TV One 1T-VS-647 User manual

Instruction Manual
1T-VS-647
SDI to HDMI Scaler w/Audio
99 Washington Street
Melrose, MA 02176
Phone [phone]
Toll Free 1-800-517-8431
Visit us at www.TestEquipmentDepot.com

Test Equipment Depot - 800.517.8431 - 99 Washington Street Melrose, MA 02176
TestEquipmentDepot.com

Table of Contents
1.0
Introduction
2
2.0
Specifications
3
3.0
Checking Package Contents
4
4.0
Connecting The Hardware
4
5.0
Operating The Unit
5
6.0
Troubleshooting
8
7.0
Limited Warranty
9
8.0
Regulatory Compliance
10
9.0
Contact Information
10

2
1.0 INTRODUCTION
Thanks for purchasing this 1T-VS-647 SDI to HDMI Scaler with Audio from TV One.
The 1T-VS-647 SDI to HDMI Scaler converts a variety of SDI transmission rates and
video resolutions into an HDMI signal. It also provides audio flexibility by outputting the
audio embedded in the SDI signal to external connectors (both analog and digital
formats) for distribution separate from the HDMI data stream. Additional capabilities
include SDI loop-thru with equalization and reclocking which means the 1T-VS-647 SDI
to HDMI Scaler doubles as an SDI repeater. Finally, as part of the SDIto HDMI scaling
process, SDI timing is automatically converted to PC timing parameters. Our
professional video conversion products have been serving the industry for over twenty
years. TV One offers a full line of high quality Seamless Switchers, VideoScalers,
Up/Down/Cross Converters, Analog-Digital Converters (SD/HD-SDI, HDMI, DVI),
Format Converters, Standards Converters, TBC/Frame Synchronizers, Matrix Routing
Switchers, Signal Distribution Amplifiers and Cat.5 Transmission Systems.
1.1 Liability Statement
Every effort has been made to ensure that this product is free of errors. TV One cannot
be held liable for the use of this hardware or any direct or indirect consequential
damages arising from its use. It is the responsibility of the user ofthe hardware to check
that it is suitable for his/her requirements and that it is installed correctly. All rights
reserved. No parts of this manual may be reproduced or transmitted by any form or
means electronic or mechanical, including photocopying, recording or by any
information storage or retrieval system without the written consent of the publisher.
TV One reserves the right to revise any of its hardware and software following its policy
to modify and/or improve its products where necessary or desirable. This statement
does not affect the legal rights of the user in any way.
All third party trademarks and copyrights are recognised. The TV One logo, TV One-
task and CORIO are the registered Trademarks of TV One. All other trademarks are the
property of their respective holders.
1.2 Features
Bitrates to 2.970Gb/s
Resolutions to1080p
Accepts 480i or 576i SDTV input
SMPTE 425 A&B, 424M, 292M & 259M-C
SDI equalized and Re-Clocked loop-thru
De-embedded Audio –Analog and DigitalOutputs
OSD (On Screen Display)
Automatic Input VideoFormat Detection
SMPTE 425M level B to level A Conversion
Converts SDI HD Timing to PC Timing

3
2.0 SPECIFICATIONS
Video/Audio Input
SDI SD, HD, 3G-SDI
Via 2x BNC (1x Input w/Loop-Thru)
Video Output
HDMI v1.3
Via 1x HDMI Connector
Ancillary Audio Outputs
De-Embedded Digital Audio
Via 1x RCA, 48KHz
De-Embedded Analog Audio
Via 2x RCA, 48KHz
Transmission Bitrates
SDI Inputs
2.970Gbit/s & 2.970/1.001 Gbit/s
Frequency Bandwidth
MHz/Link
165MHz
SDI Loop Thru
Signal Processing
Equalization & Re-Clocking
Cable Distance (Belden 1694A)
SD=300M, HD=200M, 3G=100M
SDI Format Support
SD
480i, 576i
HD
720p 50/60, 1080i 50/60, 1080p 24/25/30
3G-SDI
1080p 50/60
Signal Conversion
SMPTE Standard
425M Level B to Level A
Max Output Resolution
1080p 60, WUXGA
De-Embedded Audio Support
Output Signal Types
Digital Coaxial, Analog R&L
Channel Compliment
4 Groups, 2 per Group
Mechanical
Size (H-W-D)
30x180x142mm (1.2x7x5.6”)
Weight (Net)
460g (16.2oz)
Warranty
Limited Warranty
3 Years Parts and Labor
Environmental
Operating Temperature
0 to +40 C (+32 to +104 F)
Operating Humidity
20% to 90%, Non-condensing
Storage Temperature
-20 to +60 C (-4 to +140 F)
Storage Humidity
20% to 90%, Non-condensing
PowerRequirement
External Power Supply
5VDC@2.6A
Regulatory Approvals
Converter Unit
FCC, CE, RoHS
Power Supply
UL, CUL, CE, PSE, GS, RoHS
Accessories Included
1x AC Power Adapter
US, UK or Euro
1x Operations Manual
Optional Accessories
Rack Mount Kit
RM-230
Test Equipment Depot - 800.517.8431 - 99 Washington Street Melrose, MA 02176
TestEquipmentDepot.com

