Series DS-1 – 5.6 K-factor, Dry-type Sprinklers
Pendent, Upright, and Horizontal Sidewall
Standard Response, Standard Coverage
General
Description
TYCO Series DS-1 5.6K Pendent,
Upright, and Horizontal Sidewall, Stan-
dard Response (5 mm bulb), Standard
Coverage Dry-type Sprinklers are dec-
orative glass bulb automatic sprinklers
typically used where:
•
pendent sprinklers are required
on dry pipe systems that are
exposed to freezing temperatures;
for example, sprinkler drops from
unheated portions of buildings
• sprinklers and/or a portion of the
connecting piping may be exposed
to freezing temperatures (for
example, sprinkler drops from wet
systems into freezers, or horizontal
piping extensions through a wall to
protect unheated areas of a building
such as loading docks, overhangs,
and building exteriors)
•
sprinklers are used on systems that
are seasonably drained to avoid
freezing (for example, vacation
resort areas)
NOTICE
Series DS-1 Dry-type Sprinklers
described herein must be installed
and maintained in compliance with this
document, as well as with the applica-
ble standards of the NATIONAL FIRE
PROTECTION ASSOCIATION (NFPA),
in addition to the standards of any other
authorities having jurisdiction. Failure
to do so may impair the performance
of these devices.
The owner is responsible for main-
taining their fire protection system
and devices in proper operating con-
dition. Contact the installing contrac-
tor or product manufacturer with any
questions.
Series DS-1 Dry-type Sprinklers must
only be installed in fittings that meet
the requirements of the Design Crite-
ria section.
Sprinkler
Identification
Numbers (SINs)
TY3255 – Pendent
TY3155 – Upright
TY3355 – Horizontal Sidewall
Technical
Data
Approvals
UL and C-UL Listed
FM Approved
NYC Approved under MEA 352-01-E)
LPCB Approved, Reference No. 094a/11
CE Certified, Certificate of Conformity
No. 2831-CPR-S2015
EAC Approved
See Tables A and B for Approvals details.
Maximum Working Pressure
175 psi (12,1 bar)
Inlet Thread Connections
1 in. NPT
ISO 7-R 1
Discharge Coefficient
K=5.6 gpm/psi½(80,6 lpm/bar½)
Temperature Ratings
See Tables A and B.

TFP500
Page 2 of 8
Finishes
Sprinkler: See Table D.
Escutcheon: See Table D.
Physical Characteristics
Inlet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Copper
Plug . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Copper
Yoke....................... Stainless Steel
Casing .............Galvanized Carbon Steel
Insert . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Bronze
Bulb Seat. . . . . . . . . . . . . . . . . . . Stainless Steel
Bulb (5 mm dia.) . . . . . . . . . . . . . . . . . . . . . Glass
Compression Screw . . . . . . . . . . . . . . . . .Bronze
Deflector . . . . . . . . . . . . . . . . . . . . . . . . . .Bronze
Frame . . . . . . . . . . . . . . . . . . . . . . . . . . . .Bronze
Guide Tube . . . . . . . . . . . . . . . . . Stainless Steel
Water Tube . . . . . . . . . . . . . . . . . Stainless Steel
Spring ..................... Stainless Steel
Sealing Assembly ..Beryllium Nickel w/TEFLON
Escutcheon ....Carbon Steel or Stainless Steel
Operation
When TYCO Series DS-1 5.6K Pendent,
Upright, and Horizontal Sidewall, Stan-
dard Response, Standard Coverage
Dry-type Sprinklers are in service,
water is prevented from entering the
assembly by the Plug with Sealing
Assembly (see Figure 1) in the Inlet of
the sprinkler.
The glass bulb contains a fluid that
expands when exposed to heat. When
the rated temperature is reached, the
fluid expands sufficiently to shatter
the glass bulb, and the Bulb Seat is
released.
The compressed Spring is then able
to expand and push the Water Tube as
well as the Guide Tube outward. This
action simultaneously pulls inward on
the Yoke, withdrawing the Plug with
Sealing Assembly from the Inlet, allow-
ing the sprinkler to activate and flow
water.
