NEKA
Outdoor Self-Powered Siren
Installation Instructions

2Outdoor Self-Powered Siren
Description
The NEKA range provides the following models:
NEKA, self-powered horn with flash;
NEKA-F, self-powered horn with flash and foam tamper device;
NEKA-FS, self-powered horn with strobe and foam tamper device.
This manual provided installation instructions for all NEKA sirens. Information relating to a specific model is denoted by the ap-
plicable model number within the text. The term “siren” is used to describe functionality that is applicable to all series.
This siren is a self-powered microprocessor controlled horn strobe/flash, especially designed to provide differentiated audible and
visual alarm signals.
The distinctive low profile shape is acoustically very efficient and ensures uniform sound distribution.
Robust construction and state-of-the-art technology greatly extend application flexibility, whilst microprocessor supervision of the
battery charge (NEKA and NEKA-F only), horn and flash ensure maximum performance and reliability.
Parts
1Screws (2) for innerplate fixing. 12 Cable entry.
2Screws (2) for cover fixing. 13 Strobe board (NEKA-FS only).
3Battery connector. 14 Flash bulb (NEKA and NEKA-F only).
4Connector for strobe board or flash bulb. 15 Tamper device.
5Connector for foam tamper device. 16 Hole for wall-tamper plate fixing.
6Jumpers for operating mode setup. 17 Loudspeaker.
7Jumpers for tamper mode setup. 18 Foam tamper device (NEKA-F and NEKA-FS
only).
8Connector for tamper device switch. 19 Battery location.
9Terminal board. 20 Battery connection cable.
10 Electronic board. 21 Hole for siren temporary hanging.
11 Backplate anchor screw locations (4).
Table 1 – Parts.

NEKA 3
Figure 1 – Parts: a) cover; b) innerplate; c) backplate; e) Electronic board.
2
1
1
2
11
3
4
5
6
7
8
9
10
11
12
11
21
20
19
18
17
15
11
14
13
16
ab
c
d

4Outdoor Self-Powered Siren
General features
Self-powered microprocessor controlled horn withstrobe/flash for outdoor applications.
New design.
Strong weatherproof plastic material moulding.
Tropicalized-steel innerplate.
4 audible and visual signal inputs.
Modulated frequency sound emission with sound options.
High output magnetodynamic exponential horn withtest circuit.
Protected against tamper, wall tamper, flash bulb damage and wire cutting.
Foam tamper device (NEKA-F and NEKA-FS only).
Programmable maximum alarm time.
Battery test circuit with flash shutdown under low battery or battery trouble conditions (NEKA and NEKA-F only).
Drilling pattern for easy installation.
Houses 12 V, 2 Ah, buffer battery.
Box
The hard wearing plastic moulding is resistant to the most adverse weather conditions. The louver grille has been especially de-
signedtoprotecttheinternalcomponentsagainstrainwhileepitomisingsoundemission.Thetropicalized-steelinnerplateprovides
extra protection against acts of delinquency.
Tamper protection
The tamper device (must be anchored to the wall) triggers alarms when either the frontplate or innerplate is removed, or when the
siren is pulled from the wall (wall tamper). The foam tamper protection (NEKA-F and NEKA-FS only) comprises an active in-
frared barrier with a dual detector that provides high immunity to false alarms (caused by insects).
The siren canoperate in normal orautomatic mode. In normalmode, the siren opensthe AS andASG terminalswhen tampered.
Theseterminals havetobeconnectedtocontrolpanel tamperlinethat activatesthesiren (andothertypesof signalling,depending
on requirements) through +N, AF, Aor Fterminals.
Inautomatic mode,thesirenindependentlyactivatestheacousticandopticalsignallingfortamperevents:AS and ASG terminals
donotneedtobeconnectedtotamperlinebutthecontrolpaneldonotknowthesirentamperstatus.Inautomaticmode,thetamper
alarm ends when 40 seconds after all causes have been removed, or when maximum alarm time elapses.
Activation
The siren can be activated by the tamper device, andby +N, AF, Aand F terminals. For example: the siren activates when the
voltage fails on terminal +N. This operating mode allows the siren to detect wire cutting, as this terminal also supplies the power
and battery charge. The polarity programmable AF, Aand Fterminals can be used for connection to other devices.
The siren blocks for 4 minutes if receive most then 6 activating requests in 4 minutes. This is to protect against control panel
malfunctioning.
Signalling
Theaudibleandvisualsignalsontheloudspeakerandstrobe/flashdependonthetypeofalarm,andthealarmsignalconfiguration.
The sound modulation extremes generate a fastidious shrill tone — intended to discourage intruders,and a low tone — to ensure
goodaudibility.ItispossibletoselecttwoaudiblesignalspatternsforalarmInputs—withtheexceptionoftheinternaltamperevent
which has only one audible signal (up-scale modulated frequency between 800 and 2000 Hz). The audible signals and modulated
frequencyrange canbe foundin “Settingthe operatingmode” onpage 7. Thereare twofrequency ranges:800/2000 Hzand 1100/
2400 Hz. The audible signalling will stop as soon as the maximum alarm time expires, whereas, the visual signalling will continue
until the alarm conditions clear (memory flashing).

