Ubiquiti UBNT-US-8-150W-US User manual

Managed PoE+ Gigabit Switch
with SFP
Model: US-8-150W

Introduction
Thank you for purchasing the Ubiquiti Networks® UniFi®
Switch. This Quick Start Guide is designed to guide you
through the installation and also includes the warranty terms.
Package Contents
UniFi Switch
Power Cord Mount Brackets
(Qty. 2)
Bracket Screws
(M4, Qty. 8)
ManagedPoE+ Gigabit Switch
withSFP
Model:US-8-150W
Mounting Screws
(M4, Qty. 4)
Screw Anchors
(M4, Qty. 4)
Quick Start
Guide
System Requirements
• Linux, MacOSX, or Microsoft Windows 7/8/10
• Java Runtime Environment 1.6 (1.8 or newer recommended)
• Web Browser: Mozilla Firefox, Google Chrome, Microsoft
Edge, or Microsoft Internet Explorer 11
• UniFi Controller software v5 or above (recommended) or
v4.8.x (offers possibly reduced feature set) available at:
downloads.ubnt.com/unifi
TERMS OF USE: All Ethernet cabling runs must use CAT5 (or above). It is the customer’s
responsibility to follow local country regulations, including operation within legal frequency
channels, output power, indoor cabling requirements, and Dynamic Frequency Selection
(DFS) requirements.

Network Topology Requirements
• A DHCP-enabled network for the UniFi Switch to obtain an
IPaddress (connected devices will also obtain IP addresses
after deployment)
• A UniFi Cloud Key or management station running the UniFi
Controller software v5 or above (recommended) or v4.8.x
(possibly offering reduced feature set), located either on-site
and connected to the same Layer2 network, or off-site in a
cloud or NOC
UniFi Switch US-8-150W
UniFi Security Gateway Pro
(DHCP Server)
Internet
UAP-AC-PRO UAP-AC-LR
UAP-IW
LAN
WAN
UniFi Cloud Key
(UniFi Controller)
Remote Access to
UniFi Controller
Sample Network Diagram
All UniFi devices support off-site management controllers.
For setup details, refer to the User Guide on the website:
documentation.ubnt.com/unifi

Hardware Overview
Front Panel
RJ45 1-8 SFP 1-2
Reset Button
Port Description
RJ45 1-8 RJ45 ports support 10/100/1000 Ethernet
connections and Power over Ethernet (PoE).
SFP 1-2 Hot-swappable SFP ports support 1 Gbps
connections.
Reset
Button
This button serves two functions for the
UniFi Switch:
• Restart Press and release the Reset button
quickly.
• Restore to Factory Default Settings Press
and hold the Reset button for more than
five seconds.
Back Panel
AC Power
Port Description
AC Power Connect the included Power Cord to the AC
Power port.

LEDs
System PoE
SFP
Link/Speed/Activity
RJ45
Link/Speed/Activity
System LED
State Status
Flashing White Initializing.
Steady White Factory defaults, waiting for integration.
Alternating
White/Blue
Device is busy; do not touch or unplug it.
This usually indicates that a process such
as a firmware upgrade is taking place.
Steady Blue Successfully integrated into a network
and working properly.
Flashing Blue
This is used to locate a device.
When you click Locate in the UniFi
Controller software, the System LED
will flash blue. The software will also
display the location of the UniFi Switch
on themap.

RJ45 LEDs
LED State Status
PoE
Off No PoE
Amber IEEE 802.3af/802.3at
Green 24V Passive
Link/
Speed/
Activity
Off No Link
Amber
Link Established at
10/100Mbps
Flashing Indicates Activity
Green
Link Established at
1000Mbps (1 Gbps)
Flashing Indicates Activity
SFP LEDs
LED State Status
Link/
Speed/
Activity
Off No Link
Green Link Established at 1Gbps
Flashing Indicates Activity

Side Panels
Ventilation Holes
WARNING: FAILURE TO PROVIDE PROPER VENTILATION
MAY CAUSE FIRE HAZARD. KEEP AT LEAST 20 MM OF
CLEARANCE NEXT TO THE VENTILATION HOLES FOR
ADEQUATE AIRFLOW.
WARNING: The US-8-150W must not be stacked. Do not
place it on top of another switch. Do not place anything
on top of the US-8-150W.

Hardware Installation
WARNING: To reduce the risk of fire or electric shock, do
not expose the switch to rain or moisture.
Shelf Mounting
1. Position the two Mount Brackets as shown below, and
attach the brackets using the eight Bracket Screws.
2. Secure the UniFi Switch to the shelf using the four
MountingScrews.

Wall Mounting
1. Position the two Mount Brackets as shown below, and
attach the brackets using the eight Bracket Screws.
2. Attach the UniFi Switch to the wall using the four Screw
Anchors and four Mounting Screws.

Connecting Power
1. Connect the Power Cord to the power port on the back of
the UniFi Switch.
2. Plug the Power Cord into a power outlet.

