AUTOPULSE Z-20 Agent Releasing Panel Operator’s Manual (579-1165AR)
Introduction
The AUTOPULSE Z-20 Agent Releasing Panel* 4007-9201AR user interface is touchscreen based. The various
functions of the panel are access-level protected, this restricts access to sensitive features to appropriate personnel only.
The 4606-9202AR is a Color Touchscreen LCD Annunciator for the AUTOPULSE Z-20. It provides remote annunciation
of the AUTOPULSE Z-20 status. Access to Annunciator switch functions can be enabled or locked using the keyswitch. A
maximum of six color touchscreen annunciators can be installed on a AUTOPULSE Z-20 panel. Refer to the
Programmers’ Manual, 579-1167AR, for more information on how to enable/disable the operations on the Color
Touchscreen LCD Annunciator.
*The AUTOPULSE Z-20 Agent Releasing Panel will be referred as the AUTOPULSE Z-20 in this document.
In this
publication
Reference
Documents
579-1102AR: AUTOPULSE Z-20 Agent Releasing Panel Installation Manual
579-1167AR: AUTOPULSE Z-20 Agent Releasing Panel Programmer’s Manual
579-1110AR: AUTOPULSE Z-20 Service Parts List
579-1172AR: AUTOPULSE Z-20 Color Touchscreen LCD Annunciator Installation Manual
User Interface ............................................... 4 Panel Setup ................................................................18
Alarm Conditions ........................................... 5 Alarm Log ...................................................................20
Supervisory and Trouble Conditions ........... 10 Trouble Log ................................................................ 21
Main Menu .................................................. 13 Search ........................................................................22
User Access Level ...................................... 14 Diagnostics .................................................................23
System Info ................................................. 16 Report Menu ...............................................................27
Index..............................................................30

4
AUTOPULSE Z-20 Agent Releasing Panel Operator’s Manual (579-1165AR)
User Interface
Overview:
The user interface is used to operate the AUTOPULSE Z-20.
Figure 1. AUTOPULSE Z-20 User Interface
Figure 2. Color Touchscreen LCD Annunciator User Interface
Table 1. The AUTOPULSE Z-20 User Interface is made-up of the following components:
Touchscreen Used as the panel’s input/output interface.
Piezo Emits tones during Alarm, Trouble, Pri2 and Supervisory conditions.
Bi-color User-
Defined LEDs
Associated with the three custom-configured user buttons. The top two LEDs can be either
yellow or red. The bottom LED can be either yellow or green.
Slide-in Labels Used to describe the functions of the user buttons.
Fire LED Indicates a fire alarm when flashing and an acknowledged alarm when steady on.
Priority 2 LED Indicates a Priority 2 condition when flashing and an acknowledged condition when steady on.
Supervisory LED
Indicates a Supervisory condition when flashing and an acknowledged condition when steady on.
Trouble LED Indicates a Trouble state when flashing and acknowledged Trouble when steady on.
Alarm Silence LED Indicates an alarm has been silenced when steady on.
Power LED Indicates AC power is applied to the panel when steady on.
Keyswitch (Only on the Color Touchscreen LCD Annunciator) Allows interaction with the panel if the key is
used.
Touchscreen
Piezo Bi-Color User Defined LEDs Slide-in Labels
Fire LED
Priority 2 LED
Supervisory LED
Power LED
Alarm Silenced LED
Trouble LED
Supervisory LED
Priority 2 LED Alarm Silenced LED
Fire LED
Keyswitch
Trouble LED
Power LED
Slide-in Labels
Piezo Touchscreen Bi-Color User
Defined LEDs
User Interface

