND PIECES (OPPOSED-ANGLES) ..........................................24
7. CONTROL PANEL AND SYMBOLS USED.............................................................................................25
7.1 WASHING PROGRAMMES.......................................................................................................................................25
7.2 DETAILS OF THE ELECTRONIC CARD........................................................................................................................25
7.3 FEATURES OF MASTER CARD .................................................................................................................................25
7.4 CONTROL PANEL ..................................................................................................................................................26
7.5 SWITCHES...........................................................................................................................................................26
7.6 CONTROL PANEL UNLOAD SIDE (ONLY FOR 2DOORS VERSION)...................................................................................28
7.7 BUTTONS ............................................................................................................................................................28
8. MACHINE STATUS ..................................................................................................................................29
8.1 WAIT ..................................................................................................................................................................29
8.2 CYCLE ................................................................................................................................................................29
8.3 SHUTDOWN .........................................................................................................................................................29
9. SPECIAL FEATURES...............................................................................................................................29
9.1 POWER FAILURE...................................................................................................................................................29
9.2 RESET PROCEDURE..............................................................................................................................................29

REV_2.00_COD.500159_A4 PAG. 4
10. WORK PROCEDURES.........................................................................................................................30
10.1 INTRODUCTION.....................................................................................................................................................30
10.2 INSTRUCTIONS TO PERSONNEL...............................................................................................................................30
10.3 DECONTAMINATION PROCEDURES ..........................................................................................................................30
11. MENU ....................................................................................................................................................31
11.1 MENU PLAN .........................................................................................................................................................31
11.2 PHASE PARAMETERS ............................................................................................................................................34
11.2.1 DRAIN PHASE...............................................................................................................................................34
11.2.2 PREWASHING PHASE ....................................................................................................................................34
11.2.3 TREATMENT PHASE.......................................................................................................................................34
11.2.4 DRYING PHASE.............................................................................................................................................34
11.3 PARAMETER SETTINGS..........................................................................................................................................35
11.4 FLOWMETER SETTING...........................................................................................................................................39
11.5 STARTING UP AND DISPLAY OF DEVICES...................................................................................................................39
11.6 INPUT/OUTPUT.....................................................................................................................................................40
12. CLOCK.......................................................................................................................................................41
13. HISTORICAL DATA..............................................................................................................................41
14. ALARMS AND EVENTS LIST...............................................................................................................42
14.1 LOGICAL DESCRIPTION OF ALARM INTERVENTIONS ....................................................................................................42
14.2 LIST OF ALARM MESSAGES.....................................................................................................................................42
15. PC INTERFACE.....................................................................................................................................44
16. MAINTENANCE.....................................................................................................................................45
16.1 GENERAL RECOMMENDATIONS ON MAINTENANCE .....................................................................................................45
16.2 PROCEDURE FOR ROUTINE MAINTENANCE WORK......................................................................................................45
16.3 TABLE OF ROUTINE MAINTENANCE TASKS ................................................................................................................45
16.4 PROCEDURE FOR SPECIAL MAINTENANCE WORK.......................................................................................................49
16.5 TABLE OF SPECIAL MAINTENANCE ...........................................................................................................................49
17. PROBLEMS – CAUSES – SOLUTIONS...............................................................................................50
17.1 INTRODUCTION.....................................................................................................................................................50
17.2 PROBLEMS -CAUSES -SOLUTIONS ........................................................................................................................50
18. DECOMMISSIONING............................................................................................................................52
18.1 INSTRUCTIONS FOR DISASSEMBLY OF THE MACHINE..................................................................................................52
Thank you for purchasing this appliance.
The installation, maintenance and operating instructions given in the following pages have been
prepared to ensure the long life and good performance of the appliance.
Following the instructions carefully.
The appliance was designed and constructed using the latest technological innovations available.
Please take good care of it.
Your satisfaction is our best reward.
WARNING:
NON OBSERVANCE, EVEN IN PART, OF THE RULES INDICATED IN THIS MANUAL WILL
CAUSE THE PRODUCT GUARANTEE TO BECOME INVALID AND RELIEVES THE
MANUFACTURER OF ANY RESPONSIBILITY.

