TV One 1T-MX-3344 User manual

Instruction Manual
1T-MX-3344
4x4 Matrix Switcher
Component Video with Stereo Audio

Table of Contents
1.0 Introduction 2
2.0 Specifications 3
3.0 Checking Package Contents 4
4.0 Connecting The Hardware 4
5.0 Operating The Unit 5
6.0 Troubleshooting 7
7.0 Limited Warranty 8
8.0 Regulatory Compliance 8
9.0 Contact Information 9

2
1.0 INTRODUCTION
Thanks for purchasing this 4x4 Matrix Switcher for Component Video with Stereo Audio
from TVOne. The 1T-MX-3344 is designed to allow distribution of four Component
Video and Stereo Audiosources to four devices independently. Our professional video
conversion products have beenserving the industryfor over twenty years. TV One
offers a full line of high qualitySeamless Switchers,Video Scalers, Up/Down/Cross
Converters, Analog-Digital Converters (SD/HD-SDI, HDMI, DVI), Format Converters,
Standards Converters, TBC/Frame Synchronizers, MatrixRouting Switchers, Signal
Distribution Amplifiers and Cat.5 Transmission Systems.
1.1 Liability Statement
Everyeffort has beenmade to ensure that this product is free of errors. TVOne cannot
be held liable for the use of this hardware or anydirect or indirect consequential
damages arising from its use. It is the responsibilityof the user of the hardware to check
that it is suitable for his/her requirements and that it is installed correctly. All rights
reserved. No parts of this manualmaybe reproduced or transmitted byany form or
means electronic ormechanical, including photocopying, recording or byany
information storage or retrieval system without the written consent of the publisher.
TV One reserves the right to revise anyof its hardware andsoftware following its policy
to modifyand/or improve its products where necessaryor desirable. This statement
does not affect the legal rights of the user in anyway.
All third party trademarks and copyrights are recognised. The TVOne logo, TV One-
task and CORIO are the registered Trademarks of TVOne. All other trademarks are the
propertyof their respective holders.
1.2 Features
The 1T-MX-3344 has manyfeatures that enable it to perform in asuperior manner.
Among those features you will find:
4x4 Matrix for YPbPr or YUV(Y,R-Y,B-Y) Video Signals
4x4 Matrix for Stereo (L&R) Audio Signals
Buffered Video and Audio Signal Handling
Support 480i, 576i SDTVand 480p, 576p, 720p, 1080i, 1080p HDTV
RC-44 IR Remote Control
RS-232 Control
Rack Mount Kit included

3
2.0 SPECIFICATIONS
Video Inputs
YPbPr or YUVComponent 4x via 3x RCA
Video Outputs
YPbPr or YUVComponent 4x via 3x RCA
Audio Inputs
Analog Stereo (R/L) 4x via 2x RCA
Audio Outputs
Analog Stereo (R/L) 4x via 2x RCA
Performance
Television Standards NTSC, PAL
Video Level Y=1Vp-p, Pb/Pr=0.7Vp-p
Video Bandwidth 300MHz+
Video Impedance 75
Differential Gain 0.05%
Differential Phase 0.05 degrees
Audio Level (Analog) (L/R) 2Vrms max@ 47K
Audio Level (Digital) 0.5~1Vp-p@75
Audio Bandwidth 20Hzto 20 KHz
Audio Impedance 47K
Supported Video Signals
NTSC & PAL, I/O YPbPr & YUV(Y,R-Y,B-Y)
Mechanical
Size (H-W-D) 44x436120mm (1.75”x17”x6.3”)
Weight (Net) 1.6 kg (3.5 lbs)
Warranty
Limited Warranty 2 Years Parts and Labor
Environmental
Operating Temperature 0to +50C (+32to +122F)
Operating Humidity 10% to 90%, Non-condensing
Storage Temperature -10to +60C (+14to +140F)
Storage Humidity 10% to 90%, Non-condensing
Power Requirement
External Power Supply 12VDC@1A- Locking DC
Regulatory Approvals
Switcher Units FCC, CE, RoHS
Power Supplies UL, CUL, CE, PSE, GS, RoHS
Accessories Included
1x AC Power Adapter US, UK or Euro
1xRC-44 IR Remote Control RC-44
1xRack Mount Kit
1xOperations Manual

