Tyco Fire Protection Products F3200 Instruction sheet

F3200/NDU
AS4428.1
INSTALLATION & CONFIGURATION MANUAL
F3200 PRODUCT MANUAL
Document Number: LT0255
Issue .......... 1.22; 5 July 2016
-- A P P R O V A L S --
AUSTRALIAN STANDARD AS4428.1 - ActivFire Listing Number ..……………..afp789
NEW ZEALAND STANDARD NZS4512 2003.……………………………………...VF/632
AS/NZS CISPR 22 : 2006
AS/NZS 60950-1 : 2015
The F3200 and NDU is manufactured by:
Tyco Fire Protection Products
17 Mary Muller Drive
Christchurch 8022
NEW ZEALAND
Tel: [phone]
Fax: [phone]
COPYRIGHT (C) 2001, 2004, 2009, 2015, 2016
Information contained in this document is subject to copyright, and shall not be reproduced
in any form whatsoever, without the written consent of Tyco Fire Protection Products.
Information contained in this document is believed to be accurate and reliable, however
Tyco Fire Protection Products reserves the right to change the content without prior notice.

F3200/NDU AS4428.1 Installation Manual Document No: LT0255
Page ii 5 July 2016 Issue 1.22
TYCO FIRE PROTECTION PRODUCTS
END USER LIABILITY DISCLAIMER
The VIGILANT F3200 Fire Indicator Panel and NDU have a configuration programming
facility which may be accessed from the keypad by using a password.
This programming facility allows the user to define detail of the operation of the System is
being customised. It is possible for the user to program operational features that prevent the
unit from meeting statutory requirements.
Tyco Fire Protection Products does not accept responsibility for the suitability of the
functions programmed by the user.
CISPR 22 NOTICE
This is a class A product. In a domestic environment this product may cause radio
interference in which case the user may be required to take adequate measures.

Document No: LT0255 F3200/NDU AS4428.1 Installation Manual
Issue 1.22 5 July 2016 Page iii
TABLE OF CONTENTS
End User Liability Disclaimer....................................................................................................ii
Amendments ...........................................................................................................................iv
CHAPTER 1 INTRODUCTION ...............................................................................1-1
1.1 SCOPE...................................................................................................................................1-2
1.2 ASSOCIATED DOCUMENTATION....................................................................................... 1-3
1.3 PRODUCT HISTORY LOG.................................................................................................... 1-4
1.4 GLOSSARY OF ABBREVIATIONS ...................................................................................... 1-5
1.5 GLOSSARY OF TERMINOLOGY......................................................................................... 1-6
CHAPTER 2 SYSTEM DESCRIPTION...................................................................2-1
2.1 OVERVIEW............................................................................................................................2-2
2.2 PHYSICAL STRUCTURE......................................................................................................2-6
2.3 SYSTEM STRUCTURE ......................................................................................................... 2-8
CHAPTER 3 SYSTEM SPECIFICATIONS .............................................................3-1
3.1 GENERAL..............................................................................................................................3-2
3.2 MECHANICAL SPECIFICATIONS........................................................................................3-3
3.3 ELECTRICAL SPECIFICATIONS ......................................................................................... 3-4
3.4 INPUT SPECIFICATIONS ..................................................................................................... 3-8
3.5 OUTPUT SPECIFICATIONS ............................................................................................... 3-16
3.6 CONTROLS .........................................................................................................................3-20
3.7 DISPLAYS ........................................................................................................................... 3-21
3.8 ORDERING INFORMATION................................................................................................ 3-22
CHAPTER 4 CONFIGURING A FIP .......................................................................4-1
4.1 GENERAL..............................................................................................................................4-2
4.2 MODULE CONFIGURATION ................................................................................................ 4-2
4.3 BATTERY & POWER SUPPLY............................................................................................. 4-3
4.4 LINKS ON PCB MODULES .................................................................................................. 4-9
CHAPTER 5 INSTALLATION & WIRING...............................................................5-1
5.1 INSTALLATION.....................................................................................................................5-2
5.2 FIELD WIRING....................................................................................................................... 5-9
5.3 AZC WIRING........................................................................................................................5-11
5.4 MAF ANCILLARY RELAY WIRING....................................................................................5-13
5.5 WARNING SYSTEM WIRING .............................................................................................5-16
5.6 MODULE RELAY WIRING ..................................................................................................5-21
5.7 OPEN COLLECTOR WIRING .............................................................................................5-27
5.8 ASE INSTALLATION AND WIRING ...................................................................................5-29
5.9 RDU WIRING ....................................................................................................................... 5-30
5.10 NDU INSTALLATION AND WIRING................................................................................... 5-32
5.11 NZ MODE INPUTS AND OUTPUTS ................................................................................... 5-33
5.12 INSTALLATION : NZ DISPLAY EXTENDER BOARD & BRIGADE DISPLAYS...............5-35
5.13 NETWORKING ....................................................................................................................5-39
CHAPTER 6 APPLICATIONS ................................................................................6-1
6.1 AS1668 AIR CONDITIONING CONTROL............................................................................. 6-2
6.2 GASEOUS FIRE EXTINGUISHING.....................................................................................6-10
6.3 SUB FIP MONITORING.......................................................................................................6-23
6.4 FIRE DETECTION IN HAZARDOUS AREAS (EXPLOSIVE ATMOSPHERES)................6-25
6.5 USE OF NORMALLY CLOSED CONTACTS ..................................................................... 6-34
6.6 SPECIAL CONNECTIONS TO DETECTORS.....................................................................6-35