Design
Criteria
TYCO Series DS-1 5.6K Pendent,
Upright, and Horizontal Sidewall, Stan-
dard Response, Standard Coverage
Dry-type Sprinklers are intended for
use in fire sprinkler systems designed
in accordance with the standard instal-
lation rules recognized by the appli-
cable listing or approval agency (for
example, UL Listing is based on NFPA
13 requirements). For more information
on LPCB Approval, contact Johnson
Controls at the following office:
Kopersteden 1
7547 TJ Enschede
The Netherlands
Tel: [phone]
Fax: [phone]
Sprinkler Fittings
Install 1 in. NPT Series DS-1 Dry-type
Sprinklers in the 1 in. NPT outlet or run
of the following fittings:
• malleable or ductile iron threaded
tee fittings that meet the dimen-
sional requirements of ANSI B16.3
(Class 150 )
• cast iron threaded tee fittings that
meet the dimensional requirements
of ANSI B16.4 (Class 125)
Do not install Series DS-1 Dry-type
Sprinklers into elbow fittings. The Inlet
of the sprinkler can contact the interior
of the elbow.
The unused outlet of the threaded tee is
plugged as shown in Figure 12.
You can also install Series DS-1 Dry-
type Sprinklers in the 1 in. NPT outlet
of a GRINNELL Figure 730 Mechanical
Tee and GRINNELL G-FIRE Figure 522;
however, the use of the Figure 730 Tee
and Figure 522 for this arrangement is
limited to wet pipe systems.
The configuration shown in Figure 13
is only applicable for wet pipe systems
where the sprinkler fitting and water-
filled pipe above the sprinkler fitting
are not subject to freezing and where
the length of the dry-type sprinkler has
the minimum exposure length depicted
in Figure 11. See the Exposure Length
section.
For wet pipe system installations of
1 in. NPT Series DS-1 Dry-Type Sprin-
klers connected to CPVC piping, use
only the following TYCO CPVC fittings:
• 1 in. x 1 in. NPT Female Adapter
(P/N 80145)
• 1 in. x 1 in. x 1 in. NPT Sprinkler Head
Adapter Tee (P/N 80249)
For dry pipe system installations,
use only the side outlet of maximum
2 1/2 in. reducing tee when locat-
ing Series DS-1 Dry-type Sprinklers
directly below the branchline; other-
wise, use the configuration shown in
Figure 12 to assure complete water
drainage from above Series DS-1
Dry-type Sprinklers and the branch-
line. Failure to do so may result in pipe
freezing and water damage.
NOTICE
Do not install Series DS-1 Dry-type
Sprinklers into any other type fitting.
5 mm BULB
WATER
TUBE
VENT HOLE
GUIDE
TUBE
INSERT
YOKE
SCREW
INLET
SEALING
PLUG WITH
CASING
DEFLECTOR
BULB
SPRING
COMPRESSION
SEAT
ASSEMBLY
FRAME
INLET
BAND
RECESS
WRENCH
FLAT
WRENCH
WITH SPRINKLER
ENGAGEMENT
IN TO ENSURE
WRENCHING AREA
PUSH WRENCH
FIGURE 1
SERIES DS-1 DRY-TYPE SPRINKLER, 5.6K, STANDARD RESPONSE
ASSEMBLY
FIGURE 2
W-T YPE 7
WRENCH

TFP500
Page 3 of 8
Failure to use the appropriate fitting
may result in one of the following:
•
failure of the sprinkler to operate
properly due to formation of ice
over the Inlet Plug or binding of the
Inlet Plug
•
insufficient engagement of the
Inlet pipe-threads with consequent
leakage
Drainage
In accordance with the minimum
requirements of the NATIONAL FIRE
PROTECTION ASSOCIATION for dry
pipe sprinkler systems, branch, cross,
and feed-main piping connected to Dry
Sprinklers and subject to freezing tem-
peratures must be pitched for proper
drainage.