4
3.0 CHECKING PACKAGE CONTENTS
Before attempting to use this unit, please check the packaging andmake certain the
following items are contained in the shipping carton:
1x1T-MX-3344 MatrixSwitcher
1x AC Power Adapter
1xRC-44 IR Remote Control
1xRack Mount Kit
1xOperations Manual
Note:Please retain the original packingmaterialshould the need ever arise to return
the unit.If you find anyitems are missing, contact your reseller or TVOne immediately.
Have the Model Number, Serial Number and Invoice available for reference when you
call.
4.0 CONNECTING THE HARDWARE
Pleasestudythe panel drawings below and become familiar with thesignal input,
outputs, power requirements/inputs plus anycontrols present.
The 1T-MX-3344 is a 4x4 Matrix Switcher capable of switching Component Video
Signals, YPbPr or YUV(Y,R-Y,B-Y), plus line level Stereo (L&R) Audio Signals input via
connectors on the rear of the unit.
To realize the full bandwidth capabilityof the switcher, you must use the highest quality
cables available. Using poor qualitycables or cables that are damaged will degrade the
performance of the switcher and mayresult in an absence of signals entirely.
To begin to configure thesystem, mount the unit with the supplied rackmounting
hardware if desired or place the unit on a flat surface that offers securityand
accessibility. Insure that there is adequate ventilation and makesure that there is
access to the rear and front panels.
Turn off anyequipment that will be part of the installed system and then connect the
video and audio inputs and outputs as required. Nextconnect the supplied AC adapter
to a working AC outlet and then to the 1T-MX-3344.

5
If you are using the RS-232 control function, connect the RS-232 cable at this time.
Turn the input and destination equipment on and then turn on the 1T-MX-3344 Matrix
Switcher.
5.0 OPERATING THE UNIT
The 1T-MX-3344 is aspecial type of Video/Audio switcher called a MatrixRouting
Switcher. A MatrixSwitcher allows anyinput to be routed to any(or all) outputs whereas
a regular routing switcher onlyallows the operator toselect an input that will besent to
one, dedicated output.
The 1T-MX-3344 can be controlled via anyof three (3) methods: From the front panel,
byuse of the included Infrared Remote Controller, or via the RS-232 functionality.
If you have not done so already, press the Power Switch and observe that the Power
“On” LED illuminates. If it does not, make certain that the AC adapter is plugged in to
both the unit and the AC socket and that appropriate AC voltage is available at the
socket.
5.1 Control via the Front Panel Switches
Decide on an output (1 through 4) and repeatedlypress thesmall button associated
with that output as shown in the example above to select the input.LEDs will illuminate
as you step through the possible inputs, showing the input number you have selected
and, when you arrive at the input you wish to associate with the selected output, merely
stop pressing the button.
Using this method, you can make anyof the inputs appear on anyof the outputs or you
can make thesame input appear on all orsome of the outputs. Decide the input you
wish to associate with an output and press the appropriate output button until the input
signal you want appears on that output.

6
5.2 Control via the Infrared Controller
The included RC-44 Infrared Remote Controller has a Power Switch at the top right that
can be used to turn the 1T-MX-3344 on and off. Beneath that switch you’ll find four rows
of selector buttons. The top row controls selections for output number one, the second
row controls inputselections for output two and the third and fourth rows control input
selections for outputs number three and four respectively.
Operation is similar to front panel operation but instead of stepping through the
available inputs, you simplypress the appropriate input button for the output you wish to
control.
As an example, pressing the second button from the lefton the second row of buttons
will cause input number two to appear on output number two. Pressing the third button
from the lefton thesecond row of buttons will cause input three to appear on output two
andso on.
5.3 Control via the RS-232 Option
Using appropriate control codes, it is possible to switch anyinput to anyoutput under
control of a computer or other hardware control device.
To use this functionality, first prepare a control cable byreference to the table below.
Make certain that you have continuitybetween the pins as shown.
The RS-232 control connections are as follows:
1T-MX-3344 Controller
Pin Number Definition Pin Number Definition
1 NC 1 NC
2 Tx 2 Rx
3 Rx 3 Tx
4 NC 4 NC
5 GND 5 GND
6 NC 6 NC
7 NC 7 NC
8 NC 8 NC
9 NC 9 NC