F3200/NDU AS4428.1 Installation Manual Document No: LT0255
Page iv 5 July 2016 Issue 1.22
CHAPTER 7 ALIGNMENT, ADJUSTMENT & PLACING INTO OPERATION.......7-1
7.1 ALIGNMENT & ADJUSTMENT.............................................................................................7-2
7.2 PLACING INTO OPERATION............................................................................................... 7-3
7.3 ERROR MESSAGES FOR STARTUP.................................................................................. 7-7
APPENDIX A COMPATIBLE ACTUATING DEVICES (DETECTORS) .......................A-1
AMENDMENTS
ISSUE
DATE
COMMENTS
ECN
1.0
07/02/01
Original. Split from LT0122 and modified for AS4428.1
1.01
02/07/01
Pages 5-20, 6-21, 6-23, 6-25 and Appendices A-1, A-2
revised.
3190
1.02
15/08/01
Chapter 5 Installation revised and Section 6.2 Gas Flood
revised. Added section 5.12, section 3.3.5.2.
3154
1.04
30/06/04
Preface, Pages 5-6, 5-15, 5-16, 5-19, Section 6.2 and
Appendix A revised
3322
1.05
01/03/05
Appendix A –added 614CH, 614I & 614P
3635
1.06
28/10/05
Appendix A –added System Sensor detector 885WP-B
ECS
1181
1.07
24/03/06
Section 5.6.2 and 5.6.3 added.
Appendix A –added 614T heat detector.
3731
1.08
28/03/07
Section 6.1 amended.
1.10
24/07/09
Updated for V5.xx.
3995
1.20
18-Jan-13
MAF relay rating, S231+ connection revised, HF actuator
connection added.
4443
1.21
09/02/15
AZC specification altered for changed transistor.
Added 5.13 for IP Networking.
4564
1.22
05/07/16
Added RCM details. Revised PSU current down from
3A/6A.
4925

Document No: LT0255 F3200/NDU AS4428.1 Installation Manual
Introduction
Issue 1.22 5 July 2016 Page 1-1
CHAPTER 1
INTRODUCTION

