TVS Apache RR 310 User manual

st
Revision:- Rev. 1, 1 Aug'2018 onwards
TVS Apache RR 310
Owner’s Manual
Part number:- N7210130
Revision :- Rev. 1, Aug 2018

st
Revision:- Rev. 1, 1 Aug'2018 onwards

st
Revision:- Rev. 1, 1 Aug'2018 onwards
FOREWORD
Foreword
Dear Racer,
Thank you for choosing the TVS Apache
RR 310. The most powerful and technologically
advanced Apache yet.
The precision racer has been shaped in the
wind tunnel, honed on the dyno and perfected
over countless laps on the racetrack. The
flagship racer is the culmination of 35 years of
TVS Racing heritage, the racing prowess
reflects in every straight and every corner of the
track. The Apache RR 310 has been crafted to
be the ultimate racer.
This manual explains the features and
operations of your TVS Apache RR 310. Please
read it carefully and follow the instructions to
enjoy the racing experience.
To prolong your journey on the TVS Apache
RR 310, we urge you to get your TVS Apache
RR 310 services only at TVS Motor Company
Authorized Dealers.
Here’s to breaking lap records on your Apache
RR 310.
TVS Motor Company Limited
I

st
Revision:- Rev. 1, 1 Aug'2018 onwards
In case, you need any clarification or Service Assistance, please contact our Dealer
Dealer code, name .......................................................................................................................................................
Address ...........................................................................................................................................................................
............................................................................................................................................................................................
............................................................................................................................................................................................
Contact person name and mobile no. (Sales)
............................................................................................................................................................................................
Contact person name and mobile no. (Service)
............................................................................................................................................................................................
Email id.............................................................................................................................................................................
Or
TVS Motor Company’s Area Offices (flip over for addresses)
Or
Toll free number : 1800-258-7111
Email : [e-mail]
CONTACT(S) FOR SUPPORT
Contact(s) for Support
II

st
Revision:- Rev. 1, 1 Aug'2018 onwards
Contact at Our Area Offices
TAMILNADU-1
1. TVS Motor Company Limited
V Floor, Gee Gee Universal,
No. 2, MC Nichols Road,
Chetpet, Chennai - 600 031.
Phone : [phone]
Email : [e-mail]
TAMILNADU-2
2. TVS Motor Company Limited
No.10, 2nd floor,
Shree Shanmugapriya Towers,
Kannuswamy Street,
Behind Hotel Annapoorna,
R S Puram, Coimbatore - 641 002.
Phone : [phone]
Email : [e-mail]
TAMILNADU-3
3. TVS Motor Company Limited
D-09, Srinidhi Block, Agrini Apartments,
Andalpuram, TPK Road,
Madurai - 625 003.
Phone : [phone]
Email : [e-mail]
TAMILNADU-4 & 5
4. TVS Motor Company Limited
No. 37, 1st Floor, Mian Road,
West Brindavan,
Near Hotel Le Royal Park,
Puducherry - 605 103.
Phone : [phone]
Email : [e-mail]
KERALA
5. TVS Motor Company Limited
Ambady Towers, Second Floor,
Door No. 27/631, A6,
Edappally, Pookkattupady Road,
Edappally PO., Cochin - 682 024.
Phone : [phone]
Email : [e-mail]
ANDHRA PRADESH-1 & 3
6. TVS Motor Company Limited
No. D-19, 302, 3rd floor, Gayathri Arcade,
Vikrampuri, Secunderabad - 500 003.
Phone : [phone]
Email : [e-mail]
CONTACT(S) FOR SUPPORT
Area Office Address
III

st
Revision:- Rev. 1, 1 Aug'2018 onwards
ANDHRA PRADESH-2
7. TVS Motor Company Limited
Door No. 58-2-35, NCK Plaza,
Near NTR Circle, Patamata,
Vijayawada - 520 010.
Phone : [phone]
Email : [e-mail]
KARNATAKA-1
8. TVS Motor Company Limited
No. 600, Anand Surya, 2nd Floor, 15th Cross, 6th
Phase, JP Nagar, Opp. BMTC Stop,
Bangalore - 560 078.
Phone : [phone]
Email : [e-mail]
KARNATAKA-2 & GOA
9. TVS Motor Company Limited
No. 122/111 B, PDP Plaza, 3rd floor,
New Cotton Market, Karnataka Bank Road,
Hubli - 580 029.
Phone : [phone]
Email : [e-mail]
MAHARASHTRA-1, 2 & 4
10. TVS Motor Company Limited
No. 401, 4th floor, The Chambers, Plot No. 4/12/3,
Near Ganpati Chowk,
Viman Nagar, Pune - 411 014.
Phone : [phone]
Email : [e-mail]
MAHARASHTRA-3
11. TVS Motor Company Limited
Plot No. 206, House No. 241,
Ward No. 73, 1st floor,
West High Court Road,
Dharampeth, Nagpur - 400 010.
Phone : [phone]
Email : [e-mail]
[e-mail]
CHATTISGARH
12. TVS Motor Company Limited
No. 627-628, Magneto Offizo,
Magneto the Mall, Labhandi,
GE Road, Raipur - 492 010.
Phone : [phone]
Email : [e-mail]
MADHYA PRADESH-1
13. TVS Motor Company Limited
211-212, 2nd floor,
Chinar Incube Business centre,
Chinar Fortune City,
Near Vrindavan Dhaba,
Hoshangabad Road, Bhopal - 462 026.
Phone : [phone]
Email : [e-mail]
CONTACT(S) FOR SUPPORT
Area Office Address
IV