5
AUTOPULSE Z-20 Agent Releasing Panel Operator’s Manual (579-1165AR)
Alarm Conditions
Overview:
An alarm condition occurs when an initiating device (such as a manual pull station, smoke
detector, etc.) activates. The panel indicates the presence of the alarm condition by:
• Displaying messages on the user interface.
• Flashing the Fire or PRI2 LEDs.
• Activating the hazard area’s notification appliances (horns and strobes).
Screen Buttons:
Scroll Up Scroll Down Return Accept Decline
Recognizing an Alarm
Condition:
When an alarm condition occurs, the following events occur at the user interface:
Fire PRI2
1. The Fire LED begins to blink.
2. The piezo begins to sound a pulsating tone.
3. The user interface displays the Fire Alarm
in System screen, which shows the list of
all the triggered alarms.
1. The PRI2 LED begins to blink.
2. The piezo begins to sound a pulsating tone.
3. The user interface displays the PRI2 Alarm in
System screen, which shows the list of all the
triggered alarms.
Note: A zone groups multiple points together, and the Zone Fire and Zone PRI2 Alarms lists display all the
zones where alarm conditions occurred. You can view the points that triggered the alarms within each
zone by pressing on any given zone from the list.
Figure 3. Alarm Condition Screen (Fire Alarm Shown as an Example)
Tap anywhere on the user interface touchscreen to silence the piezo. Until the alarm conditions are
acknowledged, it will re-sound after 1 minute of inactivity at the user interface.
Piezo is emitting a pulsating tone A list of alarms is displayed
Fire Alarm in System Date
Time
First of 1 Date
PULL STATION 1
FIRE ALARM
ACK
1Alarm Functions Menu
The Fire LED is blinking
The number displayed represents the number of alarms
Alarm Conditions

6
AUTOPULSE Z-20 Agent Releasing Panel Operator’s Manual (579-1165AR)
Processing Alarms: There are three actions that may be taken when an alarm condition occurs:
1. Acknowledge an Alarm
2. Silence the Alarm
3. Reset the System
Each step is explained in detail in the rest of this section.
Acknowledge an Alarm: Two types of acknowledging modes can be configured on the panel:
1. Global Acknowledge
All the zones inside the Zone Alarm list are acknowledged at the same time.
2. Individual Acknowledge
Each zone inside the Zone Alarm list is acknowledged separately.
Global Acknowledge
Tap ACK.
Note: Acknowledging an alarm does not silence the horns. You need to silence an alarm as shown in the section Silence the Alarm.
Individual Acknowledge
Tap the unacknowledged alarm from the Zone Alarm List.
Note: The unacknowledged alarms display Press to acknowledge on the top right of the button.
Fire Alarm in System Date
Time
First of 1 Date
PULL STATION 1
FIRE ALARM
ACK
1Alarm Functions Menu
Fire Alarm in System Date
Time
First of 1 Date
PULL STATION 1
FIRE ALARM
ACK
1Alarm Functions Menu
Alarm Conditions, Continued

7
AUTOPULSE Z-20 Agent Releasing Panel Operator’s Manual (579-1165AR)
Silence the Alarm: Silencing an alarm turns off all the audible notification appliances that are programmed
to turn off when it is pressed.
1. Tap Alarm Functions.
2. Press Alarm Silence.
3. Confirm
WARNING: Ensure the evacuation of the building is completed prior to silencing the alarm.
Fire Alarm in System Date
Time
First of 1 Date
PULL STATION 1
FIRE ALARM
ACK
1Alarm Functions Menu
Fire Alarm in System
System Reset
USER
BUTTON 1
USER
BUTTON 2
USER
BUTTON 3
Alarm Silence
Are you sure?
Alarm Conditions, Continued

8
AUTOPULSE Z-20 Agent Releasing Panel Operator’s Manual (579-1165AR)
Reset the System: Resetting the system allows it to return to a normal state after alarm activation.
IMPORTANT: Reset the system only after the source of the alarm is determined
and dealt with.
1, Tap Alarm Functions.
2. Tap System Reset.
3. Confirm.
Notes: 1. If a zone or device has reset successfully, the user interface returns to its normal display.
2. If a zone or device remains in alarm when you reset the system, the system reset terminates. A message confirming the
abort appears on the user interface.
Fire Alarm in System
Date
Time
First of 1 Date
PULL STATION 1
FIRE ALARM
ACK
1Alarm Functions Menu
Fire Alarm in System
System Reset
USER
BUTTON 1
USER
BUTTON 2
USER
BUTTON 3
Alarm Silence
Are you sure?
Alarm Conditions, Continued