F3200/NDU AS4428.1 Installation Manual Document No: LT0255
Introduction
Page 1-2 5 July 2016 Issue 1.22
1.1 SCOPE
This manual provides information for the personnel responsible for planning, ordering,
installing and configuring a VIGILANT F3200 Fire Alarm System or an NDU. It is assumed
that such staff have been trained to plan/install fire alarm equipment and are familiar with the
relevant standards.
The manual is divided into the following chapters:
Chapter 1 Introduction: Information on this and other manuals.
Chapter 2 System Description: A description of the structure of the F3200 FIP.
Chapter 3 Specifications: A detailed specification and list of part numbers for the F3200.
Chapter 4 Configuring a FIP: Information on configuring a system, in particular battery
and charger calculations.
Chapter 5 Installation & Wiring: Detail of installation and field wiring.
Chapter 6 Applications: Detail of configuration and wiring for specific applications.
Chapter 7 Alignment, Adjustment & Placing Into Operation: Detail on how to adjust an
F3200 in the field and place it into operation.
Appendix A 1. Compatible Detectors: A list of detectors which are approved for use
with F3200.
2. Detector Configuration: Detail on AZC and zone configuration for
specific detector types.

Document No: LT0255 F3200/NDU AS4428.1 Installation Manual
Introduction
Issue 1.22 5 July 2016 Page 1-3
1.2 ASSOCIATED DOCUMENTATION
1.2.1 PRODUCT
The following manuals for the AS4428.1-approved F3200 are available:
F3200 AS4428.1 Operator's Manual For panels that comply with AS4428.1
LT0251 is in A4, loose leaf form.
LT0250 is in A5, bound form.
F3200 Technical Manual Provides technical information for system
designers and service staff. Part number
LT0121.
F3200 AS4428.1 Installation & This manual. Provides information for
Configuration Manual personnel responsible for system design,
installation and commissioning. Part number
LT0255.
F3200 AS4428.1 Programming Manual Provides information for programming an F3200
and NDU. Part number LT0256.
1.2.2 STANDARDS RELATED
This manual makes reference to the following Australian and combined Standards:
AS1603.4 Automatic Fire Detection and Alarm Systems (obsolete)
Part 1 - Control and Indicating Equipment.
AS4428.1 Automatic Fire Detection and Alarm Systems
Part 1 - Control and Indicating Equipment.
AS/NZ1668.1 The use of Ventilation and Air-conditioning in Buildings.
Part 1 - Fire and Smoke Control in Multi-compartment Buildings.
AS1670.1 Automatic Fire Detection and Alarm Systems-
System Design, Installation and Commissioning.
AS1851 Maintenance of Fire Protection Equipment
Automatic Fire Detection and Alarm Systems.
AS/NZS 60950.1 Information Technology Equipment –Safety
AS/NZS CISPR22Information Technology Equipment –Radio Disturbance Characteristics
AS4214 Gaseous Fire Extinguishing Systems.
This manual makes reference to the following New Zealand standards.
NZS4512 Automatic Fire Detection and Alarm Systems in Buildings.

F3200/NDU AS4428.1 Installation Manual Document No: LT0255
Introduction
Page 1-4 5 July 2016 Issue 1.22
1.3 PRODUCT HISTORY LOG
1.3.1 HARDWARE
Part No. Description Iss Rev Date Comments
PA0492 8 ZONE MODULE A 1 27/09/93 Original
A 2 24/04/99 C31-38
B 2 Feb 03 Transistor footprint
C 2 Oct 03 C29 moved
D 2 May 09 Logo changed
E 3 March 14 Transistor sub. + EMC
PA0493 8 RELAY MODULE A 1 10/09/93 Original
A 2 22/09/99 C17, C18
B 2 Feb 03 Transistor footprint
C 2 Dec 08 Logo changed
PA0773 RS485 Comms Bd C 4 10/04/01 Component Changes
D 5 May 09 R17, C11
D 6 Aug 10 Added 5V regulator
PA0870/974 Controller/Display A 1 30/01/01 Original
B 2 Nov. 2001 Board changed, now
supports flash
B 3 Oct. 2002 Minor change
B 4 Feb. 2003 Circuit correction
B 5 April 2003 DFM applied
D 6 Jan 09 Logo changed
G 11 Oct 14 Add mem. SMD, EMC
PA0873 MAF/PSU 3A D 9 20/04/01 Original AS4428.1
Version
E 9 April 03 C67, C68 added
E 10 March 07 Q10 was MTP2955
F 10 May 09 Logo changed
J 13 April 14 Relay/FET sub. + EMC
PA0874 MAF/PSU 6A D 9 20/04/01 Original AS4428.1
Version
E 9 April 03 C67, C68 added
E 10 March 07 Q10 was MTP2955
F 10 May 09 Logo changed
J 13 April 14 Relay/FET sub. + EMC
1.3.2 SOFTWARE
Part No. Description Revision Date Comments
SF0221 F3200 AS4428 V3.00 Feb 2001
SF0222 F3200 AS4428 Net V3.00 Feb 2001
SF0224 NDU AS4428 V3.00 Feb 2001
SF0286 F3200/NDU AS4428 V4.00 March 2003 Used in standard F3200,
Networked F3200, and
NDUs that have an Issue
B or higher 1931-111
Controller.

