TYAN TYAN S1572 ATX User manual

Revision 1.0
TYAN S1572 ATX
Pentium Class 75 thru 200MHz
430TX PCI-ISA System Board
User's Manual

2S1572-001-01 http://www.tyan.com
Notice for the USA
ComplianceInformationStatement
( Declaration of Comformity Procedure) DoC
FCC Part 15: This Device complies with Part 15 of the FCC Rules.
Operation is subject to the following conditions:
1) this device may not cause harmful interference, and
2) this device must accept any interference received
including interference that may cause undesired operation.
If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on,
the user is encouraged to try one or more of the following measures:
w Reorient or relocate the receiving antenna.
w Increase the separation between the equipment and receiver.
w Connect the equipment into an outlet on a circuit different from that of the
receiver connected.
w Consult the dealer or an experienced radio/TV technician for help.
Notice for Canada
This apparatus complies with the Class "B" limits for radio interference as
specified in the Canadian Department of Communications Radio Interference
Regulations.
Cet appareil est conforme aux normes de CLASSE "B" d' interference radio
tel que spec' cifie' par le Ministe're Canadien des Communications dans les
re'glements d'interfe'rence radio.
Noticefor Europe (CEMark)
This product is in conformity to the Council Directive 89/336/EEC, 92/31/EEC
(EMC)

3S1572-001-01 http://www.tyan.com
TableOfContents
1.Introduction.......................................................................3
1.1 Overview................................................................3
1.2Hardware Specifications..........................................4
1.3Software Specifications.......................................... 5
1.4Environment........................................................... 5
2.BoardInstallation.............................................................. 6
2.1 Unpacking..............................................................6
2.2 Installation.............................................................. 6
3.S1572OnBoardResource Settings................................. 7
3.1S1572BoardLayout&JumperLocations................ 7
3.2 Quick Reference for Jumpers.................................. 8
3.3 CMOS RTC............................................................12
3.4Speaker Connector..................................................12
3.5 Turbo Switch.......................................................... 12
3.6TurboLEDConnect................................................12
3.7 Reset Connector..................................................... 13
3.8Flash EPROM Jumpers.......................................... 13
3.9 CMOS & Password Reset...................................... 13
3.10DRAM Installation................................................ 14
3.11CPUInstallation....................................................15
3.12 Cache Upgrade................................................... 16
3.13PeripheralDevice Installation.................................16
4.BIOSConfiguration...........................................................17
4.1Entering Setup....................................................... 17
4.2 Control Keys......................................................... 18
4.3 Getting Help........................................................... 19
4.4 The Main Menu......................................................19
4.5StandardCMOSSetupMenu...................................21
4.6BIOS Features Setup.............................................. 24
4.7Chipset Features Setup............................................27
4.7.1PowerManagement Setup........................28
4.8PCISlotConfiguration.............................................30
4.9IntegratedPeripherals............................................. 32
4.10LoadingSetup Defaults..........................................33
4.11Password Setting ..................................................33
4.12 IDE HDD AutoDetection..................................... 35
4.13Save & ExitSetup.................................................35
5.FlashWriterUtility............................................................ 36
5.1TheFlashMemoryWriterUtilityScreen...................38
6.System Resources............................................................. 39
6.1Timer&DMAChannelMap....................................39

4S1572-001-01 http://www.tyan.com
1. Introduction
1.1 Overview
The S1572 is a quality, high performance mainboard designed for Intel
Pentium microprocessors. This mainboard utilizes the Intel 430TX chipset
and can support CPU speeds of 75MHz through 200MHz. The S1572
will also support the CyrixM1/6x86 CPU's and the Intel multimedia
Pentium with MMX processor, both the P55C and P54CTB Overdrive
versions.
The S1572's PCI Local Bus provides high performance capabilities that
are ideal for a wide range of demanding applications such as: CAD,
CAM, CAE, networking, multi-user environments, database management,
desktop publishing, image processing and 3D animation.
This integrated system board achieves high reliability with numerous
features and yet is small enough to be supported in a "ATX" form-factor.
Some of the features included are: on-board dual channel PCI PIO,
DMA IDE and UltraDMA/33, on-board floppy controller, on-board high
speed I/O, and support for pipeline-burst SRAM.
Flexibility and expandibility have been designed into the S1572. With I/O
and drive controller support built on-board, the five PCI and three ISA
(One ISA and one PCI as a shared slot) slots are free for numerous add-
on expansion cards.
Remember to take a look at Tyan Computers web site located at
http://www.tyan.com. Here you can find information on all of Tyan's
products along with FAQ's, distributors list, drivers and CMOS setting
explanations. If you have a tech support question please contact us at
www.tyan.com.
Notice
This board uses the Intel 430TX chipset. According to Intel , the USB
function in this chipset is not guaranteed. Compatibility tests cannot be
conducted for USB at this time due to no availability of Operating
System support for these devices. Please log on to the Tyan web page for
the latest infomation.