Exposure Length
When using Dry Sprinklers in wet pipe
sprinkler systems to protect areas
subject to freezing temperatures, use
Table C to determine a sprinkler’s
appropriate exposed barrel length to
prevent water from freezing in the con-
necting pipes due to conduction. The
exposed barrel length measurement
must be taken from the face of the
sprinkler fitting to the surface of the
structure or insulation that is exposed
to the heated area. See Figure 11 for
an example.
For protected area temperatures
between those given above, the
minimum recommended length from
the face of the fitting to the outside of
the protected area may be determined
by interpolating between the indicated
values.
SPRINKLER
TYPE ESCUTCHEON TYPE TEMPERATURE RATING BULB COLOR CODE
SPRINKLER FINISH
NATURAL
BRASS CHROME PLATED POLYESTER*
PENDENT
(TY3255)
STANDARD
135°F (57°C) Orange
1, 2, 3, 4, 5, 6 1, 2, 4, 5, 6
155°F (68°C) Red
175°F (79°C) Yellow
200°F (93°C) Green
286°F (141°C) Blue
360°F (182°C) Mauve 1, 2, 3, 6 1, 2, 6
RECESSED
135°F (57°C) Orange
1, 2, 3, 5, 6 1, 2, 5, 6
155°F (68°C) Red
175°F (79°C) Yellow
200°F (93°C) Green
286°F (141°C) Blue 1, 2, 6
360°F (182°C) Mauve N/A
DEEP
135°F (57°C) Orange
1, 2, 3, 4, 5, 6 1, 2, 4, 5, 6
155°F (68°C) Red
175°F (79°C) Yellow
200°F (93°C) Green
286°F (141°C) Blue
360°F (182°C) Mauve
WITHOUT
135°F (57°C) Orange
155°F (68°C) Red
175°F (79°C) Yellow
200°F (93°C) Green
286°F (141°C) Blue
360°F (182°C) Mauve 1, 2, 3, 6 1, 2, 6
UPRIGHT
(TY3155) WITHOUT
135°F (57°C) Orange
1, 2, 3, 4, 5, 6 1, 2, 4, 5, 6
155°F (68°C) Red
175°F (79°C) Yellow
200°F (93°C) Green
286°F (141°C) Blue
360°F (182°C) Mauve 1, 2, 3, 6 1, 2, 6
Notes:
1. Listed by Underwriters Laboratories, Inc. (UL), maximum order length of 48 in.
2. Listed by Underwriters Laboratories for use in Canada (C-UL), maximum order length
of 48 in.
3. Approved by FM Global (FM Approvals), maximum order length of 48 in.
4. Loss Prevention Certication Board (LPCB) and CE conformity apply to these
temperature ratings only
5. Approved by the City of New York under MEA 352-01-E
6. EAC Approved
• Frame and deector only
TABLE A
SERIES DS-1 PENDENT & UPRIGHT DRY-TYPE SPRINKLERS, 5.6K, STANDARD RESPONSE
LABORATORY LISTINGS AND APPROVALS

TFP500
Page 4 of 8
Clearance Space
In accordance with NFPA 13, when
connecting an area subject to freez-
ing and an area containing a wet pipe
sprinkler system, the clearance space
around the sprinkler barrel of dry-type
sprinklers must be sealed. Due to tem-
perature differences between two
areas, the potential for the formation
of condensation in the sprinkler and
subsequent ice build-up is increased. If
this condensation is not controlled, ice
build-up can occur that might damage
the dry-type sprinkler and/or prevent
proper operation in a re situation.
Use of the Model DSB-2 Dry Sprinkler
Boot, described in technical data sheet
TFP591 and shown in Figures 14 and
15, can provide the recommended seal.
Installation
TYCO Series DS-1 5.6K Pendent,
Upright, and Horizontal Sidewall, Stan-
dard Response, Standard Coverage
Dry-type Sprinklers must be installed
in accordance with this section.
General Instructions
Series DS-1 Dry-type Sprinklers must
only be installed in fittings that meet
the requirements of the Design Cri-
teria section. See the Design Criteria
section for other important require-
ments regarding piping design and
sealing of the clearance space around
the Sprinkler Casing.