Document No: LT0255 F3200/NDU AS4428.1 Installation Manual
Introduction
Issue 1.22 5 July 2016 Page 1-5
SF0286 F3200/NDU AS4428 V4.04 Dec 2009 Fixes fault buzzer
operation.
SF0423 F3200/NDU AS4428 V5.02 Dec 2010 Adds non-volatile history,
TAP, panel to panel
Tandem mode, support
for 33 display boards
including 2 column, non-
latching AZC type, NDU
operation to NZS 4512:
2003. Fixes network
zone LED operation.
SF0427 F3200/NDU PAL V1.10 July 2009 Supports non-volatile
history.
1.4 GLOSSARY OF ABBREVIATIONS
The following abbreviations are used throughout this manual:
A/C : Air Conditioning
ac : Alternating Current
AEOL : Active End of Line
Ah : Ampere Hour
ANC 1 : Ancillary Relay 1
ASE : Alarm Signalling Equipment
AZC : Alarm Zone Circuit, or Detection Zone
AZF : Alarm Zone Facility, or Group (AS1603.4 terminology)
AVF : Alarm Verification Facility, or Check Alarm
Bd : Board
CIE : Control & Indicating Equipment
Char : Character
Cct : Circuit
COM : COMMON relay contact
dc : Direct current
EB : External Bell
EEPROM : Electrically Erasable Programmable Read Only Memory
ELV : Extra Low Voltage
EOL : End Of Line (device)
EOLR : End of Line Resistor
Expn : Expansion
E2 : Electrically Erasable Programmable Read Only Memory
FF : Fire Fighter Facility (part of Display/Keyboard)
FIP : Fire Indicator Panel
FRC : Flat Ribbon Cable
I/O : Input/Output
LCD : Liquid Crystal Display
LED : Light Emitting Diode
MAF : Master Alarm Facility
Max : Maximum
Min : Minimum
MCP : Manual Call Point (Break Glass Switch)
MOV : Metal Oxide Varistor (Used for electrical Surge Protection)
msec : Millisecond
NC : Normally Closed
NDU : Network Display Unit

F3200/NDU AS4428.1 Installation Manual Document No: LT0255
Introduction
Page 1-6 5 July 2016 Issue 1.22
NO : Normally Open
No : Number
Nom : Nominal
PC : Personal Computer (small computer)
PCB : Printed Circuit Board
PSU : Power Supply Unit
PTC : Positive Temperature Co-efficient (Thermistor)
R1 : Module Relay Number 1 (program abbreviation)
RL1 : Module Relay Number 1 (text abbreviation)
RAD : Return Air Duct (Air Conditioning Plant)
RDU : Remote Display Unit
RMS : Root Mean Square
Reqd : Required
RTC : Real Time Clock
SAD : Supply Air Duct (Air Conditioning Plant)
SID : System Identification Number (Network device)
sq mm : square millimetre
T1 : Programmable Timer Number 1 (program abbreviation)
Tmnl : Terminal
V1 : Programmable Variable Number 1
VA : Volts Amperes
VB : Battery Backed Voltage
VNB : Non Battery Backed Voltage
+VBF : Fused Battery-Backed Voltage
+VNBF : Fused Non-Battery-Backed Voltage
WS : Warning System
Z1 : Zone Number 1 (program abbreviation)
Zn1 : Zone Number 1 (text abbreviation)
8RM : 8 Relay Module
8ZM : 8 Zone Module
1.5 GLOSSARY OF TERMINOLOGY
The following terminology is used throughout this manual:
Ancillary Equipment : Equipment external to Fire Alarm system
Ancillary Relay : Relay to switch external equipment
Auxiliary Output : Output for driving additional LEDs/relays
Baud : Bits per second
Control Output : Output from FIP to other equipment
Default : Pre-programming option or logic equation i.e. one that exists
without the user configuring or programming it.
Detector : Alarm Detection Device (electrical transducer)
In Situ Test : Mode allowing one person to test detectors
Monitoring Service : Fire Brigade Authority, or any other authority which receives
the FIP alarm signals.
Mapping : Programmable causal relationship between inputs and outputs
Zone : Fire searchable area of building represented by a unique
number and name in the FIP, and associated with the AZC of
the same number.