Connecting Ethernet
1. Connect an Ethernet cable from your DHCP server or LAN
to any port on the UniFi Switch.
2. Connect your computer or host system and other devices
to the other ports on the UniFi Switch.

Using SFP Ports
To use an SFP port:
1. Remove the dust plug covering the SFP port.
2. Insert a compatible fiber SFP module into the SFP port.
1000MbpsSM/SC20KM DDM
Tx1550nm/Rx1310nm
3. Connect the fiber optic cable to the fiber SFP module.
For information about compatible fiber SFP modules, visit:
community.ubnt.com/unifi

Software Installation
Download and install the latest version of the UniFi Controller
software at downloads.ubnt.com/unifi and follow the
on-screen instructions.
Note: If you already have UniFi Controller v4.8.x or above
installed, skip to the section, Adopting the UniFi Switch.
After you have installed the software and run the UniFi
Installation Wizard, a login screen will appear for the UniFi
Controller management interface. Enter the admin name and
password that you created and click Log In.
You can manage your network and view network statistics
using the UniFi Controller management interface.
To adopt the UniFi Switch, proceed to the Adopting the UniFi
Switch section.
For information on configuring and using the UniFi
Controller software, refer to the User Guide on the website:
documentation.ubnt.com/unifi

Adopting the UniFi Switch
1. From the UniFi Controller dashboard, click Devices in the
left menu bar.
2. On the Devices screen, locate the UniFi Switch in the list
of devices under the Model column. To adopt the UniFi
Switch, click Adopt.
3. The System LED on the UniFi Switch will turn blue to
confirm that it has been successfully adopted.
*640-00225-06*
640-00225-06

Configuring PoE Settings
By default, PoE settings for ports 1-8 are set to auto-sensing
PoE+. PoE will automatically be activated on the port when an
802.3af/at device is connected. For 24V passive PoE, PoE must
be manually activated.
WARNING: Before manually activating 24V passive
PoE, ensure that the connected device supports 24V
passive PoE.
1. On the Devices screen, locate the UniFi Switch in the list of
devices under the Model column. Click the switch to access
its settings.
2. Click the Ports tab.

3. Click Actions for the port you want to configure.
4. Select the appropriate mode: Off, 24V Passive, or PoE+
from the PoE setting. ThenclickApply.
For more information, refer to the User Guide on the website:
documentation.ubnt.com/unifi

Specifications
UniFi Switch US-8-150W
Dimensions 204 x 43 x 235 mm (8.03 x 1.69 x 9.25")
Weight
With Mount Brackets
1.65 kg (3.64 lb)
1.73 kg (3.81 lb)
Interfaces
Networking
Management
(8) 10/100/1000 Mbps RJ45 Ports
(2) 1 Gbps SFP Ports
Ethernet In-Band
Power Method 100-240VAC/50-60 Hz, Universal Input
Power Supply AC/DC, Internal, 150W DC
Max. Power Consumption
Including PoE Output
Excluding PoE Output
150W
20W
Processor Specs ARM Cortex-A9 400 MHz
Memory Information 256MB DDR3
Code Storage 32 MB NOR Flash
Line Rate 10 Gbps, Non-Blocking
LEDs
System
RJ45 Data Ports
SFP Data Ports
Status
PoE; Link/Speed/Activity
Link/Speed/Activity
PoE Output (RJ45 Ports) IEEE 802.3at/af 2-Pair (+1, 2; -3, 6);
Passive 24V/0.7A 2-Pair (+4, 5; -7, 8)
ESD/EMP Protection ± 24kV Air, ± 24kV Contact
Shock and Vibration ETSI300-019-1.4 Standard
Operating Temperature -5 to 45° C (23 to 113° F)
Operating Humidity 5 to 95% Noncondensing
Certications CE, FCC, IC

Safety Notices
1. Read, follow, and keep these instructions.
2. Heed all warnings.
3. Only use attachments/accessories specified by the manufacturer.
WARNING: Failure to provide proper ventilation may
cause fire hazard. Keep at least 20mm of clearance next
to the ventilation holes for adequate airflow.
WARNING: To reduce the risk of fire or electric shock, do
not expose this product to rain or moisture.
WARNING: Do not use this product in location that can
be submerged by water.
WARNING: Avoid using this product during an electrical
storm. There may be a remote risk of electric shock from
lightning.
Electrical Safety Information
1. Compliance is required with respect to voltage, frequency, and current
requirements indicated on the manufacturer’s label. Connection to a
different power source than those specified may result in improper
operation, damage to the equipment or pose a fire hazard if the
limitations are not followed.
2. There are no operator serviceable parts inside this equipment. Service
should be provided only by a qualified service technician.
3. This equipment is provided with a detachable power cord which has
an integral safety ground wire intended for connection to a grounded
safety outlet.
a. Do not substitute the power cord with one that is not the provided
approved type. Never use an adapter plug to connect to a 2-wire
outlet as this will defeat the continuity of the grounding wire.
b. The equipment requires the use of the ground wire as a part of the
safety certification, modification or misuse can provide a shock
hazard that can result in serious injury or death.
c. Contact a qualified electrician or the manufacturer if there
are questions about the installation prior to connecting the
equipment.
d. Protective earthing is provided by Listed AC adapter. Building
installation shall provide appropriate short-circuit backup
protection.
e. Protective bonding must be installed in accordance with local
national wiring rules and regulations.