st
Revision:- Rev. 1, 1 Aug'2018 onwards
MADHYA PRADESH-2
14. TVS Motor Company Limited
301, 3rd floor, Shagun Arcade,
Vijay Nagar circle, A B Road,
Indore - 452 010.
Phone : [phone]
Email : [e-mail]
GUJARAT-1 & 2
15. TVS Motor Company Limited
109, Ayana Complex,
Opp. Suvarna Villa Bungalows,
100 ft Thaltej Hebbatpur road,
Off : S.G. highway, Thaltej,
Ahmedabad - 380 054.
Phone : [phone]
Email : [e-mail]
UTTAR PRADESH-EAST, CENTRAL & HILLS
16. TVS Motor Company Limited
1st floor, Cyber Tower, TC-34/V-2,
Vibhuti Khand, Gomti Nagar,
Lucknow - 226 010.
Phone : [phone]
Email : [e-mail]
[e-mail]
UTTAR PRADESH-WEST
17. TVS Motor Company Limited
D-3 & D-4, 2nd floor,
Sector - 10, Noida,
Uttar Pradesh - 201 301
Phone : [phone]
Email : [e-mail]
DELHI & HARYANA
18. TVS Motor Company Limited
D-3 & D-4, 2nd floor,
Sector - 10, Noida,
Uttar Pradesh - 201 301
Phone : [phone]
Email : [e-mail]
[e-mail]
PUNJAB, HIMACHAL PRADESH, JAMMU &
KASHMIR
19. TVS Motor Company Limited
SCF- 10-11, Kalghaidhar Enclave,
Baltana Road, Zirakpur,
District Mohali - 140 603.
Phone : [phone]/511661
Email : [e-mail]
Area Office Address
CONTACT(S) FOR SUPPORT
V

st
Revision:- Rev. 1, 1 Aug'2018 onwards
Area Office Address
VI
CONTACT(S) FOR SUPPORT
RAJASTHAN-1
20. TVS Motor Company Limited
Plot No. 17-18,
2nd floor of National Motors building,
Jhotwara Industrial Area,
Jaipur - 302 012.
Phone : [phone]
Email : [e-mail]
RAJASTHAN-2
21. TVS Motor Company Limited
204, 2nd floor, Daulet Chambers,
Near Meera Girls Collage, 4-D,
Sardarpura, Udaipur - 313 004.
Phone : [phone]
Email : [e-mail]
BIHAR
22. TVS Motor Company Limited
N-Plaza, Jamal Road,
P.S. Kotwali, Patna - 800 001.
Phone : [phone]
Email : [e-mail]
JHARKHAND
23. TVS Motor Company Limited
2nd floor, Lucas Building,
Argora Bypass Road,
Ranchi - 834 002.
Phone : [phone]
Email : [e-mail]
ODISHA
24. TVS Motor Company Limited
#303, 3rd floor,
Creative Plaza, Rasulgarh,
Bhubaneshwar - 751 010.
Phone : [phone]
Email : [e-mail]
WEST BENGAL
25. TVS Motor Company Limited
Ground floor & First floor,
133 A.S.P. Mukherjee Road,
Opp. Tollygunge Police Station,
Kolkata - 700 026.
Phone : [phone]
Email : [e-mail]
NORTH EAST STATES
26. TVS Motor Company Limited
147, Udayan, Ganesh Guri,
Opp. Punjab National Bank,
R G B. Road,
Guwahati - 781 005.
Phone : [phone]
Email : [e-mail]