5S1572-001-01 http://www.tyan.com
1.2 Hardware Specifications/Features
wCPU Intel Pentium 75 MHz thru 200 MHz (Socket 7)
Intel Pentium P55C/P54CTB Overdrive (MMX)
Cyrix/IBM/SGS M1/6x86 P120+, P150+, P166+,
and AMD K5 PR90 through PR166.
wSpeed 50/60/66 MHz system bus
25/30/33 MHz PCI bus
wDRAM 3 banks of 72 pin SIMM and 2 DIMM sockets
Supports 5V or 3.3V memory
Supports EDO(Extended Data Out) DRAMs
Supports SDRAM(Synchronous DRAM)
Supports Fast Page Mode DRAMs
Supports 8MB to 256MB of DRAMs
wL2 Cache 512KB on board 2nd level cache memory
Supports pipeline-burst SRAM
wEIDE Controller Primary and secondary PCI EIDE channels on
board for support of up to four EIDE Mode 0
through Mode 4 drives.
Supports DMA(Bus Master) mode 1 and 2.
( Bus Master driver on web at www.tyan.com)
Supports "UltraDMA/33" Synchronous mode.
wEnhanced I/O Multi-mode bi-directional parallel port that
supports standard, EPP and ECP modes.
Supports 16550 compatible UARTS for on-board
high speed serial ports.
Support for an IrDA compliant Infra Red inter-
face.
On-board floppy controller
On-board Universal Serial Ports (2)
wI/O Bus Slots 5 Master/Slave PCI-Bus
3 ISA Bus One ISA and one PCI shared slot
wMouse On-board PS/2 mouse connector.

6S1572-001-01 http://www.tyan.com
1.3 Software Specifications
wBIOS Award or AMI BIOS
AT CMOS setup, BIOS/CHIPSET setup,
and hard disk utility included.
Support for easy BIOS upgrades with flash
EPROM chip.
wO.S. Operates with MS-DOS, Windows 3.x, Windows
for Work Group 3.x, Windows 95, Windows NT
OS/2, Novell Netware,and SCO Unix.
Tyan is also a Solaris certified manufacturer.3
1.4 Environment
Ambient Temperature 0 to +50 C (operating)
Relative Humidity 0 to +85% (operating)
Altitude 0 to 10,000 feet (operating)
Vibration 0 to 1,000 Hz
Voltage 4.9 to 5.2 V
Informationpresentedinthispublicationhasbeencarefullycheckedfor
reliability;however,noresponsibilityisassumedforinaccuracies.The
informationcontainedinthisdocumentissubjecttochangewithout
notice.
Trademarks
AwardBIOS/FlasharetrademarksofAwardSoftwareInternationalInc.
AMIBIOSisatrademarksofAmericanMegatrendsInc.
IBM,PC,AT,PS/2aretrademarksofIBMCorporation
INTEL,PentiumaretrademarksofIntelCorporation.

7S1572-001-01 http://www.tyan.com
2. Board Installation
2.1 Unpacking
The mainboard package should contain the following:
wS1572Mainboard
wOne IDE 40 pin cable
wOne 34 pin floppy cable
wUser's Manual
The mainboard contains sensitive electric components which can be easily
damaged by static electricity, so the mainboard should be left in its original
packaging until it is ready to be installed.
With the power supply plugged in and turned off, touch an unpainted area of
the system chassis immediately before handling the mainboard or any com-
ponent. Doing so discharges the static charge your body may have built.
After opening the mainboard carton, extract the system board holding it by
its edges ,and place it only on a grounded anti-static surface, component
side up. Inspect the board for damage. Press down on any of the socket
IC's if it appears they are not properly seated. Do this only with the board
placed on an anti-static mat. Do not touch the bottom of the board.
DO NOT APPLY POWER TO THE BOARD IF IT HAS BEEN
DAMAGED!
2.2 Installation
You are now ready to install your mainboard. The mounting hole pattern of
the S1572 matches the ATX system board spec. It is assumed that the
chassis is for a standard ATX mainboard form factor.