Limited Warranty
UBIQUITI NETWORKS, Inc (“UBIQUITI NETWORKS”) warrants that the
product(s) furnished hereunder (the “Product(s)”) shall be free from defects
in material and workmanship for a period of one (1) year from the date
of shipment by UBIQUITI NETWORKS under normal use and operation.
UBIQUITI NETWORKS’ sole and exclusive obligation and liability under
the foregoing warranty shall be for UBIQUITI NETWORKS, at its discretion,
to repair or replace any Product that fails to conform to the above
warranty during the above warranty period. The expense of removal and
reinstallation of any Product is not included in this warranty. The warranty
period of any repaired or replaced Product shall not extend beyond its
original term.
Warranty Conditions
The above warranty does not apply if the Product:
(I) has been modified and/or altered, or an addition made thereto,
except by Ubiquiti Networks, or Ubiquiti Networks’ authorized
representatives, or as approved by Ubiquiti Networks in writing;
(II) has been painted, rebranded or physically modified in any way;
(III) has been damaged due to errors or defects in cabling;
(IV) has been subjected to misuse, abuse, negligence, abnormal physical,
electromagnetic or electrical stress, including lightning strikes, or
accident;
(V) has been damaged or impaired as a result of using third party
firmware;
(VI) has no original Ubiquiti MAC label, or is missing any other original
Ubiquiti label(s); or
(VII) has not been received by Ubiquiti within 30 days of issuance of
the RMA.
In addition, the above warranty shall apply only if: the product has been
properly installed and used at all times in accordance, and in all material
respects, with the applicable Product documentation; all Ethernet cabling
runs use CAT5 (or above), and for outdoor installations, shielded Ethernet
cabling is used, and for indoor installations, indoor cabling requirements
are followed.

Returns
No Products will be accepted for replacement or repair without obtaining
a Return Materials Authorization (RMA) number from UBIQUITI NETWORKS
during the warranty period, and the Products being received at UBIQUITI
NETWORKS’ facility freight prepaid in accordance with the RMA process of
UBIQUITI NETWORKS. Products returned without an RMA number will not
be processed and will be returned freight collect or subject to disposal.
Information on the RMA process and obtaining an RMA number can be
found at: www.ubnt.com/support/warranty.
Disclaimer
EXCEPT FOR ANY EXPRESS WARRANTIES PROVIDED HEREIN, UBIQUITI
NETWORKS, ITS AFFILIATES, AND ITS AND THEIR THIRD PARTY DATA,
SERVICE, SOFTWARE AND HARDWARE PROVIDERS HEREBY DISCLAIM
AND MAKE NO OTHER REPRESENTATION OR WARRANTY OF ANY KIND,
EXPRESS, IMPLIED OR STATUTORY, INCLUDING, BUT NOT LIMITED TO,
REPRESENTATIONS, GUARANTEES, OR WARRANTIES OF MERCHANTABILITY,
ACCURACY, QUALITY OF SERVICE OR RESULTS, AVAILABILITY,
SATISFACTORY QUALITY, LACK OF VIRUSES, QUIET ENJOYMENT, FITNESS
FOR A PARTICULAR PURPOSE AND NON-INFRINGEMENT AND ANY
WARRANTIES ARISING FROM ANY COURSE OF DEALING, USAGE OR
TRADE PRACTICE IN CONNECTION WITH SUCH PRODUCTS AND SERVICES.
BUYER ACKNOWLEDGES THAT NEITHER UBIQUITI NETWORKS NOR
ITS THIRD PARTY PROVIDERS CONTROL BUYER’S EQUIPMENT OR THE
TRANSFER OF DATA OVER COMMUNICATIONS FACILITIES, INCLUDING
THE INTERNET, AND THAT THE PRODUCTS AND SERVICES MAY BE
SUBJECT TO LIMITATIONS, INTERRUPTIONS, DELAYS, CANCELLATIONS
AND OTHER PROBLEMS INHERENT IN THE USE OF COMMUNICATIONS
FACILITIES. UBIQUITI NETWORKS, ITS AFFILIATES AND ITS AND THEIR THIRD
PARTY PROVIDERS ARE NOT RESPONSIBLE FOR ANY INTERRUPTIONS,
DELAYS, CANCELLATIONS, DELIVERY FAILURES, DATA LOSS, CONTENT
CORRUPTION, PACKET LOSS, OR OTHER DAMAGE RESULTING FROM ANY
OF THE FOREGOING. In addition, UBIQUITI NETWORKS does not warrant
that the operation of the Products will be error-free or that operation will
be uninterrupted. In no event shall UBIQUITI NETWORKS be responsible
for damages or claims of any nature or description relating to system
performance, including coverage, buyer’s selection of products (including
the Products) for buyer’s application and/or failure of products (including
the Products) to meet government or regulatory requirements.