Do not install any bulb-type sprinkler
if the bulb is cracked or there is a loss
of liquid from the bulb. With the sprin-
kler held horizontally, a small air bubble
should be present. The diameter of the
air bubble is approximately 1/16 in.
(1,6 mm) for the 135°F (57°C) rating to
1/8 in. (3,2 mm) for the 360°F (182°C)
rating.
Obtain a leak-tight 1 in. NPT sprinkler
joint by applying a minimum-to-maxi-
mum torque of 20 to 30 lb-ft (26,8 to
40,2 N·m). Higher levels of torque may
distort the sprinkler Inlet with conse-
quent leakage or impairment of the
sprinkler.
Do not attempt to compensate for
insufficient adjustment in an Escutch-
eon Plate by under or over-tightening
the Sprinkler. Re-adjust the position of
the sprinkler fitting to suit.
Notes:
• Install pendent sprinklers only in
the pendent position; install upright
sprinklers only in the upright posi-
tion. The deflector of a pendent or
upright sprinkler is to be parallel to
the ceiling.
• Install horizontal sidewall sprinklers
in the horizontal position with their
centerline of waterway perpendicu-
lar to the back wall and parallel to
the ceiling. Ensure the word “TOP”
on the Deflector faces the ceiling.
Step 1. With a non-hardening pipe-
thread sealant such as TEFLON applied
to the inlet threads, hand-tighten the
sprinkler into the sprinkler fitting.
Step 2. Wrench-tighten the sprinkler
using either:
• a pipe wrench on the Inlet Band or
the Casing, see Figure 1
• the W-Type 7 Sprinkler Wrench on
the Wrench Flat, see Figure 2
Apply the wrench recess of the W-Type
7 Sprinkler Wrench to the wrench flat.
SPRINKLER
TYPE ESCUTCHEON TYPE TEMPERATURE RATING BULB COLOR CODE
SPRINKLER FINISH
NATURAL
BRASS CHROME PLATED POLYESTER***
HSW*
(TY3355)
STANDARD
135°F (57°C) Orange
1**, 2**, 3***, 4, 5, 6 1**, 2**, 4, 5, 6
155°F (68°C) Red
175°F (79°C) Yellow
200°F (93°C) Green
286°F (141°C) Blue
360°F (182°C) Mauve
DEEP
135°F (57°C) Orange
155°F (68°C) Red
175°F (79°C) Yellow
200°F (93°C) Green
286°F (141°C) Blue
360°F (182°C) Mauve
WITHOUT
135°F (57°C) Orange
155°F (68°C) Red
175°F (79°C) Yellow
200°F (93°C) Green
286°F (141°C) Blue
360°F (182°C) Mauve 1**, 2**, 5, 6 1**, 2**, 6
Notes:
1. Listed by Underwriters Laboratories, Inc. (UL), maximum order length of 48 in.
2. Listed by Underwriters Laboratories for use in Canada (C-UL), maximum order
length of 48 in.
3. Approved by FM Global (FM Approvals), maximum order length of 48 in.
4. Loss Prevention Certication Board (LPCB) and CE conformity apply to these
temperature ratings only
5. Approved by the City of New York under MEA 352-01-E
6. EAC Approved
* Horizontal sidewall with top of deector-to-ceiling distance of 4 to 12 in.
(100 to 300 mm)
** Light and ordinary hazard occupancies only
*** Light hazard occupancies only
**** Frame and deector only
TABLE B
SERIES DS-1 HORIZONTAL SIDEWALL (HSW) DRY-TYPE SPRINKLER, 5.6K, STANDARD RESPONSE
LABORATORY LISTINGS AND APPROVALS

TFP500
Page 5 of 8
Note: If sprinkler removal becomes
necessary, remove the sprinkler using
the same wrenching method noted
above. Sprinkler removal is easier when
a non-hardening sealant was used
and torque guidelines were followed.
After removal, inspect the sprinkler for
damage.
Step 3. After installing the ceiling or
wall and applying a ceiling finish, slide
on the outer piece of the escutch-
eon until it comes in contact with the
ceiling/wall. Do not lift the ceiling panel
out of its normal position.