Document No: LT0255 F3200/NDU AS4428.1 Installation Manual
System Description
Issue 1.22 5 July 2016 Page 2-1
CHAPTER 2
SYSTEM DESCRIPTION

F3200/NDU AS4428.1 Installation Manual Document No: LT0255
System Description
Page 2-2 5 July 2016 Issue 1.22
2.1 OVERVIEW
2.1.1 GENERAL
The F3200 is a self-contained, modular, intelligent Fire Indicator Panel (FIP) which performs
the functions of the Control and Indicating Equipment (CIE) as specified by the Australian
Standard AS4428.1.
It has a high degree of flexibility and expandability, catering for medium to very large
buildings from 8 zones or less, to 64 zones maximum. Refer to the constraints specified in
Section 3.1.3. More panels and zones can be added through the use of the Panel-link
Network and the appropriate networkable F3200s.
An NDU (Network Display Unit) is essentially a networked F3200 that doesn’t have any
alarm zone or relay modules, but displays information received from other FIPs on the
network. A number of versions are available. Some in larger cabinets have their own
MAF/PSU and battery, while other slim-line versions have just the Operator Display (and
Controller) and require power from a FIP (or similarly monitored and battery backed source).
An NDU may be programmed to operate in either Australian (default) or New Zealand Mode.
2.1.2 DETECTOR CIRCUITS
The F3200 detector interface electronics caters for a wide range of detectors, including
various types which have high alarm current requirements. A full range of compatible
detectors is listed in Appendix A. F3200 also caters for interfacing to:
Intrinsically safe circuit barriers/isolators (hazardous areas);
Long line circuits e.g. from a sub-indicator FIP;
Tamper-proof circuits e.g. for water valve supervision.
2.1.3 DISPLAYS
The primary display of the F3200 is a 2 line by 40 character LCD on which the status
messages and prompts are shown. The LCD has backlight illumination which is turned on
when there is an alarm or operator interaction. Common conditions are displayed on 9 LEDs
adjacent to the LCD.
The display panel composed of the LCD, common LEDs and keypad is called the Operator
Display panel. The portion within the red border is called the Fire Fighter's Facility (FF). It
includes the common status LEDs for ALARM, ISOLATED and FAULT. As an optional
extra, individual zone status (ALARM, ISOLATE and FAULT) can be displayed on LEDs by
fitting the appropriate number of 16 Zone LED Display boards. By default Zone 1
corresponds to the top row of LEDs (3) on the left most display, Zone 2 to the row below it,
etc, (top to bottom, left to right). Display Bds may also annunciate Relay status. Alarm LED
on = relay energised, Isolated LED on = relay isolated, Fault LED on = relay wiring fault (i.e.
supervision fault). The relay LEDs simply follow the zone LEDs in the same order that they
occur in the FIP. For example, a system with 3 x 8 Zone Modules, 2 x 8 Relay Modules,
would require 3 Display Bds. Relay 1 will be annunciated on the 25th row of LEDs and the
last 8 rows will be unused. Mapping zones and relays to LEDs in other patterns is
programmable.
The F3200 electronics includes, as standard, an open collector transistor output for each
zone which can be used to drive an internal or remote mimic display.
An NDU in New Zealand mode may have an additional 3 system status indicators on the
NZ Display Extender board fitted. This provides the Fire, Defect, Normal LEDs, and also
connects to a Termination Bd which accepts the NZ specific inputs and outputs including the
Trail Evac and Silence Alarms key-switches.