REV_2.00_COD.500159_A4 PAG. 5
1. GENERAL RULES
1.1 Limits of manufacturer's liability
The manufacturer shall not be held liable for failures or problems which arise due to tampering and/or incorrect
applications and/or improper use of the machine.
The purchaser must comply with all instructions set forth in the user's manual, and he must in particular:
•Always work within the allowable limits for the use of the machine;
•Always carry out constant and diligent maintenance;
•Allow use of the machine by persons with proper skills and abilities for their role and purpose who have been
properly trained and instructed;
•Use only manufacturer original spare parts.
Any modifications, adaptation or the like which may be made to machines which are subsequently placed on the market
do not oblige the manufacturer to intervene on previously supplied machines, nor to consider the machine and the
related user's manual lacking and inadequate.
The installation, maintenance and operating instructions given in the following pages have been prepared to ensure the
long life and outstanding performance of the appliance.
For some especially demanding programming or maintenance operations, this manual serves as a memorandum of the
main operations to be carried out.
Education on these topics can be obtained by attending training course held by the manufacturer.
The instructions in this manual do not replace but rather are in addition to employer requirements to adhere to current
legislation on standards of prevention and safety.
1.2 Manual validity, contents and conservation
•This manual reflects the state of the art at the moment of manufacture and delivery of the appliance and is valid
for its entire life cycle.
•The manufacturer is at clients' disposal for further information or to receive suggestions for making the manual
more compliant with the needs for which it was prepared.
•The translation of the contents into the client's language has been carefully prepared.
In order to prevent possible accidents to persons or property due to in correct translation of the instructions, the
client must:
Not perform operations or manoeuvres with the machine if there are any doubts or uncertainties about the
operation to be performed;
Ask technical service for clarification of the instruction.
•If lost, ask for a new copy from the manufacturer.
It is important to keep this instruction manual with the machine for future reference.
If the machine is sold or transferred, the manual must be handed over to the new owners or user in order for them to
become acquainted with its functioning and the relative warnings.
The purpose of the warnings is to safeguard the user in compliance with directive 2007/47/CE and incorporated in the
"Harmonised Technical Product Standards " EN 61010-1 and EN61010-2-45 and directives 2002/95/EC, 2002/96/EC
and 2003/108/EC concerning the reduction of the use of hazardous substances in electrical and electronic equipment
as well as the disposal of waste which is mentioned in the CE declaration of conformity included below.
Read the warnings carefully before installing and using the machine.

REV_2.00_COD.500159_A4 PAG. 6
2. SAFETY INFORMATION
Compliance with safety standards allow the operator to work productively and calmly, without the danger of harming
himself or others.
Before starting work, the worker must be completely familiar with the functions and proper operation of the machine.
He must know the precise function of all command and control devices of the machine.
2.1 Intended use, improper use
The intended use of the machine is the washing and thermal disinfection of instruments, equipment and objects.
Therefore:
INTENDED USE:
Use is permitted of this machine only and exclusively for washing and thermal disinfection of orthodontic instruments,
trays and objects normally used in orthodontic studios, hospital wards, assisted living centres, and so forth, like:
•Scissors
•Clogs
•Glass works
•Laboratory instruments
Improper use of this unit may be hazardous to the operator and may seriously damage the machine itself.
WARNING:
If the appliance is used in a manner not specified by the manufacturer, protection of the appliance may be
compromised.
As an example, hereunder is a list of some of the most common items and components which must not be washed
using this appliance:
IMPROPER USE:
Any use other than that for which the machine was intended is forbidden.
2.2 Important warnings and suggestions
For proper use of the machine, and in order to safeguard employed staff, carefully comply with the following general and
specific standards.
THE OPERATOR MUST:
•Carefully adhere to the provisions and instructions provided by the employer, managers and supervisors
for individual and group safety.
•Use safety devices appropriately and with care, as well as group and individual safety gear provided by the
employer.
•Immediately inform the employer, the manager and the supervisor of deficiencies in the aforementioned
devices and means, as well as any hazardous conditions which he may become aware of, taking action
directly in urgent cases within their scope of responsibilities and abilities to eliminate or reduce the
deficiencies or hazards.
THE OPERATOR MUST NEVER:
• Remove or modify, without authorization, the safety devices, nor those for signalling and measuring, nor
the individual and group safety gear.
• Undertake on his own initiative operations or manoeuvres which are not his responsibility which may
compromise safety.
• Insert foreign objects into the electrical parts.
Do not insert foreign bodies into the covers of the electrical motors or into the moving parts of the machine.
• Provide power to the machine by tampering with the main switch and the safety devices.