When using the Deep Escutcheon,
hold the outer piece in contact with the
mounting surface (ceiling or wall). Then
rotate the inner piece approximately 1/4
turn with respect to the outer piece,
to hold the Deep Escutcheon firmly
together.
Care and
Maintenance
TYCO Series DS-1 5.6K Pendent,
Upright, and Horizontal Sidewall,
Standard Response, Standard Cover-
age Dry-type Sprinklers must be main-
tained and serviced in accordance with
this section.
Before closing a fire protection system
main control valve for maintenance
work on the fire protection system
that it controls, obtain permission to
shut down the affected fire protection
systems from the proper authorities
2-1/4" DIA.
(57,2 mm)
1-3/8" ± 1/8"
(34,9 ± 3,2 mm)
2-7/8" DIA.
(73,0 mm)
IN 1/4" (6,4 mm)
3-3/4" to 48"
INCREMENTS
(95,3 to 1219,2 mm)
ORDER LENGTHS:
SPRINKLER
FACE OF
FITTING
CEILING
FACE OF
SPRINKLER FITTING
(REFER TO DESIGN
CRITERIA SECTION)
ORDER LENGTHS:
(69,9 to 1219,2 mm)
2-3/4" to 48"
IN 1/4" (6,4 mm)
INCREMENTS
FITTING
FACE OF
SPRINKLER
(76,2 mm)
3" DIA.
1-3/4" DIA.
(44,5 mm)
(55,6 ± 3,2 mm)
2-3/16" ± 1/8"
CEILING
FACE OF
SPRINKLER FITTING
(REFER TO DESIGN
CRITERIA SECTION)
ORDER LENGTHS:
INCREMENTS
4-1/4" ± 1/8"
(108,0 ± 3,2 mm)
IN 1/4" (6,4 mm)
(12,7 to 1168,4 mm)
1/2" to 46"
FACE OF
CEILING
FITTING
FACE OF
SPRINKLER
(88,9 mm)
3-1/2" DIA.
2-1/2" DIA.
(63,5 mm)
CRITERIA SECTION)
(REFER TO DESIGN
SPRINKLER FITTING
SPRINKLER
FACE OF
FITTING
(127,0 to 1219,2 mm)
INCREMENTS
IN 1/4" (6,4 mm)
ORDER LENGTHS:
5" to 48"
DEFLECTOR
TO CEILING
1-3/4" (44,5 mm)
MINIMUM
SPRINKLER FITTING
(REFER TO DESIGN
CRITERIA SECTION)
TOP OF
DEFLECTOR
CRITERIA SECTION)
(REFER TO DESIGN
SPRINKLER FITTING
SPRINKLER
FITTING
FACE OF
IN 1/4" (6,4 mm)
INCREMENTS
(127,0 to 1219,2 mm)
5" to 48"
ORDER LENGTHS:
FIGURE 3
PENDENT (TY3255)
WITH STANDARD ESCUTCHEON
FIGURE 5
PENDENT (TY3255)
WITH DEEP ESCUTCHEON
FIGURE 4
PENDENT (TY3255)
WITH STANDARD
RECESSED ESCUTCHEON
FIGURE 6
PENDENT (TY3255)
WITHOUT ESCUTCHEON
FIGURE 7
UPRIGHT (TY3155)
WITHOUT ESCUTCHEON

TFP500
Page 6 of 8
and notify all personnel who may be
affected by this action.
Absence of the outer piece of an
escutcheon, which is used to cover a
clearance hole, may delay the time to
sprinkler operation in a fire situation.
A Vent Hole is provided in the Bulb
Seat (see Figure 1) to indicate if the Dry
Sprinkler is remaining dry. Evidence of
leakage from the Vent Hole indicates
potential leakage past the Inlet seal
and the need to remove the sprinkler
to determine the cause of leakage;
for example, an improper installation
or an ice plug. Close the fire protec-
tion system control valve and drain the
system before removing the sprinkler.
