UMBRA RIMORCHI 937 User manual

ISTRUZIONI DI MONTAGGIO
FITTING INSTRUCTIONS
INSTRUCTIONS DE MONTAGE
MONTAGEANLEITUNG
INSTRUCCIONES DE MONTAJE
DISPOSITIVO DI TRAINO TIPO
TOWING BRACKET TYPE
DISPOTIF DE REMORQUAGE TYPE
ANHAENGEVORRICHTUNG TYP
DISPOSITIVO DE CAREO TIPO
01053/1C
PER AUTOVEICOLI
FOR CARS
POUR AUTOS
FUR KRAFTAHRZEUGE
PARA AUTOVEHICULO
ALFA ROMEO GT
TYPE 937 2003 
CLASSE E TIPO DI
ATTACCO
CLASS AND HITCH TYPE
CLASSE ET TYPE DE CROCHET
KLASSE UND BEFESTIGUNGSART
CLASES DE ACOPLAMIENTO
OMOLOGAZIONE
HOMOLOGATION
HOMOLOGATION
ZULASSUNG
APROBACION
CARICO VERTICALE MAX
S VALUE
MASSE VERTICALE MAXIMUM
ZUL. STUETZLAST
CARGA MAX. VERTICAL
Fe3 00 – 7166
(DIR. 94/20/CE) S = kg 95
VALORE D
D VALUE
VALEUR D
D WERT
VALOR D
D = 8,8 kN
COPPIA DI SERRAGGIO PER VITI (8.8):
TORQUE SETTINGS FOR NUTS AND BOLTS (8.8)
COUPLE DE SERRAGE POUR VIS (8.8)
SCHRAUBENANZUGSMOMENT (8.8)
MOM. DE PRESION PARA TORNILLOS Y TUERCAS (8.8)
Cod. 01053/1C
- Alfa Romeo GT - v. 1.0 01/01/2011 P. 1 / 6
8,8 kN
M6 = 10 Nm M8 = 25 Nm
M10 = 55 Nm M12 = 85 Nm
M14 = 135 Nm M16 = 200 Nm
www.umbrarimorchi.it
[email protected]
Tel. [phone]
Fax [phone]
Via Pizzoni 37/39
06132 Perugia
ITALY

SAFETY INSTRUCTIONS
Make sure that the towbar is suitable for the vehicle before starti g the
i stallatio .
For safety, all work i volvi g towbar i stallatio (i cl. electrical compo e ts) must
be u dertake by skilled tech icia s.
Damaged compo e ts must be replaced with ma ufacturer’s spares a d fitted by
qualified staff.
It is forbidde to make a y modificatio or structural repair to towi g assembly.
The towball must be kept clea a d lubricated. For added safety, his diameter (50
mm) must be checked at regular i tervals. If the towball measures less tha 49 mm
after selected readi gs across the diameter, the towball must be replaced with a ew
o e.
After 1000 km of towi g, check torque setti gs for uts a d bolts, i accorda ce
with the table.
Umbra Rimorchi ca ot be held respo sible for a y defects i the product caused
by fault or by a y i judicious use whatever of the user or a perso he is liable for.
Cod. 01053/1C
- Alfa Romeo GT - v. 1.0 01/01/2011 P. 2 / 6

FITTING INSTRUCTIONS
01053/1C ALFA ROMEO GT
•Remove a y mastic from co tact poi ts the pai t with a ti-rust pai t. The
ecessary holes have to be drilled out.
•1 Lift up the i er boot trim, remove the spare tire from its casi g.
•2 Remove the rear right screw to fit the heat shield support from u der the vehicle
j st if it interferes.
•3 Locate item D i side the boot, it has to adhere to the rear wall a d side wall of
the carbody, the drill out the floor correspo di g to holes 2 a d 4. Remove the
cou terplate, e large holes 2 i sert spacers E, re-locate the cou terplate the fit
i terposi g large washers o poi ts 4 from u der the vehicle.
•4 Locate item B i side the boot, it has to adhere to the rear wall of the car body
a d to the side of the spare wheel casi g a d drill out the floor correspo di g to
holes 2 a d 3. Remove the cou ter plate e large holes 2 i sert spacers E, re-
locate the cou terplate, i sert the screws a d fit i terposi g u der the chassis rail
plate C fitti g it just o the most far mou ti g poi ts.
•5 Re-fit the heat shield support fitti g it o the fro t part to the origi al screws
while o the left rear side, locate it to screw 2 already i serted the fit.
•6 Locate item A referri g to holes 2 o the right a d to holes 3 o the left
i terposi g i positio 3 large washers the fit.
•7 Tighte all bolts a d uts as per torque setti gs.
•8 Co ect the wiri gs to the socket.
•9 Cut bumper as showed.
•10 Re-fit the i er boot trim the re-fit the spare wheel i its casi g
Cod. 01053/1C
- Alfa Romeo GT - v. 1.0 01/01/2011 P. 3 / 6

Cod. 01053/1C
- Alfa Romeo GT - v. 1.0 01/01/2011 P. 4 / 6

Cod. 01053/1C
- Alfa Romeo GT - v. 1.0 01/01/2011 P. 5 / 6

Cod. 01053/1C
- Alfa Romeo GT - v. 1.0 01/01/2011 P. 6 / 6
