Tuttnauer EZ9 Manual

OPERATION
&
MAINTENANCE
MANUAL
Electronic Tabletop Autoclaves
Models EZ9 EZ10 EZ10K
Cat. No. MAN205-0263001EN Rev. E
 Tuttnauer USA Co., Ltd., 25 Power Drive Hauppauge, NY 117 USA, : ( 00) 624 5 36, (631) 737 4 50, Fax: [phone]
e-mail: [e-mail]

1
TABLE OF CONTENTS
PARAGRAPH PAGE NO.
1. GENERAL.............................................................................................................4
1.1 Incoming Inspection..................................................................................4
1.2 arranty ....................................................................................................4
1.3 arranty Statement...................................................................................4
2. TECHNICAL DATA.............................................................................................6
2.1 Introduction ...............................................................................................6
2.2 Standby Heating Mode ..............................................................................6
2.3 Environmental Emission Information .....................................................7
2.4 Operating Conditions ................................................................................7
2.5 Utilities .......................................................................................................7
2.6 Construction ..............................................................................................7
2.7 Symbol Description....................................................................................8
2.8 Electrical Data ...........................................................................................9
2.9 Specifications...........................................................................................10
2.10 Technical Specifications .........................................................................11
2.11 Standards .................................................................................................11
2.12 ater Quality...........................................................................................12
3. KEYBOARD (Keys and Display)........................................................................15
3.1 Indicator Light Description.....................................................................16
3.2 Description and Functions of the Control Panel Keyboard ..................17
3.3 Description of the Display Panel ............................................................19
3.4 Description of Displayed Messages and Safety Measures .....................19
4. STERILIZATION PROGRAMS ........................................................................22
4.1 PROGRAM 1. Unwrapped Instruments .................................................22
4.2 PROGRAM 2. rapped Instruments and Porous Loads ......................23
4.3 PROGRAM 3. Glassware ........................................................................24
4.4 PROGRAM 4. Accessory (Dry Only).....................................................24
5. PRINTER (Optional) ..........................................................................................25
5.1 Printer Operation.....................................................................................25
5.2 Printer Handling .....................................................................................27
6. INSTALLATION INSTRUCTIONS ..................................................................28
6.1 Electrical ..................................................................................................28
6.2 ater Filling............................................................................................29
6.3 Lifting and Carrying................................................................................30
6.4 Loading and Unloading the Device ........................................................30
6.5 Filling the ater Reservoir.....................................................................31
7. PREPARATION BEFORE STERILIZATION.................................................32
8. OPERATING INSTRUCTIONS ........................................................................35

2
TABLE OF CONTENTS (Cont.)
PARAGRAPH PAGE NO.
9. MAINTENANCE INSTRUCTIONS..................................................................38
9.1 Preventive and Scheduled Maintenance.................................................38
9.2 Replacing the Air Filter...........................................................................39
9.3 Draining the Reservoir ............................................................................40
9.4 Cleaning the Air Jet.................................................................................41
9.5 Replacing the Door Gasket .....................................................................42
9.6 Checking the Safety Valve.......................................................................43
9.7 Replacing the Fuse ..................................................................................44
9.8 Cleaning ater Outlet Strainer ..............................................................45
9.9 Cleaning Tabletop Autoclaves with Chamber Brite ™..........................46
9.10 ater Sensor Cleaning............................................................................48
10. TROUBLESHOOTING FOR THE OPERATOR .............................................49

3
TABLE OF CONTENTS (Cont.)
DRAWINGS PAGE NO.
Front View...................................................................................................................13
Rear View ....................................................................................................................14
Front Panel Keyboard.................................................................................................15

4
1. GENERAL
Read the Operating Instructions carefully, before beginning any operation
on the autoclave!
1.1 Incoming Inspection
Upon receiving your Tuttnauer Autoclave, carefully inspect the outside
of the shipping carton for signs of damage. If any damage to the carton is
found, note the location with respect to the autoclave and check that area
of the autoclave carefully once it is fully unpacked. Observe packing
method and retain packing materials until the unit has been inspected.
Mechanical inspection involves checking for signs of physical damage
such as: scratched panel surfaces, broken knobs, etc.
If any damage is found contact your dealer as soon as possible so
that they can file a claim with the shipping carrier and also notify
Tuttnauer.
All Tuttnauer products are carefully inspected prior to shipment and all
reasonable precautions are taken in preparing them for shipment to
assure safe arrival at their destination.
Note: Lifting and carrying should always be done by two people.
1.2 arranty
We certify that this instrument is guaranteed to be free from defects in
material and workmanship for two years against faulty components and
assembly.
This warranty does not include routine cleaning and preventive
maintenance to be performed according to instructions in
section 9.1 (Preventive and Scheduled Maintenance).
Tuttnauer warrantees all new autoclaves for a period of two full years,
covering both parts and labor. This two year warranty covers defects in
materials and workmanship on every part in the autoclave except door
gaskets and HEPA filters (they are wear items).
Tuttnauer warrantees all chambers for a period of ten (10) years against
defects in materials and workmanship. This chamber warranty went
into effect January 1997.
This warranty does not apply to any instrument that has been subjected
to misuse, neglect, accident or improper installation or application, nor
shall it extend to autoclaves that have been repaired or altered outside
the factory without prior authorization from Tuttnauer.
Tuttnauer’s obligation is limited to the repair or replacement of parts
for the autoclave. This warranty will be void if the unit is not purchased
from an authorized Tuttnauer dealer. No other warranties or obligations
are expressed or implied.
The Autoclave should only be used in a manner described in this
manual!
1.3 arranty Statement
To activate the warranty, the registration card must be completed and
returned to Tuttnauer within fourteen (14) days of purchase or you may
call our customer service department at the number listed below.
No product will be received or accepted for repair without prior return
authorization from Tuttnauer. All transportation charges to and from
Tuttnauer must be paid by the owner of the autoclave. During the first
90 days after purchase of an autoclave, Tuttnauer will pay shipping
costs on an individually evaluated basis and ONLY with pre-approval.