4
2.1 Supported Resolutions
INPUT
SDI
SD, HD, 3G-SDI
OUTPUT
HDMI
NATIVE, 800x600@60, 1024x768@60, 1280x768@60,
1360x768 @60, 1280x800@60, 1280x1024@60, 1440x900@60,
1400x1050 @60, 1680x1050@60, 1600x1200@60,
1920x1200@60, 720x480p @60, 1280x720p @60,
1920x1080p@60, 720x576p@50, 1280x720p @50,
1920x1080p@50, 1920x1080i @60, 1920 x 1080i @50
Note: The 1T-VS-647 automatically detects the type of the SDI source: (SD, HD,
3G-SDI)
3.0 CHECKINGPACKAGE CONTENTS
Before attempting to use this unit, please check the packaging and make certain the
following items are contained in the shipping carton:
1x 1T-VS-647 SDI to HDMI Scaler w/Audio
1x AC Power Adapter
1x Operations Manual
Note: Please retain the original packing material should the need ever arise to return
the unit. If you find any items are missing, contact your reseller or TV One immediately.
Have the Model Number, Serial Number and Invoice available for reference when you
call.
4.0 CONNECTING THE HARDWARE
Please study the panel drawings below and become familiar with the signal inputs,
outputs, operational controls and the location of the power connector. Turn off the SDI
source and the HDMI Display and connect the appropriate SDI, HDMI and audio cables;
first between the source and the 1T-VS-647 and then between the 1T-VS-647 and the
display. Plug in the provided AC adapter, first to the 1T-VS-647 and then to an active
AC power source. Lastly, turn on the SDI source and display device. (The 1T-VS-647
has no power switch and will begin to function as soon as it has the AC adapter
connected to it.)

5
Note: By default, the 1T-VS-647 will have an output resolution that matches the native
resolution of the connected displaydevice. The resolution that is output by the scaler
can be changed via the On Screen Display menu however, it’s very important that you
determine beforehand if the display deviceis capable of accepting the output resolution.
Failure to do so can result in no imageon the displaydevice –a situation that is difficult
to recover from since you would not be able to see the OSD display.
5.0 OPERATING THE UNIT
The front panel of the 1T-VS-647 has four LEDs and four push buttons that are used to
indicate status or to allow user interaction with the device. From left to right, the Power
LED will illuminate anytime the device is receiving power from the included AC adapter.
Next, the 3G, HD or SD LEDs will be illuminated to indicate what type of SDI signal is
present as the device’s source signal. (If none of the three SDI status LEDs are
illuminated, a source signal is either missing or is not a suitable signal.)
The four push buttons are used to access the menu structure for making operational
parameter changes as explained in the OSD menu discussion below. Other than these
displays and push buttons, there are no status observations or user adjustments
involved with using the 1T-VS-647 SDIto HDMI Scaler with Audio.
Please note that the SDI input is configured as a Loop-Thru system. The input signal is
automatically equalized to a unity frequency response and signal level and is also
reclocked which allows the 1T-VS-647 to function both as a SDI to HDMI scaler and
also as an SDI repeater. Please consult the specification section above to determine
the cable distance offered for each of the three supported SDI signal types.

6
5.1 On Screen Display (OSD) Structure
The 1T-VS-647 is controlled via an On Screen Display (OSD) menu structure. Much of
the operation of the scaler is done automatically (Plug & Play), however there may be
an occasion where an adjustment is desired. Numerous parameters can be controlled
from the menu including adjustment of output resolutions, type of audio output, etc.
Note: Pressing the Menu button enters the OSD structure and also exits the structure
when you are finished with your selections.
The menu structure is grouped into a three tier arrangement. When you press the Menu
button for the first time, you will display the top tier which is where you select the basic
parameters. From Left to Right, the icons represent the following basic parameters:
Display Setup, Color Adjustments, SDI Audio Group, Factory Reset and Device
Information. (Display Setup is shown selected in the example below.)
Use the + and –buttons to move horizontally across the first tier selections until you
arrive at the one associated with the parameters you wish to adjust and then press the
Enter button to select that parameter.
If there is only one item in the second tier associated with the parameter where you are
working, you can use the + and –buttons to directly make an adjustment or selection
without selecting an item from the third tier. Press the Enter button to save the selection.
If there is more than one second tier item associated with the parameter, use the + and
–buttons to move to the item you wish to work with and press the Enter button to select
that item. Use the + and –buttons to make the adjustment or selection, and once the
adjustment or selection is made, press the Enter button to save your change.
When the adjustment or selection has been made and saved, use the Menu button to
exit the OSD. (From within the second tier, you can select the Exit function from the list
to return to the first tier if it’s offered.)
Test Equipment Depot - 800.517.8431 - 99 Washington Street Melrose, MA 02176
TestEquipmentDepot.com