Document No: LT0255 F3200/NDU AS4428.1 Installation Manual
System Description
Issue 1.22 5 July 2016 Page 2-3
FIG 2.1.1
F3200 STANDARD CABINET - FRONT VIEW

F3200/NDU AS4428.1 Installation Manual Document No: LT0255
System Description
Page 2-4 5 July 2016 Issue 1.22
2.1.4 OUTPUTS
The F3200 MAF/PSU Module provides 7 relays as standard. These are used for signalling
to the Brigade (Monitoring Service) and for switching the External Bell, Warning System and
ancillary equipment such as door holders, air-conditioning shutdown, etc.
When more than 7 relays are required, additional sets of 8 can be added by fitting 8 Relay
Modules.
All outputs, including the open collectors on the 8 Zone Modules, are individually
programmable by a logic equation of zone and FIP status. The default configuration (link
setting and programming) dedicates 4 of the 7 relays (Alarm, Isolated, Fault and Standby,
commonly called the MAF relays) to interface to the ASE (Alarm Signalling Equipment), 1
(labelled Anc2) to drive the External Bell (EB), and 1 (labelled Anc3/Bells) to drive the
Warning System (WS). The MAF Standby relay has electronics which forces it to de-
energise at the Battery Very Low voltage, and this must be considered if using if for any
function other than its default one.
2.1.5 POWER SUPPLY
The F3200 has a 3 Amp battery charger/power supply as standard. There is adequate room
for large batteries. Versions are available that have a 6 Amp PSU.
2.1.6 REMOTE DISPLAYS & PRINTER
A serial port (RZDU protocol) is included in the F3200 and NDU that provides a 3 or 4 wire
link to up to 8 Remote Display Units (RDU). Several versions of RDU are available.
The most commonly used versions have small, slimline cabinets (flush and surface
mounting) not much larger than the F3200 display-keyboard which is fitted on them. They
receive power from the F3200 FIP or NDU. Other versions look like an F3200 FIP, have
their own power supply, and may have LED Display Boards fitted to them.
Additional mimic-only devices can be connected to the RDU output to monitor the F3200
zone status. For example, IO-NET can be used to provide floor mimic panels, AS1668
interfaces or remote outputs for evacuation panels.
For a networked system, an RDU can display (and control) only the zones and relays of the
FIP to which the RDU is connected. With appropriate programming, such an RDU could be
used to isolate the Warning System of that FIP, and hence isolate the Warning System
across the entire network.
2.1.7 LOGGING PRINTER
A serial printer may be connected to the F3200 or NDU to provide a log of events and
operator actions, and also to print the programmed database.
Events which are printed include:
(i) Zone Events, e.g. Alarm, Fault;
(ii) Zone Commands, e.g. Reset, Isolate;
(iii) System events, e.g. communication failures, battery faults, etc.
The printout includes the time and date, the cause of the event (e.g. Zone, Relay, RDU or
FIP), and the event type. Events and commands for zones and relays that have a text name
programmed also have the name printed. F3200 is able to store at least 100 events for
printing, being the first 100 events to occur.
As events are printed, more events are able to be put into the list. If events cannot be put
into the list because it is full, the FIP keeps a count of those events it has had to discard.

Document No: LT0255 F3200/NDU AS4428.1 Installation Manual
System Description
Issue 1.22 5 July 2016 Page 2-5
LOGGING PRINTER (CONTINUED)
When the FIP is next able to put more events into the list, it prints out the number of events it
had to discard.
For a networked system, with appropriate programming, an F3200 panel (or NDU) may print
events and accumulate history for some or all of the other panels on the network.
2.1.8 NETWORKING CAPABILITIES
A number of F3200 fire panels, NDUs and other Panel-link compatible devices may be
connected together to form a large distributed system. With suitable programming events
may be annunciated at, and controlled from, other panels on the network. A panel (or NDU)
may be set up as a main panel to provide a common monitoring service connection point
with display and control of all facilities on the network.
The F3200 can be networked in a variety of ways:
- Dual channel RS485 links using the FP0795 kit.
- Ring RS485 using the FP0771 I-HUB.
- IP over fibre-optic cable using the FP0986 PIB and Moxa Ethernet switches, or over
copper wire pairs by adding 2 x Westermo Ethernet Extenders per cable pair.
The F3200 system supports the addition of colour graphics display and control terminals on
the network. These units can be programmed to show graphical displays on zone alarm or
fault conditions. The operator can use function keys or an optional touch screen to generate
commands to the F3200 and thus have remote control of it.
2.1.9 GASEOUS FIRE EXTINGUISHING PANELS
A range of F3200 panels are available specially assembled and programmed for gaseous
fire extinguishing applications complying with AS4214.