st
Revision:- Rev. 1, 1 Aug'2018 onwards
Provides additional information
about the current operation.
Follow these instructions to
avoid risk of damage to the motorcycle and/or
its components.
Failure to comply with these
instructions may put you at risk, and could
lead to severe injury or deadly accidents.
VII
Note
This Owner’s Manual forms an integral part of
motorcycle and must be handed over to the
new owner if you ever sell your motorcycle.
TVS Motor Company Limited advices you to
read this manual carefully in order to familiarise
yourself with your motorcycle. In case of any
clarification, please contact any of our
Authorised Main Dealer.
This manual contains important information
about controls and operation, technical
features, maintenance and care to be taken to
keep your vehicle reliable and safe. We
recommend that you strictly follow the
instructions in this manual, especially those
regarding the running-in period and periodic
maintenance.
TVS Motor Company Limited declines any
liability whatsoever for any mistakes incurred
during the development of this manual. All the
information in this manual is valid at the time of
publication.
TVS Motor Company Limited reserves the right
to make any modifications required due to the
ongoing development of their products. In such
events it is possible that the relevant part of this
Owner’s Manual does not apply to your vehicle.
INTRODUCTION
Prior permission of TVS Motor Company
Limited is required for quoting, copying or
reproducing any part of this Owner’s Manual.
This Owner’s manual uses a set of symbols with
special meanings. They are:
General Information
Warning
Caution

st
Revision:- Rev. 1, 1 Aug'2018 onwards
INTRODUCTION
General Information
The terms ‘LH’ and ‘RH’ are referred to the
motorcycle viewed from the riding position.
Accessories shown in the picture may not be
the part of standard equipment.
For your safety, as well as to preserve warranty,
reliability and road worthy of your motorcycle,
use original TVS Motor Company Limited spare
parts only.
In order to ensure the reliability of your product,
you are strongly advised to refer our Authorised
Main Dealers for any service requiring particular
technical expertise.
Skilled personals of our Dealer have the tools
required to perform any servicing job to the
highest professional standards to ensure
smooth running and long life of your
motorcycle.
VIII

st
Revision:- Rev. 1, 1 Aug'2018 onwards
TABLE OF CONTENTS
Table of Contents
DESCRIPTION PAGE No.
RUNNING-IN RECOMMENDATIONS 01
SAFE RIDING TIPS 02
Safe Riding Recommendations 02
Maximum Permissible Load 05
ACCESSORY INSTALLATION TIPS 06
KNOW YOUR MOTORCYCLE 07
Anti-Lock Brake System 07
EMS a Glance 09
Emission Control 10
Vehicle Identification Number 12
Control Key 13
Location of Parts
Vehicle RH Side View 14
Vehicle LH Side View 16
Instrument Cluster 18
Hazard Switch 18
Set Button 19
Warning and Indicator Lights 19
Multifunction Display 22
Alpha Numeric Display 23
ODO, Range, IMI, etc. 23
Range 24
IMI 24
Mileage 25
Total Fuel 25
Trip 1 & Trip 2 25
IX
Trip A 26
HI-Speed 26
Average Speed 27
Engine Temperature 27
Over Speed 28
1 to 60 29
Trip Time 29
Date 30
Lap Timer 30
Lap Information 31
Setup 32
Service Reminder 33
Fuel Level Indicator 34
Coolant Temperature Indicator 35
Side Stand Warning Indicator 35
Gear Position Indicator 37
Speedometer 37
Engine rpm Indicator 37
Clock 37
Controls & Its Operations 38
Ignition cum Steering Lock 39
Clutch Lever 40
Switch Assembly LH 41
Gear Shift Pedal 43
Rear Brake Pedal 44
Switch Assembly RH 44
Throttle Twist Grip 46
Front Brake Lever 46

st
Revision:- Rev. 1, 1 Aug'2018 onwards
TABLE OF CONTENTS
Table of Contents
XDESCRIPTION PAGE No.
MAJOR COMPONENTS 47
Cooling System 48
Fuel Tank Cap 49
Side Stand 51
Rear Shock absorber 52
Seat Lock 53
RIDING YOUR MOTORCYCLE 55
Before Riding 55
While Riding 57
Starting the Engine 58
Moving the vehicle 59
Braking 60
Parking 60
Fuel Recommendation 61
Fuel Economy Tips 62
GENERAL ADJUSTMENTS 64
Rear View Mirrors LH & RH 64
Gear Shift Pedal Position 64
Rear Shock absorber Pre-Load 65
Head Lamp Aiming 67
MAJOR MAINTENANCE 69
Maintenance Schedule 69
Planned Maintenance Schedule (Table) 70
Safety Precautions 73
Engine Oil Level 74
Clutch Free Play 76
Throttle Cable Play 78
Brake Fluid Level 79
Brake Pad Wear 81
Rims and Tubeless Tyres 82
Drive Chain 85
Front Wheel 88
Rear Wheel 91
Battery 94
Fuses 95
Diagnostic Connector 98
Cleaning your Motorcycle 99
Storage Procedure 100
Restoring Vehicle for Use 101
Taking Long Trips 102
GENERAL INFORMATION 103
Tool Kit 103
Auxillary Stand (Paddock Stand) 104
WARRANTY AND SERVICES 107
Warranty Policy 107
Service information 111
Pre-Delivery Inspection 113
Planned Service Schedule 114
Pickup & Drop 115
Planned Service Record Sheet 117
Additional Service Record Sheet 118