NEKA 5
The Memory and Alarm flash sequences are as follows:
Under low battery conditions, the siren bypasses the flash and use the residual charge to power the loudspeaker (NEKA and
NEKA-F only). This statusis signalled on terminal G (NEKA and NEKA-F only). This terminal (open collector) is connected
to ground during standby status, but disconnects in the event of low battery (NEKA and NEKA-F only), or damage to the loud-
speaker or flash.
No Trouble: the loudspeaker emits an acoustic signal and the flash blinks once.
Battery trouble: the loudspeaker emits two acoustic signal and, if battery charge is sufficient,the flash blinks twice.
Flash trouble: the loudspeaker emits three acoustic signal.
Loudspeaker trouble: the flash blinks four times.
The above listed signalling are displayed every 5 seconds until troublesare present or the jumper is removed. The siren runs the
power-up sequence when the jumper is removed.
If troubles are not present, the inhibition of siren activation is delayed between 30 seconds and 2 minutes, to prevent this
function being used to tamper the siren.
Inthisphase,anti-foamdevicecanbetestedasFT outputactivatesas soonasthe infraredbarrierof thedeviceis interrupted
(NEKA-F and NEKA-FS only).
Alarm priority
The siren priority is as follows:
Higher priority alarm always overrides lower priority alarm, generating a variation in the audible signal.
Aand Fterminals have the same priority because theacoustic signalling activated by terminal Adoes not interfere with the
optical signalling activated by terminal F.
The alarm time is counted from activation of the loudspeaker and strobe/flash.
NEKA/NEKA-F ON (ms) OFF (ms) Description
Alarm flashing 250 750 StandardBlink
Memory flashing 250 1500 Slow Blink
NEKA-FS Frequency (Hz) Description
Alarm flashing 1 Standard Blink
Memory flashing 0.6 Slow Blink
When Sand T’s pins are connected as shown at the side, siren activation is inhibit and the siren displays the trou-
bles as following.
Alarm Priority
Internal tamper 1
+N 2
AF 3
A4
F4

6Outdoor Self-Powered Siren
When the maximum alarm time of the higher priority alarm expires, or when the alarm conditions clear, the lower priority alarm
signal activates the loudspeaker and strobe/flash in accordance with its configuration.
If a priority alarm signal overrides an alarm that has been running for more than 30 seconds, the maximum alarm time of the inter-
rupted signal will run on.
Ifthepriorityalarmterminates(duetotimeoutorrestoral)beforethemaximumalarmtimeoftheinterruptedsignalexpires,thelatter
activates the loudspeaker and strobe/flash for the residual time.
If a priority alarm signal overridesan alarm that has been running for less than30 seconds, the maximum alarm time of the inter-
ruptedsignalwillfreeze.Iftheinterruptedalarmsignalis stillpresentwhenthe priorityalarmterminates(due totimeoutor restoral),
it activates the loudspeaker and strobe/flash in accordance with its configuration. If theinterrupted alarm signal has restored when
the priority alarm terminates (due to timeout or restoral), it activates the loudspeaker and strobe/flash for 30 seconds. Figure2
shows how the lower priority alarm signal Aactivates the horn and strobe/flash after the higher priority alarm (alarm signal +N)
has been executed.
Memory flashing will stop (after the maximum alarm-time) when all the signals, that triggered the alarm, restore to standby for 5
seconds (restoral time). Internal tamper restoral requires 40 seconds.
Figure 2 shows an example on how signalling devices (optical and acoustic) work for aparticular activation sequence.
Figure 2 – Alarm priority: standard flashing; memory flashing.
+N
F30 s
40 s
T Max.
AF
A
ON
AF +N AF A
AF +N AF AF
OFF
ON
OFF
ON
OFF
ON
OFF