F3200/NDU AS4428.1 Installation Manual Document No: LT0255
System Description
Page 2-6 5 July 2016 Issue 1.22
2.2 PHYSICAL STRUCTURE
The F3200 has a rugged, lockable painted steel cabinet, which houses 19 inch rack-mount
equipment and comes in two height options (both have the same width and depth). The
standard cabinet accommodates 15U total and the small cabinet accommodates 8U (where
1U = 1 3/4" = 44.5mm).
The Operator Display has a screened, polyester overlay mounted on a hinged inner door
fitted to the top 4U position. The Controller/Display pcb mounts directly to the rear of this
door.
Standard Cabinet
In the standard cabinet the space below the 4U Operator Display panel is covered by a
blanking plate, but there is provision for mounting other equipment (e.g. a 7U hinged inner
door for a mimic, or 16 Zone LED Display Bds), in place of this blanking plate.
There is provision for mounting additional equipment in the bottom 4U (e.g. an ASE rack),
but this might encroach on battery space.
The outer door has a large acrylic window to allow viewing of the equipment inside.
Four versions of FIP are available in this cabinet. The FP0781 and FP0783, which cater for
up to 64 zones, have a Cardframe fitted to the rear wall as shown in Fig 2.2.1. The FP0780
and FP0782 have provision (PCB stand-offs) for mounting up to three 8 way modules (i.e. 3
x 8 Zone or 8 Relay Modules) on the rear wall. All of these panels are supplied with one 8
Zone Module fitted.
Small Cabinet
In the small cabinet, only 1U (of the 4U) below the 4U Operator Display is visible through the
outer window. The gap is covered by a blanking plate (2U), which can be replaced by a
bracket for mounting a limited range of equipment, e.g., a 1U ASE bracket, or a 1U 1 Zone
Gas Control Panel.
A 6A PSU or a 7U LED Display door cannot be fitted, but the 4U 80 zone door (ME0457)
can be (note reduces battery space).
Up to four 8 way modules can be mounted on the rear wall, but the bottom two of these
share space with the batteries. Mounting arrangement and maximum capacity are shown in
Fig 2.2.2.
Only one FIP is available (FP0784), and this comes with one 8 Zone Module fitted (in the top
left position).

Document No: LT0255 F3200/NDU AS4428.1 Installation Manual
System Description
Issue 1.22 5 July 2016 Page 2-7
FIG 2.2.1
F3200 STANDARD CABINET WITH CARDFRAME - INTERNAL LAYOUT
FIG 2.2.2
F3200 SMALL CABINET, MAXIMUM CONFIGURATION
FP0781 and FP0783 have the Cardframe as shown.
FP0780 and FP0782 have the modules on the rear wall (3 max).

