TV One MX-2522 User manual

Instruction Manual
MX-2522
2x2 RGBHV MATRIX SWITCHER

Table of Contents
1.0 Introduction 2
2.0 Specifications 3
3.0 Checking Package Contents 4
4.0 Connecting the Hardware 4
5.0 Operating The Unit 5
6.0 Troubleshooting 5
7.0 Limited Warranty 6
8.0 Regulatory Compliance 6
9.0 Contact Information 7

2
1.0 INTRODUCTION
Thanks for purchasing this MX-2522 Matrix switcher from TV One. The MX-2522 is a
2x2 Matrix switcher. With a 2x2 matrix switcher, either input can be directed to either
output, or both inputs to a single output, a feature that greatly improves its utility. Our
professional video conversion products have been serving the industry for over twenty
years. TV One offers a full line of high quality Seamless Switchers, Video Scalers,
Up/Down/Cross Converters, Analog-Digital Converters (SD/HD-SDI, HDMI, DVI),
Format Converters, Standards Converters, TBC/Frame Synchronizers, Matrix Routing
Switchers, Signal Distribution Amplifiers and Cat.5 Transmission Systems.
1.1 Liability Statement
Every effort has been made to ensure that this product is free of errors. TV One cannot
be held liable for the use of this hardware or any direct or indirect consequential
damages arising from its use. It is the responsibility of the user of the hardware to check
that it is suitable for his/her requirements and that it is installed correctly. All rights
reserved. No parts of this manual may be reproduced or transmitted by any form or
means electronic or mechanical, including photocopying, recording or by any
information storage or retrieval system without the written consent of the publisher.
TV One reserves the right to revise any of its hardware and software following its policy
to modify and/or improve its products where necessary or desirable. This statement
does not affect the legal rights of the user in any way.
All third party trademarks and copyrights are recognised. The TV One logo, TV One-
task and CORIO are the registered Trademarks of TV One. All other trademarks are the
property of their respective holders.
1.2 Features
The MX-2522 Matrix Switcher has many features that enable it to perform in a superior
manner. Among those features you will find:
•1920x1440 Maximum Resolution
•250Mhz Pixel Frequency
•Extends Video Signal Distribution up to 17 Feet
•Supports DDC, DDC2 and DDC2B on the outputs
•Can be Cascaded
•Output compatible with standard VGA cards
•Optional Rack Mount kits are available

3
2.0 SPECIFICATIONS
Video Inputs
RGBHV 2x via HD-15 Female Connectors
Video Outputs
RGBHV 2x via HD-15 Female Connectors
General
Maximum Resolution 1920x1440
R-G-B Bandwidth >300MHz
R-G-B Level Range 0.5-2.0 Vp-p
Maximum Distance Up to 50 meters from Switcher
Signal Type RGBHV, RGBS, RGsB
Monitor Support DDC1, 2, DDC2B, 2B+, 2AB
Mechanical
Size (H-W-D) 44x130x74mm (1.75"x5.1"x2.9")
Weight (Net) 450 g (1 lb)
Warranty
Limited Warranty 2 Years Parts and Labor
Environmental
Operating Temperature 0° to +50° C (+32° to +122° F)
Operating Humidity 10% to 90%, Non-condensing
Storage Temperature -20° to +70° C (-4° to +158° F)
Storage Humidity 10% to 90%, Non-condensing
Power Requirement
MX-2522 7.5VAC@800mA
Regulatory Approvals
Amplifier Units FCC, CE, RoHS
Power Supplies UL, CUL, CE, PSE, GS, RoHS
Accessories Included
1x Operations Manual
1x Power Adapter US, UK or Euro
Product Item Numbers
MX-2522 2x2 Matrix Routing Switcher
2.1 Input/Output Signals
Pin # Signal Pin # Signal
1 Red Video 9 NC
2 Green Video 10 Ground
3 Blue Video 11 ID0
4 ID2 12 ID1
5 Ground 13 Horizontal Sync
6 Analog Ground 14 Vertical Sync
7 Analog Ground 15 ID3
8 Analog Ground

4
3.0 CHECKING PACKAGE CONTENTS
Before attempting to use this unit, please check the packaging and make certain the
following items are contained in the shipping carton:
•1x MX-2522 Matrix Switcher
•1x User Manual
•1x Power Adapter with 7.5VAC, 800mA output
Note: Please retain the original packing material should the need ever arise to return the
unit. If you find any items are missing, contact your reseller or TV One immediately.
Have the Model Number, Serial Number and Invoice available for reference when you
call.
4.0 CONNECTING THE HARDWARE
Please study the panel drawings below and become familiar with the signal input,
outputs, power requirements/inputs plus any controls present.
After you have familiarized yourself with the front and rear panel layouts, connect the
various signal cables and power connections in the following order:
1. Turn off all PCs and Monitors
2. Connect PCs to A and B inputs using high quality HD-15 Cables
3. Connect Outputs 1 and/or 2 to the desired monitors or projectors
4. Connect Power to Video Matrix, turning and locking DC connector in place, then
plug Power Adapter into AC socket
5. Turn on PCs and Monitors or Projectors.
Note: Optional rack mount kits are available to allow placing either one or two MX-2522
units in a standard 19” rack. The part numbers are RM-310S for mounting a single MX-
2522 and RM-310D for mounting two MX-2522 units.