NEKA 7
Setting the operating mode
If you are installing several sirens in the same area, the jumpers on the electronic board allow to select different sound for each
one, thus permitting users to distinguish between them. You can also select different sounds for different alarm types (gas leak,
burglary, flooding, etc.) or locations (office, warehouse, garage, etc.). This feature allowsusers to recognize the alarm type and its
location.JumpersSallows to select the soundsforinputs+N,AF andA. Otherjumpersallow to set themaximumalarmtime,the
inputpolarityandinternaltampermode.Forthe variousprogramming options providesby thejumpers refer totable 2 (firstcolumn
shows the default). For the frequency profile of the audible signals refer to “Available sounds” on page 15.
Maximum alarm time
T10 minutes T3 minutes
Alarm sound
STamper (automatic mode): Up scale modu-
lation LF.
+N: Up and downscale modulation (LF).
AF: Up and down scale modulation (HF).
A: Multitone HF.
STamper (automatic mode): Up scale modula-
tion LF.
+N: Up and downscale modulation (HF).
AF: Up scale modulation HF.
A: Up and down scale modulation LF.
AF, Aand F input activation polarity
PInputs on standby when disconnected.
Inputsactivatewhen connectedtonegative. PInputs on standby when connected to nega- tive.
Inputs activate when disconnected.
If this option is selected, not used inputs
must be connected to
M terminal.
Trouble signalling
Trouble signalling ON (test mode): alarm
activation is inhibited.
Tamper mode
Automatic mode: automatic activation of the
siren for tamper. Normal mode: the siren must be connected to the control panel tamper line.
Foam-tamper mode (NEKA-F/NEKA-FS only)
Foam tamper generates a tamper alarm like
siren opening and siren wall removal. Foam tamper generates an alarm independ- ent from siren opening and siren wall
removal.
Table 2 – Jumper description. HF and LF indicate the sound frequency range: HF = 1100/2400 Hz, LF = 800/2000 Hz.

8Outdoor Self-Powered Siren
Mounting
The siren should be mounted as high up as possible on a flatwall, as uneven surfaces may jeopardize proper functioning of wall-
tamper protection.
To facilitate the mounting operation, a drilling pattern and screws for fixing are in the package. On the drilling pattern are drawn 5
holes, corresponding to those of fixing, placed on the bottom of the siren.
Proceed as described below (see figure 1 on page 3).
Make sure that the strobe flash is connected before powering the siren, otherwise the flash may not work properly (NEKA-
FS only).
1. Place the drilling pattern on the wall with PC opening over the wiring cable: make sure the drilling pattern is horizontal.
2. Mark the anchor screw holes F1, F2, F3, F4 e F5.
Make sure to mark the upper side of F2 hole.
3. Mark the wall-tamper anchor screw hole F6.
4. Take off the drilling pattern.
5. Drill the marked holes.
6. Insert the wall plugs in the holes.
7. Screw a screw into hole F2 up to a distance of about 1 cm from the wall.
8. Pull the wires through the cable entry 12 and hang the siren through the hole 21.
9. Fix the siren permanently through the holes 11.
10. Fix the wall-tamper plate through the hole 16, without tightening the screw too much in order not to break the stop tabs.
11. Set the siren operating mode by means of the jumpers 6and 7and make the connections on the terminal board 9.
12. Place the battery on shelf 19 and then connect it to connector 3(BATT) via cable 20: the flash starts to blink in alarm mem-
ory mode (slow blink).
Tamperprotectionisnotactiveuntilthecoverand theinner-coverofthesirenareclosed,anduntilthe+N terminal ispowered
for at least 20 seconds.
The foam tamper device can be tested in this phase because FT output activates as soon as the device infrared barrier is
interrupted (NEKA-F and NEKA-FS only).
13. Put in place the inner cover and fix it by means the screws1.
!Be careful not to cause a short circuit by touching the flash contacts.
14. Put in place the cover and fix it by means the screws 2: the flash blinks in alarm mode for 20 seconds (standard blink).
If the cover or inner cover is removed, the 20 seconds reset and the flash restart to blink in alarm memory mode (step 12).
15. Apply the voltageon +N terminal: the siren becomes operational when 20 seconds have elapsed from the +N power supply.
If the voltage on +N terminal fails before 20 seconds have elapsed, the 20 seconds reset and the flash continues to blink in
alarm mode (step 14).

