U-Line H-8109 Manual instruction

PAGE 1 OF 3 0819 IH-8109
H-8109, H-8110
H - 8111
OHAUS CX COMPASS
SCALE
OVERVIEW OF CONTROLS
CONTROL PANEL AND DISPLAY
CONTROL FUNCTIONS
BUTTON g0
PRIMARY FUNCTION
(Short Press) Changes unit of measure. Turns the scale on.
If the scale is on, sets zero.
SECONDARY FUNCTION
(Long Press) Enter user menu. Turns off the scale.
CONTROL PANEL PARTS
#DESCRIPTION
1Battery Indicator
2 Unit Cal Menu Button
3Negative Sign
4Stability Indicator
5Symbol for Newtons
6Symbol for Ounces
7 On/Off Zero Button
8 Symbol for Grams
1
5
6
7
8
2
3
4
™
g
0

PAGE 2 OF 3 0819 IH-8109
SETUP
WARNING! Verify that the AC adapter input
voltage matches the local AC power supply.
Use the scale only in dry locations. For best
results, use the scale in the specified optimum
operating temperature. Do not operate the
scale in hostile or unstable environments. Use
the scale with care, gently loading items to
be weighed onto the center of the pan. Avoid
rough treatment to prolong life of scale. Indoor
use only.
REMOVING TRANSPORT SPACER (H-8109 ONLY)
1. To remove the red transport spacer, pull it out from
the side of the scale. (See Figure 1)
INSTALLING THE PLATFORM
1. Place the stainless steel pan onto the weighing
platform. (See Figure 1)
CONNECTING POWER
BATTERY
1. Remove the battery cover on the bottom of the scale.
2. Place three AA batteries into the compartment.
CAUTION! Do not use excessive force or press
on the weighing pan.
3. Re-insert the battery cover.
AC POWER (OPTIONAL. H-8112 SOLD SEPARATELY.)
1. Connect the AC adapter to the receptacle at the
rear of the scale.
2. Plug the AC adapter into a properly grounded
electrical outlet.
SELECTING THE LOCATION
1. Place on a firm, steady surface with sufficient space.
2. Avoid excessive air currents, vibrations, heat sources
or rapid temperature changes.
Figure 1
OPERATION
POWER UP TEST
When the scale is turned on, all display segments will be
displayed for a few seconds, indicating that the unit is
self-adjusting to zero. Once 0is displayed, the scale is
ready for use.
STABLE READING INDICATION
A star indicator, , will appear in the lower left corner of
the display when a stable reading has been reached.
OVERLOAD
If the applied load exceeds the capacity of the scale,
Ewill appear on the display and the load should be
removed immediately. The scale will return to normal
operation.
TARE FUNCTION
Values can progressively be added to a sample. By
pressing the ON/OFF ZERO button, the scale display
returns to zero. After adding additional mass, press
ON/OFF ZERO to zero the scale again. Additional mass
may be added up to the capacity of the scale.
NEGATIVE VALUE
When a load is removed from the scale, any zeroed
value will be displayed as a negative number. To
return to normal operation, the zeroed value can be
cancelled by pressing ON/OFF ZERO button.
Stainless
Steel Pan
Transport
Spacer

PAGE 3 OF 3 0819 IH-8109
LOW BATTERY INDICATION
The display will show Lo when the batteries are weak
and need to be replaced.
AUTO SHUT-OFF
To extend battery life, the scale will automatically turn off
after approximately four minutes if no active weighing is
occurring. This feature is active with battery operation only.
CALIBRATION
For best results, calibrate the scale at regular intervals,
especially if using for prolonged periods. Calibration
weights are not provided with the scale.
The message Ewill appear
if the calibration steps are
not followed or the wrong
weight was used.
1. Press and hold the g
button until 7ENU is
displayed. Release the
button, first menu CAL
will be displayed.
NOTE: The calibration process can be aborted
by pressing g
2. Press 0to start span calibration.
3. The display shows 0.
With no weight on the
pan, press the 0
button to establish the
zero point. The display
shows --C-- while the
scale stores the zero
load signal.
4. The display shows the
span calibration point,
for example, 200g. Place
the specified calibration
weight on the pan and
press the 0button. The
display shows --C-- while
the scale stores the
calibration point signal.
5. The display shows
[- d O N E -] and returns
to the normal weighing
mode.
BACKLIGHT
The backlight settings can be adjusted using the menu.
Press and hold the gbutton until 7ENU is displayed.
Release the button, first menu CAL will be displayed.
Press gto select desired option.
MENU OPTION SETTING
b.Auto
Scale turns on light
automatically with any
button or weighing operation.
b.ON Backlight is always on.
b.OFF Backlight is always off.
Once desired setting is displayed, press 0to select
and return to current weighing mode.
OPERATION CONTINUED
CALIBRATION VALUES
MODEL # CALIBRATION POINT (g.)
H-8109 200
H - 8110 1,000
H - 8111 2,000