REV_2.00_COD.500159_A4 PAG. 7
2.3 Safety recommendations
•If the new machine appears to be damaged, contact the retailer before starting it.
•Any modification of electrical and hydraulic systems necessary to install the machine must be carried out by
qualified, authorised persons only.
•This machine must be operated by trained persons only;
•The machine must be used for treatment and thermo disinfection of instruments for orthodontic and medical
use and for laboratory glasses.
•Any use other than that for which the machine was intended is forbidden.
•The user is forbidden to carry out any work or repairs on the machine.
•Technical Assistance for this washer disinfector should be carried out by qualified and authorised operators
only.
•The equipment should be installed by authorised persons only.
•Do not install the equipment in rooms where there is the risk of explosion.
•Do not expose the equipment to intense cold.
•The electrical safety of this washer disinfector is only guaranteed if it is connected to an efficient earth system.
•Take great care when handling detergents and additives: avoid contact, wear gloves and act in compliance with
the safety recommendations indicated by the manufacturer of the chemical products.
•Do not inhale the fumes produced by chemical products.
WARNING:
The chemical products are an irritant for the eyes, in case of contact rinse thoroughly with plenty of
water and consult a doctor.
If these products come into contact with the skin, rinse with plenty of water.
•The water in the tank is not drinking water.
•Do not lean on the door and do not use it as a step.
•The machine reaches a temperature of 93°C during the work cycle: take great care to avoid burns.
•Do not wash the machine using high-pressure jets of water.
•Disconnect the machine from the electrical supply before carrying out maintenance work.
•The acoustic pressure of the machine is below 70 dB(A).

REV_2.00_COD.500159_A4 PAG. 8
2.4 Recommendations to ensure high quality
performance
•The user must oversee the machine during the cycle.
•The injection tube for washing water must always be connected with the appropriated basket.
•When the machine is running do not interrupt the cycle since this jeopardises disinfection.
•Check periodically using chemical indicators to ensure correct disinfection.
•Use recommended detergents and chemical additives only.
The use of other products may damage the machine.
•During the manipulation of treated objects, it is required the use of appropriated DPI to prevent contact
with infected material and the risk of contamination.
•Recommending chemical additives does not make the manufacturer responsible for any damage to the
materials and objects treated.
•Do not introduce dirty instruments of substances that must not be discharged in sewage system (in
accordance with current legislation) but must be disposed in specific way.
•Follow the manufacturer's indications when using chemical products and use them for the foreseen
use only.
•The machine was designed for use with water and chemical additives.
Do not use organic or other types of solvent as this may result in the risk of explosion or the rapid
deterioration of certain machine parts.
•Residues of solvents or acids, particularly “hydrochloric acid”, can damage steel.
Contact should be avoided.
•Use original accessories only.
•Do never use soap powder.
•Do never use foaming detergent.
•Accessories which are not approved by the manufacturer may compromise the results achieved as well
as user safety.
•Do never use chemical products based on chlorides (bleaches, sodium hypochlorite, hydrochloric acid
and so on).
These kinds of chemical detergents irreparably damage the machine and jeopardise the integrity of
materials and objects treated.
The taps of the water feeding must be always turned off, as the safety and diagnosis system will be deactivated,
in the following situations:
•if the machine is left unused
•if the machine is disconnected from the electrical connection
The manufacturer declines all responsibility for personal injury or material damage resulting from
the non-observance of the above rules.
The non-observance of these rules produces the total and prompt cancellation of the guarantee.