st
Revision:- Rev. 1, 1 Aug'2018 onwards
TABLE OF CONTENTS
XI
Table of Contents
DESCRIPTION PAGE No.
TECHNICAL DATA 119
Recommended Fuel and Lubricants 119
Engine 121
Transmission 122
Dimensions 123
Frame and Suspension 124
Wheel and Brakes 125
Free Plays 126
Electricals 127
Important Torque 128
Basic Trouble Shooting 129

st
Revision:- Rev. 1, 1 Aug'2018 onwards
XII

st
Revision:- Rev. 1, 1 Aug'2018 onwards
RUNNING-IN INFORMATION
Running-in Recommendations
Running-in is essential to preserve engine life
and performance over time. Twisty roads and
gradients are ideal to run in the engine, brakes
and suspension effectively. The first 1000 km is
a running-in period for your motorcycle.
Maximum engine speed during running-in
0 to 1000 km - below 7000 rpm
During the first 1000 km, avoid the full throttle
starts and rapid acceleration, which could
expose the engine parts to excessive stress. It is
advisable to run the engine at varying load and
rpm, though still within recommended rpm
limit. Avoid riding at constant engine rpm for
prolonged periods.
During initial running, use brakes gently. Do not
brake hard or keep brake applied for too long to
enable a correct break-in of brake pad friction
material against the brake discs.
To allow all the mechanical parts of motorcycle
to adapt each another, and to avoid reduction of
engine components life, it is advisable to avoid
sudden acceleration and running the engine at
high rpm for too long, especially uphill.
Check the drive chain frequently and if required
adjust it. Also ensure that the chain is lubricated
as required to increase its service life.
Caution On completion of running -in
period, scheduled maintenance service
should be observed carefully without fail.
Failure to comply with this will result in
damage to the engine parts and other key
parts of the vehicle or shorter engine life.
Keeping to the running-in recommendations
will ensures longer engine life and reduce the
need for overhauls and re-tuning.
Running-in Information
01

st
Revision:- Rev. 1, 1 Aug'2018 onwards
SAFE RIDING TIPS
02
Safe Riding Recommendations

st
Revision:- Rev. 1, 1 Aug'2018 onwards
SAFE RIDING TIPS
03
Safe Riding Recommendations

st
Revision:- Rev. 1, 1 Aug'2018 onwards
SAFE RIDING TIPS
Warning This vehicle is designed for
use only on streets and other smooth, paved
surfaces. Do not use this motorcycle on
unpaved surfaces. Such use could lead to
skid or other accident.
Do not ride the motorcycle with helmets
attached to the hook; the helmets could
cause an accident by distracting the rider or
interfering with normal vehicle operation.
04
Safe Riding Recommendations

st
Revision:- Rev. 1, 1 Aug'2018 onwards
SAFE RIDING TIPS
05
Maximum Permissible Load

st
Revision:- Rev. 1, 1 Aug'2018 onwards
Use only TVS Motor Company Limited
approved accessories.
Take extreme caution while selecting and
installing the accessories for your motorcycle.
The addition of unsuitable accessories can lead
to unsafe operating conditions. Your friendly
dealer will assist you in selecting quality
accessories and installing them correctly.
While selecting the accessories, make sure the
accessories should not obstruct lighting,
steering, suspension and ground clearance.
ACCESSORY INSTALLATION TIPS
Additional electrical equipments and controls
should not exceed the specified electrical
system load of the vehicle (capacity of battery
and magneto).
Do not change / add any lighting loads. Use only
accessories listed by TVS Motor Company
Limited.
Caution
Caution
This motorcycle was not
intended to be equipped with a sidecar or to
be used to tow any trailer or other vehicle.
TVS Motor Company Limited does not
produce any of those things and not sure
about the effects of those accessories on
handling or stability. But we can warn that the
effects will be adverse and any damage
caused to motorcycle and its components by
the use of such accessories will not be
covered under warranty.
Care should taken not to
damage the wiring harness of the vehicle to fit
additional electrical accessories; which
in-turn affects the ‘CAN bus’ system of the
vehicle.
06
Accessory Installation Tips