8S1572-001-01 http://www.tyan.com
Parallel Port
PCI Slot 1
PCI Slot 2
PCI Slot 3
PCI Slot 4
PCI Slot 5
ISA Slot 1
ISA Slot 2
ISA Slot 3
3. On Board Resource Setting
Figure3.1S1572 ATX Board Layout
PS/2
Mouse
PS/2
KB
Socket 7
CPU 0
SRAM SRAM
ATX PWR CON
DRAM Bank 2
SDRAM Bank 0
DRAM Bank 2
DRAM Bank 1
DRAM Bank 1
DRAM Bank 0
DRAM Bank 0
SDRAM Bank 1
82439TX
Clk Gen.
Floppy Con.
Secondary IDE
Primary IDE
82371AB
TagRAM
1
1
1
Com1
Com2
USB0
USB1
pin 1
3Volt
Battery
J20
J21
JP4 JP5
JP13
JP11
JP12
J18
J23
pin 1
BIOS AMI/AWARD
pin 1
J8
KB CTR
JP2
JP17
pin 1
pin 1
JP14
J25
pin 1
J2
JP1pin 1
JP3
JP9JP10
pin 1
pin 1
JP18
JP19
JP15
JP16

9S1572-001-01 http://www.tyan.com
3.2 Jumper Settings
CPU Speed Settings for Pentium P54C and P55C:
JP4 JP5 JP23 CPU Speed
off off 1-2,3-4 75MHz
off off 3-4 90MHz
off off 1-2 100MHz
on off 3-4 120MHz
on off 1-2 133MHz
on on 3-4 150MHz
on on 1-2 166MHz
off on 3-4 180MHz
off on 1-2 200MHz
CPU Speed Settings for Cyrix/SGS/IBM 6x86/M1/AMD:
JP4 JP5 JP6 CPU Speed/ID
on off 1-2,3-4 100MHz/P120+
on off 3-4 120MHz/P150+
on off 1-2 133MHz/P166+
DIMM Memory Voltage Select: 3V is Default
DIMM VCC 3V 5V
JP9 1-2 2-3
JP10 1-2 2-3
Heatsink Fan Power: J18
pin1 GND
pin2 +12V
pin3 GND

10S1572-001-01 http://www.tyan.com
BIOS Voltage Select: JP2 (Default is 5V)
BIOS 5V BIOS 12V
JP2 1-2 2-3
J8 Jumper Block:
Desc. PIN#
Soft Power 1-2
Ext SMI 3-4
IR1 8-11
Pri HDD LED 13-14
Sec HDD LED 15-16
PWR LED 18-20
Reset SW 22-23
Speaker 24-27
CPU Select: Default P54C, P55C(MMX), & Cyrix
These jumpers need not be changed. The system
will auto-detect your CPU type.
P54C,
P55C(MMX)
Cyrix
JP11 Off
JP12 Off
JP13 On
CMOS Reset: JP1(Default Battery On)
Battery On CMOS Reset
1-2 2-3
To reset CMOS, jumper JP1 on pins 2-3 for two
seconds, then jumper it back to pins 1-2.

11S1572-001-01 http://www.tyan.com
Reset Connector: J8 pin 22-23
Pinout Assignment
22 Power Good
23 Ground
Flash EPROM: JP2
This jumper should be left at the factory default.
JP2 1-2
Keylock Connector: J25 Pinout Assignments
1Led
2No Connect
3Ground
4Keylock
5Ground

12S1572-001-01 http://www.tyan.com
Infra Red Interface: J8 pins 8-11 and J2
Pinout Assignments
1(8) Signal In
2(9) Gnd
3(10) SignalOut
4(11) VCC
I/O Port Setting: J15 and J16
J15 J16
For Serial Port 1-2 1-2
For IR Port 2-3 2-3
Speaker Connector: J8 pins 24-27
Pinout Assignments
1Speaker out
2Ground
3NC
4+ 5V
HDD LED: J8 pins 13-14 and pins 15-16
Pinout Assignments
13 Anode
14 Cathode
15 Anode
16 Cathode