Sprinklers which are found to be
leaking or exhibiting visible signs of
corrosion must be replaced.
Automatic sprinklers must never be
painted, plated, coated, or other-
wise altered after leaving the factory.
Modified sprinklers must be replaced.
Sprinklers that have been exposed to
corrosive products of combustion, but
have not operated, should be replaced
if they cannot be completely cleaned
by wiping the sprinkler with a cloth or
by brushing it with a soft bristle brush.
Care must be exercised to avoid
damage to the sprinklers before,
during, and after installation. Sprin-
klers damaged by dropping, striking,
wrench twist/slippage, or the like, must
be replaced. Also, replace any sprinkler
that has a cracked bulb or that has lost
liquid from its bulb. See the Installation
section.
The owner is responsible for the
inspection, testing, and maintenance of
their fire protection system and devices
in compliance with this document, as
well as with the applicable standards
of the NATIONAL FIRE PROTECTION
ASSOCIATION, such as NFPA 25, in
addition to the standards of any other
authorities having jurisdiction. Contact
the installing contractor or product
manufacturer with any questions.
Automatic sprinkler systems are rec-
ommended to be inspected, tested,
and maintained by a qualified Inspec-
tion Service in accordance with local
requirements and/or national codes.
FACE OF
SPRINKLER
FITTING
SPRINKLER FITTING
(REFER TO DESIGN
CRITERIA SECTION)
CENTERLINE
OF WATERWAY
1-3/4" DIA.
(44,5 mm)
FACE OF
MOUNTING
SURFACE
ORDER LENGTHS:
2-3/4" to 48" (69,9 to 1219,2 mm)
IN 1/4" (6,4 mm) INCREMENTS
3" DIA.
(76,2 mm)
5/16"
(7,9 mm)
2-3/8" ± 1/8"
(60,3 ± 3,2 mm)
3.5°
3.5° 5/16"
(7,9 mm)
CENTERLINE
OF WATERWAY
FITTING
SPRINKLER
FACE OF
2-1/4" (57,2 mm)
DEFLECTOR TO
5-1/2" to 48" (139,7 to 1219,2 mm)
IN 1/4" (6,4 mm) INCREMENTS
ORDER LENGTHS:
MINIMUM
MOUNTING
SURFACE
SPRINKLER FITTING
CRITERIA SECTION)
(REFER TO DESIGN
FACE OF
SPRINKLER
FITTING
SPRINKLER FITTING
(REFER TO DESIGN
CRITERIA SECTION)
CENTERLINE
OF WATERWAY
FACE OF
MOUNTING
SURFACE
ORDER LENGTHS:
1/2" to 45-3/4" (12,7 to 1162,1 mm)
IN 1/4" (6,4 mm) INCREMENTS
5/16"
(7,9 mm)
3.5°
2-1/2" DIA.
(63,5 mm)
4-1/4" ± 1/8"
(108,0 ± 3,2 mm)
3-1/2" DIA.
(88,9 mm)
FIGURE 8
HORIZONTAL SIDEWALL (TY3355)
WITH STANDARD ESCUTCHEON
FIGURE 9
HORIZONTAL SIDEWALL (TY3355)
WITH DEEP ESCUTCHEON
FIGURE 10
HORIZONTAL SIDEWALL (TY3355)
WITHOUT ESCUTCHEON

TFP500
Page 7 of 8
Ambient
Temperature
Exposed to
Discharge
End of
Sprinkler
Temperatures for
Heated Area(1)
40°F
(4°C) 50°F (10°C) 60°F (16°C)
Minimum Exposed
Barrel Length(2),
in.
(mm)
40°F
(4°C) 000
30°F
(-1°C) 000
20°F
(-7°C)
4
(100) 0 0
10°F
(-12°C)
8
(200)
1
(25) 0
0°F
(-18°C)
12
(305)
3
(75) 0
-10°F
(-23°C)
14
(355)
4
(100)
1
(25)
-20°F
(-29°C)
14
(355)
6
(150)
3
(75)
-30°F
(-34°C)
16
(405)
8
(200)
4
(100)
-40°F
(-40°C)
18
(455)
8
(200)
4
(100)
-50°F
(-46°C)
20
(510)
10
(255)
6
(150)
-60°F
(-51°C)
20
(510)
10
(255)
6
(150)
Notes:
1. For protected area temperatures that occur
between values listed above, use the next cooler
temperature.