NEKA 9
Wiring
Use shielded cable only, with one endconnected tothe control panel negative and the other left free.
T. Description
SPK Loudspeaker connection terminals.
AS
ASG Tamper signalling terminals: when tamper signalling is set to normal mode, these terminals open when the cover or innerplate is removed, or when siren is pulled from the wall, or when the foam tamper is detected (NEKA-F
and NEKA-FS only).
FT Foam tamper signalling terminal (NEKA-F and NEKA-FS only): open-collector normally closed to ground, it
opens when at least 30 seconds has been elapsed from interruption of the device infrared barrier.
Thisterminalisdisabledwhentampersignallingisin automatic mode ( ) andsirenisautomatically
activated by foam tamper too ( ).
GTrouble signal terminal: open-collector normally closed to ground, opens for low battery and battery trouble
(NEKA and NEKA-F only), loudspeaker trouble, flash bulb damage (strobe board not present).
FAlarm activation terminal with programmable polarity (optical signalling only).
AAlarm activation terminal with programmable polarity (acoustic signalling only).
AF Acoustic and optical signalling activation terminal, with programmable polarity.
+N Power supply (positive) and alarm terminal. 13.8V must be applied to this terminal for the battery charge. If this
voltage fails (wire cutting or alarm) the siren go into alarm status (acoustic and optical signalling).
MNegative supply terminal and ground of the internal circuit.

Table 3 – Terminal description.

10 Outdoor Self-Powered Siren
Automatic mode
For siren basicoperation are required two wires only, as shown in figure 3: the control panel (A) must have a terminal (+N) where
13.8 Vvoltage(minimum 600 mA)ispresent onstandbyandno voltageinalarm;thecontrolpanelcannotdetectsthesirentamper,
and foam tamper (NEKA-F and NEKA-FS only) but the siren automatically activates for those events.
Figure 3 – Automatic mode: A) control panel; B) siren.
Automatic mode with independent management of foam tamper (NEKA-F/NEKA-FS only)
If foam tamper have to be managed by the control panel, jumpers position must be as shown in figure 4, and FT terminal of the
siren (B) must be connected to an input line of the control panel (A) that is on standby when connected to ground and in alarm
when floating (Zterminal in the figure).
Figure 4 – Automatic mode with independent management of foam tamper: A) control panel; B) siren.
AF+N AS SPK
ASG
FTGFA
+N
A
B
NEKA-F
NEKA-FS
NEKA
AF+N AS SPK
ASG
FTGFA
+N
Z
A
B
NEKA-F
NEKA-FS

NEKA 11
Normal mode
If siren tamper, and foam tamper (NEKA-F/NEKA-FS only) have to be managed by the control panel, jumpers position must
be as shown in figure 5, and AS terminal of the siren must be connected to the tamper line of the latest device: in this operating
mode, AS terminal of the siren is normally connected to the ground while is open for siren tamper or foam tamper.
Figure 5 – Normal mode: A) control panel; B) siren; C) to second-last device on tamper line.
Normal mode with independent management of foam tamper (NEKA-F/NEKA-FS only)
If foam tamper have to managed by control panel independently from the siren tamper, jumper positions must be as shown in
figure 6, and FT terminal of the siren (B) must be connected to an input line of the control panel (A) that is on standby when con-
nected to ground and in alarm when floating (Zterminal in the figure).
Figure 6 – Normal mode with independent management of foam tamper: A) control panel; B) siren; C) to second-last device on
tamper line.
AF+N AS SPK
ASG
FTGFA
+N
A
B
C
NEKA-F
NEKA-FS
NEKA
AF+N AS SPK
ASG
FTGFA
+N
Z
AS
A
B
C
NEKA-F
NEKA-FS

12 Outdoor Self-Powered Siren
Normal mode when the siren is not latest device on tamper line
Ifthe siren isnot thelatest deviceon tamperline, jumperpositionmust be asshown infigure 7,and ASG andAS terminals of the
sirenmustbeseriesconnectedtothetamperline:ASG andAS terminalsofthesirenarenormallyconnected,anddisconnectfor
siren tamper. The FT terminal have to be connected for NEKA-F/NEKA-FS sirens only.
Figure 7 – Normal mode when the siren is not latest device on tamper line: A) control panel; B) siren; D) to previous device on
tamper line; E) to next device on tamper line.
Other modes for siren activation
If the control panel do not have a terminal where 13.8 V voltage is present on standby, and no voltage in alarm, it is possible to
simulate one by means of the free-voltage contacts of alarm relay, as shown in figure 8.
Figure 8 – Activation by means of the free-voltage contacts of alarm relay:A) control panel; B) siren.
AF+N AS SPK
ASG
FTGFA
NC
+12
C
NO
B
ANEKA-F
NEKA-FS
NEKA