13S1572-001-01 http://www.tyan.com
3.3 CMOS RTC
CMOS RTC includes an internal battery and Real Time Clock circuit. It
provides the date and the time for the system. Normally the life span of a
RTC internal battery is 10 years. This function is built onto the Intel TX
chipset and cannot be field upgraded.
3.4 Speaker Connector Installation
S1572 provides a 4-Pin header to connect the speaker. The speaker is
connected to pins 24-27 of J8.
3.7 Hardware Reset Switch Connector Installation
The RESET switch on your cases' display panel provides users with the
HARDWARE RESET function which is the same as power on/off. The
system will do a cold start after the RESET switch is pushed by the user.
The RESET switch is a 2 pin connector and should be installed on pins
22 and 23 on J8.
3.8 Flash EPROM-Jumper JP2
The S1572 uses flash memory to store BIOS programs. It can be updated
as new versions of the BIOS becomes available. The flash utility will guide
you through the process step by step.
JP2 determines which type of EPROM is used. This jumper has been set
to match the on board BIOS chip. The factory default for the S1572 is on
pins 1-2. Depending on the type of EPROM used, some boards will have
JP2 on pins 2-3.

14S1572-001-01 http://www.tyan.com
Refer to chapter 5 for Flash EPROM upgrade procedures.
3.9 Hardware CMOS & Password Reset
If you have been locked out of your system because you forgot your pass-
word or set the CMOS incorrectly, follow the instructions below.
a. Power off the system
b. Jumper JP1 to pins 2 and 3.
d. Wait for 2 seconds then return the jumper to pins 1 and 2.
e. Power on the system again.
By doing the above procedures, your password will be erased and the CMOS
will be reset to the BIOS default.

15S1572-001-01 http://www.tyan.com
3.10 DRAM Installation
The S1572 uses a 64-bit data path from memory to CPU and can
accommodate up to 256MB of RAM. The mainboard supports Fast Page
Mode, and EDO (Extended Data Out) 72 pin SIMMs.
SDRAM(Synchronous) are also supported in the DIMM slots. DIMM's
must be of the unbuffered variety. All installed memory will be automati-
cally detected so there is no need to set jumpers.
wSIMM modules must be installed in pairs.
wEach pair of SIMMs must be of the same size and type.
wThe mainboard supports 1, 2, 4, 8 and 16MBx32 SIMMs.
wSIMM bank 0, 1 and 2 can use either double or single sided SIMMs.
wTwo SIMMs or One unbuffered DIMM must be installed for the system
to POST.
wSDRAM DIMMs can be installed one at a time.
wThe mainboard supports 1, 2 and 4Mx 64 DIMM modules.
wSIMM bank 0 and DIMM bank 0 cannot be used at the same time.
SIMM bank 1 and DIMM bank 1 cannot be used at the same time.
You can use SIMM bank 0 with DIMM bank 1.
You can use SIMM bank 1 with DIMM bank 0.
wIf you use 4Mx64 DIMMs you cannot use DRAM bank 2.
wWe do not recommend using DRAM bank 2 along with DIMMs.
wThe following table shows some of the available memory configurations.
DRAM
Bank 0 DRAM Bank 1 DRAM Bank 2 SDRAM Bank 0 SDRAM Bank 1 Total
4MB x2 none none none none 8MB
none none none 8MB x1 none 8MB
none none none 16MB x1 none 16MB
8MB x2 none none none none 16MB
4MB x2 4MB x2 4MB x2 none none 24MB
16MB x2 none none none none 32MB
none 8MB x2 none 16MB x1 none 32MB
32MB x2 none none none none 64MB
none none none none 64MB x1 64MB
none none none 32MB x1 64MB x1 96MB
none none none 64MB x1 64MB x1 128MB
64MB x2 none none none 64MB x1 192MB
64MB x2 64MB x2 64MB x2 none none 256MB

16S1572-001-01 http://www.tyan.com
1. Make sure the ZIF socket lever is up. To raise the lever, pull it out
to the side a little and raise it as far as it will go. The top plate will
slide back.
2. Align the CPU and socket Pin 1 corners. The pins on the bottom
should align with the rows of holes in the socket.
3. Insert the CPU in the socket. It should insert easily. If it does
not, adjust the position of the lever a little.
4. Press the lever down. The top plate will slide forward. You will
feel some resistance as the pressure starts to secure the CPU in
the socket. This is normal and will not damage the CPU.
The lever should snap into place at the side of the socket.
3.11 CPU Installation
Several types of CPUs (75 thru 200MHz) can be used on S1572.
Please refer to section 3.2 for the correct CPU jumper settings for your
board.
wThe CPU is a sensitive electronic component and it can be easily
damaged by static electricity. Do not touch the CPU pins with your
fingers.
w When installing the CPU into the socket, match the CPU pins to the
socket pins.
w Before the CPU is installed, the mainboard must be placed on a flat
plane. You should be able to insert the CPU with minimal pressure.
Do not push down hard, use firm pressure.
wA cooling fan and heat sink assembly is required to protect the
CPU from being damaged.