2. These lengths are inclusive of wind velocities up
to 30 mph (18,6 kph).
(SEE DESIGN
CRITERIA
SECTION)
FACE OF
SPRINKLER
FITTING
LENGTH
EXPOSURE
DSB-2
INTENDED
FOR FREEZER
STRUCTURES
HEATED
AREA
RUN
OUTLET
PLUGGED
TO DRY
SYSTEM
DSB-2
INTENDED
FOR FREEZER
STRUCTURES
FITTING
(SEE DESIGN
CRITERIA
SECTION)
SPRINKLER
AREA
SUBJECT
TO
FREEZING
SIDE
OUTLET
PLUGGED
TO WET
SYSTEM
FITTING
(SEE DESIGN
CRITERIA
SECTION)
SPRINKLER
DSB-2
INTENDED
FOR FREEZER
STRUCTURES
HEATED
AREA
INSULATED
FREEZER
STRUCTURE
STRAP TIES
(ENDS ON
OPPOSING
SIDES OF
BOOT)
ADHESIVE
DS-1
SHOWN WITH
STANDARD
ESCUTCHEON
1-3/4" DIA.
(44,5 mm)
CLEARANCE
HOLE
DSB-2 BOOT
INSULATED
FREEZER
STRUCTURE
STRAP TIES
(ENDS ON
OPPOSING
SIDES OF
BOOT)
ADHESIVE
DS-1
SHOWN WITH
STANDARD
ESCUTCHEON
1-3/4" DIA.
(44,5 mm)
CLEARANCE
HOLE
DSB-2
BOOT
TABLE C
EXPOSED SPRINKLER BARRELS
IN WET PIPE SYSTEMS
MINIMUM RECOMMENDED
LENGTHS
FIGURE 11
EXPOSURE LENGTH
FIGURE 12
SPRINKLER FITTING
UNHEATED AREA
FIGURE 13
SPRINKLER FITTING
HEATED AREA
FIGURE 14
MODEL DSB-2 DRY SPRINKLER
BOOT WITH PENDENT SERIES
DS-1 DRY-TYPE SPRINKLER
FIGURE 15
MODEL DSB-2 DRY SPRINKLER
BOOT WITH SIDEWALL SERIES
DS-1 DRY-TYPE SPRINKLER

TFP500
Page 8 of 8
NATIONAL FIRE PROTECTION ASSOCIATION and NFPA are registered trademarks of National Fire Protection Association;
TEFLON is a trademark of The Chemours Company FC, LLC
1400 Pennbrook Parkway, Lansdale, PA 19446 | Telephone [phone]
© 2022 Johnson Controls. All rights reserved. All specifications and other information shown were current as of document revision date and are subject to change without notice.
Limited
Warranty
For warranty terms and conditions, visit
www.tyco-fire.com.
Ordering
Procedure
Contact your local distributor for avail-
ability. When placing an order, indi-
cate the full product name, including
description and part number (P/N).
Dry-type Sprinklers
When ordering Series DS-1 5.6K
Pendent, Upright, and Horizontal Side-
wall, Standard Response, Standard
Coverage Dry-type Sprinklers, specify
the following information:
• SIN:
TY3255 – Pendent
TY3155 – Upright
TY3355 – Horizontal Sidewall
• Order Length:
Dry-type Sprinklers are furnished
based upon Order Length as mea-
sured per Figures 3 through 10, as
applicable. After the measurement is
taken, round it to the nearest 1/4 in.
increment.
• Inlet Connections:
1 in. NPT
(Standard)
ISO 7-R 1
(For information on ISO Inlet Thread
Connections, contact your Johnson
Controls Sales Representative.)
