Description
Item No.
: TUSCAN KITCHEN ISLAND
: WC-10
ASSEMBLY INSTRUCTIONS

ITEM NO : WC-10
ISSUED JUN 30, 2015
Printed in Vietnam
THIS ITEM IS PACKED IN TWO CARTONS
- 2 -
Thank you for purchasing this quality product. This product has been designed for easy assembly
and constructed for durability. All parts were checked prior to packaging to insure quality. Prior to
beginning assembly, however, make sure all parts and hardware are included and free of obvious
defect. If a part is missing or defective, please contact the store where purchased. If hardware is
missing, or you need help with assembly, please call toll free 888-944-8396.
IMPORTANT NOTE:
-Place all wooden parts on a clean and smooth surface such as a rug or carpet to avoid the
parts from being scratched.
-Remove all wrapping material, including staples & packing straps before you start to
assemble.
-DO NOT tighten all screws and bolts until completely assembled.
-Keep all hardware parts out of reach of children.
WARNING:
Long exposure to rubber or soft plastic may cause a chemical reaction and damage the
finish of your product. Protect the surface of the product with cloth if you are using any
product with rubber feet or base.
PART LIST WC-10A
When unpacking, please be careful not to discard any parts with the packaging. Before continuing,
please make sure you have the following parts:
NO Description Qty Sketch NO Description Qty Sketch
A Top 1 B Bottom
panel 2
BEFORE ASSEMBLY
ASSEMBLY TOOLS REQUIRED
NOT INCLUDED

ITEM NO : WC-10
ISSUED JUN 30, 2015
Printed in Vietnam
THIS ITEM IS PACKED IN TWO CARTONS
- 3 -
PART LIST WC-10B
When unpacking, please be careful not to discard any parts with the packaging. Before continuing,
please make sure you have the following parts:
NO Description Qty Sketch NO Description Qty Sketch
C Leg 4
HARDWARE LIST
When unpacking, please be careful not to discard any parts with the packaging. Before continuing,
please make sure you have all of the following hardware:
NO Description Qty Sketch NO Description Qty Sketch
1 Bolt
( M6 x 60mm) 16
2 Lock Washer
()6.5 x11mm) 16
3 Flat Washer
()6.5 x19mm) 16
4 Pan head screw
(M4 x 28 mm) 3
5
Knob
3
6
Allen key
(M4x80mm)
1
NOTE: HARDWARE IS PACKED IN CARTON WC-10B

ITEM NO : WC-10
ISSUED JUN 30, 2015
Printed in Vietnam
THIS ITEM IS PACKED IN TWO CARTONS
- 4 -
STEP 1
Attach legs (C) to the top (A) with bolts (1) and washers (2) and (3) as shown below. Tighten with Allen
key (6).
STEP 2
Attach bottom panel (B) to the legs (C) with bolts (1) and washers (2) and (3) as shown below. Tighten
with Allen key (6).

ITEM NO : WC-10
ISSUED JUN 30, 2015
Printed in Vietnam
THIS ITEM IS PACKED IN TWO CARTONS
- 5 -
STEP 3
Attach knob (5) to front of drawer with pan head screw (4). Tighten with the screwdriver.