9
AUTOPULSE Z-20 Agent Releasing Panel Operator’s Manual (579-1165AR)
Viewing the Alarm Condition
Details:
Each alarm condition contains detailed information on the point (or points) that have
triggered it. To access that info:
1. Tap a desired alarm condition from the Fire Alarm in System screen. The alarm condition can either be a point or a
zone containing a variety of points. A point in alarm is shown as an example.
2. Take the necessary actions, using the buttons available at the point details screen. A pull station point is shown as an
example.
Fire Alarm in System Date
Time
First of 1 Date
PULL STATION 1
FIRE ALARM
ACK
1Alarm Functions Menu
M1-1-0
PULL STATION 1
Date
Time
Enable
Disable
M1-1
M1-1 PULL STATION
DEVICE ADDRESS: 2-1 TYPE: ADRPUL
IDNET2 CARD
UNIT NUMBER: 0 RUI NUMBER: LOCAL
---------------------------------------------------------------------
PRIMARY STATUS FIRE ALARM
CURRENT DEVICE CORRECT DEVICE
DEVICE ON-LINE
PHYSICAL STATE ABNORMAL
RAW STATE ABNORMAL
ACTIVE STATE OFF
ARMED STATE ARMED
ENABLED STATE ENABLED
Alarm Conditions, Continued

10
AUTOPULSE Z-20 Agent Releasing Panel Operator’s Manual (579-1165AR)
Supervisory and Trouble
Conditions Overview:
A Supervisory condition indicates a problem with the building’s automatic sprinkler system or
some other system used for the protection of life and property.
A Trouble condition indicates the presence of a circuit break, or a ground, within a system
point, or somewhere between the AUTOPULSE Z-20 and one of its points. It can also be used
to indicate a failure in the system that requires attention.
The panel indicates the presence of a Supervisory, or Trouble condition by:
• Displaying messages on the user interface
• Flashing the Supervisory or Trouble LEDs
Screen Buttons:
Scroll Up Scroll Down Return Accept Decline
Recognizing a Supervisory
and a Trouble Condition:
When an Supervisory or a Trouble event occurs, the following events occur at the user
interface
Supervisory Trouble
1. The Supervisory LED begins to blink.
2. The piezo begins to sound a continuous
tone.
3. The user interface displays the
Supervisory in System screen, which
shows the list of all the Supervisory
conditions.
1. The Trouble LED begins to blink.
2. The piezo begins to sound a continuous tone.
3. The user interface displays the Trouble in
System screen, which shows the list of all the
Troubles.
Figure 3. Supervisory or Trouble Condition Screen (Trouble Conditions Shown as an Example)
Tap anywhere on the user interface touchscreen to silence the piezo. Until the trouble and supervisory
conditions are acknowledged, the piezo re-sounds after 1 minute of inactivity at the user interface.
Piezo is emitting a continuous tone The list of Troubles is displayed
The Trouble LED is blinking
The number displayed represents the number of Troubles and Supervisory conditions
Trouble in System Date
Time
Most Recent of 5
SYSTEM TIME/DATE INVALID OR NOT SET
ABNORMAL
ACK
5Alarm Functions Menu
First of 5 Date
CARD 1, NAC POWER SUPPLY
NAC MISWIRE TROUBLE
Supervisory and Trouble Conditions

11
AUTOPULSE Z-20 Agent Releasing Panel Operator’s Manual (579-1165AR)
Processing Supervisory and
Trouble Conditions:
When a Supervisory or a Trouble event occurs, it needs to be acknowledged and the
cause of the event resolved for the system to return to normal. Two types of
acknowledging modes can be configured on the panel.
1. Global Acknowledge
All the zones inside the Zone Supervisory or Zone Trouble lists are acknowledged at
the same time.
2. Individual Acknowledge
Each zone inside the Zone Alarm List is acknowledged separately.
Note: A zone groups multiple points together and the Zone Supervisory or Zone Trouble list
displays all the zones where Trouble or Supervisory conditions occurred.
Global Acknowledge
Tap ACK.
Individual Acknowledge
Tap the unacknowledged Trouble from the events list.
Note: The Troubles that have not been acknowledged display Press to acknowledge on the top right of the button.
Fire Alarm in System Date
Time
First of 1 Date
PULL STATION 1
FIRE ALARM
ACK
1Alarm Functions Menu
Trouble in System
Date
Time
Most Recent of 5 Press to acknowledge
SYSTEM TIME/DATE INVALID OR NOT SET
ABNORMAL
ACK
5Alarm Functions Menu
First of 5 Press to acknowledge
CARD 1, NAC POWER SUPPLY
NAC MISWIRE TROUBLE
Supervisory and Trouble Conditions, Continued