17S1572-001-01 http://www.tyan.com
3.12 Upgrading Cache Memory
The S1572's 512kb of on-board pipelined burst SRAM and cannot be
field upgraded. The TX chipset can cache a maximium of 64MB of
RAM.
3.13 Peripheral Device Installation
After all the jumpers on the mainboard have been set, then it can be mounted
into the case. Proceed to install the display card and any other peripheral
devices.
If a PCI-Bus interface card is to be installed in the system, any one of the
five PCI-Bus slots can support either a Master or a Slave device.
After installing the peripheral controllers, the user should check everything
again, and prepare to power on the system.

18S1572-001-01 http://www.tyan.com
4. BIOS Configuration
Award's BIOS has a built in setup program that allows the user to modify
the basic system configuration. This type of information is stored in the
battery-backed CMOS NVRAM. Entering incorrect information or for-
getting your password can lock you out of your system.(refer to 3.9
for resetting of CMOS)
4.1. Entering Setup
Power ON the computer and press <Del> immediately and you will enter
Setup. The other way to enter setup is to power on the computer, when the
below message appears briefly at the bottom of the screen during the POST
(Power On Self Test), press <Del> key or simultaneously press <Ctrl>,
<Alt>, and <Esc> keys.
* TO ENTER SETUP BEFORE BOOT PRESS CTRL-ALT-
ESC OR DEL KEY
If the message disappears before you respond and you wish to enter Setup,
restart the system by turning it OFF then ON or by pressing "Reset" on the
systemcase. You may also restart by simultaneously pressing <Ctrl>, <Alt>,
and <Del> keys. If you do not press the keys at the correct time, the system
will not boot and an error message will appear on the screen. You will be
asked to;
* PRESS F1 TO CONTINUE, CTRL-ALT-ESC OR DEL TO
ENTER SETUP.
Figure 4.1 will appear on the sceen. The Main Menu allows you to select
from the 8 setup functions and 2 exit choices. Use the arrow keys to select
among the items and press <Enter> to accept or enter each sub-menu.

19S1572-001-01 http://www.tyan.com
4.2. Control Keys
PgUp key Increases the numeric value or make changes
PgDn key Decreases the numeric value or make changes
F1 key General help, only for Status Page Setup menu
and Option Page Setup Menu
F2 key Change color from a total of 16 colors
F3 key Calendar, only for Status Page Setup Menu
F4 key Reserved
F5 key Restore the previous CMOS value, only for Option
Page Setup Menu
F6 key Load defaults
F8 key Reserved
F9 key Reserved
F10 key Save all CMOS changes, only for Main Menu

20S1572-001-01 http://www.tyan.com
4.3. Getting Help
4.3.1. Main Menu
The on-line description of the highlighted setup function is displayed at the
bottom of the screen.
4.3.2. Setup Page menu/Option Page Setup Menu
Press F1 to pop up a small help window that describes the appropriate keys
to use and the possible selections for the highlighted items. To exit the Help
Window, press <Esc>.
4.4.The Main Menu
Once you enter the Award BIOS CMOS Setup Utility, the Main Menu
(Figure 4.1) will appear on the screen. The Main Menu allows you to
select from the eight setup functions and 2 exit choices. Use the arrow
keys to select among the items and press <Enter> to accept or enter the
sub-menu.
Figure 4.1: Main Menu
ROM ISA BIOS (2A59CT51)
CMOS SETUP UTILITY
AWARD SOFTWARE, INC.
ESC : Save & Exit Setup
F10 : Quit (Shift)F2 :Change Color
:Select Item
Time, Date, Hard Disk Type,.....
STANDARD CMOS SETUP INTEGRATED PERIPHERALS
BIOS FEATURES SETUP SUPERVISOR PASSWORD
CHIPSETFEATURESSETUP USERPASSWORD
POWERMANAGEMENT IDE HDD AUTO DETECT
PNP/PCICONFIGURATION SAVEANDEXIT
LOADBIOSDEFAULTS EXITWITHOUTSAVING