NEKA 13
Figures 9and10show,instead,wiring toactivatethesirenby meansanopen-collectoroutput(theOC terminalofthecontrolpanel
A): Pjumper must be inserted if theOC output closes to ground on alarm, must be removed ifOC output opens on alarm. On
+terminal of the control panel 13.8 V voltage (minimum 600 mA) must be present for siren power supply, and siren battery charg-
ing.
Figure 9 – Wiring to activate the siren by means an open-collector output that closes to ground on alarm: A) control panel; B)
siren.
Figure 10 – Wiring to activate the siren by means an open-collector output that opens on alarm: A) control panel; B) siren.
Acoustic signalling activation by meansthe Aterminal and opticalsignalling activation by means theFterminal can be done
in the same way.
AF+N AS SPK
ASG
FTGFA
+
A
B
OC
NEKA-F
NEKA-FS
NEKA
AF+N AS SPK
ASG
FTGFA
+
A
B
OC
NEKA-F
NEKA-FS
NEKA

14 Outdoor Self-Powered Siren
Trouble shooting
Problem Cause Solution
The battery is connected but the flash
does not function. The battery may be low. Replace the battery.
Continuous flashing and/or continuous
sound on the loudspeaker. 1) The wall-tamper device is not secured properly.
2) The cover or the metal innerplate is
not closed properly.
Eliminate the causes.
The loudspeaker sounds but the flash
does not function. 1) The battery may be low. 2) The flash may be out-of-order. 1) Replace the battery if necessary. 2) Change the flash bulb or call the
installer.
The flash functions but the loud-
speaker is silent. 1) More than the maximum alarm-time has elapsed since the start of audible
signalling.
2) The loudspeaker is out-of-order.
3) The siren has been activated more
than six times in 4 minutes.
1) Eliminate the causes of alarm.
2) Call the installer.
3) Wait 4 minutes with no siren activa-
tion.
It is impossible to activate the siren. 1) The installation-time has not
expired.
2) The battery is low.
1) Wait 20 seconds.
2) Replace the battery if necessary.
Table 4 – Trouble shooting.

NEKA 15
Technical specifications
Nominal voltage: 13.8 V_
Alarm current: 1.4 A (max 2.8 A)
Voltage on terminal +N: 13.8 V ±0.2 V
Current on terminal +N: max 0.6 A
Minimum (maximum) supply voltage: 10 V_(13.8 V_)
Battery requirements: 2 Ah (177x34x66 mm)
Maximum alarm-time (programmable): 3 / 10 minutes
Protection class: IP34
Temperature range: -25 – +55 C°
Dimensions (WxHxD): 208x252x98 mm
Weight (without battery): 2300 g
Available sounds
Type of sound Frequencies Period Soundlevelat
3 m
Multitone 1108 Hz for 200 mS
1244 Hz for 180 mS
1396 Hz for 150 mS
1567 Hz for 145 mS
1760 Hz for 110 mS
2123 Hz for 100 mS
2430 Hz for 90 mS
0.3 s 106 dB(A)
Up scale modula-
tion (LF) 800 - 2000 Hz 0.3 s 104 dB(A)
Up scale modula-
tion (HF) 1100 - 2400 Hz 105 dB(A)
Up and down scale
modulation (LF) 800 - 2000 Hz 0.6 s 104 dB(A)
Up and down scale
modulation (HF) 1100 - 2400 Hz 105 dB(A)
Table 5 – Available sounds.
F
T
a
F
T
b
F
T
c

16 Outdoor Self-Powered Siren
Compliance with standards
Recycling information
BENTELSECURITY recommends that customersdisposeoftheirusedequipment (panels, detectors,sirensandotherdevices)in
an environmentally sound manner.Potential methods include reuse of parts or whole products andrecycling of products, compo-
nents, and/or materials.
For specific information see www.bentelsecurity.com/index.php?o=/environment.htm.
Waste electrical and electronic equipment (WEEE) directive
Hereby Bentel Security Srl declares that the product NEKA/NEKA-F/NEKA-FS complies with standards
EN 60950, EN 61000-6-3, EN 50130-4 and thereby, complies with the essential requirement of directives 2014/35/EU,
2014/30/EU and 2011/65/EU.
In the European Union, this label indicates that this product should NOT be disposed of with household waste. It
should be deposited at an appropriate facility to enable recovery and recycling.
For specific information see www.bentelsecurity.com/index.php?o= environment.htm.

NEKA 17

18 Outdoor Self-Powered Siren

NEKA 19

The manufacturer reserves the right to change the technical specifications of this product without prior notice.
BENTEL SECURITY s.r.l. – Via Gabbiano, 22 – Z. Ind. S. Scolastica – Corropoli (TE) – Italy – tel.: [phone]
Fax: [phone] – infobentelsecu[email protected] – www.bentelsecurity.com ISTISBLENEKA 1.0 270219 FM10