7
Note: Press the Enter and the –button together to immediately select 720p output
timing and press Enter and the + button together to immediately select XGA output
timing. These are the two most commonly used scaler parameters.
Note 2: After making a resolution change you will have 15 seconds to confirm the newly
selected resolution by pressing the “ENTER” button. If the new resolution is not
confirmed then the output will revert to the original resolution.
Here are textual representations of the items that will be shown for the three tiers within
the OSD. The first tier list shown below is for Display functions:
1st Tier
2nd Tier
3rd Tier
Display
Information
On/Auto/Off
Output
NATIVE
800 x 600 @60
1024 x 768 @60
1280 x 768 @60
1360 x 768 @60
1280 x 800 @60
1280 x 1024 @60
1440 x 900 @60
1400 x 1050 @60
1680 x 1050 @60
1600 x 1200 @60
1920 x 1200 @60
720 x 480p @60
720 x 576p @50
1280 x 720p @50
1280 x 720p @60
1920 x 1080i @60
1920 x 1080i @50
1920 x 1080p @50
1920 x 1080p @60
Size
Full
Over Scan
Under 1
Under 2
16:9
4:3
Exit

8
The remaining first tiers lists allow you to reach adjustments for the Color parameters,
select the SDI Audio Groups you wish to de-embed, perform a Factory Reset to default
conditions and display the current status Information for the device:
Color
Contrast
0~255 (105)
Brightness
0~192 (96)
R
0~255 (128)
G
0~255 (128)
B
0~255 (128)
R Offset
0~63 (32)
G Offset
0~63 (32)
B Offset
0~63 (32)
Exit
SDI Audio
Group 1+2
Group 2+3
Group 3+4
Group 4+1
Auto
Off
Factory
Reset
Yes
Information
Input Timing, Output Timing & Version
6.0 TROUBLESHOOTING
Faulty cables are the most common problem associated with the 1T-VS-647. Make
certain you are using the highest quality cables available. In the event of trouble with the
unit, inspect the cables for damage and make sure they are completely seated in their
connectors. Also make certain that the AC adapter is plugged in to a working AC
socket and that the Power LED is illuminated.
After trying the above suggestions should the problem still persist, contact your dealer
for additional suggestions before contacting TV One. Should the dealer’s technical
personnel be unable to assist you, contact TV One via our support website:
http://tvone.crmdesk.com. Create a technical support request on the site and our
support team will respond within a short period of time.

9
7.0 LIMITED WARRANTY
TV One warrants the original purchaser that the equipment it manufactures or sells will
be free from defects in materials and workmanship for a fixed term from the date of
purchase. The warranty term for specific product lines is defined below.
1. TV One branded products based on TV One’s CORIO technology are warranted for
a period of five years from the date of purchase. This includes products with the
model number prefix of C2, 1T-C2, CX, A2 or S2.
2. TV One-task branded products, other than those based on TV One’s CORIO
technology mentioned above, are warranted for a period of three years from the date
of purchase. This includes products with the model number prefix of 1T, with the
exception of 1T-C2.
3. LCD Monitors are warranted for a period of three years from the date of purchase,
with the exception of the LCD panels integrated into the monitors that are supplied
by third parties. LCDpanels are limited to the term and conditions of the warranty
offered by the respective LCD panel manufacturer. Such specific LCD panel
warranties are available upon request to TV One.
Should a product, in TV One’s opinion, prove defective within this warranty period, TV
One, at its option, will repair or replace this product without charge. Any defective parts
replaced become the property of TV One. This warranty does not apply to those
products which have been damaged due to accident, unauthorized alterations, improper
repair, modifications, inadequate maintenance and care, or use in any manner for which
the product was not originally intended.
If repairs are necessary under this warranty policy, the original purchaser must obtain a
Return Authorization Number from TV One and return the product to a location
designated by TV One, freight prepaid. After repairs are complete, the product will be
returned, freight prepaid.
LIMITATIONS - All products sold are "as is" and the above Limited Warranty is in lieu of
all other warranties for this product, expressed or implied, and is strictly limited to two
years from the date of purchase. TV One assumes no liability to distributors, resellers or
end-users or any third parties for any loss of use, revenue or profit.
TV One makes no other representation of warranty as to fitness for the purpose or
merchantability or otherwise in respect of any of the products sold. The liability of TV
One with respect to any defective products will be limited to the repair or replacement of
such products. In no event shall TV One be responsible or liable for any damage
arising from the use of such defective products whether such damages be direct,
indirect, consequential or otherwise, and whether such damages are incurred by the
reseller, end-user or any third party.
Test Equipment Depot - 800.517.8431 - 99 Washington Street Melrose, MA 02176
TestEquipmentDepot.com