REV_2.00_COD.500159_A4 PAG. 9
2.5 Residual risks
The appliance includes a series of fixed guards to prevent access to hazardous internal parts or zones.
It is however considered that the WASHER DISINFECTOR includes some residual risks.
Hereunder for each phase or significant work intervention are useful measures to be taken:
PHASE TROLLEY LOADING
RISK Contusions and cuts to the upper limbs, due to accidental contact with due to falling or
striking against tools, objects and instruments, mainly while loading and handling the
basket.
MEASURE Assign staff that is instructed and equipped with work equipment (e.g. trolley with protections, transport carts) and appropriate clothing and individual protection gear (e.g.
shirts and protective gloves).
PHASE OBTAINING DETERGENTS/CHEMICAL ADDITIVES
RISK Contact with body parts with chemical washing products.
MEASURE
Assign staff that is instructed and equipped with appropriate clothing and individual
protection gear.
Wear clothing, gloves and goggles and act in compliance with the safety
recommendations indicated by the manufacturer of the chemical products.
FIRST AID MEASURE
•Immediately take off/remove clothing which has been contaminated or soaked by the
product.
•If the substances come into contact with the skin, wash off affected skin areas
immediately and rinse with water.
RISK Inhalation of vapours of chemical wash products.
MEASURE Assign staff that is instructed and equipped with appropriate clothing and individual
protection gear.
Comply with the safety instructions provided by the manufacturer of the chemical products
and if there are none, wear a mask for the protection of the respiratory airways.
RISK Accidental release of chemical wash product
MEASURE Do not flush concentrate into drains, surface or ground waters.
Collect spillage with adsorbent material (e.g. sand, earth, vermiculite, diatomaceous
earth).
Flush away minor amounts with plenty of water.
IN CASE OF CONTACT WITH BODY OR RELEASE OF CHEMICAL PRODUCT LOOK
ALWAYS AT THE SAFETY MEASURES INDICATED IN THE CHEMICAL TECHNICAL
DATASHEET.
PHASE MAINTENANCE OF INTERNAL EQUIPMENT
RISK Burns of body parts by hot parts of the appliance.
MEASURE Allow maintenance to be performed only by trained personnel, equipped with appropriate clothing and individual protection gear.
Wear suitable clothing and protective gloves.
PHASE EMISSION OF HAZARDOUS GAS
RISK Inhalation of vapours of hazardous gas
MEASURE
With a correct installation, concurring with the manufacturer prescription, using the
authorized chemical product and concurring with the rules in force in your country, the
machine don’t generate hazardous gas.
However the machine is supplied with vapours discharge, that have to be connected
concurring with the instruction on section 4.7.

REV_2.00_COD.500159_A4 PAG. 10
2.6 Safety signal used
To inform personnel operating on the machines of obligations of behaviour and residual risks, adequate safety signals
(as set forth by 92/58 EEC) are applied to the machine and near the work place.
GENERIC SAFETY SIGNALS:
In particular, labels with signals of obligation, prohibition and danger contained in this manual and pertinent to this
machine and most commonly used are:
Electrical risk Warning!
See annex documentation Caution hot surface
INDIVIDUAL SAFETY WEAR:
The evaluation of risks for the health and safety of workers carried out in the workplace and on any equipment used, as
well as the evaluation of residual risks as indicated, allow the employer to evaluate the need to adopt the individual
protection gear which is most suitable and appropriate to be provided to workers.
Considering the type of machine, it is felt that the individual protection gear should be provided to staff.