F3200/NDU AS4428.1 Installation Manual Document No: LT0255
System Description
Page 2-8 5 July 2016 Issue 1.22
2.3 SYSTEM STRUCTURE
2.3.1 PCB MODULES
The printed circuit boards which may be used in an F3200 include:
Controller/Display
Mounts on 4U inner door.
Includes: LCD, status LEDs, buzzer, and keypad connection
5Vdc supply voltage monitors for battery charger
microprocessor & memory
serial I/O bus control for all other modules
reference voltage generation for I/O modules
UARTs and serial port electronics
real time clock calendar integrated circuit
FRC connection to other modules.
MAF/PSU
Mounts on cabinet rear wall.
Includes: battery charger/PSU
22V regulator for detector circuits
Brigade & Ancillary relays and supervision circuitry
MCP & door switch inputs
screw terminals (most demountable) for field wiring
FRC connection to other modules.
8 Zone Module
Mounts on cabinet rear or in Cardframe.
Includes: electronics to I/F to 8 Alarm Zone Circuits (AZCs)
8 open collector auxiliary outputs
demountable screw terminals for field wiring
FRC connection to other modules.
8 Relay Module
Mounts on cabinet rear or in Cardframe.
Includes: 8 relays and supervision circuitry; demountable screw terminals for field
wiring; FRC connection to other modules.
16 Zone LED Display (FP0475)
Mounts on 7U inner door (ME0060).
Includes: 16 sets of 3 LEDs; electronics to control the LEDs (serial bus).
16 Zone LED Display (FP1002)
Mounts on 4U door (ME0457).
Includes: 16 sets of 2 LEDs, red = alarm, amber = fault (flashing), isolated (steady).
RS485 Communications Bd
Mounts on right hand side of cabinet.
Includes: Connecting FRC and mounting parts.
I-HUB Communications Bd
Mounts on right hand side of cabinet.
Includes: Connecting FRC and mounting parts.
PIB Panel-Link to IP Bridge Communications Bd
Typically mounts on bracket on right hand side of cabinet.
Includes: Mounting hardware and panel connection cables.

Document No: LT0255 F3200/NDU AS4428.1 Installation Manual
System Description
Issue 1.22 5 July 2016 Page 2-9
FIG 2.3.1
SYSTEM STRUCTURE

F3200/NDU AS4428.1 Installation Manual Document No: LT0255
System Description
Page 2-10 5 July 2016 Issue 1.22
2.3.2 INTER-CONNECTION & STRUCTURE
A basic F3200 system has one Controller/Display, one MAF/PSU, and one 8 Zone Module,
all connected by Flat Ribbon Cable (FRC) on a common Input/Output (I/O) Bus.
Additional 8 Zone Modules and/or 8 Relay Modules can be fitted to the I/O bus, with a
maximum of eight 8 way modules. This is shown in the block diagram of Fig 2.3.1.
The physical maximums are:
three 8 way modules in an FP0780 or FP0782.
four 8 way modules in an FP0784 (with restrictions)
eight 8 way modules in an FP0781 or FP0783.
Expansion is from top to bottom.
The I/O Bus Out of one module connects to the I/O Bus In of the next module via the 20 way
FRC provided (LM0053). No link or "End of Bus" is required on the last module.
To further extend these capabilities, up to 64 F3200s may be networked together, with full
sharing of information and remote control of each panel by a master panel.
16 Zone LED Display Bds are driven from a separate serial bus on the Controller/Display.
They receive power from the MAF/PSU via two power leads. Where more than one is
required they are connected in series (up to 4 maximum) from right to left (as viewed from
the front) on the FIP. The 26 way FRC from J13 of the Controller goes to J1 ("From
Previous") of the right hand Display Bd. Zone 1 (default) corresponds to the top LEDs on
the left hand Display Bd. The last board requires the "end of bus" Minijump connector to be
fitted. Note that a special FRC cable is required to connect the Controller Board to the first
Display Board (LM0092).
Where LED Display Bds are fitted, the default programming requires one Display Bd (16
zones) for every two 8 Zone or 8 Relay Modules, i.e. one for 1-16 zones, two for 17-32
zones, etc.
Zone 1 corresponds to the top row of LEDs on the left most Display; Zone 2 to the row below
it, etc., (top to bottom, left to right).
LED Display Bds may also annunciate relay status, i.e. Alarm = relay energised, Isolated =
relay isolated, Fault = relay wiring fault (i.e. supervision fault). The relay LEDs simply follow
the zone LEDs in the same order that they occur in the modules. E.g. a system with three 8
Zone Modules and two 8 Relay Modules would require 3 Display Bds. Relay 1 would be
annunciated on the 25th row of LEDs and the last 8 rows would be unused.
Mapping zones and relays to LEDs in other patterns is programmable.