12
AUTOPULSE Z-20 Agent Releasing Panel Operator’s Manual (579-1165AR)
Viewing the Supervisory and
Trouble Conditions Details:
Each Supervisory or Trouble condition contains detailed information on the point, or
points, that have triggered it. To access that info, complete the following steps (Trouble
screen is shown as an example):
1. Tap a desired Trouble condition from the Trouble in System screen. The Trouble condition can either be a point or a
zone containing a variety of points. A point in Trouble state is shown as an example.
2. Take the necessary actions, using the buttons available at the point details screen. A Time and Date Trouble is used
as an example.
Fire Alarm in System Date
Time
First of 1 Date
PULL STATION 1
FIRE ALARM
ACK
1Alarm Functions Menu
P58
SYSTEM TIME/DATE WAS NOT SET
Date
Time
On
Off
Time /Date
Trouble Details
Auto
Supervisory and Trouble Conditions, Continued

13
AUTOPULSE Z-20 Agent Releasing Panel Operator’s Manual (579-1165AR)
Main Menu
Overview:
The Main Menu screen displays the functions available at the panel
To access these functions:
• Tap anywhere on the touchscreen to remove the screensaver image.
• Tap Menu on the user interface if the user interface is in use.
Screen Buttons:
User Button 1* User Button 2* User Button 3* Return Button
* User Buttons can be assigned to custom panel functions. Each function can be assigned to a
task, such as Manual evacuation or City Disconnect. User buttons that have not been assigned a
function do not appear on the user interface.
Figure 4. Main Menu Screen
Main Menu Icons Description Page
System Info Use the System Info function to obtain detailed information regarding the panel and its
components. 16
Panel Setup Use the Panel Setup function to modify the configuration of the basic components. 18
Alarm Log The Alarm Log contains the list of alarms that the panel has received. 20
Trouble Log The Trouble Log contains the list of Troubles that the panel has received. 21
Search Use the Search screen to look for any configured point on the system controlled by the
panel. 22
System Reset Tap System Reset to reset all devices in alarm and clear all acknowledged Alarms,
Troubles, and Supervisory conditions. 8
Hardware Reset
Tap Hardware Reset to re-initialize the state of certain hardware components. A
hardware reset is typically used to reset Class A Troubles after the problem causing the
Trouble is resolved.
22
Diagnostics Use Diagnostics function to run tests on the panel and the connected devices. 23
User Access Level Tap User Access Level to access the login screen. From this screen, the user can log
into the panel with a desired access level, or log out of the access level that he is
currently in.
14
Lamp Test
Tap Lamp Test to light all 9 LEDs on the front panel for 5 seconds. The three dual-
colored LEDs blink alternately. The touch screen alternates between red, green and
blue.
13
Report Menu Tap Report Menu to generate various types of reports on the system points. 27
USER
BUTTON 1
USER
BUTTON 2
USER
BUTTON 3
Main Menu
System Info Panel Setup Alarm Log Trouble Log USER
BUTTON 1
USER
BUTTON 2
USER
BUTTON 3
Search System Reset Hardware
Reset Diagnostics
User Access
Level Lamp Test Report Menu
Date
Time
Main Menu

14
AUTOPULSE Z-20 Agent Releasing Panel Operator’s Manual (579-1165AR)
User Access Level
Overview:
Tap User Access Level to access the login screen, where the user can log in to the
panel with a desired access level, or log out of the current access level.
Notes: 1. Four access levels can be used to log in to the panel, with the lowest, User Access
Level 1, being the default.
2. Only some functions are available at each access level. The User Access Level Chart
(Figure 6) shows functions with associated default user access levels.
3. The AUTOPULSE Panel Programmer can be used to modify default user access
levels for each function, or set user access level passcodes. Refer to document
579-1167AR: AUTOPULSE Z-20 Agent Releasing Panel Programmer’s Manual for
more details.
The following values are the default passcodes for each level:
Level 1 = 111
Level 2 = 222
Level 3 = 333
Level 4 = 444
Screen Buttons:
Erase Accept Return
Figure 5. User Access Level Screen
User Access Level
Current Access Level: 1
Enter Passcode
Logout
1ABC
2
DEF
3
JKL
5
TUV
8
WXYZ
9
0
GHI
4
MNO
6
PQRS
7
Date
Time
Logout:
Tap Log Out to log out of the current user access level. When logged out, the user is returned to
Access Level 1.
Continued on next page
Logout
User Access Level