5
5.0 OPERATING THE UNIT
FRONT VIEW
6.0 TROUBLESHOOTING
Problems with the MX-2522 Matrix Switcher are rare. Most of the time, the problem is
caused by the use of an incorrect cable for the signal type, too long a cable run, bad
connectors on the cable or damaged cables. Bad grounds or use of different AC power
sources for the MX-2522 Matrix Switcher, Signal Source and/or Display Device(s) may
also cause problems due to ground loops.
After trying the above suggestions should the problem still persist, contact your dealer
for additional suggestions before contacting TV One. Should the dealer’s technical
personnel be unable to assist you, contact TV One via our support website:
http://tvone.crmdesk.com. Create a technical support request on the site and our
support team will respond within a short period of time.
Selec
t
Status
Inputs A or B are directed to the desired output (1 or 2) by pressing the Select Buttons.
These are toggle buttons and will cause either Input A or Input B to appear on either
Output 1 or Output 2. By using the same procedure, both Outputs can be assigned to the
same Input. LEDs (Status) indicate your choice.
In
p
uts
Power
In Out
p
uts
REAR VIEW

6
7.0 LIMITED WARRANTY
LIMITED WARRANTY – With the exceptions noted in the next paragraph, TV One
warrants the original purchaser that the equipment it manufactures or sells will be free
from defects in materials and workmanship for a period of two years from the date of
purchase. Should this product, in TV One’s opinion, prove defective within this warranty
period, TV One, at its option, will repair or replace this product without charge. Any
defective parts replaced become the property of TV One. This warranty does not apply
to those products which have been damaged due to accident, unauthorized alterations,
improper repair, modifications, inadequate maintenance and care, or use in any manner
for which the product was not originally intended.
Items integrated into TV One products that are made by other manufacturers, notably
computer hard drives and liquid crystal display panels, are limited to the term of the
warranty offered by the respective manufacturers. Such specific warranties are
available upon request to TV One.
If repairs are necessary under this warranty policy, the original purchaser must obtain a
Return Authorization Number from TV One and return the product to a location
designated by TV One, freight prepaid. After repairs are complete, the product will be
returned, freight prepaid.
LIMITATIONS - All products sold are "as is" and the above Limited Warranty is in lieu of
all other warranties for this product, expressed or implied, and is strictly limited to two
years from the date of purchase. TV One assumes no liability to distributors, resellers or
end-users or any third parties for any loss of use, revenue or profit.
TV One makes no other representation of warranty as to fitness for the purpose or
merchantability or otherwise in respect of any of the products sold. The liability of TV
One with respect to any defective products will be limited to the repair or replacement of
such products. In no event shall TV One be responsible or liable for any damage
arising from the use of such defective products whether such damages be direct,
indirect, consequential or otherwise, and whether such damages are incurred by the
reseller, end-user or any third party.
8.0 REGULATORY COMPLIANCE
The MX-2522 Matrix Switcher has been tested for compliance with appropriate FCC
and CE rules and regulations. The Power Adaptor/Supply has been tested for
compliance with appropriate UL, CUL, CE, PSE, GS Rules, Regulations and/or
Guidelines. This Product and Power Adapter is RoHS Compliant.

7
9.0 CONTACT INFORMATION
Should you have questions or require assistance with this product in areas not covered
by this manual, please contact TV One at the appropriate location shown below:
TV One USA
2791 Circleport Drive
Erlanger, KY 41018
USA
Tel [phone]
Fax [phone]
[email protected]
www.tvone.com
TV One Europe
Continental Approach
Westwood Industrial Estate
Margate, Kent CT9 4JG, UK
Tel [phone]
Fax [phone]
[email protected]
www.tvone.eu
TV One Latin America
6991 NW 82 Avenue #8
Miami, FL 33166
USA
Tel [phone]
Fax [phone]
[email protected]
www.tvonela.com
TV One Mercosur
Honduras 5849, 2nd Floor, Office C
(C1414BNI) Capital Federal
Buenos Aires, Argentina
Tel [phone]
Fax [phone]
[email protected]
www.tvonela.com
TV One Asia
11F, NO.28, Sec. 2
San-Min Rd, Panchiao City
Taipei Hsien 220
Taiwan R.O.C.
Tel [phone]
Fax [phone]
[email protected]
www.tvoneasia.com
TV One China
Rm.9C, Neiwailian Building
No.518 Shangcheng Road
Pudong, Shanghai
China 200120
Tel [phone]
Fax [phone]
Email: [email protected]
Website: www.tvonechina.com
End of Manual