7
RS-232 transmission format:
Baud Rate: 9600 bps
Data bit:8 Bits
Parity: None
Stop Bit:1 bit
The RS-232 control codes used bythe 1T-MX-3344 are as follows:
Code Meaning
P0 Power Off (Standby)
P1 Power On
ST Status
VR Firmware Version
A1 Output 1, Select Input 1
A2 Output 1, Select Input 2
A3 Output 1, Select Input 3
A4 Output 1, Select Input 4
B1 Output 2, Select Input 1
B2 Output 2, Select Input 2
B3 Output 2, Select Input 3
B4 Output 2, Select Input 4
C1 Output 3, Select Input 1
C2 Output 3, Select Input 2
C3 Output 3, Select Input 3
C4 Output 3, Select Input 4
D1 Output 4, Select Input 1
D2 Output 4, Select Input 2
D3 Output 4, Select Input 3
D4 Output 4, Select Input 4
ACarriage Return is not required.
6.0 TROUBLESHOOTING
Aside from faulty AC or DC power, most problems with the 1T-MX-3344 relate to
damaged/poor qualitycables or incorrect signal levels.
If some inputs function correctlyand others do not,interchange cables betweensources
andsee if the problem moves with the cables. If it moves, a bad cable or cable
connector is the probable reason for the trouble. Ifthe problem remains with one
particular input, connect that source to a different input using thesame cable andsee if
the problem moves. If it does, the problem is with thesource.
After trying the above suggestions should the problem still persist, contact your dealer
for additionalsuggestions before contacting TV One. Should the dealer’s technical
personnel be unable to assist you, contact TVOne via our support website:
http://tvone.crmdesk.com. Create a technicalsupport request on the site and our
support team will respond within ashort period of time.

8
7.0 LIMITED WARRANTY
LIMITED WARRANTY – With the exceptions noted in the next paragraph, TVOne
warrants the original purchaser thatthe equipment it manufactures orsells will be free
from defects inmaterials and workmanship for a period of two years from thedate of
purchase. Should this product,in TVOne’s opinion, prove defective within this warranty
period, TV One, at its option, will repair or replace this product without charge. Any
defective parts replaced become the propertyof TVOne. This warrantydoes not apply
to those products which have been damaged due to accident, unauthorized alterations,
improper repair, modifications, inadequatemaintenance and care, or use in anymanner
for which the product was not originallyintended.
Items integrated into TVOne products that aremade byother manufacturers, notably
computer hard drives and liquid crystal displaypanels, are limited to the term of the
warrantyoffered bythe respective manufacturers. Suchspecific warranties are
available upon request to TVOne.
If repairs are necessaryunder this warrantypolicy, the original purchasermust obtain a
Return Authorization Number from TVOne and return the product to a location
designated byTV One, freight prepaid. After repairs are complete, the product will be
returned, freight prepaid.
LIMITATIONS - All products sold are "as is" and the above Limited Warrantyis in lieu of
all other warranties for this product,expressed or implied, and is strictlylimited to two
years from the date of purchase. TV One assumes no liabilityto distributors, resellers or
end-users or anythird parties for anyloss of use, revenue or profit.
TV One makes no other representation of warrantyas to fitness for the purpose or
merchantabilityor otherwise in respectof anyof the products sold. The liabilityof TV
One with respect to anydefective products will be limited to the repair or replacement of
such products. In no event shall TVOne be responsible or liable for anydamage
arising from the use of such defective products whethersuch damages be direct,
indirect, consequential or otherwise, and whethersuch damages are incurred bythe
reseller, end-user or anythird party.
8.0 REGULATORY COMPLIANCE
The 1T-MX-3344 has been tested for compliance with appropriate FCC and CE rules
and regulations. The Power Adaptor/Supplyhas been tested for compliance with
appropriate UL, CUL, CE, PSE, GS Rules, Regulations and/or Guidelines. This Product
and Power Adapter is RoHS Compliant.

9
9.0 CONTACT INFORMATION
Should you have questions or require assistance with this product in areas not covered
bythis manual, please contact TV One at the appropriate location.
End of Manual
TV One USA
2791 Circleport Drive
Erlanger, KY41018
USA
Tel [phone]
Fax[phone]
[e-mail]
www.tvone.com
TV One Europe
Continental Approach
Westwood Industrial Estate
Margate, Kent CT9 4JG, UK
Tel [phone]
Fax[phone]
[e-mail]
www.tvone.eu
TV One Latin America
6991 NW 82 Avenue #8
Miami, FL 33166
USA
Tel [phone]
Fax[phone]
[e-mail]
www.tvonela.com
TV One Mercosur
Honduras 5849, 2nd Floor, Office C
(C1414BNI) Capital Federal
Buenos Aires, Argentina
Tel [phone]
Fax[phone]
[e-mail]
www.tvonela.com
TV One Asia
11F, NO.28, Sec. 2
San-Min Rd, Panchiao City
Taipei Hsien 220
Taiwan R.O.C.
Tel [phone]
Fax[phone]
[e-mail]
www.tvoneasia.com
TV One China
Rm.9C, Neiwailian Building
No.518 Shangcheng Road
Pudong, Shanghai
China 200120
Tel [phone]
Fax[phone]
Email: [e-mail]
Website: www.tvonechina.com