• Temperature Rating
• Sprinkler Finish
• Escutcheon Type and Finish, as
applicable
• P/N from Table D
Part numbers are for 1 in. NPT stan-
dard order sprinklers. Orders for
all other sprinkler assemblies must
be accompanied by a complete
description.
Replacement Escutcheons
Order replacement escutcheons
separately.
Note: Style 10 Recessed Escutcheons
are shipped as assemblies comprised
of closure ring and mounting plate. The
included mounting plate is not used
for Dry Type Sprinkler applications,
discard accordingly.
Specify: (specify type), (specify) finish,
P/N (specify):
Recessed (Style 10)
Brass Plated . . . . . . . . . . . . . . . . . 56-701-2-010
Signal White (RAL9003) 56-701-4-010
Chrome Plated . . . . . . . . . . . . . . . 56-701-9-010
Standard (Push-On)
White Color . . . . . . . . . . . . . . . . . . 91-106-0-007
Brass Plated . . . . . . . . . . . . . . . . . 91-106-2-007
Chrome Plated . . . . . . . . . . . . . . . 91-106 -9-007
Deep
Brass Plated . . . . . . . . . . . . . . . . . . 91-107-2-010
White ........................91-107-4-007
Chrome Plated . . . . . . . . . . . . . . . 91-107-9-007
Sprinkler Wrench
Specify W-Type 7 Sprinkler Wrench,
P/N 56-850-4-001
Sprinkler Boot
Specify Model DSB-2 Dry Sprinkler
Boot, P/N 63-000-0-002
This part number includes one (1) Boot,
two (2) Strap Ties, and 1/3 oz of Adhe-
sive (a sufficient quantity for installing
one boot).
Notes:
1. Escutcheon Finish applies to sprinklers provided with escutcheons.
2. 360°F (182°C) temperature rating applies to non-recessed sprinkler
assemblies.
3. Dry-type Sprinklers are furnished based upon “Order Length” as
measured per Figures 3 through 10, as applicable, and for each
individual sprinkler where it is to be installed. After the measurement
is taken, round it to the nearest 1/4 in. increment.
* Use Prex “I” for ISO 7-R 1 Connection (for example, I-60-961-1-180).
P/ N*60 – XXX – X – XXX
SIN
96 Pendent with Standard
Escutcheon (1 in. NPT)
TY3255
(Figure 3)
93 Pendent with Deep
Escutcheon (1 in. NPT)
TY3255
(Figure 5)
97 Pendent with Recessed
Escutcheon (1 in. NPT)
TY3255
(Figure 4)
92 Pendent without
Escutcheon (1 in. NPT)
TY3255
(Figure 6)
94 Sidewall with Standard
Escutcheon (1 in. NPT)
TY3355
(Figure 8)
53 Sidewall with Deep
Escutcheon (1 in. NPT)
TY3355
(Figure 9)
54 Sidewall without
Escutcheon (1 in. NPT)
TY3355
(Figure 10)
98 Upright without
Escutcheon (1 in. NPT)
TY3155
(Figure 7)
SPRINKLER
FINISH ESCUTCHEON FINISH¹
0CHROME
PL ATED
SIGNAL WHITE
(RAL9003)
POLYESTER
1NATURAL
BRASS
SIGNAL WHITE
(RAL9003)
POLYESTER
2NATURAL
BRASS
BRASS
PL ATED
4
SIGNAL WHITE
(RAL9003)
POLYESTER
SIGNAL WHITE
(RAL9003)
POLYESTER
8CHROME
PL ATED
STAINLESS
STEEL
9CHROME
PL ATED
CHROME
PL ATED
TEMPERATURE
RATING²
0135°F (57°C)
1155°F (68°C)
2175°F (79°C)
TEMPERATURE
RATING²
3 200°F (93°C)
4286°F (141°C)
5360°F (182°C)
SAMPLE
ORDER
LENGTH³
055 5.50 in.
082 8.25 in.
180 18.00 in.
187 18.75 in.
372 37. 2 5 i n .
480 48.00 in.
TABLE D
SERIES DS-1 DRY-TYPE SPRINKLERS, 5.6K, STANDARD RESPONSE
PART NUMBER SELECTION