15
AUTOPULSE Z-20 Agent Releasing Panel Operator’s Manual (579-1165AR)
Figure 6. User Access Level Chart
System Info
1
Panel Setup
2
Alarm Log
1
Trouble Log
1
Search
1
System Reset
1
Hardware Reset
2
Diagnostics
2
User Access
Level
1
Lamp Test
1
Report Menu
1
User Buttons 1,2 3
***
Main Menu
1
Card
Revisions
1
Software
Revisions
1
Panel Serial
Number
1
Card Status
1
Swap Config
2
Set Time/Date
2
Touchscreen
Calibration
2
Mass Storage
1
HW Reset
2
Restart
4
Walktest
3
Cfig Download
3
Earth Fault Search
3
Earth Fault Latch
2
NAC Miswire Test
3
Duplicate Device Search
3
Weak Answer Search
3
Install Mode
2AlarmLog
1
TroubleLog
1
TrueAlarm
Status
1
TrueAlarm
Service
1
TrueAlarm CO
1
Active List
1
Verification Tally
1
Main Menu
1
Function Name
Default Access Level
Show Alternate
Config Version
2
Use Alternate
Config
2
Location
3
IDNet
3
Last Result
3
IViewMod
2
IAddMiss
3
IAddOpens
3
IRemvNorm
3
IRemvAll
3
Log Menu
1
*** = Default Access Level Configured with the ES Panel Programmer
Clear
3
Clear
3
Select Item
1
Calibrate
2
Clear
2
Next Group
3
Prev Group
3
Select Item
3
Enable
3
Enable All
3
Disable
3
Revert
3
Off
3
On
3
ViewRaw
2
All
3
Single
3
Off
3
On
3
Off
3
On
3
PrtInstal
1
System
Upgrade
1
Job
Backup
1
Save
Reports
1
Upgrade
Status
1
SnapShot
Recovery
1
Eject USB
1
Piezo Silence
3
Off
3
On
3
User Access Level, Continued

16
AUTOPULSE Z-20 Agent Releasing Panel Operator’s Manual (579-1165AR)
System Info
Overview:
Use the System Info function to obtain detailed information regarding the panel and its
components. Tap a menu icon to access that option’s main screen. Refer to Figure 6 for
access levels required to use each option inside the System Info screen.
Screen Buttons:
Scroll Up Scroll down Accept Return
Figure 7. System Info Screen
System Info
Card
Revisions
Software
Revisions
Panel Serial
Number
Card
Status
USER
BUTTON 1
USER
BUTTON 2
USER
BUTTON 3
Date
Time
System
Files Info IP Info
Card Revisions:
Tap Card Revisions to see a list of all the cards (modules) installed in the panel.
Software Revisions:
Tap Software Revisions to see the latest master revisions loaded on the panel.
Panel Serial Number:
Tap Serial Number to see the serial number of the panel.
Card Status:
Tap Card Status to see the status of the different cards installed in the panel.
Continued on next page
Card Revision
Information
Appears Here
Card Revisions Date
Time
Software Revision
Information
Appears Here
Software Revisions Date
Time
Serial Number
Appears Here
Panel Serial Number Date
Time
Card Status
Appears Here
Select Card for Status Date
Time
System Info

17
AUTOPULSE Z-20 Agent Releasing Panel Operator’s Manual (579-1165AR)
System Files Info:
Tap System Files Info to see the latest master revisions loaded on the
Remote Annunciator.
IP Info:
Tap IP Info to see the IP and the MAC address of the AUTOPULSE Z-20
panel.
BOOTLOADER REV: 1.01.00.03
KERNEL REV: 1.01.00.10
FILESYSTEM REV: 1.01.01.15
PANELUI: 1.01.02.16
System Files Info Date
Time
IP ADDRESS: 192.168.1.150
HARDWARE ADDRESS:
00:08:bd:01:dc:43
IP Info Date
Time
System Info, Continued

