Unfinished Furniture of Wilmington WC-3222 User manual

ITEM NO.: WC-3222
REVISED JAN 03, 2015
Printed in Vietnam
- 1 -
ASSEMBLY INSTRUCTIONS
Description
Item No.
:KITCHENWORKCENTER
: WC-3222

ITEM NO.: WC-3222
REVISED JAN 03, 2015
Printed in Vietnam
- 2 -
Thank you for purchasing this quality product. This product has been designed for easy assembly and
constructed for durability. All parts were checked prior to packaging to insure quality. Prior to beginning
assembly, however, make sure all parts and hardware are included and free of obvious defect. If a part is
missing or defective, please contact the store where purchased. If hardware is missing, or you need help with
assembly, please call toll free 888-944-8396.
IMPORTANT NOTE:
-Place all wooden parts on a clean and smooth surface such as a rug or carpet to avoid the parts from
being scratched.
-Remove all wrapping material, including staples & packing straps before you start to assemble.
-DO NOT tighten all screws and bolts until completely assembled.
-Keep all hardware parts out of reach of children.
WARNING:
Long exposure to rubber or soft plastic may cause a chemical reaction and damage the finish of your
product. Protect the surface of the product with cloth if you are using any product with rubber feet or
base.
PART LIST
When unpacking, please be careful not to discard any parts with the packaging. Before continuing,
please make sure you have the following parts:
NO Description Qty Sketch NO Description Qty Sketch
A Top Panel 1 F Bottom shelf 1
B Left side
panel 1
G Adjustable
shelf 1
C Right side
panel 1
H Assembled
drawer 1
D Back
panel 1
I
Front panel
with door
1
E Top rail 2
BEFORE ASSEMBLY
ASSEMBLY TOOLS REQUIRED
NOT INCLUDED

ITEM NO.: WC-3222
REVISED JAN 03, 2015
Printed in Vietnam
- 3 -
HARDWARE LIST
When unpacking, please be careful not to discard any parts with the packaging. Before continuing,
please make sure you have all of the following hardware:
NO Description Qty Sketch NO Description Qty Sketch
1 Long bolt
(M6x45mm) 10 2 Pan head screw (M4x30mm) 4
3 Shelf support
bracket 4
4
Long wood
screw
(M4x38mm)
9
5 Wooden knob
4 6 U - washer 4
7 Short wood screw
(M3x15mm) 4
8 Allen key
(4x80mm) 1
STEP 1
Attach Left side panel (B) to back panel (D) with Long bolts (1), and U-washers (6) .Tighten with Allen
key (8).

ITEM NO.: WC-3222
REVISED JAN 03, 2015
Printed in Vietnam
- 4 -
STEP 2
Attach Right side panel (C) to back panel (D) with Long bolts (1), and U-washers (6) .Tighten with
Allen key (8).
STEP 3
Insert Top rails (E) into the unit as shown below.

ITEM NO.: WC-3222
REVISED JAN 03, 2015
Printed in Vietnam
- 5 -
STEP 4
Attach knobs (5) to front panel with door (I) with screws (2) .Tighten with a screwdriver.
STEP 5
Attach Front panel with door (I) to the unit with bolts (1) as shown below .Tighten with Allen key (8).

ITEM NO.: WC-3222
REVISED JAN 03, 2015
Printed in Vietnam
- 6 -
STEP 6
Attach Top (A) to the unit with screws (4). Tighten with a screwdriver.
STEP 7
Attach knobs (5) to front of drawers (H) with screws (2) .Tighten with a screwdriver.
STE

ITEM NO.: WC-3222
REVISED JAN 03, 2015
Printed in Vietnam
- 7 -
STEP 8
Insert the drawer (H) into the unit as shown below.
STEP 9
Place Bottom shelf (F) into the unit as shown below.

ITEM NO.: WC-3222
REVISED JAN 03, 2015
Printed in Vietnam
- 8 -
STEP 10
Insert the brackets (3) to the unit as shown below.
STEP 11
Attach the shelf (G) to the brackets with screws (7). Tighten with a screwdriver.