5
Note:
If you have any questions or there are any difficulties with this instrument
and the solution is not covered in this manual, please contact your dealer or
Tuttnauer USA Co. Do not attempt to service this instrument yourself.

Tuttnauer USA Co., Ltd., 25 Power Drive Hauppauge, NY 117 , USA
: ( 00) 624 5 36, (631) 737 4 50, Fax: [phone]
e-mail:[email protected].

6
2. TECHNICAL DATA
2.1 Introduction
This tabletop autoclave is designed for the sterilization of wrapped and
unwrapped instruments and related items found in dental, medical and
veterinary clinics, first aid rooms, hospitals, laboratories, etc.
This autoclave is an electrically heated sterilizer using steam as the
sterilizing agent. A computerized control unit ensuring a fully automatic
sterilization cycle, control and monitoring of physical parameters and a
clear documentation of the sterilization cycle controls the autoclave.
The autoclave has three automatic programs, according to the material
to be sterilized, and one auxiliary drying program. The autoclave is
equipped with an air compressor that, during the drying stage draws air
through a HEPA filter (0.2µm). It pushes the air through the heated
chamber to remove moisture and facilitate the drying operation. Drying
is performed with the door closed.
On all models, a water pump is installed between the water reservoir
and the chamber. This pump guarantees fast and accurate filling of the
chamber every time. Entry of water may be accompanied by a noise for
approximately 30 seconds. This is normal noise generated by regular
operation of the pump.
The control system provides adequate protection, to ensure the safety of
personnel and reliable operation with a minimum of shutdown time.
On all models, a printer is an optional addition to the autoclave. The
printer prints the preset and actual parameters of the cycle (temperature,
time and pressure).
This manual is intended for the user and gives the user a general
understanding of the instrument and the best ways to operate and take
care of it, in order to obtain optimum effective results.
After reading this manual, operating the autoclave will be easy.
However, since this instrument is built with high technology sensitive
components, no attempt should be made by the user or any other
unauthorized person to repair or recalibrate it.
Only technical personnel having proper qualifications and holding
technical documentation (including a technician manual) and
adequate information are authorized to service the apparatus.
2.2 Standby Heating Mode
The autoclave provides an option of heating the chamber in standby
mode between cycles, with a very low power, in order to reduce total
cycle time (1.6% of the total power only). The autoclave turns off
automatically if the interval between the sterilization cycles is more
than 2 hours. This feature is standard on model EZ10K and optional on
EZ9 and EZ10 models.

7
2.3 Environmental Emission Information
1. The peak sound level generated by the autoclave is less than 70 dBA
with background noise of 60 dBA.
2. The total heat per hour transmitted by the autoclave is < 100 Wh for
all models.
2.4 Operating Conditions
This device is to be used for indoor use.
This autoclave is intended for NORMAL environment conditions as
follows:
♦ Altitude up to 2000m.
♦ Room temperature range 5ºC to 40ºC.
♦ Installation Category II.
♦ Pollution Degree 2.
♦ Maximum relative humidity 0% for temperature up to 31ºC
decreasing linearly to 50% relative humidity at 40ºC.
♦ Mains supply voltage fluctuations up to +/-10% of the nominal voltage.
The sterilizer should be loaded only with autoclavable material.
Caution!
Waste water should be brought into the public net in accordance with
the local rules or requirements i.e.
ONLY NON-HAZARDOUS LIQUIDS SHALL BE DISPOSED IN
PUBLIC SEWAGE!
2.5 Utilities
Utilities Unit Value
V-A 1ph, 120V – 16A,50/60 Hz
Power supply (as appropriate) V-A 1ph, 230V – 16A,50/60 Hz
Attention:
The electrical net must be protected with a current leakage safety relay.
The electrical network must comply with local rules or regulations.
2.6 Construction
The main parts of the autoclave are made of materials as indicated
below:
♦ Chamber is electro-polish and built of stainless steel 316 L.
♦ Door is made of stainless steel CF .
♦ Trays are made of stainless steel 304.
♦ Water reservoir is made of hard plastic material.
♦ Door handle is made of hard plastic material, which is safe to touch
and thermo-insulated.
♦ Covers are made of aluminum sheet, coated with Epoxy paint.

2.7 Symbol Description
Caution! Consult accompanying documents.
Caution! Hot surface.
Caution! Hot steam.
Protective earth (Ground).
Standby