18
AUTOPULSE Z-20 Agent Releasing Panel Operator’s Manual (579-1165AR)
Panel Setup Overview: Use the Panel Setup function to modify the configuration of the basic panel components.
Tap on a menu icon to access that option’s main screen. Refer to Figure 6 for access levels
required to use each option inside the Panel Setup screen.
Screen Buttons:
Scroll Up Scroll down Accept Return
Figure 8. Panel Setup Screen
Panel Setup
Swap Config Set Time/Date Touchscreen
Calibration
Mass
Storage
USER
BUTTON 1
USER
BUTTON 2
USER
BUTTON 3
Date
Time
Swap Config:
Tap Swap Config to access the functions below. These functions allow
roll back to the previous versions of the panel firmware.
• Tap Show Alternate Config Version to display the previous
version of the panel firmware.
• Tap Use Alternate Config Version to install the previous version
of the panel firmware.
Set Time/Date:
Tap Set Time/Date to access the screen where the date and time
displayed at the panel can be updated:
1. Tap the button that corresponds to either day, month, year, hour,
minute or second.
2. Enter a new value using the touchscreen keypad.
3. Repeat steps 1 and 2 for the date and time values that remain.
4. Tap Accept for the new date and time to take effect immediately.
Touchscreen Calibration:
Tap Touchscreen Calibration to access the calibration screen and
adjust the sensitivity of the user interface touchscreen. Follow these
steps to adjust:
1. Increase or decrease the touchscreen sensitivity by using the Scroll
Up and Scroll Down buttons.
2. Tap Calibrate and then tap the +signs that appear to adjust the
precision of the touchscreen pressure sensors.
3. Return to the System Menu screen.
Continued on next page
Swap Config
Show Alternate
Config Version
Use Alternate
Config
USER
BUTTON 1
USER
BUTTON 2
USER
BUTTON 3
Date
Time
Day Month Year
Hrs Mins Sec
::
123
456
789
0
Panel Setup
0101 01
01 01 01
Date
Time
Calibrate
Clear
Sensitivity
3x
Panel Setup
Date
Time
Panel Setup

19
AUTOPULSE Z-20 Agent Releasing Panel Operator’s Manual (579-1165AR)
Mass Storage:
Tap Mass Storage to access the functions listed below. The USB key
must be inserted in the USB Port slot of the AUTOPULSE Z-20 CPU
Card for the Mass Storage button to work.
• Tap Job Backup to save the job currently loaded on the panel to
the USB key.
• Tap Save Reports:to save reports to the USB key.
• Tap Upgrade Status to see the progress of the software
upgrades.
• Tap SnapShot Recovery before doing a system upgrade to copy
the software types currently loaded on the panel to the USB key.
To upload these software types back on the panel, re-insert the
USB key in the USB Port of the AUTOPULSE Z-20 CPU Card and
tap SnapShot Recovery.
• Eject USB: Tap this button to safely remove the USB from the
panel.
With a USB thumb drive inserted, tap System Upgrade to open the
System Upgrade screen which contains a list of all the panel software
types and their current revisions. The software type in bold and colored
green indicates that a more recent version can be loaded on the panel.
Note: The System Upgrade screen is launched by default when the USB key is
inserted in the USB Port of the AUTOPULSE Z-20 CPU Card.
• Tap Select All to select all of the software types listed in the table.
• Tap Change Job to load a new job on the panel.
• Tap Refresh Reset to refresh the software type list.
• Tap Process Upgrade to proceed with the change.
System
Upgrade
Mass Storage
Job
Backup
Save
Reports
Upgrade
Status
SnapShot
Recovery Eject USB
Select
All
System Upgrade
Change
Job
Refresh
Reset
Process
Upgrade 0 of 10 files selected
CARD SOFTWARE TYPE REVISION
0
0
0
0
0
4007H1LN
Main App
Bootloader
Kernel
Filesystem
1
302.03.02.02
1.00.00.14
1.00.00.11
1.00.00.20
Panel Setup, Continued

20
AUTOPULSE Z-20 Agent Releasing Panel Operator’s Manual (579-1165AR)
Alarm Log Overview: The Alarm Log screen contains a list of alarms that the panel has received. Refer to Figure
6 for access levels required for each option inside the Alarm Log screen.
Screen Buttons:
Scroll Up Scroll down Return
Figure 9. Alarm Log Screen
FIRE ALARM IN SYSTEM
Menu
Date
Time
First of 1 M1-30-0 Date Time
M1-30-0
PULL STATION FIRE ALARM
Alarm
Functions
ACK
1
Clear:
IMPORTANT: Use the Clear button only after the alarms have been
investigated.
Ta p Clear to erase all entries in the Alarm Logs screen.
Clear
Alarm Log
